Adaptiv Mini ADVM-FD1 User manual

1
WWW.ADAPTIV-MULTIMEDIA.COM

ADVM-FD1 FORD SYNC3
2
ABOUT
Adaptiv Mini
Adaptiv Mini allows HDMI & Camera input to the OEM screen.
This plug and play Mini interface adds HDMI to connect your Apple or Android de-
vice, allowing you to mirror your smartphone display on the vehicle’s original screen.
Inputs for front and rear aftermarket cameras also come as standard with the Mini.
Application
For Ford vehicles with Sync3 System.
Kit Includes
Adaptiv Interface
Vehicle Harness
Prior to installation
Read the manual prior to installation. Technical knowledge is necessary for installa-
tion. The place of installation must be free of moisture and away from heat sources.
Connects2 cannot be held responsible for the installation of this product.
Technical Support
Connects2 want to provide a fast and suitable resolution should you encounter any
technical issues. With this in mind, when contacting Connects2, try to provide as
much Information as possible. This will speed up the process and help us to help you.
Please use our dedicated online technical support centre: support.connects2.com

3
WWW.ADAPTIV-MULTIMEDIA.COM
CONNECTION DIAGRAM
DIP SWITCH SETTINGS
DIP 1
If the vehicle has OEM
reverse camera
( ON: YES OFF: NO )
DIP 3
If the vehicle has after-
market reverse camera
( ON: YES OFF: NO )
DIP 2
If the vehicle has after-
market front camera (
ON: YES OFF:NO )
DIP 4
OFF
DIP 5
OFF

ADVM-FD1 FORD SYNC3
4
USER GUIDE
HDMI Access
Connect the USB dongle supplied to the Sync USB input**. Select USB source from the OEM
menu sources. The dongle will appear as ‘USB AUX’.
Hold BUTTON 1 for 2 seconds to switch between OEM screen and Adaptiv Mini HDMI screen
Rear and Front Camera Access
From either HDMI mode or OEM mode
1. Select reverse gear for reverse camera
2. Deselect reverse gear - will go to after market front camera ( if DIP 2 ON )
Press top right corner of screen to cancel front camera or drive over 10 MPH
Front Camera Access
Hold BUTTON 2 for 2 seconds to enter the front camera screen ( if DIP 2 is ON )
or double press SOUND button on OEM head unit.
View Version Number
Hold BUTTON 1 Button for 8 seconds to enter rmware information screen
**Note that there may be a slight delay in HDMI audio lip sync , due to the USB audio buffer time of the OEM system. This is
dependant on manufacturer original equipment specication.
Hold BUTTON 2 ( or press top right corner of touch screen ) to disable the video in
motion warning message
Video In Motion Warning - 10 MPH
Button Conguration
Button 1 - Left arrow (steering wheel)
or SOUND button on OEM head unit
Button 2 - Right arrow (steering wheel)
