ACT-HSC HEAT PIPE COOLERS:
INSTALLATION GUIDE
SEALED ENCLOSURE COOLING
HSC -22 HSC -45 HSC -68
SA44609
ULUS LISTED
C

ADVANCED COOLING TECHNOLOGIES
The Thermal Management Experts | www.1-ACT.com
OPERATION
2
The ACT Heat Sink Cooler (HSC) is a conduction based enclosure cooling product
that is available in three sizes to address a large range of enclosure sizes and heat
loads. The HSC design features two high performance heat sinks bonded to a center
mounting plate. The center plate is designed in a way that prevents water or dust
from passing between the opposing sides where the heat sinks are bonded. The
center plate has an embedded gasket groove around its perimeter flange that
contains a weatherproof gasket that ensures a quality seal with the enclosure that
the HSC is being mounted to.
ACT-HSC units can be mounted to the side, door or roof of electrical enclosures.
Installation requires a square cutout in the wall of the enclosure for the HSC to stick
through. A bolt pattern around the perimeter secures the HSC to the enclosure and
compresses the perimeter gasket, making a seal that prevents dirt or water from
entering the cabinet.
ACT-HSC units operate by exchanging the heat from the air inside of the electronics
enclosure with the ambient air outside of the enclosure without allowing the two air
streams to mix.
Typical Installation location
for an ACT-HSC-22 unit
Top View of ACT-HSC-22 with arrows showing the airflow patterns of the internal and external air streams
CAUTION
BEFORE INSTALLING AND USING THE ACT-HSC PRODUCT, IT IS IMPORTANT THAT THIS MANUAL BE
READ AND UNDERSTOOD THOROUGHLY.
Ambient Air
Heated Air
Exhausted to
Ambient
Cooled Air
Returned to
Enclosure
Hot Air From
Enclosure
Enclosure Wall
The HSC’s internal fan blows the hot
enclosure air over the high eciency bonded
fins. The internal enclosure’s heat is rejected
outside of the enclosure via a common
sealed heat transfer plate.
The HSC’s external fan blows the cool
ambient air over the external high
eciency bonded fins reducing the
internal enclosure temperature.
TOP VIEW HSC-22
W W W.1-ACT.COM

OPERATION
The number that has been assigned to each of the ACT-HSC models corresponds to its thermal conductance in
Watts/°C. For example, the ACT-HSC 22 is capable of dissipating 22 Watts of heat for every 1°C temperature
dierence between the inside air and the ambient air outside of the enclosure. The ACT-HSC-68 is capable of
dissipating 68 Watts of heat for every 1°C temperature dierence
If an electrical cabinet has 1000W of internal heat, a maximum ambient condition of 40°C and a maximum cabinet
air temperature of 60°C, the enclosure designer needs to specify a heat exchanger with greater than
[1000W/(60°-40°C)] = 50W/°C conductance to keep the cabinet air from exceeding the 60°C limit. A complete
product part number description can be reviewed below.
Product Warranty Policy
In the event of a performance issue, please contact the factory before
troubleshooting the unit. Removal of the cover prior to contacting the
factory will void the warranty. ACT provides a one-year warranty against
defects in materials and workmanship in its products. For more information,
refer to ACT's exclusive terms and conditions of online sales at:
www.1-ACT-com/enclosure-cooling/act-exclusive-terms-conditions/
All returns must be pre-approved and issued an RMA number. The RMA
number must be included in the box with the returned product
documentation.
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY, PLEASE OBSERVE THE
FOLLOWING: nstallation work and electrical wiring must be done by qualified person(s) in
accordance with all applicable codes and standards, includingfire-rated construction.
ACT HSC- - 22 - 12 - 12
Thermal Conductance
Watts/°C
- 22
- 45
- 68
Voltage Range
- 12 VDC
- 24 VDC
- 48 VDC
- 115 VAC
- 230 VAC
NEMA RATING
-NEMA 12
-NEMA 4
-NEMA 4X
-NEMA 3R
Heat Sink Cooler
ACT-HSC PART NUMBER DESCRIPTION
3 W W W.1-ACT.COM

INSTALLATION PROCEDURE
Check for any damage to the box that the unit was shipped in. Remove all shipping foam and inspect the unit for
external damage. Any sign of damage should be documented and reported to the carrier.
Assuming there is no visible damage, stand the unit up vertically so that both air streams are clear and plug the unit
into a power source to verify that the internal and external fan(s) are operational. After successfully completing this
quick test, the ACT- HSC unit is ready for installation.
The following assembly procedure details the installation of a sealed enclosure cooler to the wall of an electronics
enclosure. The procedure applies to each of the products in the ACT-HSC line. The three Heat Sink Cooler models
(ACT-HSC-22, ACT-HSC-45 and ACT-HSC-68) are very similar in design and therefore have a similar assembly
process. The major dierence between the models is the size of the cutout in the wall of the enclosure and the hole
pattern used to fasten the enclosure cooler to the wall of the enclosure.
The size and weight of the ACT-HSC-22 is manageable for one person to install alone. The ACT-HSC-45 and
ACT-HSC-68 are larger in size and heavier, so it is recommended that two people work together to install these units.
Step 1: Determine the location of the cooler on the enclosure. The ACT-HSC models can be top or side mounted.
Ensure that you have at least 6” of open space between the fan intake and the next closest enclosure or wall. When
you have decided on a location, use masking tape to outline the square cutout, see figure 2. The cutout dimensions
are shown in the drawings in Appendix A and are available for download in .DXF or SOLIDWORKS® format from the
ACT- Enclosure Cooling Resources area of our website. Start by using a hole saw to establish holes in each corner.
Use a reciprocating saw to make straight cuts between the corner holes, using the masking tape as a reference
edge and to minimize damage to the enclosures surface.
CAUTION
The risk of fire, electric shock or injury exists when installing, cleaning or performing
maintenance on the ACT-HSC unit. ALWAYS DISCONNECT the ACT-HSC from the
power supply during installation or prior to servicing.
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY,
PLEASE OBSERVE THE FOLLOWING:
Installation work and electrical wiring must be done by qualified person(s) in
accordance with all applicable codes and standards, including fire-rated construction.
4 W W W.1-ACT.COM

Step 2: Use the edge of the cutout as a reference edge and plot out the perimeter hole locations according to the
drawing shown below in Appendix A. Once the holes have been marked, drill the remaining mounting holes at the
correct location.
Step 3: Deburr the edges of the cutout using a file. Deburr the holes using a countersink bit.
Step 4: Remove the masking tape and clean any excess cutting oil from the surface/internals of the enclosure.
Step 5: Place the HSC in position on the wall of the enclosure. The electrical cord should be passed through the
opening in the enclosure prior to inserting the HSC body through the cutout. The ACT-HSC should be oriented so
the gasket contacts the outside surface of the enclosure. Ensure that the gasket surface is free of dust, dirt, and
imperfections and that it makes consistent contact with the external surface of the enclosure.
Step 6: With the HSC held in place, install the fastening bolts around the perimeter flange of the ACT-HSC. The
ACT-HSC-22 has 12 bolts, the ACT-HSC-45 has 16 bolts, and the ACT-HSC-68 has 22 bolts. Make sure the sealing
washer is properly located on the bolt as shown in below. The sealing washer is meant to seat on the external face
of the ACT-HSC (the face opposite the gasket).
INSTALLATION PROCEDURE
Risk of injury
Carefully deburr all drilled holes and cut-outs to prevent injuries caused by
sharp edges.
5 W W W.1-ACT.COM

INSTALLATION PROCEDURE
For the HSC-22 model this step can be completed by one person. For the HSC-45 and HSC-68
models, it is recommended that two people work together to complete this step (one person can hold
the HSC in place while the other person installs the hardware).
Caution
ACT recommends applying an anti-seize lubricant to the threads of the mounting
hardware to prevent galling.
Perimeter bolt with sealing washer and locking nut (left)
perimeter bolts installed on enclosure after being
torqued down.
Step 7: Torque the perimeter bolts evenly, alternating
between bolts in a diagonal pattern so that the sealing
gasket is compressed in an even fashion. Ensure that
every bolt is torqued to at least 20 in-lbs.
6 W W W.1-ACT.COM
