Acuity Brands Lithonia Lighting VAP User manual

VAP
Installation Instructions
Lithonia Lighting
INDUSTRIAL VALUE STREAM
One Lithonia Way, Conyers, GA 30012
Phone: [phone] Fax: [phone]
www.lithonia.com
Part Number: U21316
Revision Date: 03/2010
READ AND FOLLOW ALL SREAD AND FOLLOW ALL SAFETY INSTRUCTIONS!
SAVE TREAD AND FOLLOW ALL SAFETY INSTRUCTIONS!
SAVE THESE INSTRUCTIONS AND DELIVER TO OWNER
AFTER INSTALLATIONHESE INSTRUCTIONS AND DELIVER TO OWNER
AFTER INSTALLATIONAREAD AND FOLLOW ALL SAFETY INSTRUCTIONS!
SAVE THESE INSTRUCTIONS AND DELIVER TO OWNER AFTER INSTALLATION FETY INSTRUC-
TIONS!
SAVE THESE INSTRUCTIONS AND DELIVER TO OWNER
AFTER IREAD AND FOLLOW ALL SAFETY INSTRUCTIONS!
SAVE THESE INSTRUCTIONS AND DELIVER TO OWNER AFTER INSTALLATION NSTALLATION
WARNING
To reduce the risk of death, injury or property damage from fire, electric shock, cuts,
abrasions, falling parts, and other hazards:
•Service of the equipment must be performed by qualified service personnel.
•Installation and maintenance must be performed by a person familiar with the construction
and operation of this product and any hazards involved. All applicable codes and ordinances
must be followed.
•Read this document before installing, servicing, or maintaining this equipment or installing a
lamp. These instructions do not cover all installation, service, and maintenance situations. If
your situation is not covered, or if you do not understand these instructions or additional
information is required, contact Lithonia Lighting or your local Lithonia LIghting Distributor.
•Read and follow all warnings and instructions provided by the lamp manufacturer.
WARNING
Before installing, servicing, or maintaining this equipment, follow these general precautions.
To reduce the risk of electrocution:
•Make sure the equipment is properly grounded.
•Always de-energize the circuit and/or equipment before connecting to, disconnecting
from, or servicing the equipment.
To reduce the risk of fire:
•Keep material away that can burn from hot lamp.
•Make sure lamps are correctly installed.
•Use supply conductors with a minimum installation temperature rating as specified
on equipment.
To reduce the risk of personal injury from cuts, abrasions, or falling parts:
•Wear gloves to prevent cuts or abrasions from sharp edges when removing from
carton, handling and maintaining this equipment.
•Do not use abrasive materials, glass cleaners or other solvents on reflector or lens.
These substances may damage equipment and cause parts to eventually break and
fall.
•Do not install a damaged fixture.
CAUTION: Observe lamp manufacturer’s recommendations and restrictions on lamp operation,
including but not limited to ballast type, burning position, replacement and cycling. Use only lamps
that comply with applicable ANSI standards.
NOTICE: If lamp is marked it contains mercury. Follow disposal laws. See
www.lamprecycle.org
Lithonia Lighting, a division of Acuity Brands Lighting, Inc., assumes no responsibility for claims arising out of
improper or careless installation or handling of this product.
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS!
sAVE THESE INSTTRUCTIONS AND DELIVER TO OWNER AFTER INSTALLATION
READ AND FOLLOW ALL SAFETY INSTRUCTIONS!
SAVE THESE INSTRUCTIONS AND DELIVER TO OWNER AFTER INSTALLATION

VAP
Installation Instructions
Lithonia Lighting
INDUSTRIAL VALUE STREAM
One Lithonia Way, Conyers, GA 30012
Phone: [phone] Fax: [phone]
www.lithonia.com
Part Number: U21316
Revision Date: 03/2010
VAP QUICK-MOUNT BRACKET (QMB) INSTALLATION
INSTRUCTIONS
Fig 7
Fig 6
Fig 7
1. Attach two (2) steel mounting brackets(Fig 6) to ceiling
(hardware provided by others). The distance between
brackets is 40.3” on center.
2. Remove diffuser, lamps and channel cover. Using a 7/8”
hole saw drill out access hole in the fixture housing for
electrical connection. Remove KO from channel.
3. If field installing snap bracket mounting, attach four (4)
brackets to fixture housing (Fig 7) (maximum 25 inch-pounds
torque on screws).
4. Push fixture housing up into surface brackets until the
surface bracket snaps locking it into place (Fig 8).
5. Make electrical connections and re-install the channel
cover, lamps and diffuser.
