INTRODUCTION
Thank you for purchasing the Acoustic Energy AE1 Active loudspeaker. ‘AE1’ is more than
a model number for Acoustic Energy. Our rst ever speaker wore the AE1 name and ever
since then, we have had a speaker in the range that is so called. The AE1 Active is the latest
speaker to wear the badge and takes the name in a dierent direction to its predecessors
while still embodying the traits and qualities that have made them so highly regarded.
This manual is intended to be a source of information about the speakers themselves and the
materials they are supplied with, oer some advice and hints about setting them up for the best
possible performance and provide some suggestions in the unlikely event you experience any
problems with the product. Please retain this document and all packaging for future use.
CONTENTS OF PACKAGING
The AE1 Active loudspeaker box contains the following items:
2 AE1 Active loudspeakers in transit bags
2 speaker grilles
2 IEC mains leads for mains connection
2 RCA interconnects (3 metre) for audio connection
8 isolating foam feet
1 pair of handling gloves
1 instruction manual
1 certicate of authenticity
If any of these items are not present, it would be best to immediately contact your dealer.

WHAT IS AN ACTIVE SPEAKER?
The AE1 Active diers from preceding AE1 models due to it being an active design but what
does this actually mean? An active speaker is a design where the amplication that provides the
power for the drivers is placed after the crossover - the device that determines what frequencies
are sent to what driver. By doing this, only the frequencies relevant to that particular drive unit
are amplied by an amplier that has been congured exactly for that task. The result is a speaker
that solves the balancing act of amplier, crossover and driver at the design stage without any
trial and error on the part of the owner and oers higher performance than a passive speaker of
the same basic size and design.
The AE1 Active combines the amplier and drivers into a single enclosure which has further
benets in terms of space eciency and packaging. The drivers have received no less attention.
The AE1 Active includes an all new Wide Dispersion Technology (WDT) tweeter. This incorporates
a waveguide into the tweeter surround that ensures that the tweeter interacts more eectively
with the room it is in. Higher frequency coverage is wider than it would otherwise be without
the waveguide while lower frequencies are narrowed at the same time. This is called constant
directivity and is something Acoustic Energy has been working on over the course of many years.
The result is that more of these frequencies reach the listener’s ear directly rather than reected
o other surfaces which increases eciency and reduces distortion.
The mid bass driver is no less sophisticated and builds on the vast experience that Acoustic
Energy has with metal drivers to create a driver that has extraordinary impact but not at the
expense of the transient speed and tonal accuracy required of a truly high performance
loudspeaker. The bass response of the AE1 Active is enhanced by the latest version of the
slotted bass port used on a number of our speakers. The slotted prole allows for a large surface
area that does not take up too much space on the speaker and also reduces the audibility of the
air passing through it.

AE1
CAUTION: TO REDUCE THE RISK OF FIRE,
REPLACE WITH ONLY THE SAME
TYPE AND RATING OF FUSE.
MODEL: AE1 ACTIVE
AMPLIFIED 2-WAY LOUDSPEAKER SYSTEM
FEATURING 2 X 50 WATT (RMS) CLASS A/B
AMPLIFIERS PER LOUDSPEAKER
SERIAL NUMBER
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: SHOCK HAZARD - DO NOT OPEN
AVIS: RISQUE DE CHOC ELECTRIQUE
- NE PAS OUVRIR
SIGNAL INPUT EQ
PIN 1 = GROUND
PIN 2 = + INPUT
PIN 3 = - INPUT
ASSEMBLED IN PRC
DESIGNED, ENGINEERED, TESTED
& QUALITY CONTROL CHECKED BY
IN CIRENCESTER, ENGLAND
ACOUSTIC ENERGY LTD
BASS TREBLE
dB
+2
0
-2
-2 +2
0
+2
0
-2
dB
+2
0
-2
+2
0
-2
-2 +2
0
Rear connections and controls, refer to numbers and instructions opposite
12
3
4
5
6
230v

REAR CONNECTIONS AND CONTROLS
INPUTS
The AE1 Active has the option of receiving an audio signal on either an RCA or Balanced XLR
input. The speakers are supplied with RCA cabling that should allow for their connection in most
situations but some devices oer XLR outputs which are technically superior, so the AE1 Active
has been equipped accordingly. For very long runs of cable, it is frequently better to use the XLR
connection if you have the means to do so as this type of cabling is better suited to long
transmission lengths.
Please note that any XLR cable used must correspond to the wiring of the connection on the AE1
Active, as marked on the rear panel.
Do not connect both inputs at the same time as this risks damage to the loudspeaker.
BASS AND TREBLE CONTROLS
The AE1 Active has a pair of adjustable controls for bass and treble. These allow for you to alter
the response of the speaker in your room for best results.
The bass control adjusts between -2 and +2dB and is designed to help the speaker work more
eectively relative to rear walls. If the speaker is close to a wall, the bass response will increase as
a natural function of energy reected o the wall and you can reduce the bass output to bring it
back in line with the treble output.
The treble control adjusts between -2 and +2dB and is designed to help tailor the output of the
AE1 Active depending on the furnishings of the room it is placed in. In a room with little in the
way of furniture and bare walls, you may nd that you need to reduce the treble output for an
even response in room. Conversely, in very large or heavily furnished rooms, you may nd that
the speakers benet from a boost to the treble output.
There are no right and wrong actions to the use of these controls and we would recommend
you experiment and see what works best for you. As a fully active loudspeaker design, these
trim controls have no detrimental eect on the sound quality.
1
2

VOLUME CONTROL
The AE1 Active is tted with a volume control that adjusts the level between zero (no output) and
max (full output). This volume control serves two purposes. If you are using the AE1 Active with a
device that has no volume control, you can use it to adjust the level. You can also use the volume
to limit the output of the AE1 Active relative to the volume control of the connected device. This
means you can either ensure that a given level cannot be exceeded either for preference or, in
extreme cases, to avoid damage to the speaker.
MAINS VOLTAGE SWITCH
The AE1 Active is tted with a power supply that is able to operate on both a 100-120v and
220-240v mains supply. This switch is used to alter the speakers between these two voltages.
The switch is protected by a cover to avoid accidental adjustment.
Any adjustment of this switch MUST be undertaken with the speaker disconnected from
the mains.
MAINS INPUT
This is the mains input to power the speaker. Always ensure you use a correctly certied IEC
mains cable.
POWER SWITCH
The power switch is a two position unit that completely switches the AE1 Active o. If you are
leaving the speakers inactive for a sustained period, they should always be switched o before
doing so.
3
4
5
6

CONNECTION AND SETUP
The AE1 Active is designed to take an output directly from a piece of source equipment. It is
possible to use a piece of equipment that has a xed output and adjust the volume on the
speakers themselves but the most eective results will be gained by using a device with a
variable level output - commonly referred to as a preamplier output. Recently, the number of
items of source equipment that have volume controls and preamplier outputs has increased
considerably so there is a huge variety of possible sources for the AE1 Active. You can also use a
dedicated preamplier if you prefer which will allow for multiple pieces of source equipment to
be used.
Each AE1 active speaker will need mains power and a signal from a device to function. The
connection can be made either using the RCA input or the XLR connection but you should not
try and use both connections at the same time. Make a single audio connection from the source
equipment or preamplier to both AE1 Active speakers.
There is no means of looping the signal from one AE1 Active speaker to another and the
speakers must not be connected together in this way.
With power and signal connected, you should now be able to play audio. If you are using a
preamplier output to connect the speakers, you can control the level of the system from the
volume control of the source equipment of preamplier. If you are controlling the volume this
way, set the volume control on the rear of each AE1 Active to maximum. If you nd that this
results in levels that can become uncomfortably loud too quickly, you can use these volume
controls to reduce the output of the AE1 Active to have a greater degree of ne control over
the volume.
We have designed the AE1 Active to give excellent performance when used in a variety of
locations and it will work well when placed on shelves or furniture. For best results however, we
would always recommend using a dedicated pair of speaker stands that help to isolate the
speaker and elevate it to the right height for listening- this height will vary slightly due to
dierent requirements but should leave the tweeter of the speaker at the height of your ear
when seated.
Isolating foam feet are supplied to protect the loudspeakers and surface they are placed upon,
from damage and vibration. We would recommend that the foam feet are not used when placing
the speakers on a dedicated stand.

SIGNAL INPUT
PIN 1 = GROUND
PIN 2 = + INPUT
PIN 3 = - INPUT
RCA (phono) InputBalanced XLR
Rear input connections using either RCA
(phono) or Balanced XLR cables
AE1
CAUTION: TO REDUCETHE RISK OF FIRE,
REPLACE WITH ONLY THE SAME
TYPE AND RATINGOF FUSE.
MODEL: AE1 ACTIVE
AMPLIFIED 2-WAY LOUDSPEAKER SYSTEM
FEATURING2 X 50 WATT (RMS) CLASS A/B
AMPLIFIERS PER LOUDSPEAKER
SERIAL NUMBER
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING:SHOCK HAZARD - DO NOT OPEN
AVIS:RISQUE DE CHOC ELECTRIQUE
- NE PAS OUVRIR
SIGNAL INPUT EQ
PIN 1 = GROUND
PIN 2 = + INPUT
PIN 3 = - INPUT
ASSEMBLED IN PRC
DESIGNED, ENGINEERED, TESTED
& QUALITY CONTROL CHECKED BY
IN CIRENCESTER, ENGLAND
ACOUSTIC ENERGY LTD
BASS TREBLE
dB
+2
0
-2
-2 +2
0
+2
0
-2
dB
+2
0
-2
+2
0
-2
-2 +2
0
SIGNAL INPUT
PIN 1 = GROUND
PIN 2 = + INPUT
PIN 3 = - INPUT
Depending on how far apart the speakers are and your distance from them, it may also be
worthwhile experimenting with pointing the speakers inwards so that you and the speakers
form the points of a triangle and the sound is directed towards you.
We have tted the AE1 Active with bass and treble controls that will alter the output of the
speaker to reect how close it is to walls and the size and furnishing of the room (their function is
described in the ‘Rear panel connections’ section). It is worthwhile experimenting with these bass
and treble settings to obtain the best results in your room.
The grille of the AE1 Active is acoustically transparent and designed to protect the drivers. In
many domestic situations, we would strongly recommend that they are left in place.

TROUBLESHOOTING
The speaker will not power on
- Check there is power available to the speaker
- Check that the rear panel switch is set to ON
- Check that the white power LED is lit (in bottom of the bass driver surround)
There is no sound
- Check there is power to the speakers and they are switched on
- Check there is power to the source equipment and it is switched on
- Check that there is an audio connection from preamplier out of the source equipment to
both of the AE1 Active speakers
- Check that the source equipment is not muted
The sound is intermittent or distorted
- Check your audio connections between the source equipment and the speakers
- Check that the levels from your source equipment are not too high and causing the speaker
to cut out or distort. You can cap the volume of the system by reducing the volume via
the controls on the rear panel
Volume levels are too low
- Check that the volume controls on the rear panel are not set to a low level
- Check that the source equipment has not been set to a low gain mode and that the
connections are still solidly in place between source and the AE1 Active
If only one speaker exhibits a problem - try swapping it with the other speaker to see if the issue
follows the speaker or stays on the same side. This will help to identify the cause of the issue and
let you seek assistance for the right component.

WARRANTY
Your Acoustic Energy AE1 Active speaker is guaranteed against defects in materials, manufacture
and workmanship for three years from the date of purchase. Please retain all original packaging
materials for possible future use.
If you register your Acoustic Energy loudspeakers online via our website (acoustic-energy.co.uk)
we will extend your guarantee, free of charge, to ve years.
Under this warranty Acoustic Energy agrees to repair any defect or, at the company’s discretion,
replace the faulty component(s) without charge for parts and labour. This warranty does not
imply any acceptance by Acoustic Energy or its agents for consequential loss or damage and
specically excludes fair wear and tear, accident, misuse or unauthorised modication.
This warranty is applicable in the United Kingdom only and does not in any way limit the
customer’s legal rights. Claims and enquiries under the warranty for AE products purchased
outside the UK should be addressed to the local importers or distributors.
If you have any reason to claim under the warranty please contact your dealer or point of
purchase in the rst instance.

AE1 ACTIVE SPECIFICATION
Input Sensitivity1104dB for 1VRMS @ 1kHz
Bandwidth242Hz-28kHz
Horizontal coverage3130 degrees
Vertical Coverage 120 degrees
Peak SPL4115dB
Maximum SPL5105dB
Amplier Class A/B with linear power supply.
Amplier Power LF: 50W
HF: 50W
Crossover 3.5kHz 4th Order Linkwitz-Riley
Woofer 140mm chassis with Alu/Ceramic cone.
Tweeter 27mm Alu dome with WDT waveguide.
Cabinet 18mm MDF with bracing and damping panels.
Inputs RCA and Balanced XLR
Controls Volume adjust 0dB to -inf
HF shelf +/-2dB
LF shelf +/-2dB
Power connection IEC C13
Voltage selection Manual switching
NOTES:
1Measured at 1m using pink-weighted MLS noise.
2 Measured at 1m using pink-weighted MLS noise, +/-6dB limits.
3 Measured at 1m using pink-weighted MLS noise, +/-6dB limits.
4 Measured using a toneburst signal.
5 Measured using a band limited sine sweep.
All specications and images are correct at the time of going to press.
Acoustic Energy withhold the right to change specications without notice.

3
0
Y
E
A
R
S
I
N
B
R
I
T
I
S
H
A
U
D
I
O
-
3
0
Y
E
A
R
S
I
N
B
R
I
T
I
S
H
A
U
D
I
O
-
ACOUSTICENERGY.CO.UK
Acoustic Energy
16 Bridge Road, Cirencester
Gloucestershire, England
GL7 1NJ
[phone]
[e-mail]
