Fortinet FortiGate 80F Series User manual

QuickStart Guide
FortiGate\FortiWiFi 80F Series
FG-80F, FG-81F, FWF-80-2R, FWF-81F-2R, FWF-81F-2R-POE

3
Product Registration
Thank you for purchasing a FortiGate.
http://support.fortinet.com
Register to access:
▪ Cloud Management
▪FortiGuard Updates
▪Firmware Upgrades
▪Technical Support
▪Warranty Coverage
Please register your FortiGate:
Vous devez enregistrer le produir:
Debe registrar el producto:
登録のお願い:
请马上注册:
March 16, 2021
Copyright© 2021 Fortinet, Inc. All rights reserved. Fortinet®, FortiGate®, FortiCare® and FortiGuard®, and certain other marks are registered trademarks
of Fortinet, Inc., in the U.S. and other jurisdictions, and other Fortinet names herein may also be registered and/or common law trademarks of Fortinet. All
other product or company names may be trademarks of their respective owners. Performance and other metrics contained herein were attained in internal
lab tests under ideal conditions, and actual performance and other results may vary. Network variables, different network environments and other conditions
may affect performance results. Nothing herein represents any binding commitment by Fortinet, and Fortinet disclaims all warranties, whether express or
implied, except to the extent Fortinet enters a binding written contract, signed by Fortinet’s General Counsel, with a purchaser that expressly warrants that
the identified product will perform according to certain expressly-identified performance metrics and, in such event, only the specific performance metrics
expressly identified in such binding written contract shall be binding on Fortinet. For absolute clarity, any such warranty will be limited to performance
in the same ideal conditions as in Fortinet’s internal lab tests. In no event does Fortinet make any commitment related to future deliverables, features or
development, and circumstances may change such that any forward-looking statements herein are not accurate. Fortinet disclaims in full any covenants,
representations, and guarantees pursuant hereto, whether express or implied. Fortinet reserves the right to change, modify, transfer, or otherwise revise this
publication without notice, and the most current version of the publication shall be applicable.
2

54
Table of Contents
Installation
Licensing & Services
About Fortinet
Setup
FortiGate 80F Series..................................................................................... 6
FortiWiFi 81F-2R Series ............................................................................. 10
FortiWiFi 81F-2R-POE ..................................................................... 14
Basic Connections ..................................................................................... 18
Wall Mount Option...................................................................................... 19
Desktop Option .......................................................................................... 20
Rack/Rail Mount Option............................................................................. 21
SFP Installation........................................................................................... 22
Setup Options............................................................................................. 23
GUI ................................................................................................... 24
FortiGate Cloud ............................................................................... 26
FortiExplorer .................................................................................... 27
Command Line Interface (CLI) ........................................................ 28
Resources................................................................................................... 29
Free Licences & Services........................................................................... 30
FortiCare Subscriptions ............................................................................. 32
Bundled Services with FortiCare............................................................... 34
Fortinet Security Fabric.............................................................................. 36
FortiGate Security Fabric Integration ........................................................ 38
Solution Spotlight: Secure SD-WAN.......................................................... 40
Fortinet Security Processors ..................................................................... 42
Corporate Overview ................................................................................... 44
Regulatory Compliance Information.......................................................... 46
Product Series

76
QuickStart Guide
FortiGate 80F/81F/Bypass
Box Includes - FG 80F Series
Wall Mount Hardware
(Not included, sold separately)
Wall Mount Kit
(Not included, sold separately)
12V DC Power AdapterPower Cable
Ethernet Cable
Back Panel - FG 80F Series
6
5
3
4
7
2
1
Power Input 12V DC 3A, 100-240V AC 50/60Hz
(optional redundant power adapter and cable available for purchase)
Console (RJ-45) CLI management computer interface
Ports 1 to 6 (RJ-45) 1 Gbps Ethernet interface
BYPASS Port Pair (RJ45) 1 Gbps Ethernet interface
FortiLink Ports A & B (RJ-45) 1 Gbps Ethernet interface
SFP Shared Ports 1 & 2 (SFP) 1 Gbps SFP interface
WAN Shared Ports 1 & 2 (RJ45) 1 Gbps Ethernet interface
6 7
USB (USB A) USB 3.0 server port
40F/41FFG-80F Series
SFP 1 WAN 1
WAN 2
1
2 4 6 B
3 5 A
SFP 2 – shared –
– shared –CONSOLE
USB
31 2 4 5
—BYPASS—
(FG 80F-Bypass model only. WAN1 & Port1 are the default conguration )

98
2
3
5
1
FortiGate 80F
Green: The device is on
Off: The device is off
FortiGate 80F - BYPASS
Green: The device is on
Off: The device is off
Green: Both power supplies are functioning
Amber: One power supply is functioning
Off: Power is off
Amber: Bypass Port Pair is active
Off: Bypass Port Pair is off
Green: Operating normally; BLE is off
Flashing Green: Booting up
Flashing Amber: BLE is on
LOGO
POWER
STATUS
BYPASS
HA
PORT
LINK/ACT
WAN
BLE/RESET Restores factory default and BLE settings
SFP
4
6
Green: Operating in an HA cluster
Amber: HA failover
Off: Not in an HA cluster
Flashing Green:1000M/100M/10M data activity
Off: No link established
Flashing Green:1000M/100M/10M data activity
Off: No link established
Flashing Green:1000M/100M/10M data activity
Off: No link established
Front Panel - FG 80F Series
41 2 63 5
(FG 80F-Bypass
model only)
(WAN1 & Port1, default conguration)
(WAN & SFP
are Shared Ports)
FG-80F Series

1110
FWF-80F-2R Series
QuickStart Guide
FortiWiFi-80F/81F/-2R
Box Includes - FWF 80F-2R Series
Wall Mount Hardware
(Not included, sold separately)
Wall Mount Kit
(Not included, sold separately)
Ethernet Cable
HA
POWER
WAN1
WAN2
A
B
SFP1
SFP2
1
2
3
4
5
6
STATUS
81F-2R
WiFi
BLE / RESET
3 WiFi Antennas
Back Panel - FWF 80F-2R Series
6
5
4
7
3
2
1
Power Input 12V DC 5A, 100-240V AC 50/60Hz
(optional redundant power adapter and cable available for purchase)
Console (RJ-45) CLI management computer interface
Ports 1 to 6 (RJ-45) 1 Gbps Ethernet interface
FortiLink Ports A & B (RJ-45) 1 Gbps Ethernet interface
SFP Shared Ports 1 & 2 (SFP) 1 Gbps SFP interface
WAN Shared Ports 1 & 2 (RJ45) 1 Gbps Ethernet interface
67
USB (USB A) USB 3.0 server port
SFP 1 WAN 1
WAN 2
1
2 4 6 B
3 5 A
SFP 2 – shared –
– shared –CONSOLE
USB
WiFi WiFi SCAN
3 4
1 2 5
Antenna Connection (SMA) passive directional antenna connection
12V DC Power AdapterPower Cable

1312
FWF-80F-2R Series
2
3
5
1
FortiWiFi 81F-2R
Blue: The device is on
Off: The device is off
Green: Both power supplies are functioning
Amber: One power supply is functioning
Off: Power is off
LOGO
POWER
WIFI
STATUS
HA
PORT
LINK/ACT
WAN
BLE/RESET Restores factory default and BLE settings
SFP
4
6
Green: Operating in an HA cluster
Amber: HA failover
Off: Not in an HA cluster
Flashing Green:1000M/100M/10M data activity
Off: No link established
Flashing Green:1000M/100M/10M data activity
Off: No link established
Flashing Green:1000M/100M/10M data activity
Off: No link established
Green: Operating normally; BLE is off
Flashing Green: Booting up
Flashing Amber: BLE is on
Front Panel - FWF 80F-2R Series
41 2 6 3 5
(WAN & SFP
are Shared Ports)
Green: WiFi connected
Flashing Green:WiFi activity
Off: WiFi is off
HA
POWER
WAN1
WAN2
A
B
SFP1
SFP2
1
2
3
4
5
6
STATUS
81F-2R
WiFi
BLE / RESET

1514
FWF-81F-2R-POE
QuickStart Guide
FortiWiFi-81F-2R-POE
Box Includes - FWF 81F-2R-POE
Wall Mount Hardware
(Not included, sold separately)
Wall Mount Kit
(Not included, sold separately)
Ethernet Cable
HAPWR
WAN1
WAN2
5 6
SFP1 PoE
PoE
SFP2 MAX
PoE
LINK/ACT
4321 A B
STATUS
81F-2R-PoE
WiFi
BLE / RESET
3 WiFi Antennas
Back Panel - FWF 81F-2R-POE
6
5
4
7
3
2
1
Power Input 54V DC 2.78A, 100-240V AC 50/60Hz
(optional redundant power adapter and cable available for purchase)
Console (RJ-45) CLI management computer interface
Ports 1 to 6 (RJ-45) 1 Gbps Ethernet interface
FortiLink Ports A & B (RJ-45) 1 Gbps Ethernet interface
SFP Shared Ports 1 & 2 (SFP) 1 Gbps SFP interface
WAN Shared Ports 1 & 2 (RJ45) 1 Gbps Ethernet interface
67
USB (USB A) USB 3.0 server port
54 54
SFP 1 WAN 1
WAN 2
1
2 4 6 B
3 5 A
SFP 2 – shared –
– shared –CONSOLE
USB
WiFi WiFi SCAN
3 4
1 2 5
Antenna Connection (SMA) passive directional antenna connection
54V DC Power AdapterPower Cable

1716
FWF-81F-2R-POE
2
3
5
1
FortiWiFi 81F-2R
Blue: The device is on
Off: The device is off
Green: Both power supplies are functioning
Amber: One power supply is functioning
Off: Power is off
LOGO
PWR
WIFI
STATUS
HA
SFP/WAN
MAX PoE
BLE/RESET Restores factory default and BLE settings
Ports
4
6
Green: Operating in an HA cluster
Amber: HA failover
Off: Not in an HA cluster
Flashing Green:1000M/100M/10M data activity
Off: No link established
Flashing Green:1000M/100M/10M data activity
Off: No link established
Green: Operating normally; BLE is off
Flashing Green: Booting up
Flashing Amber: BLE is on
Front Panel - FWF 81F-2R-POE
41 2 6 3 5
(WAN & SFP
are Shared Ports)
LINK/ACT
PoE
Green: WiFi connected
Flashing Green:WiFi activity
Off: WiFi is off
HAPWR
WAN1
WAN2
5 6
SFP1 PoE
PoE
SFP2 MAX
PoE
LINK/ACT
4321 A B
STATUS
81F-2R-PoE
WiFi
BLE / RESET
Red: Providing Max PoE Power
Off: PoE power available
Green:PoE power on
Off: PoE power off
