ACU-RITE 603 User manual

Thank You! We appreciate you for purchasing the Acu-rite Digital Window Thermometer.
This instrument is designed and engineered with state-of-the-art technology and
components. It will provide the current temperature and low and high temperature
records for wherever it is placed.
This thermometer can be mounted and used in almost any location by utilizing the
rotating suction cups. The suction cups rotate 270º from front to back, allowing the
thermometer to adhere to any clean, flat surface.
1 CHECK PACKAGE CONTENTS
(1) Digital Window thermometer
(1) Instruction manual
00603 INST 0726-06
Digital Window Thermometer
Do not return product to retail store. For Technical Assistance and
product return information, please call Customer Care:
877-221-1252
HOURS: Monday through Friday from 8:00 a.m. to 4:45 pm CST.
Digital Window Thermometer
Instruction Manual
MODEL # 00603
PLEASE DISPOSE OF OLD OR DEFECTIVE BATTERIES IN AN
ENVIRONMENTALLY SAFE WAY IN ACCORDANCE WITH
YOUR LOCAL REGULATIONS

2 READ
Please read this entire manual carefully before you set up the thermometer and begin to
use it. In this way you can become familiar with the features and get the most benefit
from it.
3 ACTIVATE BATTERY
(1) CR2032 “coin-style” lithium battery is included and pre-installed.
A protective strip that prevents the battery from draining during shipping must be
removed from the battery compartment before you can begin using your Digital WIndow
Thermometer.
1) Remove the two small Phillips type screws with a small Phillips screwdriver
2) Remove the battery compartment carefully as to not loose the screws.
3) Remove the small plastic tab from the battery compartment.
4) Replace the battery compartment cover and screws, making sure the battery is still
installed correctly.
NOTE: It is recommended that a lithium type battery always be used in the
Digital Window Thermometer to ensure a long battery life and better cold
weather operation than regular alkaline batteries.
4 CHOOSE WHERE TO USE THE WINDOW THERMOMETER
The Acu-Rite® Digital WIndow Thermometer can be used almost anywhere a
reliable temperature reading is needed. When choosing where to place the
thermometer, keep the following in mind:
• When placing, clean the surface area where the suction cups will adhere to
thoroughly. The suction cups will adhere to surfaces like glass or smooth plastic best.
• For the most accurate reading, place the thermometer in an area OUT OF DIRECT
SUNLIGHT.
• The Digital Window Thermometer is weather-resistant, but is not WATERPROOF.
Place in an area out of direct weather elements, such as under an overhang or on
a recessed or inset window surface when placing outdoors.
• In the case of very cold temperatures outdoors, the thermometers suction cups may
become stiff and loose suction. It is recommended that the window thermometer be
brought indoors in extremely cold weather to prevent the unit from falling.
• The suction cup mounting bracket rotates 270º to allow mounting placement on
various angles of surfaces. The Digital Window Thermometer can be mounted on any
SMOOTH FLAT SURFACE and used anywhere a temperature reading is needed,
provided the previous mounting suggestions are followed.
• When removing the Digital WIndow Thermometer from a mounting surface, lift tab of
suction cup itself. DO NOT pull on the case or the display to remove the thermometer
from a mounting surface as this may cause damage to the rotating suction cup
bracket.
After you have decided where to place the unit, be sure the mounting surface is
clean before mounting. After the Digital WIndow Thermometer is mounted,
consider rotating the display SLIGHTLY down or up to provide the best viewing
angle height for where the location the thermometer will be viewed most from.
PLACE INSIDE
WINDOW FOR INDOOR
TEMPERATURE READING
PLACE OUTSIDE
WINDOW FOR OUTDOOR
TEMPERATURE READING
ROTATE SUCTION CUPS
FOR OUTDOOR TEMPERATURE
READING PLACEMENT
HOME USE
5 DIGITAL WINDOW THERMOMETER FEATURES
SUCTION CUPS
ROTATE 270º FOR
PLACEMENT IN
VARIOUS DIRECTIONS
AND LOCATIONS
WHEN THE
BATTERY
IS LOW, THE
UNIT WILL DISPLAY
“CHANGE BATTERY SOON.”
LARGE EASY-TO-READ
TRANSPARENT LCD
DISPLAY
MINIMUM & MAXIMUM
MEMORY RECORDS THE
LOWEST AND HIGHEST
TEMPERATURES
OBSERVED IN THE
PREVIOUS 24 HOURS.
THE MEMORY WILL
CLEAR ITSELF EVERY
24 HOURS.
note: if the unit loses power,
the memory will clear.
CHANGE BATTERY SOON
WEATHER RESISTANT
BATTERY COMPARTMENT
TEMPERATURE MEASUREMENT
RANGE IS -4ºF TO 140ºF
CHANGEBATTERYSOON
