Page 1of 4AR-B1565/1565A Manual
AR-B1565/1565A Manual
Edition 1.0
B
1.1 PACKING LIST
! The quick setup manual
! 1 AR-B1565 CPU board
! 2 Hard disk drive adapter cable
! 1 Floppy disk drive adapter cable
! 1 Parallel port adapter cable mounted on one bracket
! 1 Software utility CD
! 4 RS-232 and PS/2 Mouse & Keyboard interface cable
mounted on bracket
2. KEYBOARD & MOUSE CONNECTOR (KB1)
1. MOUSE DATA
2. KB DATA
3. GND
4. VCC
5. MOUSE CLOCK
6. KB CLOCK
1 2
KB1
3. PC/104 CONNECTOR (PC1)
(1) 64 Pin PC/104 Connector A&B
1
264
63
(2) 40 Pin PC/104 Connector C&D
1
240
39
4. HARD DISK (IDE) CONNECTOR (IDE1, IDE2)
(1) 40 Pin Hard Disk Connector (IDE1)
1
240
39
(2) 44 Pin Hard Disk Connector (IDE2)
1
244
43
5. FDD PORT CONNECTOR (FDD1)
1
234
33
6. PARALLEL PORT CONNECTOR (PRIN1)
1
226
25
Parallel Port Connector
7. CRT CONNECTOR (VGA1)
2 10
1 9
6. RED
7. GND
8. GREEN
9. GND
10. BLUE
1. GND
2. V.S
3. DDCK
4. H.S
5. DDCD
8. ETHERNET RJ-45 CONNECTOR (LAN1, LAN2)
1
8
PIN FUNCTION PIN ASSIGNMENT
1 TPTX+ 5 NOT USED
2 TPTX+ 6 TPRX-
3 TPRX+ 7 NOT USED
4 NOT USED 8 NOT USED

Page 2of 4AR-B1565/1565A Manual
9. 26-PIN AUDIO CONNECTOR (AUDIO1)
1
225
26
PIN Signal PIN Signal
1 AUXAL 2 LINEL
3 AUXAR 4 LINER
5 VCC 6 Not Used
7 AUDIOL 8 MICPH
9 AUDIOR 10 PCSPKO
11 GND 12 GND
13 Not Used 14 Not Used
15 GND 16 GND
17 Not Used 18 Not Used
19 Not Used 20 Not Used
21 Not Used 22 Not Used
23 Not Used 24 Not Used
25 GND 26 GND
Note: the connector does not contain the GAME (MIDI)
port signal. When AR-B9425 audio card is used with this
CPU board, the GAME port function is not supported.
10. SERIAL PORT A~D SELECT (JP3~JP6)
1
3
5
2
4
6
1
3
5
2
4
6
1
3
5
2
4
6
1
3
5
2
4
6
(3-4 +12V: Factory Preset)
11. COM-C RS-232/RS-485 SELECT (J6, J8)
J6
1
3
5
1
2
3
J8
RS-232
J6
1
3
5
1
2
3
J8
RS-485
Factory Preset
12. RS-485 TERMINATOR SELECT (J7)
When there is only one line the setting should be left off,
if multiple blocks are used on a single line this should be
set to “ON” in order to properly terminate the connection
for better transmission of data
OFF Factory Preset
1
21 2ON
13. SERIAL PORT A-D CONNECTOR (SERI1)
1
239
40
14. RESET SWITCH (J13)
2 – RS
1 - GND
15. POWER CONNECTOR (PWR1, J11)
1: +12V
2: GND
3: GND
4: +5V
1: GND
2: -5V
3: -12V
J11
PWR1
1
2
3
4
3
2
1
16. POWER CONTROL CONNECTOR (CN1)
1
2
3
for AT Power
PSON
+5VSB
1
2
3
for ATX Power
Factory Preset
17. POWER ON CONNECTOR FOR ATX POWER
SUPPLY (J4)
PSON GND 2 1
18. EXT.BATTERY (J5)
1 – EXBAT
2 - GND
1-2 +5V
3-4 +12V
5-6 GND

Page 3of 4AR-B1565/1565A Manual
19. BATTERY JUMPER (JP8)
1
2
3
1-2:EXTERNAL BATTERY
2-3:ON-BOARD BATTER
Y
Factory Preset
20. INFRARED CONNECTOR (IR1)
1 5
1. VCC
2. NC
3. IR DATA RECEIVER
4. GND
5. IR DATA TRANSFER
21. PCI SELECT (JP1)
1
2
3
2-3 Support one PCI Card
(Factory preset)
1-2 When riser card is applied
Factory Preset
22. LED HEADER (J12)
135
246
1.HLEDP+
2.HLEDP-
3.HLEDS+
4.HLEDS-
5.P/WLED+
6.P/WLED-
HLEDP: External LED connector for primary IDE channel.
HLEDS: External LED connector for secondary IDE
channel.
P/WLED: External LED connector for power status
indication.
23. LCD CONNECTOR (LCD1)
Only for AR-B1565
The pin assignment of LCD connector is shown below:
1
2
LCD Display Connector
Pin Signal Pin Signal
1 GND 2 SHFCLK
3 GND 4 LP
5 FLM 6 GND
7 NC 8 NC
9 P0 (B0) 10 P1 (B1)
11 P2 (B2) 12 P3 (B3)
13 GND 14 DB2 (B4)
15 P5 (B5) 16 NC
17 NC 18 P6 (G0)
19 P7 (G1) 20 GND
21 P8 (G2) 22 P9 ( G3)
23 P10 (G4) 24 P11 (G5)
25 NC 26 NC
27 GND 28 P12 (R0)
29 P13 (R1) 30 P14 (R2)
31 P15 (R3) 32 P16 (R4)
33 P17 (R5) 34 GND
35 VCC 36 VCC
37 +12V 38 +12V
39 GND 40 GND
41 DE 42 ENABLK
43 GND 44 VEE
24. TOUCH SCREEN CONNECTOR (J3)
1231 RXDF
2 TXDF
3 CGND
25. EXTERNAL SPEAKER HEADER (J9)
3-4 On
Enable Internal Buzzer
2 X
3 INT BZ
4 BUZ Z
1 Vcc
Enable External Buzzer
2 X
3 INT BZ
4 BUZ Z
1 Vcc
Factory Preset
26. LCD SUPPORTED VOLTAGE LCD1SELECT (JP11)
Only for AR-B1565
3.3V
(Factory Preset)
5 3 1
6 4 2
5V
5 3 1
6 4 2
27. LVDS SUPPORTED VOLTAGE LVDS1 SELECT
(JP12) Only for AR-B1565
5V
5 3 1
6 4 2
3.3V
(Factory Preset)
5 3 1
6 4 2

Page 4of 4AR-B1565/1565A Manual
28. ETHERNET SETUP (JP9, JP10)
Factor
y
Preset
JP9 ON:EnableLAN1
(Factory Preset)
OFF:DisableLAN1
JP10 ON: Enable LAN2
(Factory Preset)
OFF: Disable LAN2
29. D.O.C MEMORY BANK ADDRESS SELECT (JP2)
This section provides the information about how to use the D.O.C. (Disk
On Chip). There divided two parts: hardware setting and software
configuration.
OFF
Factory Preset
1
21 2
ON
D.O.C. Memory Address
30. LVDS HEADER (LVDS1)
Only for AR-B1565
1
2
25
26
PIN (LVDS1) FUNCTION PIN (LVDS1) FUNCTION
1 TXOUT0- 2 GND
3 TXOUT0+ 4 GND
5 TXOUT1- 6 VTX5
7 TXOUT1+ 8 VTX5
9 TXOUT2- 10 NC
11 TXOUT2+ 12 GND
13 TXCLK- 14 GND
15 TXCLK+ 16 VTX12
17 TXOUT3- 18 VTX12
19 TXOUT3+ 20 GND
21 VTKBP 22 NC
23 VTX5 24 NC
25 VTX5 26 NC
31. TV-OUT CONNECTOR (TV1)
Only for AR-B1565A
1 6
Composite Video and S-video
32. USB CONNECTOR (USB1)
33. GENERAL PURPOSE INPUT OUTPUT (CN2)
34. GPIO ADDRESS SELECT (JP7)
1
2
3
4
35.RS-485 CONNECTOR (J14)
NET+
NET-
GND
1
2
3
RS-485 CONNECTOR
Note:
If the content in setting is inconsistent with the CD-ROM.
Please refer to the Setting as the priority.
Step 1: Use JP2 to select the correct D.O.C.
memory bank address.
Step 2: Insert programmed Disk On Chip into
sockets U18 setting as DOC.
Step 3: Line up and insert the AR-B1565 card into
slot of your back plane.
JP2 Address Note
OFF C800 : 0000
ON D000 : 0000 Factory Preset
PIN ASSIGNMENT
1 LUMINANCE
2 CHROMINANCE
3 COMPOSITE
4 GND
5 GND
6 GND
PIN ASSIGNMENT PIN ASSIGNMENT
1 GPI0 6 GPO2
2 GPO0 7 GPI3
3 GPI1 8 GPO3
4 GPO1 9 +5V
5 GPI2 10 GND
SELECT ADDRESS SELECT ADDRESS
1-2 ON
3-4 ON 215H
(Factory Preset) 1-2 OFF
3-4 ON 216H
1-2 ON
3-4 OFF 77H 1-2 OFF
3-4 OFF 78H
1 9
2 10
1.VCC0
2.VCC1
3.DATA0-
4.DATA1-
5.DATA0+
6.DATA1+
7.8. GND
9.10.GND
1 9
2 10
