INSTEON LampLinc 2457D2 User manual

®
INSTEON Dimmer Module 2457D2
Owner’s Manual

Contents
Getting Started
INSTEON Dimmer Module 4
Device Overview
Buttons
Installation
Leave Your Lamp On
INSTEON Links
Understanding Linking 6
Links are One-Way
Links Remember a Device’s State
Controllers
Responders
Controller-Only 7
Responder-Only
Grouping Devices
Use Cross Linking
INSTEON Hub
Linking to the INSTEON Hub 9
Manual Linking
Linking with a Single-Button Controller 11
Linking with a Multi-Button Controller 12
Multi-Linking or Making a Scene 13
Unlinking from a Single-Button Controller 14
Unlinking from a Multi-Button Controller 15
Multi-Unlinking or Removing a Scene 16
Local Programming
About Local Programming 18
Local Programming Flow Chart 19
Software-Only Features
Beep on Button Press 21
Disable Local Programming
Blink on Trac
Error Blink
X10 Support
Setting the X10 Address 23
Removing the X10 Address 24
Appendix
Specications 27
Troubleshooting 30
Certications and Warnings 32
Product Warranty 33

3
Everything you need to quickly get up and running.
Getting Started

4
Leave Your Lamp OnInstallation
ButtonsDevice Overview
INSTEON Dimmer Module
Set Button
On
O
Status LEDOn
O
®
Plug your lamp into the bottom of the
Dimmer Module and plug the Dimmer Module
into an unswitched wall outlet.
Tap to turn o
Double-tap to turn o instantly
Press and hold to dim
Tap to turn on
Double-tap to turn on instantly
Press and hold to brighten
See sections on Basic Linking and
Local Programming for set button
functions
®
If your lamp’s switch is OFF, the Dimmer Module
will be unable to remotely control your lamp.
ON

5
INSTEON devices can stand alone and function as a local switch or
dimmer, but their real power comes when they are connected together to
form a control system. Most INSTEON devices can control one another
and be the recipient of control. The process of associating multiple
INSTEON devices to one another is called Linking.
INSTEON Links

6
When linking INSTEON devices, the links that
are created are one-way.
The current state of the controlled device is
stored in the link: on, o or dimmed.
Switch A will turn Switch B on and o but
Switch B cannot turn Switch A on or o.
The switch will turn on the Dimmer Module
to 75% brightness.
A SwitchB Dimmer Module
NEW
X
NEW
X
®
75%
d
f
h
a
c
e
g
b
INSTEON devices that can turn other devices
on or o are called controllers.
Sensors, Switches, Keypads and the
Hub are common controllers.
NEW
X
®
INSTEON devices that receive the command of a
controller are called responders.
Switches, LED Bulbs, Plug-In Modules and
Micro Modules are common responders.
NEW
X
®
RespondersControllers
Links Remember a Device’s StateLinks are One-Way
Understanding Linking
®
®
Neutral
On
Off
Set
N
N
Load L1
Line L

7
Controller-Only
Some devices like sensors can only control
other devices.
The Motion Sensor will turn on the Switch
but the switch cannot control the Motion
Sensor.
Motion Sensor
NEW
X
®
X
Responder-Only
Some devices cannot control other devices;
these devices only receive INSTEON commands.
Some devices can only link as
responders to devices and scenes.
LED Bulb Dimmer SwitchDimmer Switch
NEW
X
X
Understanding Linking
Grouping Devices Use Cross Linking
You may want to group together two
devices, for example, in a virtual-three way
conguration. For INSTEON, this is called
Cross Linking.
To Cross Link, simply turn on the devices and
perform the linking process twice, once in
each direction.
To group Switch A and B so that they each
control one another and the connected
load, Cross Linking is necessary.
Link Switch A to Switch B and repeat to link
Switch B to Switch A.
NEW
X
NEW
X
A AB BLoad

8
The INSTEON Hub allows you to congure your device, customize its
properties, create scenes and more, all from your smartphone or tablet.
INSTEON Hub

9
You can now control your Dimmer
Module from the INSTEON Hub.
Linking to the INSTEON Hub
1
4
From Rooms, navigate to All Devices.
When prompted, press and hold the
set button on your Dimmer Module
until the device double-beeps.
®
Rooms
All Devices Check-In Favorites
Bathroom Bedroom Hallway
Kitchen Living Room Outside
72º
Add Device
Plug-In Module Wired In
LED Bulb Thermostat
3Select Plug-In Module form the list of
devices.
2Tap the Add button.
All Devices
Back Door Bathroom Bedroom
Font Door Garage Door Garage Light
Motion Sensor Outside Lights
72º
Add

10
When not using a central controller like the INSTEON Hub, INSTEON
devices can be congured and linked manually on a device-to-device
basis. It is strongly advised that you not perform manual linking when
using a central controller. Instead, let your central controller handle the
linking for you.
Manual Linking
