Acrosser Technology ACE-B7400 Installation guide

P/N：2200104-G
0
ACE-B7400
Quick Manual
P/N：2200104-G
1
ACE-B7400 Quick Manual
1.Mainboard illustration (Top Side)
IO Conpoments and KEY Parts illustration:

P/N：2200104-G
2
Note1: PWR_BTN can be used as a Power-Button to power-on system when FPIO1/3-4 is not
shroted. If FPIO1/3-4 is shroted by a jumper-head, system will automatically boot-up when power
applied.
Note2: Please Refer to Page8 for Rears-Panel IO Configurations.
Note3: AMD eOntario Platform supports maximum totle 8GB DDRIII Memory.
LED1
Green LED: Powered On.
Orange LED: HDD Active.
CN7
Gaming Input Isolation Connector.
(note2)
CF1
CF Card Slot 1.
PWR_BTN1
System Power Button. (note1)
CN6
Gaming Input Isolation Connector.
(note2)
CF2
CF Card Slot 2.
DVI-D1
DVI-D Connector.
CN4
Gaming Open-Drain Output
Connector. (note2)
U40
Acrosser Gaming Core.
DVI-I1
DVI-I Connector.
CN4
Gaming Open-Drain Output
Connector. (note2)
SATA1/SATA2
SATA 3.0 Connectors.
USB1
Dual-Port USB 2.0 Connector
(USB 5, 6).
CN3
Selectable TTL, RS232, RS485,
cctalk Connector (UART Port 5, 6).
MINI-PCIE1
Mini-PCIe Slot.
CN25
One RJ45 with Dual USB 2.0
Connector (LAN 2 & USB 3, 4).
CN2
2.1 Channel Audio Amplifier Output
Connector.
CN_DIMM1/CN_DIMM2
DDR3 SODIMM Socket.
(note3)
CN26
One RJ45 with Dual USB 2.0
Connector (LAN 1 & USB 1, 2).
CN1
System Power Input Connector.
CASESW1
Micro-switch for Chassis
Open/Close Detection.
COM1_2
UART RS-232 Port 1, 2
(Supports 9-bits Protocol).
U43
AMD FT1 APU. (T48N/T52R) BAT_BH1
System RTC Battery Holder.
COM3_4
UART RS-232 Port 3, 4.
U44
AMD Hudson-E1 Fusion Controller
Hub.
P/N：2200104-G
3
2. Connector & Jumper setting definition (Top Side)
FPIO1
System Power Button
Pin-header & Reset Jumper.
SATA_PWR1/SATA_PWR2
Two JST 2.5mm SATAPower
Connectors.
BAT_A1, BAT_B1
Lithium Battery Connector for
SRAM, AGA and secured RTC.
CN_USB1
JST 2.0mm USB Connector
(USB7).
CN19
Clear System CMOS Jumper.
JP18
RS-485 Terminal Resistor
Selection Jumper for UART 6.
CN_USB2
JST 2.0mm USB Connector
(USB8).
JP6 ~ JP13
CN3 Output Signal Selection
Jumper.
JP17
RS-485 Terminal Resistor
Selection Jumper for UART 5.
SYSFAN2
System FAN Connector 2. SYSFAN1 System FAN Connector 1.
AUDIO1
Internal 5.1 Channel Audio
Pin-Header.
APUFAN1
APU FAN Connector.
IButtom2
JST 2.0mm External i-Button
Connector.
JP1
cctalk Supply Power Selection
Jumper.
SPAREIO1
JST 2.0mm Gaming Spare-IO
Connector. (16-bits GPIO)
JP2/JP3
SRAM A, B Clear Jumper.
CASESW2
JST 2.0mm Chassis Open/Close
Detection Connector.
SW1
8-bit DIP-Switch Input forAGC.
JP4/JP5
Bill-enable, Coin-enable
Preset Jumper.

P/N：2200104-G
4
2.1 Connectors and Jumpers Setting
2.1.1 FPIO1
System Power button & Reset Jumper. 2.1.2 CN_USB1 JST 2.0mm USB Connector (USB7).
JUMPER FUNCTION
1-2 External Power Button
Connection
3-4 Short to Enable Auto
Power-on Function.
5-6 System Reset Button
Connector
PIN SIGNAL
1 VCC (+5V)
2 Data+
3 Data-
4 GND
5 N.C
2.1.3 CN_USB1
JST 2.0mm USB Connector (USB7). 2.1.4 SYSFAN2 System FAN Connector 2.
PIN SIGNAL
1 VCC (+5V)
2 Data+
3 Data-
4 GND
5 N.C
PIN SIGNAL
1 GND
2 +12V
3 Feedback
2.1.5 APUFAN1
APU FAN Connector. 2.1.6 SPAREIO! JST 2.0mm Gaming Spare-IO Connector.
PIN SIGNAL
1 GND
2 +12V
3 Feedback
PIN SIGNAL PIN SIGNAL
1 Bit0 2 Bit8
3 Bit1 4 Bit9
5 Bit2 6 Bit10
7 Bit3 8 Bit11
9 Bit4 10 Bit12
11 Bit5 12 Bit13
13 Bit6 14 Bit14
15 Bit7 16 Bit15
17 GND 18 +3.3V
19 GND 20 +3.3V
P/N：2200104-G
5
2.1.7 SW1
8-bits DIP-Switch Input for AGC. 2.1.8 SATA_PWR1/ SATA_PWR2
Two JST 2.5mm SATA Power Connectors.
PIN SIGNAL
ON +3.3V
OFF GND
PIN SIGNAL
1 +12V
2 GND
3 +3.3V
4 +5V
2.1.9 CN19
Clear System CMOS Jumper. 2.1.10 JP6 ~ JP13 CN3 Output Signal TTL/RS232/RS485/cctalk
Selection Jumper.
JUMPER FUNCTION
1-2 (default) Normal
2-3 Clear CMOS
Please See Appendix A.
2.1.12 IBUTTON2
JST 2.0mm External i-Button Connector. 2.1.13 JP2/JP3 SRAM A, B Clear Jumper.
PIN SIGNAL
1 I-Button Signal
2 GND
JUMPER FUNCTION
1-2 (default) Normal
2-3 Clear SRAM

P/N：2200104-G
6
2.1.14 JP4/JP5
Bill-enable, Coin-enable Preset Jumper. 2.1.15 BAT_A1/BAT_B1 Lithium Battery Connector for SRAM, AGA
and secured RTC.
JUMPER FUNCTION
1-2 (default) Preset is “High”.
2-3 Preset is “Low”.
“High” means Bill-enable, Coin-enable
open-drain output is short to ground.
“Low” means Bill-enable, Coin-enable
open-drain output is open
PIN SIGNAL
1 POWER
2 GND
2.1.16 JP18
RS-485 Terminal Resistor Selection Jumper
for UART6.
2.1.17 JP17
RS-485 Terminal Resistor Selection Jumper
for UART5.
JUMPER FUNCTION
1-2 (default) Termination
2-3 Non
RS-485 terminal resistor is 120ohm.
JUMPER FUNCTION
1-2 (default) Termination
2-3 Non
RS-485 terminal resistor is 120ohm.
2.1.18 AUDIO1
Internal 5.1Channel Audio Pin-Header. 2.1.19 JP1 ccTalk Supply Power Selection Jumper.
PIN SIGNAL PIN SIGNAL
1 Front-L 2 Front-R
3 GND 4 GND
5 Surround-L 6 Surround-R
7 IO4 GND 8 GND
9 Center 10 LFE
JUMPER FUNCTION
1-2 (default) +12V
2-3 +24V
+24Vpower is from CN1 external power supply.
2.1.20 CASESW2
JST 2.0mm Chassis Open/Close Detection
Connector.
PIN SIGNAL
1 Signal
2 GND
P/N：2200104-G
7
2.2 Rears-Panel IO Configurations
CN1 System Power Input Connector (Micro-FIT 3.0mm 2*4 PINs)
PIN SIGNAL PIN SIGNAL
1 +12V Input 5 +12V Input
2 GND 6 GND
3 GND 7 GND
4 +12V Input 8 +24V Input
Note:
1. +12V Power Input voltage tolerance is ±10%.
2. +24V Power Input is only use for cctalk Vs power supply.
CN2 2.1 Channel Audio Amplifier Output Connector (Micro-FIT 3.0mm 2*3 PINs)
PIN SIGNAL PIN SIGNAL
1 Amplified Front Left + 4 Amplified Front Left -
2 Amplified Front Right + 5 Amplified Front Right -
3 Amplified LFE + 6 Amplified LFE -
Note:
1. ACE-B7400 with Audio Amplifier is D-type amp.
2. Amplified Right and Left channel support 10Watt(max) Output, Amplified LFE channel supports 20Watt(max) Output.
CN3 Selectable TTL, RS232, RS485, cctalk Connector (Micro-FIT 3.0mm 2*7 PINs)
Pin Signal Signal Pin
1 COM5 TTL/ 232 Tx/ 485 + COM5 TTL/ 232 Rx/ 485 - 8
2 COM6 TTL/ 232 Tx/ 485 + COM6 TTL/ 232 Rx/ 485 - 9
3 COM5 ccTalk Data COM6 ccTalk Data 10
4 COM5 ccTalk Vcc COM6 ccTalk Vcc 11
5 GND GND 12
6 GND GND 13
7 GND GND 14

P/N：2200104-G
8
CN4/CN5 Gaming IO Output Connector (Micro-FIT 3.0mm 2*10 PINs)
CN4: Pin Signal Pin Signal
1 LAMP 1 11 LAMP 9
2 LAMP 2 12 LAMP 10
3 LAMP 3 13 LAMP 11
4 LAMP 4 14 LAMP 12
5 LAMP 5 15 LAMP 12
6 LAMP 6 16 Tower LAMP 1
7 LAMP 7 17 Tower LAMP 2
8 LAMP 8 18 Tower LAMP 3
9 GND 19 GND
10 GND 20 GND
CN5: Pin Signal Pin Signal
1 Key-in Meter 11 Coin-Enable
2 Bill-in Meter 12 Bill-Enable
3 Coin-in Meter 13 Hopper-SSR
4 Pay-out Meter 14 GP0
5 Key-out Meter 15 GP1
6 Hand-pay Meter 1 16 GP2
7 Hand-pay Meter 2 17 GP3
8 Spare Meter 18 GP4
9 GND 19 GND
10 GND 20 GND
Note:
1. Each LAMP output supports open-drain 500mA (max) current; each Tower LAMP output supports open-drain 1A (max)
current.
2. Eight Meters support pulse-Generator function.
3. All output pin is open-drain circuit and operation maximum voltage cannot over +30V.
P/N：2200104-G
9
CN6/CN7 Gaming IO Input Connector (Micro-FIT 3.0mm 2*8 PINs)
CN6 Pin Signal Pin Signal
1 Button 12 9 Touch-Cal Key-Lock
2 Button 13 10 Spare Key-Lock
3 Button 14 11 Coin-In Signal A
4 Button 15 12 Coin-In Signal B
5 Button 16 13 Bill-In
6 Dissolve Key-Lock 14 Hopper Sensor
7 OM Key-Lock 15 GP0
8 Setup Key-Lock 16 GP1
CN7 Pin Signal Pin Signal
1 Door Switch 1 9 Button 4
2 Door Switch 2 10 Button 5
3 Door Switch 3 11 Button 6
4 Door Switch 4 12 Button 7
5 Door Switch 5 13 Button 8
6 Button 1 14 Button 9
7 Button 2 15 Button 10
8 Button 3 16 Button 11
Note:
1. All input pin logical high-level is +5V ~ +24V, logical low-level is 0V ~ +1.5V.
2. Coin-In Signal A, Coin-In Signal B, Bill-In, and Hopper Sensor support input counter fuction.

P/N：2200104-G
10
Appendix A
CN3 Output Signal TTL/RS232/RS485/cctalk Jumper Configuration
Default configuration of UART 5 and UART 6 are RS-232
Locations:
UART 5 Functions
RS-232:
TTL:
RS-485:
ccTalk:
Note: Orange block means shorted by a jumper, and others leave it N.C.
P/N：2200104-G
11
UART 6 Functions
RS-232:
TTL:
RS-485:
ccTalk:
Note: Orange block means shorted by a jumper, and others leave it N.C.

P/N：2200104-G
12
Appendix B AGC IO Definition
1. ACE-B7400 Gaming GPI:
Channel type Gaming I/O Remark
DI0 I Door SW1 AGA log 0
DI1 I Door SW2 AGA log 1
DI2 I Door SW3 AGA log 2
DI3 I Door SW4 AGA log 3
DI4 I Door SW5 AGA log 4
DI5 I AGA log 9 (onboard chassis switch, Door switch 6)
DI6 I AGA log 10 ( JST intrusion switch, Door switch 7)
DI7 I.I Button 1
DI8 I.I Button 2
DI9 I.I Button 3
DI10 I.I Button 4
DI11 I.I Button 5
DI12 I.I Button 6
DI13 I.I Button 7
DI14 I.I Button 8
DI15 I.I Button 9
DI16 I.I Button 10
DI17 I.I Button 11
DI18 I.I Button 12
DI19 I.I Button 13
DI20 I.I Button 14
DI21 I.I Button 15
DI22 I.I Button 16
DI23 I.I Dissolve Key-Lock (Key 1)
DI24 I.I OM Key-Lock (Key 2)
DI25 I.I
Setup Key-Lock(Hand Pay) (Key 3)
DI26 I.I Touch-Cal Key-Lock (Key 4)
DI27 I.I Spare Key-Lock (Key 5)
DI28 I.I Coin-In Signal A Counter 1
DI29 I.I Coin-In Signal B Counter 2
DI30 I.I Bill-In Counter 3
DI31 I.I Hopper Sensor Counter 4
DI32 I.I General Purpose
DI33 I.I General Purpose
P/N：2200104-G
13
2. ACE-B7400 Gaming GPO:
Channel type Gaming I/O Remark
DO0 O.C. Lamp1
DO1 O.C. Lamp2
DO2 O.C. Lamp3
DO3 O.C. Lamp4
DO4 O.C. Lamp5
DO5 O.C. Lamp6
DO6 O.C. Lamp7
DO7 O.C. Lamp8
DO8 O.C. Lamp9
DO9 O.C. Lamp10
DO10 O.C. Lamp11
DO11 O.C. Lamp12
DO12 O.C. Lamp13
DO13 O.C. Lamp14 1000 mA
DO14 O.C. Lamp15 1000 mA
DO15 O.C. Lamp16 1000 mA
DO16 O.C. Key-In Meter (Meter 1) Pulse Generator 1
DO17 O.C. Bill-In Meter (Meter 2) Pulse Generator 2
DO18 O.C. Coin-In Meter (Meter 3) Pulse Generator 3
DO19 O.C. Pay-Out Meter (Meter 4) Pulse Generator 4
DO20 O.C. Key-Out Meter (Meter 5) Pulse Generator 5
DO21 O.C. Hand-Pay Meter1 (Meter 6) Pulse Generator 6
DO22 O.C. Hand-Pay Meter2 (Meter 7) Pulse Generator 7
DO23 O.C. Spare Meter1 (Meter 8) Pulse Generator 8
DO24 O.C. Coin-Enable
DO25 O.C. Bill-Enable
DO26 O.C. Hopper SSR
DO27 O.C. General Purpose
DO28 O.C. General Purpose
DO29 O.C. General Purpose
DO30 O.C. General Purpose
DO31 O.C. General Purpose

P/N：2200104-G
14
3. ACE-B7400 Gaming Spare I/O:
Channel type Gaming I/O Remark
GPIO0 I/O Spare I/O bit 0
GPIO1 I/O Spare I/O bit 1
GPIO2 I/O Spare I/O bit 2
GPIO3 I/O Spare I/O bit 3
GPIO4 I/O Spare I/O bit 4
GPIO5 I/O Spare I/O bit 5
GPIO6 I/O Spare I/O bit 6
GPIO7 I/O Spare I/O bit 7
GPIO8 I/O Spare I/O bit 8
GPIO9 I/O Spare I/O bit 9
GPIO10 I/O Spare I/O bit 10
GPIO11 I/O Spare I/O bit 11
GPIO12 I/O Spare I/O bit 12
GPIO13 I/O Spare I/O bit 13
GPIO14 I/O Spare I/O bit 14
GPIO15 I/O Spare I/O bit 15
