ACT ACTLAN - INTERFACE Quick guide

Unit 8 IDA Business Park, Whitestown, Tallaght, Dublin 24, Ireland.
Telephone: [phone]. Telefax: 353 1 462 2587. E-mail: [e-mail] Web: www.actrl.com
ACTLAN Interface Configuration
ACTWin Pro Software
1. Ask the network administrator to supply you with a permanent IP network address.
2. Connect a PC directly to the ACTLAN and run HyperTerminal at 9600 baud, no parity, 1 stop.
3. Power up the ACTLAN and immediately hit 3 lowercase "x" (xxx).
4. Hit the Enter key to go inte Setup Mode.
5. Select 0 and follow the prompts until you get to IP address.
6. Enter the new IP address.
7. If the ACT controllers are on a different LAN segment to the ACTWin Pro PC, then a Gateway
Address is required. Check with the network administrator for the IP address of the router.
8. A Netmask may also be required. Check with the network administrator.
9. Follow the prompts to come back to the Setup Menu.
10. Select 1 to configure the RS232 channel.
11. Set up the following parameters as follows:
Baud Rate 9600 I/F Mode 4C for Direct Connect,4F for Network
Flow 00 Port 10001
Connect Mode C0 Disconnect Mode 00
Flush Mode 80 Pack Control 00
Remote IP Address none
12. Return to the Setup Menu and select 9 to save the settings.
13. Finally test the setup by connecting to the IP address using a Web browser or 'Pinging'.
14. From ACTWin Pro, enter the new IP address into the location manager for the site.
18-00026 Issue 4
serial
10BASE-T
9-30v
link net Tx/Rx collision diagnositc status
LAN/WAN
A B 0V
TX
RX
NETWORK
DOORS
A
B
0V
SERIAL/PRINTER
0V
DTR
DB25 Male
(Rear View)
73 2
Max cable length is 5m using standard
alarm cable or 30m using twin twisted-pair
(use 0V in each pair)
Connections for 25 Way male Connector
RX = Pin 3
TX = Pin 2
0V = Pin 7
ACT 2000
TCP/IP Configuration
Connections for Direct Connect Connections for Network
1. Connect cable directly to
ACT1000/2000 and LAN device
2. In Communications Menu Set:
Address = 1
Direct Conn = Y
ACT 2000
1. Connect LAN RS-485 cable to
NETWORK terminals on the
controller and LAN Interface
2. In ACT1000/2000 Communications
Menu set the controller Address and
set Direct Conn = N
A B 0V
NETWORK
DOORS
A
B
0V
7
22 21 15 14
DB25 Male
(Rear View)
A = Pin 14
B = Pin 15
0V = Pin 7
Pin 14 = Pin 21
Pin 15 = Pin 22
ACT, Unit C1, South City Business Centre, Tallaght, Dublin 24, Ireland. www.accesscontrol.ie
Telephone: [phone] UK Lo-Call 0845-300 5204 Fax: [phone] E-mail: [email protected]

Unit 8 IDA Business Park, Whitestown, Tallaght, Dublin 24, Ireland.
Telephone: [phone]. Telefax: 353 1 462 2587. E-mail: [e-mail] Web: www.actrl.com
ACT LAN Manufacturing Instructions
Issue 3 - 8 March 2004
A B 0V
TX
RX
NETWORK
DOORS
A
B
0V
SERIAL/PRINTER
0V
DTR
Unit C1 South City Business Centre, Tallaght, Dublin 24, Ireland.
Telephone: [phone]. Telefax: 353 1 452 0427. E-mail: [email protected] Web: www.accesscontrol.ie
DB25 Male
(Rear View)
73 2
Modem Direct Connect Cable
Connections for 25 Way male Connector
RX = Pin 3
TX = Pin 2
0V = Pin 7
ACT 2000
Instructions
1. Insert ACTLAN Interface Configuration Sheet (18-00026) inside Box
2. Insert Modem Direct Connect Cable and LAN RS-485 Cable (see below) inside Box
3. Insert 9-way to 25-way serial cable
3. Seal Box and place ACT LAN Sticker outside
3m Cable length
ACT Nework Interface Card
Line 1 Line 2 Line 3 Line 4
SCN C DI DO
+BAT-
~AC~
RS485
RS485 232 Interface
Converter
LED2
LED3
RS232
PORT
Connections for 25 Way male Connector
LAN RS-485 Cable
DO = Pin 2
DI = Pin 3
C = NC
SCN = Pin 7
DB25 Male
(Rear View)
73 2
3m Cable length
(ACT Part num 44-0005)
