ACTpro 120 Single Door Station with 12 V DC 2A power supply.
PSU Operating & Installation Instructions

ACTpro 120 PSU Operating and Installation Manual
This manual refers to the ACTpro 120 door station with an integrated 12 V DC 2A power supply. Access
Control Technology Ltd. reserve the right to change the contents of this manual and the system it applies to
without prior notice.
While every effort has been taken by ACT to ensure the accuracy of the information contained within this
document, ACT assumes no responsibility for any errors or omissions. No liability is assumed for damages
resulting from the use of information contained within this document.
Access Control Technology
Unit C1, South City Business Centre,
Tallaght, Dublin 24, Ireland.
Tel: [phone] - UK
LoCall: 0845 300 5204
Fax: [phone]
Web: www.accesscontrol.ie
E-mail: [email protected]
Copyright 2012 Access Control Technology Ltd.

ACTpro 120 PSU Operating and Installation Manual
Introduction
The ACTpro 120 is a single door station with an integrated 12 V DC 2A power supply. It
expands any of the existing ACTpro controllers (ACTpro 4000, 4200, 3000, 3200, 2000,
1500) by one door.
The power supply is capable of delivering the full rated 2A current to the load and has an
additional 0.5A for charging the battery.
ACTpro 120 Features and Specification:
Relaycontact rating Main relay 5A / 50 Vac, AUXrelay 1A / 50 Vac
Indoor use only
Compatible withall pro
controllers
ACTpro 4200, 4000, 3200, 3000, 2000, 1500
Technical Details:
Supports Clock&Data or Wiegand readers
Multiple entry& exit readers
Reader short circuit protection
Request to exit
Door Monitoring
Tamper and mains present monitoring
Status LED's
Reader current limiting / short circuit protection
Anti passback
Interlocking
Features:
Mainrelayfor door control/ AUX relayfor alarm monitoring
Supports all ACTpro readers (RFID 125KHz, MIFARE Classic, DESFire EV1)
Break Glass monitoring (ACTpro 4000 and 1500 controllers only)
Voltage Monitoring (ACTpro 4000 and 1500 controllers only)

ACTpro 120 PSU Operating and Installation Manual
Input Voltage 220-240 V AC
Frequency 47-53 Hz
Input Fuse 625mA 250V anti-surge fuse
Output Voltage 13.65V (+/- 2%)
Max Load 2A
Electronic Output fuse Yes
Battery Current ≈ 0.5A for a battery discharged to ≈ 10V
Battery Protections Deep discharge/Over charge/Reverse polarity
Operating Tempature -10 to +50 degrees C
Dimensions (H/W/D) 255mm/233mm/86mm
Weight 2.450Kg
Electrical Specification:
Physical Specification:
PSU Output Voltage:
12V DC The power supply provides two 12V outputs. One pre-wired to power
the ACTpro 120 door station.
The full load current of 2A is shared between the two outputs.
However the total current from both outputs must not exceed 2A.
Monitoring:
Mains present The PSU MAINS PRESENT output is pre-wired to the MAINS
PRESENT input of the ACTpro 120 door station.
Output Voltage The PSU output voltage level is reported to the ACT PC software and
via the web browser of the ACTpro 1520 and 1500 controller.
Tamper The enclosure lid is tamper monitored.
Note: All faults including Mains Present and Tamper are reported on the
ACT Software and via the web browser on the ACTpro 1520 and
1500 controller.

ACTpro 120 PSU Operating and Installation Manual
LED indicators:
Green - AC OK Indicates that the AC Mains is within specification.
Amber –Powered By Battery Indicates that the battery is supplying the output voltage.
Red - Fuse Fault Indicates electronic output shutdown fuse is active and
that no power is being supplied to the load.
The maximum current that the PSU can guarantee is 2A.
Beyond this the fuse will trip and the LED will stay on until
the load is fully disconnected.
Once the load has been disconnected, remove devices to
reduce the current demand below 2A.
It is important for the installer to calculate the power
budget adequately. Please refer to the section titled
„Power Budget‟ for more information.
Installation Instructions:
The ACTpro 120 door station is for indoor installation only and must be installed as
permanently connected equipment.
This equipment must be earthed and an RCD/Earth Fault device must be fitted.
An external disconnect device must be fitted. Before installation ensure that the mains
supply to the ACTpro 120 door station is disconnected.
Mains power should be connected to the ACTpro 120 door station by a licensed electrician
in accordance with local/national codes.
Mounting.
Mount the ACTpro 120 door station directly on to the wall with the supplied screws.
The keyed mounting hole should be screwed first to the wall to aid the mounting. The unit
should be installed in a ventilated area that allows for accessibility after installation.

ACTpro 120 PSU Operating and Installation Manual
Mains Power up.
Attach the correctly rated mains cable and fasten using the cable
ties.
Use an approved external mains disconnect device.
Apply mains power, check the “AC OK” LED is on and measure the
voltage at the output.
Battery insertion.
Disconnect the mains.
Ensure the battery has enough charge to supply the load.
Connect the red battery lead to the + battery terminal and the black lead to the –terminal.
Apply the mains power and check the “AC OK” Green LED is illuminated.
Remove the mains power and check that “Powered By Battery” Amber LED is illuminated.
If the Amber led is illuminated the battery is now supplying the output.
Re-apply the mains power, the “AC OK” Led will illuminate and the “Power By Battery” led
will extinguish.
Power Budget.
The ACTpro 120 can supply up to 2A to power the access control system. The ACTpro
120 door station requires 120mA leaving a balance of 1880mA to power the remainder of
the system.
A complete access control system will require readers and a lock mechanism all of which
will require power.
The following table should be used for calculating the power budget.
ACTpro 4000 Controller 400mA
ACTpro 1500 Controller 250mA
ACTpro 100e Door Station 120mA
ACTpro-X reader (1030/1040/1040/1050/1060) 50mA
ACTPro MIFARE reader (1030/1040/1040/1050) 50mA
Typical Mag Lock (consult your supplier) 800mA

ACTpro 120 PSU Operating and Installation Manual
Ordering Information:
ACT Product Code Product description
ACTpro 1500 Single door IP controller expandable to 32 doors with ACTpro door stations
ACTpro 1520 ACTpro 1500 contoller with integrated 12 V DC 2amp power supply
ACTpro 100e Single door station
ACTpro 120 ACTpro 100e door stations with integrated 12 V DC 2amp power supply
ACTpro 1030e ACT RFID slimline, proximity reader, IP67
ACTpro 1040e ACT RFID Surface / Flush, proximity reader, IP67 rated
ACTpro 1050e ACT RFID Surface/ Flush, PIN & proximity reader, IP67
ACTpro 1060e ACT PIN only reader
ACTpro-X 1030PM Panel mount multi-format proximity reader, IP67
ACTpro 1030e VR Vandal Resistant cover for the ACTpro 1030e
ACTpro MIFARE 1030e ACT RFID slimline, proximity reader, IP67
ACTpro MIFARE 1040e ACT RFID Surface / Flush, proximity reader, IP67 rated
ACTpro MIFARE 1050e ACT RFID Surface/ Flush, PIN & proximity reader, IP67
ACTpro MIFARE 1060e ACT PIN only reader
ACTpro-X MIFARE 1030PM Panel mount multi-format proximity reader, IP67
ACTpro 1030e VR Vandal Resistant cover for the ACTpro 1030e
ACTpro DESFire EV1 1030e ACT RFID slimline, proximity reader, IP67
ACTpro DESFire EV1 1040e ACT RFID Surface / Flush, proximity reader, IP67 rated
ACTpro DESFire EV1 1050e ACT RFID Surface/ Flush, PIN & proximity reader, IP67
ACTpro DESFire EV1 1060e ACT PIN only reader
ACTpro-X DESFire EV1 1030PM Panel mount multi-format proximity reader, IP67
ACTpro 1030e VR Vandal Resistant cover for the ACTpro 1030e
ACT RFID ISO-B ACT RFID Batch Cards
ACT RFID FOB-B ACT RFID Batch Fobs
ACTpro MIFARE Card ACT MIFARE 1K Cards
ACTpro MIFARE Fob ACT MIFARE 1K Fobs
ACTpro DESFire EV1 Card ACT DESFire EV1 Cards
ACTpro DESFire EV1 Fob ACT DESFire EV1 Fobs
ACTWin pro PC application software
ACT USB Mini 5m 5M mini USB cable
Controller
Readers
Cards and Fobs
Software
Communications
ACTpro MIFARE
ACT RFID
ACTpro DESFire EV1

ACTpro 120 PSU Operating and Installation Manual
ACT Contact Details:
Tel: [phone]
UK LoCall: 0845 300 5204
Fax: [phone]
Web: www.accesscontrol.ie
E-mail: [email protected]
E-mail: [email protected]
Certifications:
The ACTpro 120 door station complies with the following
European directives 2004/108/EC and EN60950-1
