ACTiSYS IR9201 User manual

A
AC CT T– –I IR R9 92 20 01 1
O
Op pt ti ic ca al l P Po ow we er r T To o V Vo ol lt ta ag ge e C Co on nv ve er rt te er r
To capture IR transmitter intensity




Maximum IR pulse frequency supported: 0.625 MHz (applicable up to SIR 115.2 kbps)
Easy to measure IR optical power, no need to know hardware details
Easy to interface with oscilloscope using BNC cable
Power: 9 V DC, 6F22DT battery
The only IrDA adapter supplier that has test tools to help your system to be IrDA compliant !

A
AC CT T– –I IR R9 92 20 01 1
O
Op pt ti ic ca al l P Po ow we er r T To o V Vo ol lt ta ag ge e C Co on nv ve er rt te er r
S
p
ecifications
 Operating Temperature:
0o C to 60 o C (32 o F to 140 o F)
Storage Temperature:
-20 o C to 85 o C (-4 o F to 185 o F)
Dimension:
130 mm (5.12") L x 130 mm (5.12") W x 30.5 mm (1.20") H
Weight:
291 g (7.7 oz.)
