Action Assist LTD Princess 5000 User manual

- Always apply the brakes when the bed is occupied.
- Always raise the side rails and lower the bed when the patient is unattended,
to reduce the risk of injury from falling.
- When moving the bed ensure the plug is removed from the mains and that cables
are not trailing on the floor.
- When raising the bed ensure there is adequate clearance for the height
adjustment i.e. No overhanging shelves or electrical mains outlets.
- Handsets must be taken around the head or footboard of the bed as this
will result in serious damage to their cables by the height adjustment mechanisms.
- Never allow children to play with the bed. The operator of the bed is always fully
responsible for ensuring that no person, pet or object is exposed to a risk of
being harmed and that the bed is always maintained to be in a safe/reliable condition.
Failure of the backrest and lateral tilt functions to operate may occur due to a
break or surge in power. To rectify, please use the following reprogramming procedure.
Remove power plug from mains outlet. Leave unplugged for a minimum of 30
seconds. Hold handset press the top left hand button (backrest up) once.
Replace power plug into mains outlet and switch on. Hold handset , continually
press the bottom right hand button (manual 30 degree tilt) until fully tilted, now
press the button directly above (button with the red outline) once, to reset to the
horizontal position. The bed will now be reprogrammed. If you are experiencing
any further problems please contact our service department.
Dimensions
Base of bedstead 89 x 203 cm
Maximum height 80 cm
Minimum height 35 cm
Overall external dimensions 102 x 220 cm
Product carries the CE marking EC Directive EN1970:1999
Product carries Medical Devices Directive (93-42/EEC) Annex IX Class1 EN ISO
3746:1995
Action Assist Ltd
Unit 6 Moor Lane Trading Estate
Sherburn in Elmet
Leeds
West Yorkshire
LS25 6ES
Tel: [phone] Fax: [phone]
email: [email protected]
web: www.actionassist.co.uk
Head function.
Reset to
horizontal
Position.
Manual 30
degree tilt.
Handsets -
Manual 8
degree tilt.
Trendelenburg.
Raise/Lower
whole bed.
Emergency
stop
Key to lock
Trendelenburg.
Timer
Indicators 30,
60 & 90 mins.
8 degree tilt
Programs.

Indicators for the timed
lateral tilt 30, 60,
or 90 minute intervals.
Reset to horizontal position (4).
Press the red brake pedal fully down, both wheels on that axle will lock.
Repeat for the wheels at the opposite end of bed.
Press the red brake pedal up once to the central position.
Press the red brake pedal up to its uppermost position.
Continually press head function button (1) until correct
level reached.
Continually press head function button (2) to lower.
Knee-break on - Knee-break off -
With side rails raised, refer to the symbols (above) located on the
side of the bed, situated towards the foot end. Move the lever
located below these symbols to the desired position, firstly
ensuring that the sleeping surface is completely flat. When
selected the knee-break will only operate as the back rest is raised.
Continually press button (3) to raise complete bed to the
desired height.
Continually press button (4) to lower the whole bed.
To select the frequency of turning, choose the required program & press once for 30, twice for 60
& three times for 90 minute intervals. (the relevant indicator will illuminate) When the full turning
program (left, flat, right, flat etc) is selected (1) the sleeping platform automatically moves gently from
the horizontal to 8 degrees towards the left, taking approximately 2 minutes and then stops. After
the time selected it will slowly move back to the horizontal and stay there for the selected time
period before moving gently to the opposite side, again for the selected time period. It then returns
to the horizontal position and the whole process is continually repeated until the program is turned
off, by pressing the reset to horizontal button (4).
The bed can also be set on a program to turn only to the left then flat positions.(2).
The bed can also be set on a program to turn only to the right then flat positions (3).
Enables one person to turn a patient easily, for changing linen, bathing or applying dressings, without
causing undue stress to the patient, or lifting injury to themselves.
The sleeping platform can be turned fully to 30 degrees, to either side by continually pressing the
relevant button (5-6).The backrest, if raised, will automatically lower when the bed is tilted using this
function.
Take hold of the upper rail and raise it until a click is heard from both locks, I.e. in the headboard
and footboard.
Slide the two side rail lock release levers towards each other and lower the side rails.
For children under the age of twelve it is strongly recommended that side rail protectors are fitted.
Annual preventative maintenance must be performed to ensure all bed features are functioning as
originally designed. Particular attention must be addressed to safety features, such as:
.
The Princess 5000 has been approved to carry a max load of 170 kilos.
Max patient weight 175 kilos.
Side rail lock release levers
Allows occupant of the bed to manually
adjust the angle at which they lay, up to a maximum of 8 degrees to the
left or right (5).
These functions should
remain locked, when not in use,. To un-lock insert the key (usually
attached to the handset cable) into the lock located on the side of the
handset to activate buttons (7-8).
When operating the Trendelenburg function ensure the bed is positioned
at a suitable distance away from walls or furniture to prevent damage.
Raise & lower
the backrest (1-2).
Reset to horizontal
position (6).
Trendelenburg
Anti -Trendelenburg
positions (7-8).
Raise & Lower the
whole bed (3-4).
Lateral tilt up to 8
degree angle right
& left manually (5).
Locking key for the
Trendelenburg/ Anti
Trendelenburg functions.
Emergency stop.
Emergency stop.
Program 8 degree tilt,
press once for 30, twice
for 60 & three times for
the 90 minute timer (1).
Manual lateral tilt
up to 30 degree
angle (5-6).
Program right tilt only (2).
Program left tilt only (3).
