CYP CLUX-SDI2HS User manual

CLUX-SDI2HS
SDI to HDMI Scaler with Audio
Operation Manual
Operation Manual

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2011 by Cypress Technology.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
VR0 25/03/11 Preliminary Release
VR1 28/09/11 Add Support Timing
VS2 11/07/12 Updated format/diagrams/SDI
standards
VS3 19/07/12 First release

CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 1
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 Front Panel ........................................3
6.2 Rear Panel.........................................4
6.3 OSD Menu and Function List...........5
6.3.1 Display ............................................7
6.3.2 Color ...............................................7
6.3.3 SDI Audio........................................8
6.3.4 Factory Reset ..........................8
6.3.5 Information..............................9
7. Connection Diagram .......................... 10
8. Specications ...................................... 11
9. Acronyms ............................................. 12

1
1. INTRODUCTION
The SDI to HDMI Scaler allows SD, HD and 3G-SDI signals to be
shown on HDMI and SDI display. This means that it is now easier for
professionals to distribute and extend their SDI signal while giving the
ability to display work on HDMI displays. Furthermore, thanks to coaxial
(S/PDIF) and L/R audio outputs users can output audio in both digital
and analog formats while the loop-through 3G-SDI design benets
users by letting them simultaneous show content on both SDI and
HDMI displays.
2. APPLICATIONS
• Broadcast video signal to HDMI/SDI display
• Broadcast video signal extension
• 3G SDI signal conversion into HDMI signal
3. PACKAGE CONTENTS
• SDI to HDMI Scaler with Audio
• 5V/2.6A DC power adaptor
• Operation Manual
4. SYSTEM REQUIREMENTS
Input source equipment such as SNG camera or any SDI signal
with connection cables and output to LCD TV or SDI monitor with
connection cables.

2
5. FEATURES
• Supports SD-SDI, HD-SDI and 3G-SDI input signals with auto-detection
• Supports HDMI and SDI (bypass) output simultaneously
• SDI interface operates at bitrates of 2.970 Gbit/s, 2.970/1.001 Gbit/s,
1.485 Gbit/s, 1.485/1.001 Gbit/s and 270 Mb/s
• Scale any SDI input signal to HDMI:
1. PC timings – SVGA@60 ~ WUXGA@60 (RB)
2. HDTV timings – 480p/576p ~ 1080p@50/60
• Supports SDI input modes:
1. SD-SDI (SMPTE 259M-C, at bitrates of 270 Mbit/s)
2. HD-SDI (SMPTE 292M, at bitrates of 1.485 Gbit/s and
1.485/1.001 Gbit/s)
3. 3G-SDI (SMPTE 424M/425M-AB, at bitrates of 2.970 Gbit/s and
2.970/1.001 Gbit/s)
• Equalized and re-clocked loop output
• Alternative audio output to coaxial and analog 2 CH
• Integrated audio de-embedder for up to 8 channels of 48 kHz audio
• Supports SDI input/output distance up to 100 meters (3G-SDI), 200
meters (HD-SDI), or 300 meters (SD-SDI)
Note: Tested with Belden 1694A Cable. Operating distances may vary
if used with cables of different specications.

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
POWER 3G HD SD MENU ENTER
-
+
720p
XGA
3G SDI to HDMI Scaler CLUX-SDI2HS
2 3 4 5 6 71
1
Power LED: The LED will illuminate blue when the device is
connected to a power supply.
2
3G LED: This LED illuminate green when a 3G-SDI input signal is
detected.
3
HD LED: This LED illuminate green when a HD-SDI input signal is
detected.
4
SD LED: This LED illuminate green when a SD-SDI input signal is
detected.
5
MENU: Press this button to enter/exit the On-Screen Display (OSD)
menu.
6
ENTER: Press this button to conrm your selection. Press both ENTER
and 'Minus' (−) buttons together to switch the display output to
720p or press both ENTER and 'Plus' (+) buttons together to switch
to XGA. After making the selection, press ENTER to conrm the
output format.
7
−/+: Press these buttons to move up or down the OSD selections.

4
6.2 Rear Panel
SDI IN SDI OUT AUDIO OUT DC 5V
COAXIAL R L
HDMI OUT
1 2 3 4 5 6
1
SDI IN: Connect to the SDI output of the SDI source device.
Accepts SD,HD or 3G SDI signals.
2
SDI OUT: Provides a 'loop-through' SDI signal output for connection
to a SDI display.
3
AUDIO OUT COAXIAL: Digital Audio output (SP/DIF). Connect to an
amplier or recording device with a suitable digital coaxial input.
4
AUDIO OUT R/L: Analogue audio output (L/R Stereo). Connect to
an amplier or recording device with a suitable analogue input.
5
HDMI Out:Connect a HDMI equipped display or to a DVI Display
with a HDMI to DVI cable.
6
DC 5V: Plug the 5 V DC power supply into the unit and connect the
adaptor to an AC outlet. The 'POWER' LED will illuminate blue when
the power is ON.

5
6.3 OSD Menu and Function List
1st Layer 2nd Layer 3rd Layer
Display
Output
NATIVE
800 x 600 @60
1024 x 768 @60
1280 x 768 @60
1360 x 768 @60
1280 x 800 @60
1280 x 1024 @60
1440 x 900 @60
1400 x 1050 @60
1680 x 1050 @60
1600 x 1200 @60
1920 x 1200 @60
720 x 480p @60
1280 x 720p @60
1920 x 1080p @60
720 x 576p @50
1280 x 720p @50
1920 x 1080p @50
1920 x 1080i @60
1920 x 1080i @50
Size
Full
Over Scan
Under 1
Under 2
Letter Box
Pan Scan
Exit

6
Color
Contrast 0~255 (105)
Brightness 0~192 (96)
R 0~255 (128)
G 0~255 (128)
B 0~255 (128)
R Offset 0~63 (32)
G Offset 0~63 (32)
B Offset 0~63 (32)
Exit
SDI Audio
Group 1
Group 2
Group 3
Group 4
Auto
Off
Factory Reset Yes
Information Input Timing, Output Timing & Version

7
6.3.1 Display
• Output Timimgs: There are a total of 20 timings available for
selection.
• Size: Adjusts the displayed screen size from Full, Over Scan, Under
Scan, Letter box or Pan scan to t the current display size or aspect
ratio.
6.3.2 Color
• Adjusts the screen's RGB Color, Contrast and/or Brightness.

8
6.3.3 SDI Audio
• Selects the SDI audio output from 4 different audio groups and each
group's 2CH contents or can be set to 'Auto' which contain up to
7.1 Channels of audio (dependent on the input source signal). If no
audio output is required, the audio can also be muted by selecting
'OFF'.
6.3.4 Factory Reset
• Select YES to return the unit to the factory settings. The default
Factory Setting for Video display is 'Full Screen' (1280×720@60Hz),
Color setting's factory default rate is the same as shown on the OSD
and SDI audio is 'AUTO'.

9
6.3.5 Information
• Displays the source input format, the output display format and the
unit's software version.

10
7. CONNECTION DIAGRAM
SDI IN SDI OUT AUDIO OUT DC 5V
COAXIAL R L
HDMI OUT
Amplier
Stereo
Audio
Output
HDMI
Output
Power
Supply
Coaxial
Digital
Audio
Output
SDI OutputSDI Input
SDI DisplaySDI Camera
HDTV/Monitor

11
8. SPECIFICATIONS
SMPTE Standard 425M Level A & B, 424M, 292M, 259M-C
SDI Transmission Rates 2.970 Gbps, 2.970/1.001 Gpbs
1.48 5 Gbps, 1.485/1.001Gbps and 270
Mbps
Video Bandwidth 165 MHz/link
Input 1×BNC (SD/HD/3G-SDI)
Output 1×BNC (SD/HD/3G-SDI), 1×HDMI,
1×Coaxial, 1×L/R (RCA)
SDI Timing Support SD-SDI:
SMPTE 259M-C, 270 Mbit/s
HD-SDI:
SMPTE 292M, 1.485 & 1.485/1.001 Gbit/s
3G-SDI:
SMPTE 424M/425M-AB, 2.970 &
2.970/1.001 Gbit/s
HDMI Timing Support 480i, 576i, 720p@50/59.94/60
1080i@50/59.94/60
[email protected]/24/25/29.97/30/50/59.94/60
Power Supply 5 V DC/ 2.6 A (US/EU standards, CE/FCC/UL
certied)
ESD Protection Human-body Model:
± 8kV (air-gap discharge)
± 4kV (contact discharge)
SDI Cable Distance 3G/HD/3G-SDI up to 100 /200/300 meters
with BELDEN 1694A Cable
Dimension 180 mm (W)×142 mm (D)×25 mm (H)
Weight 460 g
Chassis Material Aluminum
Silkscreen Color Gray
Operating Temperature 0 °C~40 °C/32 °F~104 °F
Storage Temperature −20°C ~ 60°C / -4°F ~ 140°F
Relative Humidity 20~90 % RH (Non-condensing)
Power Consumption 4 W

12
9. ACRONYMS
ACRONYM COMPLETE TERM
3G Bandwidth 2.97G bps ≈ 3G
SDI Serial Digital Interface
HD High Denition

Home page: http://www.cypress.com.tw
CYPRESS TECHNOLOGY CO., LTD
