Acqua di Parma SMART HOME DIFFUSER 2020 User manual

SMART HOME
DIFFUSER 2020

HATBOX CONTENT OVERVIEW
2

BUTTONS/DESCRIPTIONS
3
ON/OFF
USB SOCKET
FRAGRANCE SELECTION
FRAGRANCE INTENSITY
SLOTS

RECAP ON OFF BUTTON
4
Segment Y to show if the device is powered with cable AND SHOWS WHEN DEVI E IS ON
Segment Z to show battery status
Segment X to show connectivity status : off = not switched on, blinking = connecting, solid =
connected

ON OFF BUTTON ACTIVITY
5
POWER CONNECTION
The yellow LED light (Y) in the bottom of the ON OFF button (B) is turned on
when the device is powered with cable.
If cable is connected and device is OFF led light is FIXED
If cable is connected and device is ON led light is BLINKING (to define
with exalia blink frequency)
If cable is NOT connected and device is ON led light is BLINKING
(to define with exalia blink frequency)
If cable is NOT connected and device is OFF led light is OFF
BATTERY
The green LED light (Z) in the top right of the button is blinking when the battery
is charging, and is turned on when the battery is charged.
When the battery is discharged the light is turned off.
WIFI CONNECTION
The yellow LED light in the top left (X) is blinking while the smart diffuser is
trying to connect to the platform. This light will turn on when configuration is
finished and the connection is achieved .
In case of OFF line use when button On is pressed, the upper LED light (X)
starts blinking to find wifi and then switches off - has no light

RESTORE FACTORY SETTINGS
6
You can reset your smart diffuser by restoring the
factory settings by pushing on the 3 buttons at
the same time during 10 seconds.
Then the yellow LED light in the upper part of the
ON button (X) blinks again.

OFF LINE MANAGEMENT – FRAGRANCE CHOICE
7
To select the desired fragrance, press the appropriate
button (C):
once to select the fragrance in slot 1,
twice to select the fragrance in slot 2,
three times to select the fragrance in slot 3.
The first, second or third LEDs will turn on each in
correspondence to the fragrances in succession.
When the fragrance in the refill is finished, the
corresponding segment blinks and the scent is no
longer dispensed.

OFF LINE MANAGEMENT – INTENSITY CHOICE
8
To select the intensity of the fragrance, press the dedicated button
(D):
once to select low fragrance diffusing intensity,
twice for medium diffusing,
three times for high intensity diffusion
of the chosen fragrance.
The first, the first and the second or all LEDs will turn on
respectively in correspondence to the low, medium and high
fragrance levels selected.
In this use mode, the device will automatically turn off after an
hour, unless it is stopped first by the user by pressing the OFF
button (B).
Every time user has finished with one fragrance or the device is
switched off and back switched on, fragrance selection must be
done from scratch.

FRAGRANCE AND INTENSITY LIGHT FUNCTIONINIG
9
Fragrance choice and fragrance intensity leds – will be light and have same behaviuors also when selection is
done through app or we platform
