ACTi ACM-7511 User manual

www.acti.com * Latest product information: www.acti.com/product/
* Accessory information: www.acti.com/accessory/
100830
Fixed Dom e C amera
ACM-7511 IP D/N CCD Outdoor Vandal
Proof PoE Rugged Dome
• 1/3” Sony EXview HAD Interlaced Scan CCD
• Day and night function with mechanical IR cut filter
• Minimum illumination 0.05 lux at F1.2
• Built-in 3.7-12 mm / F1.4 DC iris vari-focal lens
• 25/30 fps at full D1 resolution
• Selectable MPEG-4 SP, MJPEG compressions
• Two-way audio
• Video motion detection
• Digital input and digital output
• Analog video output with 540 TVL
• Vandal proof and weatherproof IP66 rated casing
• Powered by PoE Class 3 / DC 12V
• ACM-7511N (NTSC) / ACM-7511P (PAL)
Unit: mm [inch]
1 Reset Button
2 Ethernet Indicator LED
3 Composite Video Output
4 Audio Input / Output &
Digital Input / Output
5 DC 12V Power Input
Dome Cover
PDCX-1101 4-inch, smoke, vandal proof
Popular Mounting Solutions
Surface Accessories not required
Wall PMAX-0308
Pendant PMAX-0101
PMAX-0103
Corner PMAX-0101
PMAX-0303
PMAX-0402
Pole PMAX-0101
PMAX-0303
PMAX-0502
Flush PMAX-1003
* For more mounting solutions, please refer to Mounting Accessory section of Buyer’s
Guide or Project Planner v2.0 on www.acti.com
ACCESSORY OPTIONS
PHOTO INDICATION DIMENSION DIAGRAM
+
+
+
+
+
1
2
4
5
3

Box Bulle t Cub e Fixed Do me PTZ Vid e o Decode rVid e o Enc o derSpe ed D o me
IP VIDEO SOLUT ION PRODUCT
* All specifications are subject to change without notice.
* All brand names and registered trademarks are the property of their respective owners.
www.acti.com
100830
ACM-7511
• Device
Device Type Fixed Dome Camera
Image Sensor 1/3” Sony EXview HAD Interlaced Scan CCD
Sensor Size 1/3” (4.8 x 3.6 mm)
Horizontal Resolution 540 TVL
Day / Night Yes
Minimum Illumination Color: 0.15 lux at F1.2 (30IRE, Max. AGC); B/W: 0.05 lux at F1.2 (30IRE, Max. AGC)
Color to B/W switch DSP based switch, configurable
Mechanical IR Cut Filter Yes
IR Sensitivity Range 700 - 1100 nm
IR LED No
Electronic Shutter 1/60 - 1/10,000 sec (NTSC); 1/50 - 1/10,000 sec (PAL) (manual mode)
1/60 - 1/10,000 sec (NTSC); 1/50 - 1/10,000 sec (PAL) (auto mode)
• Lens
Focal Length Vari-focal, f3.7 - 12 mm / F1.4 - 2.8
Iris DC iris
Focus Manual focus
Horizontal Viewing Angle 78.1° - 23.3°
Viewing Angle Adjustment Pan: 0° - 360°; Tilt: 0° - 180°; Rotate: 0° - 360°
• Video
Compression MPEG-4 SP, MJPEG
Maximum Frame Rate vs.
Resolution
30 fps at 720 x 480 (Full D1, NTSC); 25 fps at 720 x 576 (Full D1, PAL); 30 fps at 640 x 480 (VGA, NTSC);
25 fps at 640 x 480 (VGA, PAL); 30 fps at 352 x 240 (CIF, NTSC); 25 fps at 352 x 288 (CIF, PAL);
30 fps at 160 x 112 (QCIF, NTSC); 25 fps at 176 x 144 (QCIF, NTSC)
Multi-Streaming Multiple streams based on single configuration
Bit Rate 28 Kbps - 3 Mbps (per stream)
Bit Rate Mode Constant, Variable
S/N Ratio More than 50 dB
Image Enhancement Backlight compensation; White balance: automatic, predefined and manual; Brightness; Saturation; Contrast;
Automatic gain control; Auto exposure: automatic, predefined and manual; Flickerless
Privacy Mask 1 configurable region
Text Overlay User defined text on video
Image Orientation Image mirror
• Audio
Compression 8 kHz, Mono, PCM, 16 bit encoding
Audio-In Terminal block
Audio-Out Terminal block
• Network
Protocol & Service TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP , Bonjour
Ethernet Port 1, Ethernet (10/100 Base-T), RJ-45 connector
Security IP address filtering; HTTPS encryption; Password protected user levels
• Alarm
Alarm Trigger Video motion detection (3 regions); External device through digital input
Alarm Response Notify control center; Change camera settings; Command other devices; E-mail notification with snapshots;
Upload video, snapshot to FTP server; Activate external device through digital output
• Interface
Analog Video Output 1, CVBS, 1.0Vp-p with 75 Ω BNC connector
Digital Input 1, TTL, terminal block
Digital Output 1, TTL, terminal block
• General
Power Source / Consumption
PoE Class 3 (IEEE802.3af) / 6.72 W (heater and fan off)
PoE Class 3 (IEEE802.3af) / 8.16 W (fan on)
DC 12V / 4.44 W (heater and fan off)
DC 12V / 13.56 W (heater and fan on)
Weight 1040 g (2.29 lb)
Dimensions (Ø x H) 151.69 mm x 114.9 mm (6.0” x 4.5”)
Environmental Casing Weatherproof (IP66 rated); Transparent vandal proof dome cover, up to 659.23 kgF (1453.35 lbF)
Mount Type Surface, Pendant, Wall, Corner, Pole, Flush
Operating Temperature -30 °C ~ 50 °C (-22 °F ~ 122 °F) for DC 12V; -5 °C ~ 50 °C (7 °F ~ 122 °F) for PoE
Approvals CE, FCC, IP66
• Integration
Unified Solution Fully compatible with ACTi software
ISV Integration Software Development Kit (SDK) available
Firmware Access Browser Microsoft Internet Explorer 6.0 or newer
PRODUCT SPECIFICATION
ACM-7511
Fixed Dome Camera
