Acrosser Technology AR-B104D Installation guide

AR-B104D Quick Manual
P/N：220010396-G
1
AR-B104D Quick Manual V1.01
1.Mainboard illustration (Top Side)
JP1
CAN Bus terminal resister select pin
header.
J1
PCI BUS connector (PC-104 Plus)
CN2
CAN Bus connector
JP3
Operation mode selection.
JP2
Clear SRAM pin header.
CN3
GPIO connector.
JP8
SRAM mode select.

AR-B104D Quick Manual
P/N：220010396-G
2
2.Connector and Jumper Setting Table
1. JP1
2. CN2
3. JP2
Pin
Description
close
120 ohm
resister.
open
None.
Pin
Description
1
CAN High
2
CAN Low
Pin
Description
1-2
Normal
2-3
Clear SRAM
4. CN4
PIN
define
PIN
define
PIN
define
PIN
define
PIN
define
PIN
define
PIN
define
PIN
define
A1
GND
B1
SIRQ
A16
AD21
B16
AD20
C1
+5V
D1
AD00
C16
GND
D16
AD19
A2
VIO
B2
AD02
A17
3.3V
B17
AD23
C2
AD01
D2
+5V
C17
AD22
D17
+3.3V
A3
AD05
B3
GND
A18
IDSEL0
B18
GND
C3
AD04
D3
AD03
C18
IDSEL1
D18
IDSEL2
A4
CBE0#
B4
AD07
A19
AD24
B19
CBE3#
C4
GND
D4
AD06
C19
VIO
D19
IDSEL3
A5
GND
B5
AD09
A20
GND
B20
AD26
C5
AD08
D5
GND
C20
AD25
D20
GND
A6
AD11
B6
VIO
A21
AD29
B21
+5V
C6
AD10
D6
M66EN
C21
AD28
D21
AD22
A7
AD14
B7
AD13
A22
+5V
B22
AD30
C7
GND
D7
AD12
C22
GND
D22
AD31
A8
3.3V
B8
CBE1#
A23
REQ0#
B23
GND
C8
AD15
D8
+3.3V
C23
REQ1#
D23
VIO
A9
SERR#
B9
GND
A24
GND
B24
REQ2#
C9
SB0
D9
PAR
C24
+5V
D24
GNT0#
A10
GND
B10
PERR#
A25
GNT1#
B25
VIO
C10
+3.3V
D10
SDONE
C25
GNT2#
D25
GND
A11
STOP#
B11
+3.3V
A26
+5V
B26
PCICLK0
C11
LOCK#
D11
GND
C26
GND
D26
PCICLK1
A12
3.3V
B12
TRDY#
A27
PCICLK2
B27
+5V
C12
GND
D12
DEVDEL#
C27
PCICLK3
D27
GND
A13
FRAME#
B13
GND
A28
GND
B28
INTD#
C13
IRDY#
D13
+3.3V
C28
+5V
D28
RST#
A14
GND
B14
AD16
A29
+12V
B29
INTA#
C14
+3.3V
D14
CBE2#
C29
INTB#
D29
INTC#
A15
AD18
B15
+3.3V
A30
-12V
B30
REQ3#
C15
AD17
D15
GND
C30
GNT3#
D30
GND

AR-B104D Quick Manual
P/N：220010396-G
3
5. JP3
Note: The JP3 default setting is Mode0.
Operation mode description
Pin
Description
1-2,3-4 open
Mode 3
1-2 open,3-4 short
Mode 2
1-2 short,3-4 open
Mode 1
1-2,3-4 short
Mode 0
PCICLK
IDSEL
INT 0
Mode 0
PCICLK0
IDSEL0
A
Mode 1
PCICLK1
IDSEL1
B
Mode 2
PCICLK2
IDSEL2
C
Mode 3
PCICLK3
IDSEL3
D

AR-B104D Quick Manual
P/N：220010396-G
4
6. CN3
PIN
DESCRIPTION
PIN
DESCRIPTION
1
GPI0
2
GPI1
3
GPI2
4
GPI3
5
GPI4
6
GPI5
7
GPI6
8
GPI7
9
GPI8
10
GPI9
11
GPI10
12
GPI11
13
GND
14
GND
15
GND
16
GND
17
GND
18
GND
19
GND
20
GND
21
GND
22
GND
23
GPO0
24
GPO1
25
GND
26
GND
27
GPO2
28
GPO3
29
GND
30
GND
31
GPO4
32
GPO5
33
GND
34
GND
35
GPO6
36
GPO7
37
GND
38
GND
39
GPO8
40
GPO9
41
GND
42
GND
43
GPO10
44
GPO11
7. JP8
Pin
Description
1-2
Memory mode
open
Disk mode

AR-B104D Quick Manual
P/N：220010396-G
5
3.AR-B104D digital I/O, SRAM disk & CAN bus Module
AR-B104D is a PCI-104 super I/O module which equipped with CAN bus, SRAM disk and digital
I/Os on a single module.
Features
1x 2KV isolated CAN bus. Support 2.0A and 2.0B protocol.
Time stamp of CAN message
1MB battery backup SRAM disk. Supports disk and memory modes.
12x optical isolated digital inputs. Support counter mode.
12x 500 mA current sink digital outputs. Support pulse generator mode.
Linux and Windows 2000, XP Software Development Kit (SDK).
Specifications
General
Bus interface
1. PCI 104
2. PCI 2.0 Compliant
SRAM disk
1. Capacity: 1M Bytes
2. Battery backup
3. Operation mode:
A. Memory Mode
B. Disk Mode
C. Mode selection through Jumper (factory
default disk mode)
Digital Input
1. 12 optical isolated channels
2. Operating mode:
A. General digital input
B. Counter mode
3. Programmable de-bounce time (0 ms to
255ms, 1 ms resolution).
4. Support Change of State interrupt
5. Response time: 20 uS + de-bounce time
6. Response time: OPTO (delay time + OPTO
rising time = 20uS) + debounce time. Default =
16.02ms.
7. Trigger: rising trigger or falling trigger
8. Signal Type:
A. Open/Ground switch input

AR-B104D Quick Manual
P/N：220010396-G
6
B. Digital Logic
i. Logic High: 3V to 28V
ii. Logic Low: 0V to 1.5V
9. Maximum input frequency 10KHz( duty =
50% ).
Counter
1. All digital input support counter mode
2. 12 x independent 16-bit counters
3. Connect to all digital inputs
4. Operation Mode:
a. Count to number interrupt.
b. Read and clear
c. Read on the fly
d. Auto stop counting after programmable
constant state interval(Interrupt active
after programmable constant state
interval Resolution: 1ms, and 100ms)
Digital Output
1. 12 channels
2. Output Type: Open drain MOSFET driver
3. Output voltage range: 5V to 30V
4. Sink Current: maximum 500mAeach channel
5. Power on initial state: MOSFET off
6. Support pulse generator
A. Programmable cycle time, duty cycle and
number of cycles. User defines on and off
periods (maximum 8-bit for on and off
period value).
B. Maximum 65535 cycles
C. RUN & STOP command
D. Programmable time unit: 1 ms, 100ms
and 1 second
Timer
1. 12 x independent 16-bit timers
2. Support Time Out Interrupt
3. Programmable time unit: 1 ms and 100ms
CAN bus
1. 1 x CAN bus
2. 2KV isolation
3. Support both CAN 2.0Aand 2.0B protocol
4. Programmable baud rate: from 5K bps
Maximum 1M bps or user-defined baud rate
5. Time stamp of CAN message

AR-B104D Quick Manual
P/N：220010396-G
7
6. API library for user development
7. CAN bus device status query
8. Device driver for Windows 2000/XP/XPe and
Linux
Maximum card
Maximum 2 cards can be stacked up in one system
Software
1. Windows XP, XPe and Linux device driver and
API
2. Windows XP, XPe and Linux demo program
3. User interface for DIO, SRAM and CAN bus in
Linux and Windows XP embedded
Mechanical
Dimension
90.17 x 95.89mm (3.55”x3.775”)
Operating Temp.
-20oC to 70oC (-1~158oF) without air flow
Storage Temp.
-20~85oC (-4~185oF)
Relative Humidity
0 to 90% @ 40°C, non-condensing (95% @ 40°C, Non-Condensing by
request)
EMC & Safety
EMC
CE, FCC
