Nutone 101t User manual

INSTALLATION INSTRUCTIONS

READ & SAVE THESE INSTRUCTIONS!

Two-Note

Surface-Mounted

Door Chimes

PLANNING

•Your NuTone Door Chime is designed for two-door operation.

•If the home is multiple-level or large ranch style, two or more

chimes should be used to provide adequate coverage.

•Handle the door chime carefully, as you would any precision

instrument.

WIRING

BE SURE HOUSE POWER IS TURNED OFF WHEN WIRING

THE TRANSFORMER. WIRING CONNECTIONS MUST COMPLY

WITH LOCAL OR NATIONAL WIRING CODES.

•For a single installation, use NuTone Model 515T or 101T

Transformer.

•For two or more chimes, use NuTone Model 105T or 301T

Transformer.

NOTE: When fastening chime wiring to wall studs and ceiling

joists, care must be taken to avoid possible “shorts” that might be

created by allowing staples or clips to cut through the protective

wiring insulation.

Refer to Figure 1. Mount the transformer to a convenient junction

box (attic location is not recommended) or circuit breaker box.

Connect house power leads to transformer leads – black to black

and white to white.

Refer to Figure 2 for single chime installation or to Figure 3

for multiple chime installation. Run 2 conductor 18-22 gauge

wire from transformer and the pushbutton(s) to chime location(s).

Bring the wires through the wiring hole in the chime baseplate(s)

and fasten the baseplate(s) to the wall though the mounting holes

with the screws provided. Connect the transformer and the

pushbutton wires to the chime terminal board(s).

NOTE: Upon completion of installation, if the chime does not

operate properly, check the pushbutton(s) for poor contact or

loose connections. Be certain wires are not touching the tone

bars.

TUBE INSTALLATION (When applicable)

Refer to Figure 4. Hang tubes onto hanger bracket hooks so that

the longest tube is at the left and the shortest at the right.

MOUNTING COVER

Install the chime cover over the baseplate.

MAINTENANCE INSTRUCTIONS

If chime plungers should ever become “sluggish” in their

movement, clean plungers with a nonflammable cleaning fluid and

wipe dry.

CAUTION: NEVER OIL CHIME PLUNGERS.

REPLACEMENT PARTS OR SERVICE

Contact your local Authorized NuTone Parts Outlet or Service

Center. If you are unable to locate the facility, write NuTone Inc.,

4820 Red Bank Road, Cincinnati, Ohio 45227-1599.

Attention: Department of National Field Service.

FIGURE 1

FIGURE 2

FIGURE 3

FIGURE 4

SHORT

TERMINAL

BOARD

CHIME NO. 1

TERMINAL

BOARD

CHIME NO. 2 REAR DOOR

PUSHBUTTON

COMMON WIRES

FRONT DOOR

PUSHBUTTON

FRONT DOOR

PUSHBUTTON

SINGLE

2-NOTE CHIME

MULTIPLE

2-NOTE CHIMES

18-22 GA. INSULATED

2-CONDUCTOR WIRE

18-22 GA. INSULATED

2-CONDUCTOR WIRE

NUTONE 105T

OR 301

TRANSFORMER

NUTONE 101T

OR 515T

TRANSFORMER

120vAC WIRING

REAR DOOR

PUSHBUTTON

TERMINAL

BOARD

FRONT

TRANS

REAR

FRONT

TRANS

REAR

FRONT

TRANS

REAR

LONG

4820 Red Bank Road, Cincinnati, Ohio 45227

Printed in China, Rev. 3/02, Part No. 84790

Product specifications subject to change without notice.
