ADC ML-22 Administrator Guide

AD-22 / ML-22
Installation/Operator Manual
ADC Part No. 113279-9
AVERTISSEMENT:
RISQUE D’INCENDIE OU D’EXPLOSION
Le non-respect des avertissements de
sécurité pourrait entraîner des blessures
graves, la mort ou des dommages
matériels.
–N’entreposer pas et n’utilisez pas
d’essence ni d’autres vapeurs ou liquides
inflammables dans le voisinage de cet
appareil ou de tout autre appareil.
–QUE FAIRE SI VOUS SENTEZ UNE
ODEUR DE GAZ
●●
●●
●Ne tentez pas d’allumer d’appareil.
●●
●●
●Ne touchez à aucun interrupteur. Ne
vous servez pas des téléphones se
trouvant dans le bâtiment où vous
vous trouvez.
●●
●●
●Évacuez la pièce, le bâtiment ou la zone.
●●
●●
●Appelez immédiatement votre
fournisseur de gaz depuis un voisin.
Suivez les instructions du fournisseur.
●●
●●
●Si vous ne pouvez rejoindre le
fournisseur de gaz, appelez le service
des incendies.
– L’installation et l’entretien doivent être
assurés par un installateur ou un service
d’entretien qualifié ou par le fournisseur
de gaz.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death or
property damage.
– Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
– WHAT TO DO IF YOU SMELL GAS
●●
●●
●Do not try to light any appliances.
●●
●●
●Do not touch any electrical switch;
do not use any phone in your
building.
●●
●●
●Clear the room, building or area of
all occupants.
●●
●●
●Immediately call your gas supplier
from a neighbor’s phone. Follow
the gas supplier’s instructions.
●●
●●
●If you cannot reach your gas
supplier, call the fire department.
– Installation and service must be
performed by a qualified installer, service
agency or the gas supplier.
!!
!!
!!!
!!
!
American Dryer Corporation
88 Currant Road, Fall River MA 02720-4781 USA
Telephone: [phone] / Fax: [phone]
e-mail: [email protected] / www.adclaundry.com

2American Dryer Corp. 113279-9
We have tried to make this manual as complete as possible and hope you will find it useful. The manufacturer
reserves the right to make changes from time to time, without notice or obligation, in prices, specifications, colors, and
material, and to change or discontinue models. The illustrations included in this manual may not depict your particular
dryer exactly.
IMPORTANT
For your convenience, log the following information:
DATE OF PURCHASE ________________________________________________________MODEL NO. ______________
RESELLER’S NAME __________________________________________________________________________________
SERIAL NUMBER(S) __________________________________________________________________________________
____________________________________________________________________________________________________
____________________________________________________________________________________________________
Replacement parts can be obtained from your reseller or theADC factory. When ordering replacement parts from the
factory, you can FAX your order to ADC at [phone] or telephone your order directly to the ADC Parts
Department at [phone]. Please specify the dryer model number and serial number in addition to the
description and part number, so that your order is processed accurately and promptly.
These instructions are only valid if the following country code is on the appliance… If this code is not present on the
appliance,itisnecessarytorefertothetechnicalinstructionswhichwillprovidethenecessaryinformationconcerning
the modification of the appliance to the condition of use for the country.
In accordance with EN ISO 3166-1, the names of countries shall be represented by the following codes:
GB United Kingdom
IE Ireland
Retain This Manual in a Safe Place for Future Reference
This product embodies advanced concepts in engineering, design, and safety. If this product is properly
maintained, it will provide many years of safe, efficient, and trouble free operation.
Only qualified technicians should service this equipment.
OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation
manual included with the dryer.
The following “FOR YOUR SAFETY CAUTION” must be posted near the dryer in a prominent location.
“IMPORTANT NOTE TO PURCHASER”
Information must be obtained from your local gas supplier on the
instructions to be followed if the user smells gas. These
instructionsmustbepostedinaprominentlocationnearthedryer.
FOR YOUR SAFETY
Do not store or use gasoline
or other flammable vapors
and liquids in the vicinity of
this or any other appliance.
POUR VOTRE SÉCURITÉ
Ne pas entreposer ni utiliser d’essence
ni d’autres vapeurs ou liquides
inflammables à proximité de cet appareil
ou de tout autre appareil.

113279-9www.adclaundry.com 3
Safety Precautions ................................. 4
Specifications ......................................... 6
Installation Procedures .......................... 8
Location Requirements............................................. 8
Unpacking / Setting Up ............................................. 8
Dryer Enclosure Requirements................................. 8
Fresh Air Supply Requirements................................ 9
Exhaust Requirements.............................................. 9
Electrical Information ...............................................11
Gas Information....................................................... 13
Converting from One Family of Gas to Another ..... 14
Preparation for Operation / Start-Up....................... 16
Preoperational Test ................................................. 17
Preoperational Instructions ..................................... 17
Shutdown Instructions............................................. 18
Service / Parts Information .................. 18
Service..................................................................... 18
Parts........................................................................ 18
Warranty Information ........................... 18
Routine Maintenance ............................ 19
Data Label Information ......................... 20
IMPORTANT
You must disconnect and lockout the electric
supply and the gas supply or the steam supply
before any covers or guards are removed from the
machine to allow access for cleaning, adjusting,
installation, or testing of any equipment per OSHA
standards.
Please observe all safety precautions displayed
ontheequipment and/orspecifiedintheinstallation
manual included with the dryer.
Before installation, check that the local distribution
conditions, nature of gas and pressure, and
adjustment of the appliances are compatible.
CAUTION
Dryer(s) should never be left unattended while in
operation.
When discarding or storing your old clothes
dryer, remove the door.
Lorsque vous entreposez ou mettez votre
sécheuse au rebut, enlevez-en la porte.
Caution:Labelall wirespriortodisconnectionwhen
servicing controls. Wiring errors can cause
improper operation.
Attention: Au moment de l’entretien des
commandes, étiquetez tous les fils avant de les
débrancher. Des erreurs de câblage peuvent
entraîner un fonctionnement inadéquat.
FOR YOUR SAFETY
Do not dry mop heads in the dryer. Do not use
dryer in the presence of dry cleaning fumes.
The dryers must not be installed or stored in an
area where it will be exposed to water and/or
weather.
The wiring diagram for the dryer is located behind
the control panel.
Table of Contents __________________
WARNING
Children should not be allowed to play on or
near the dryer(s). Children should be
supervised if near dryer(s) in operation.
Under no circumstances should the dryer
door switch(es), lint door/drawer switch(es),
or heat safety circuit(s) ever be disabled.
DO NOT MODIFY THIS APPLIANCE.
The dryer must never be operated with any
of the back guards, outer tops, or service
panelsremoved. Personalinjuryorfire could
result.
The dryer must never be operated without
the lint filter/screen in place, even if an
external lint collection system is used.
If the hi-limit switch trips, a service call is
required to investigate the reason and
resolve the issue.
List of Acronyms __________________________
HVAC Heating, Ventilating, and Air-Conditioning
in WC Inches of Water Column
L.C.D. Liquid Crystal Display
L.E.D. Light Emitting Diode
OSHA Occupational Safety and Health Administration
R.M.A. Return Material Authorization
UL Underwriters Laboratory
In the State of Massachusetts, the following
installation instructions apply:
■Installations and repairs must be performed by a
qualified or licensed contractor, plumber, or gas fitter
qualified or licensed by the State of Massachusetts.
■Acceptable Shut-off Devices: Gas Cocks and Ball
Valves installed for use shall be listed.
■Aflexiblegasconnector, when used, must not exceed
4 feet (121.9 cm).

4American Dryer Corp. 113279-9
Safety Precautions ___________________
!
WARNING
For your safety, the information in this manual must
be followed to minimize the risk of fire or explosion
and to prevent property damage, personal injury, or
loss of life.
The dryer must never be operated with any of the
back guards, outer tops, or service panels removed.
Personal injury or fire could result.
Failure to properly install, maintain, and/or operate
dryer according to this manual and operator’s
manuals included with dryer may result in conditions,
which can cause serious injury, death and/or property
damage.
Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
Do not spray aerosols in the vicinity of this appliance while it
is in operation.
Purchaser and user should consult the local gas supplier for
proper instructions to be followed in the event the user smells
gas. The instructions should be posted in a prominent
location.
What To Do If You Smell Gas:
•Do not try to light any appliance.
•Do not touch any electrical switch.
•Do not use any phone in your building.
•Clear the room, building, or area of all occupants.
•Immediately call your gas supplier from a neighbor’s
phone. Follow the gas supplier’s instructions.
•If you cannot reach your gas supplier, call the fire
department.
Installation and service must be performed by a qualified
installer, service agency, or gas supplier.
Dryers must be exhausted to the outdoors.
Although the manufacturer produces a very versatile dryer,
there are some articles that, due to fabric composition or
cleaning method, should not be dried in it.
!
WARNING
Dry only water washed fabrics. Do not dry articles
spotted or washed in dry cleaning solvents,
combustible detergents, industrial chemicals, or “all
purpose” cleaner. Explosion could result.
Do not dry rags or articles coated or contaminated
with gasoline, kerosene, oil, paint, or wax. Explosion
could result.
Items that have been spotted or soaked with
vegetable or cooking oil constitute a fire hazard and
should not be placed in a tumble dryer.
Do not dry mop heads. Contamination by wax or
flammable solvents will create a fire hazard.
!
WARNING
Do not use heat for drying articles that contain plastic,
foam, sponge rubber, or similarly textured rubber
materials. Drying in a heated tumbler may damage
plastics or rubber and also may be a fire hazard.
The possible presence of residual quantities of aggressive
or decomposed chemicals in the load may produce damage
to the machine and harmful fumes.
Aprogram should be established for the inspection and
cleaning of lint in the burner area, exhaust ductwork, and area
around the back of the dryer. The frequency of inspection
and cleaning can best be determined from experience at each
location.
!
WARNING
The collection of lint in the burner area and exhaust
ductwork can create a potential fire hazard.
For personal safety, the dryer must be electrically grounded
in accordance with local codes and/or National Electric Code
ANSI/NFPA70, or in Canada, Canadian Electric Code CSA
C22.1.
NOTE: Failure to electrically ground the dryer properly will
void the warranty.
!
WARNING
Personal injury or fire could result should the dryer
door switch, lint door/drawer, or heat safety circuit
ever be disabled.
Remove articles from the dryer as soon as the drying cycle
has been completed.
!
WARNING
Articles left in the dryer after the drying and cooling
cycles have been completed can create a fire hazard.
For safety, proper operation, and optimum performance, the
dryer must not be operated with a load less than 66% of its
rated capacity.
!
WARNING
You must disconnect and lockout the electric supply
and the gas supply or the steam supply before any
covers or guards are removed from the machine to
allow access for cleaning, adjusting, installation, or
testing of any equipment per OSHA standards.
IMPORTANT: The dryer must be installed in a location/
environment, which the ambient temperature remains
between 40° F (4.44° C) and 130° F (54.44° C).

113279-9www.adclaundry.com 5
NOTES _____________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
____________________________________________________________
The operation of this appliance may affect the operation of
other types of gas appliances, which take their air for safe
combustion from the same room. If in doubt, consult the
appliance manufacturer(s).
Use this dryer only for its intended purpose, drying fabrics.
The “Cool Down” Cycle of tumble dryers should be used to
reduce the temperature of the items. They should not be
removed from the tumble dryer or piled or stacked while hot.
Fabric softeners or similar products should not be used in a
tumble dryer to eliminate the effects of the static electricity,
unless this practice is specifically recommended by the
manufacturer of the fabric softener or product.
!
WARNING
To reduce the risk of personal injury, install lockable
doors to prevent public access to the rear of the
dryers.
Exhaust duct outlet should be checked periodically for
blockages, and if any found, removed.
IMPORTANT: Ameans of restraint must be used to
prevent straining of the gas supply when the appliance is
moved.
An external means of power removal (disconnect device)
must be provided by the installer.
CE ONLY
IMPORTANT: This appliance must only be installed and
operated in the country of destination indicated on the
dryer’s data plate. If the appliance is to be installed and
operated in a country other than the one indicated on the
data plate, a data plate amendment must be obtained from
American Dryer Corporation.
IEC335 applies.
!
WARNING
This appliance must only operate with the gas type
indicated on the dryer’s data plate. If the appliance
is converted (gas type is changed), a data plate
amendment must be obtained from American Dryer
Corporation.
This appliance may cause spillage of products of
combustion from an open-flue appliance fitted in the
same room, and that such an appliance shall be
tested for clearance of products with the appliance
in operation and all windows and doors closed.
Disconnect power before resetting the hi-limit. The
hi-limit is located on the top front, left corner of the
lint box. Press and release and the hi-limit will reset.

6American Dryer Corp. 113279-9
MAXIMUM CAPACITY (DRYWEIGHT) 22 lb 9.98 kg
TUMBLER DIAMETER 25-3/4” 65.41 cm
TUMBLER DEPTH 24-3/4” 62.87 cm
TUMBLER VOLUME 7-1/2 cu ft 212.38 L
TUMBLER/DRIVE MOTOR 1/3 hp 0.25 kW
BLOWER/FAN MOTOR BLOWER DRIVEN BY TUMBLER MOTOR
DOOR OPENING (DIAMETER) 21-1/2” 54.6 cm
DOOR SILL HEIGHT 12-1/2” 31.75 cm
WATER CONNECTION N / A
DRYERS PER 20’/40’ CONTAINER 28 / 60
DRYERS PER 48’/53’ TRUCK 96 / 108
VOLTAGE AVAILABLE 120V 1ø 2w 60 Hz
APPROXIMATE NET WEIGHT 151 lb 68.49 kg
APPROXIMATE SHIPPING WEIGHT 171 lb 77.56 kg
AIRFLOW 220 cfm 6.23 cmm
HEAT INPUT 26,000 Btu/hr 6,550 kcal/hr
EXHAUST CONNECTION (DIAMETER) 4” 10.16 cm
COMPRESSED AIR CONNECTION N / A
COMPRESSED AIR VOLUME N / A
INLET PIPE CONNECTION 3/8” M.N.P.T.
VOLTAGE AVAILABLE 220-240V 1ø 50/60 Hz
APPROXIMATE NET WEIGHT 151 lb 68.49 kg
APPROXIMATE SHIPPING WEIGHT 171 lb 77.56 kg
AIRFLOW 60 Hz 220 cfm 6.23 cmm
50 Hz 183 cfm 5.19 cmm
EXHAUST CONNECTION (DIAMETER) 4” 10.16 cm
COMPRESSED AIR CONNECTION
N / A
COMPRESSED AIR VOLUME
N / A
OVEN SIZE
kW Btu/hr kcal/hr
4.1 13,843 3,488
5.0 17,065 4,300
5.4 18,430 4,644
VOLTAGE AVAILABLE
N / A
APPROXIMATE NET WEIGHT
APPROXIMATE SHIPPING WEIGHT
AIRFLOW
STEAM CONSUMPTION
OPERATING STEAM PRESSURE
EXHAUST CONNECTION (DIAMETER)
COMPRESSED AIR CONNECTION
COMPRESSED AIR VOLUME
BOILER HORSEPOWER (NORMAL LOAD)
SUPPLYCONNECTION
RETURN CONNECTION
Specifications _____________________________________________________________________
NOTE: The manufacturer reserves the right to make changes in specifications at any time without notice or obligation.
GASELECTRICSTEAM
Shaded areas are stated in metric equivalents7/8/14

113279-9www.adclaundry.com 7
Specifications _____________________________________________________________________
NOTE: The manufacturer reserves the right to make changes in specifications at any time without notice or obligation.

8American Dryer Corp. 113279-9
Installation Procedures ______________
Installation should be performed by competent professional
in accordance with local, state, and country codes. In the
absence of these codes, the installation must conform to
applicable American National Standards: National Fuel Gas
CodeANSIZ223.1/NFPA54 andNational ElectricCodeANSI/
NFPA70, or in Canada, the installation must conform to
applicable Canadian Standards: Natural Gas and Propane
Installation Code CSA B149.1 and Canadian Electric Code
CSA C22.1.
Location Requirements ______________
Before installing the dryer, ensure the location conforms to
local codes and ordinances. In the absence of such codes
or ordinances the location must conform with National Fuel
Gas Code ANSI Z223.1/NFPA54, or in Canada, the
installation must conform to applicable Canadian Standards:
Natural Gas and Propane Installation Code CSA B149.1.
The dryer must be installed on a sound level floor capable of
supporting its weight. Carpeting must be removed from the
floor area that the dryer is to rest on.
The dryer must not be installed or stored in an area where it
will be exposed to water and/or weather.
Dryers installed in residential garages must be elevated
18-inches (45.72 cm) above the floor.
Provisions for adequate air supply must be provided as noted
in this manual (refer to Fresh Air Supply Requirements
section).
Clearance provisions must be made from combustible
construction as noted in this manual (refer to Dryer Enclosure
Requirements section).
Provisions must be made for adequate clearances for
servicing and for operation as noted in this manual (refer to
Dryer Enclosure Requirements section).
The dryer must be installed with a proper exhaust duct
connection to the outside as noted in this manual (refer to
Exhaust Requirements section).
The dryer must be located in an area where correct exhaust
venting can be achieved as noted in this manual (refer to
Exhaust Requirements section).
IMPORTANT: The dryer should be located where a
minimum amount of exhaust ducting will be necessary.
The dryer must be installed with adequate clearance for air
openings into the combustion chamber.
CAUTION: This dryer produces combustible lint and
must be exhausted to the outdoors. Every 6 months,
inspect the exhaust ducting and remove any lint
buildup.
IMPORTANT: The dryer must be installed in a location/
environment, which the ambient temperature remains
between 40° F (4.44° C) and 130° F (54.44° C).
AThe requirement to allow the door to open completely is
28-inches (71.12 cm).
BA minimum overhead clearance of 6-inches (15.24 cm)
is required.
CDryer should be positioned a minimum of 12-inches
(30.48cm) awayfrom thenearest obstruction. 24-inches
(60.96 cm) is recommended for ease of installation,
maintenance, and service.
D1/16” (1.5875 mm) minimum is required.
EFlooringshould be level and belowdryer cabinetfor ease
of removing panels during maintenance.
FDryers may be positioned sidewall to sidewall, however
a 1/16” (1.5875 mm) minimum allowance must be made
for the opening and closing of the control door, along
with the removal of panels during maintenance.
Unpacking / Setting Up ________________
Remove protective shipping material (i.e., plastic wrap and
optional shipping box) from the dryer.
IMPORTANT: Dryer must be transported and handled in an
upright position at all times.
Thedryer can bemoved toitsfinal locationwhile stillattached
to the skid or with the skid removed.
With the skid removed, use caution and assure all four
leveling legs are fully retracted, if the dryer is to be slid into
its final position.
Leveling Dryer
The dryer is equipped with four leveling legs, one at each
corner of the base. For optimum performance the dryer
should be level front-to-back and side-to-side.
Dryer Enclosure Requirements _______
Commercial Type II
Bulkheads and partitions should be made of noncombustible
material.
NOTE: Allowances must be made for opening the control
door.

113279-9www.adclaundry.com 9
Domestic Type I
EXAMPLE: Two unrestricted openings measuring 6-inches
by 10-inches (15.24 cm by 25.4 cm) are acceptable.
If a closet door is installed: unobstructed air openings are
required. The air openings shall be located 3-inches
(7.62cm) fromthe loweropening(above floorlevel) andupper
opening(below ceiling). Thetotalfree areaof theairopenings
in the door shall not be less than 130 inch2(838.708 cm2).
Louvered doors with equivalent air openings are acceptable.
No other fuel-burning appliance shall be installed in the same
closet as the dryer.
Fresh Air Supply Requirements ______
This appliance may only be installed in a room that meets
the appropriate ventilation requirements specified in the
national installation regulations.
When the dryer is operating, it draws in room air, heats it,
passes this air through the tumbler, and exhausts it out of
the building. Therefore, the room air must be continually
replenished from the outdoors. If the make-up air is
inadequate,drying timeand dryingefficiency willbe adversely
affected. Ignition problems may result, as well as premature
motor failure from overheating. The dryer must be installed
with provisions for adequate combustion and make-up air
supply.
Air supply (make-up air) must be given careful consideration
to ensure proper performance of each dryer. Fresh air
ventilation openings shall not be blocked and/or sealed. As
a general rule, an unrestricted air entrance from the outdoors
of 26 inch2(168 cm2) for each dryer. (Based on 1 inch2
[6.5 cm2] per 1,000 Btu [252 kcal].)
It is not necessary to have a separate make-up air opening
for each dryer. Common make-up air openings are
acceptable. However, they must be set up in such a manner
that the make-up air is distributed equally to all the dryers.
To compensate for the use of registers or louvers used over
the openings, this area must be increased by approximately
33%. Make-up air openings should not be located in an area
directly near where exhaust vents exit the building.
Allowances must be made for remote or constricting
passageways or where dryers are located at high altitudes
or predominantly low pressure areas.
NOTE: Component failure due to dry cleaning solvent
fumes will void the warranty.
EXAMPLE: For a bank of four dryers, two unrestricted
openingsmeasuring 10-inchesby 6-inches(25.4 cmby 15.24
cm) are acceptable.
IMPORTANT: Make-up air must be free of dry cleaning
solvent fumes. Make-up air that is contaminated by dry
cleaning solvent fumes will result in irreparable damage to
the motors and other dryer components.
Exhaust Requirements _______________
Exhaust ductwork should be designed and installed by a
qualified professional. Improperly sized ductwork will create
excessive back pressure, which results in slow drying,
increased use of energy, and shutdown of the burner by the
burnerhi-limitsor blowerhousing hi-limitprotector thermostat.
The dryer must be installed with a proper exhaust duct
connection to the outside.
The dryer shall not be exhausted into any gas vent, chimney,
wall, ceiling or concealed space of a building.
The design of the flue system shall be such that any
condensate formed when operating the appliance from cold
shall either be retained and subsequently re-evaporated or
discharged.
CAUTION: This dryer produces combustible lint and
must be exhausted to the outdoors.
Improperly sized or installed exhaust ductwork can
create a potential fire hazard.
The ductwork should be laid out in such a way that the
ductwork travels as directly as possible to the outdoors with
as few turns as possible. There should be a minimum
6-inch (15.24 cm) clearance between the back guard and
the first bend in the ductwork for ease of servicing. Single or
independent dryer venting is recommended. It is suggested
thatthe useof 90°turns beavoided; use30° and/or45° bends
instead. The radius of the elbows should preferably be
1-1/2 times the diameter of the duct. All ductwork should be
smooth inside with no projections from sheet metal screws
or other obstructions, which will collect lint. When adding
ducts, overlap the duct being connected. All ductwork joints
must be taped to prevent moisture and lint from escaping
into the building. Back draft dampers must be installed in all
commonly ducted systems. Inspection doors should be
installed at strategic points in the exhaust ductwork for
periodic inspection and cleaning of lint from the ductwork.
A = 6-inches (15.24 cm) B = 10-inches (25.4 cm)
A = 10-inches (25.4 cm)
B = 6-inches (15.24 cm)

10 American Dryer Corp. 113279-9
NOTE 1 Opening from combustible materials must be 2-inches (5.08 cm)
larger than the duct (all the way around). The duct must be centered
within this opening.
NOTE 2 Distance should be 2 times the diameter of the duct to the nearest
obstruction.
Multiple Dryer (Common) Venting
IMPORTANT: For extended ductwork runs, the cross-
sectional area of the ductwork can only be increased to an
extent. When the ductwork approaches the maximum
limits as noted in this manual, a professional HVAC firm
should be consulted for proper venting information.
If it is not feasible to provide separate exhaust ducts for each
dryer, ducts from individual dryers may be channeled into a
“common main duct.” The individual ducts should enter the
bottom or side of the main duct at an angle not more than
45º in the direction of airflow. The main duct should be
tapered, with the diameter increasing before each individual
duct is added.
IMPORTANT: Exhaust back pressure measured by a
manometer/magnehelic in the exhaust duct must be no
less than 0 and must not exceed 0.6 in WC (1.5 mb).
NOTE: It is recommended that exhaust or booster fans not
be used in the exhaust ductwork system except where
necessary to maintain exhaust back pressure (in the
exhaust duct) between zero and 0.6 in WC. Where
employed, booster fans must not activate the dryer airflow
proving switch (sail switch) when the dryer is not in
operation.
When the exhaust ductwork passes through a wall, ceiling,
or roof made of combustible materials, the opening must
be 2-inches (5.08 cm) larger than the duct (all the way
around). The duct must be centered within this opening.
As per the National Fuel Gas Code, “Exhaust ducts for
type 2 clothes dryers shall be constructed of sheet metal or
other noncombustible material. Such ducts shall be
equivalent in strength and corrosion resistance to ducts
made of galvanized sheet steel not less than 26 gauge
(0.0195-inches [0.50 mm]) thick.”
The ductwork for this appliance must be suitable for the
appliance category in accordance with national installation
regulations of the country of destination.
Outside Ductwork Protection
To protect the outside end of the horizontal ductwork from
the weather, a 90° elbow bent downward should be installed
where the exhaust exits the building. If the ductwork travels
vertically up through the roof, it should be protected from the
weather by using a 180° turn to point the opening downward.
In either case, allow at least twice the diameter of the duct
between the duct opening and the nearest obstruction (refer
to the diagram).
IMPORTANT: Do not use screens, louvers, or caps on the
outside opening of the exhaust ductwork.
Single Dryer Venting
IMPORTANT: For extended ductwork runs, the cross-
sectional area of the ductwork can only be increased to an
extent. When the ductwork approaches the maximum
limits as noted in this manual, a professional HVAC firm
should be consulted for proper venting information.
Horizontal Venting
When horizontal dryer venting is used, the length of the
ductwork from the dryer to the outside exhaust outlet, must
not exceed 20 feet (6.10 meters). The diameter of this
ductwork must be 4-inches (10.2 cm). Including tumbler/
dryerelbow connectionsor elbowsused foroutsideprotection
from the weather, no more than 1 elbow should be used in
the exhaust duct run. If more than 1 elbow is used, the cross-
sectional area of the ductwork must be increased.
Vertical Venting
Whenvertical dryerventing isused, thelength ofthe ductwork
from the dryer to the outside exhaust outlet, must not exceed
12 feet (3.66 meters). The diameter of this ductwork must
be 4-inches (10.2 cm). Including tumbler/dryer elbow
connections or elbows used for outside protection from the
weather, nomore than3 elbowsshouldbe usedin theexhaust
duct run. If more than 3 elbows are used, the cross-sectional
area of the ductwork must be increased.
A=20 feet (6.10 meters)
B = 4” (10.2 cm) C = 12 feet (3.66 meters)
D = 4” (10.2 cm)

113279-9www.adclaundry.com 11
TERM LINE VOLTAGE
50 Hz 60 Hz
HIGH 260
226 283 249
MED 239
208 260 230
LOW 217
189 236 208
IMPORTANT: No more than four dryers should be
connected to one main common duct.
The illustration below shows the minimum cross-sectional
areafor multipledryer roundor squareventing. These figures
must be increased if the main duct run from the last dryer to
whereit exhauststo theoutdoors islonger than12 feet(3.656
meters) or has more than one elbow in it.
NOTE 1 Opening from combustible materials must be 2-inches (5.08 cm)
larger than the duct (all the way around). The duct must be centered
within this opening.
NOTE 2 Distance should be 2 times the diameter of the duct to the nearest
obstruction.
Multiple Dryer Venting with 4-Inch (10.2 cm) Diameter
220 cfm (6.23 cmm) Exhaust Connections at Common Duct
A = 4-inch (10.2 cm)
B =12 feet (3.656 meters)
NUMBER OF DRYERS 4 3 2 1
MINIMUM CROSS-
SECTIONAL AREA SQ IN 80 80 54 30
SQ CM 516.1 516.1 348.4 193.55
MINIMUM ROUND
DUCT DIAMETER IN 10 10 8 6
CM 25.4 25.4 20.32 15.24
Electrical Information ________________
Electrical Requirements
Allelectrical connectionsmust bemade byaproperly licensed
andcompetent electrician. This isto ensurethat theelectrical
installation is adequate and conforms to local, state, and
national regulations or codes of the country of destination.
In the absence of such codes, all electrical connections,
materials, and workmanship must conform to the applicable
requirements of National Electric Code ANSI/NFPA70, or in
Canada, Canadian Electric Code CSA C22.1.
For personal safety, the dryer must be electrically grounded
in accordance with local codes and/or National Electric Code
ANSI/NFPA70, or in Canada, Canadian Electric Code CSA
C22.1.
IMPORTANT: Failure to comply with these codes or
ordinances, and/or the requirements stipulated in this
manual can result in personal injury or component failure.
NOTE: Component failure due to improper installation will
void the warranty.
Each dryer should be connected to an independently
protected branch circuit. The dryer must be connected with
copper wire only. Do not use aluminum wire, which could
cause a fire hazard. The copper conductor wire/cable must
be of proper ampacity and insulation in accordance with
electric codes for making all service connections.
NOTE: The use of aluminum wire will void the warranty.
An individual ground circuit must be provided to each
dryer, do not daisy chain.
Component failure due to improper voltage application will
void the warranty.
The manufacturer reserves the right to make changes in
specifications at any time without notice or obligation.
IMPORTANT: Aseparate protected circuit must be
provided to each dryer.
The dryer must be connected to the electric supply shown
on the data label. In the case of 208 VAC or 240 VAC, the
supply voltage must match the electric service
specifications of the data label exactly.
The wire size must be properly sized to handle the related
current.
WARNING
208 VAC and 240 VAC are not the same. Any damage
done to dryer components due to improper voltage
connections will automatically void the warranty.
WARNING (Gas Models Only)
Dryers built for use with a voltage between 200 and
240 must verify the input voltage during installation.
If the nominal voltage is outside of the medium
tolerances shown on the diagram below, adjust the
autotransformer, located near the burner assembly.
To adjust the autotransformer wiring, place the red
wire on the appropriate tap (HIGH, MED, LOW) of the
autotransformer. For additional wiring details, refer
to the electrical diagram located on the inside of the
control panel.

12 American Dryer Corp. 113279-9
Check your National and local codes for breaker and wire sizes 11/24/14
Electric Models Only
Allelectrically heateddryers mustbe connectedto theelectric
serviceshown onthe dryer’s data label. Theconnecting wires
must be properly sized to handle the rated current.
Electrical Service Specifications
Gas Models Only
Check your National and local codes for breaker and wire sizes 11/30/20
ELECTRICAL SERVICE SPECIFICATIONS (PER POCKET)
IMPORTANT:
NOTES:A.
B.
C.
208 VAC AND 230/240 VAC ARE NOT THE SAME. When ordering,
specify exact voltage.
When fuses are used theymust be dual element, time delay, current
limiting, class RK1 or RK5 ONLY. Calculate/determine correct fuse
value, by applying either local and/or National Electrical Codes to
listed appliance amp draw data.
Circuit breakers are thermal-magnetic (industrial) motor curve type
ONLY. For others, calculate/verify correct breaker size according to
appliance amp draw rating and type of breaker used.
Circuit breakers for 3-phase (3ø) dryers must be 3-pole type.
SERVICE
VOLTAGE PHASE WIRE SERVICE
APPROX.
AMP DRAW CIRCUIT
BREAKER
60 Hz 50 Hz
120 1ø 2 11.5 —15
208 1ø 2 8 —15
220 1ø 2 7 —15
230 1ø 2 7 —15
240 1ø 2 6 —15
ELECTRICAL SERVICE SPECIFICATIONS (PER POCKET)
IMPORTANT:
NOTES: A.
B.
C.
208 VAC AND 230/240 VAC ARE NOT THE SAME. When ordering,
specify exact voltage.
When fuses are used they must be dual element, time delay, current
limiting, class RK1 or RK5 ONLY. Calculate/determine correct fuse
value, by applying either local and/or National Electrical Codes to
listed appliance amp draw data.
Circuit breakers are thermal-magnetic (industrial) type ONLY. For
others, calculate/verify correct breaker size according to appliance
amp draw rating and type of breaker used.
Circuit breakers for 3-phase (3ø) dryers must be 3-pole type.
SERVICE
VOLTAGE PHASE WIRE SERVICE OVEN kW
APPROX.
AMP DRAW CIRCUIT
BREAKER
60 Hz 50 Hz
SINGLE PHASE HEAT — SINGLE PHASE MOTOR
208 1ø 2 4.1 22 —30
220 1ø 2 4.5 22 24 30
230 1ø 2 5 23 26 30
240 1ø 2 5.4 24 27 30
THREE PHASE HEAT — SINGLE PHASE MOTOR
208 3ø 3 4.1 15 —20
220 3ø 3 4.5 15 16 20
230 3ø 3 5 16 —20
240 3ø 3 5.4 16 —20
230 3ø 3 5 —17 30
240 3ø 3 5.4 —17 30
380 3ø 4 4.5 —11 15
400 3ø 4 5 —11 15
416 3ø 4 5.4 —11 15
Grounding
Aground (earth) connection must be provided and installed
in accordance with local, state, and national regulations or
codes of the country of destination. In the absence of these
codes, grounding must conform to applicable requirements
of National Electric Code ANSI/NFPA70, or in Canada, the
installation must conform to applicable Canada Standards:
Canadian Electric Code CSAC22.1. The ground connection
maybe to aproven earthground atthe locationservice panel.
For added personal safety, when possible, it is suggested
that a separate ground wire (size per local codes) be
connected from the ground connection of the dryer to a
grounded cold water pipe. Do not ground to a gas pipe or
hot water pipe. The grounded cold water pipe must have
metal-to-metal connectionall theway tothe electrical ground.
If there are any nonmetallic interruptions, such as, a meter,
pump, plastic, rubber, or other insulating connectors, they
must be jumped out with a wire (size per local codes) and
securely clamped to bare metal at both ends.
IMPORTANT: For personal safety and proper operation,
the dryer must be grounded.
Provisions are made for ground connection in each dryer at
the electrical service connection area.
!
WARNING
Electrical Grounding Instructions – This dryer is
equipped with a 3-prong (grounding) plug for your
protection against shock hazard and should be
plugged directly into a properly grounded 3-prong
receptacle. Do not cut or remove the grounding
prong from this plug.
Electrical Connections
Where the clothes dryer or combination washer-dryer
installation instructions indicate that the appliance is not
restricted from being connected by means of a power-supply
cord kit, the instructions shall indicate that only a power-
supply cord kit rated 300V min, 30 A, and marked for use
withclothes dryersshall beused. Thespecified ampererating
for the cord shall be 30, 40, or 50 Aas applicable. The
instructions shall also specify:
•The number of conductors (3 or 4)
•The type of terminations (tinned leads, closed-loop
terminals, open-end spade lugs with upturned ends, or
the like) that the cord kit is to employ
•That only a 4-conductor cord shall be used when the
appliance is installed in a location where grounding
through the neutral conductor is prohibited. Grounding
through the neutral conductor is prohibited for new
branch-circuit installations; mobile homes; recreational
vehicles, and areas where local codes prohibit
grounding through the neutral conductor.
Awiring diagram is located behind the control panel for
connection data.
If local codes permit, power to the dryer can be made by the
use of a flexible UL listed power cord/pigtail (wire size must
conform to rating of dryer), or the dryer can be hard wired
directly to the service breaker panel. In both cases, a strain
relief must be installed where the wiring enters the dryer.

113279-9www.adclaundry.com 13
For CE Models Only
The means for disconnection from the supply must be
incorporatedinto wiring havinga minimumcontact separation
of 3.0 mm in all poles.
Single-Phase (1ø)
Wiring Connections / Hookup
Theelectrical inputconnections aremade intotherear service
box located at the upper right area of the dryer. To gain
access, the service box cover must be removed.
Input connection wiring must be sized properly to handle the
dryer’s currentdraw. This informationis printedon thedryer’s
data label.
IMPORTANT: Astrain relief must be used where the input
wiring enters the oven assembly.
Electrically Heated Models Only
The electrical input connections are made at the rear service
box located at the right upper section of the dryer. To gain
access, remove rear service cover.
The only electrical input connections to the dryer are the
3-phase(3ø) powerleads (L1,L2, L3,and sometimesneutral)
and ground. Single-phase (1ø) power for the control circuit
and for any single-phase (1ø) motors (if present) is done
internally to the dryer by the factory at the oven contactor.
No single-phase (1ø) input connection is required on a
3-phase (3ø) dryer.
The neutral will only be used on 4-wire service. This is typical
for 380-416V, 50 Hz.
CAUTION: The dryer must be grounded. Aground
lug has been provided for this purpose.
Input connection wiring must be sized properly to handle the
dryer’s currentdraw. This informationis printedon thedryer’s
data label.
Gas Information ______________________
It is your responsibility to have all plumbing connections,
materials, and workmanship conform to local and state
regulations or codes of the country of destination. In the
absence of such codes, all plumbing connections, materials,
and workmanship must conform to the applicable local
requirements. In the USA this is National Fuel Gas Code
ANSI Z223.1/NFPA54, or in Canada, Natural Gas and
Propane Installation Code CSA B149.1.
InAustralia, the fuel gas code isAS/NZS5601, local authority,
gas, electricity, and any other relevant statutory regulations.
It is important that gas pressure regulators meet applicable
pressure requirements, and that gas meters be rated for the
total amount of all the appliance Btu being supplied.
IMPORTANT: Failure to comply with these codes or
ordinances, and/or the requirements stipulated in this
manual, can result in personal injury and improper
operation of the dryer.
For ease of service, the individual gas supply line of each
dryer must have its own manual shutoff valve.
IMPORTANT: The dryer and its individual shutoff valve
must be disconnected from the gas supply piping system
during any pressure testing of that system at test
pressures in excess of 1/2 psig (3.5 kPa) for non-CE
dryers or 50 mb for CE dryers.
Failure to isolate or disconnect the dryer from supply as
noted can cause irreparable damage to the gas valve,
voiding the warranty.
NOTE: The dryer must be isolated from the gas supply
piping system by closing its individual manual shutoff valve
during any pressure test of the gas supply system at test
pressures equal to or less than 1/2 psig (3.5 kPa) for non-
CE dryers or 50 mb for CE dryers.
!
WARNING
Fire or explosion could result due to failure of
isolating or disconnecting the gas supply as noted.
NOTE: Undersized gas piping will result in ignition
problems, slow drying, increased use of energy, and can
create a safety hazard.
Thedryer mustbe connectedto thetype ofheat/gas indicated
on the data label and pressure must be confirmed. If this
information does not agree with the type of gas available, do
not operate the dryer. Contact the reseller who sold the dryer
or contact the manufacturer.
The input ratings shown on the data label are for elevations
up to 2,000 feet (610 meters), unless elevation requirements
of over 2,000 feet (610 meters) were specified at the time
the dryer order was placed with the factory. The adjustment
or conversion of dryers in the field for elevations over 2,000
feet (610 meters) is made by changing each burner orifice.
If this conversion is necessary, contact the reseller who sold
the dryer or contact the manufacturer.
IMPORTANT: If connection to this appliance is made with
a flexible hose, it must be suitable for the appliance
category in accordance with national installation
regulations of the country of destination, and if in doubt the
installer must contact the supplier. The manufacturer of
this appliance does not recommend the use of flexible gas
supply line/hose. An external gas supply shutoff must be
provided.
!
WARNING (CE Dryers Only)
This appliance must only be operated with the gas
type indicated on the dryer’s data plate. If the
appliance is converted (gas type changed), a data
plate amendment must be obtained from American
Dryer Corporation for CE approved units.
CE and Australian Dryers
Thereis anN.P.T.to B.S.P.T.adaptor includedwith eachdryer,
which must be installed to the gas inlet. The adaptor is
shipped in the tumbler.
IMPORTANT: Pipe joint compounds that resist the action
of natural, propane, and butane gases must be used.

14 American Dryer Corp. 113279 -9
Gas Specifications for Non-CE and Non-AGA Approved Dryers**
Gas
Type
Nominal
Heating Value
Supply
Pressure
Gross
Heat Input Orifice Size Orifice
(Injector)
Quantity
Burner
Pressure
Btu/ft
3
in WC Btu/hr kW DMS mm in WC
Natural 1,000 7.0-13.0 26,000 7.6 40 2.489 13.0
*Propane 2,500 11.0-13.0 26,000 7.6 53 1.511 110.5
Piping / Connections
Inlet connection is 3/8” N.P.T.
CE and Australian dryer connections will be B.S.P.T., all others
will be N.P.T.
There should be a minimum 6-inch (15.24 cm) clearance
between the back guard and the first bend in the gas piping
for ease of servicing. It is recommended that a gas shutoff
valve be provided to the gas supply line of each dryer for
ease in servicing.
The size of the main gas supply line (header) will vary
depending on the distance this line travels from the gas meter
or, in the case of propane gas, the supply tank, other gas-
operated appliances on the same line, etc. Specific
information regarding supply line size should be determined
by the gas supplier.
Heat Input / Gas Consumption / Orifice (Injector) Data
(For Non-CE [European] and Non-AGA [Australia] Models Only)
Shaded areas are stated in metric equivalents
* Gas valve’s internal regulator disabled.
** Consult factory for elevations over 2,000 feet (610 meters) for correct orifice size.
NOTE: Undersized gas supply piping can create a low or
inconsistent pressure, which will result in erratic operation
of the burner ignition system.
Consistent gas pressure is essential at all gas connections.
It is recommended that a 3/4-inch (19.05 mm) pipe gas loop
be installed in the supply line servicing a bank of dryers. An
in-line pressure regulator must be installed in the gas supply
line (header) if the (natural) gas pressure exceeds 13.0 in
WC (32.34 mb) pressure.
A plugged tap 1/8” N.P.T. minimum, accessible for a pressure
gauge connection, must be installed in the main gas supply
line immediately upstream of the dryers.
IMPORTANT: Pipe joint compounds that resist the action
of natural, propane, and butane gases must be used.
Test all connections for leaks by brushing on a soapy
water solution (liquid detergent works well).
!WARNING
Never test for leaks with a flame!!!
Converting from One Family
of Gas to Another _____________________
!WARNING (CE Dryers)
This appliance must only be operated with the gas
type indicated on the dryer’s data plate. If the
appliance is converted (gas type changed), a data
plate amendment must be obtained from American
Dryer Corporation (dryer’s serial number is required
to purchase a conversion kit).
IMPORTANT: Any burner changes or conversions must be
made by a qualified professional.
The dryers manufactured for Belgium, Luxemburg, Greece,
Estonia, Slovak Republic, Iceland, Malta, Poland and
Cyprus cannot be converted from one family of gas to
another.

113279-9www.adclaundry.com 15
Conversion from Natural Gas
to Propane or Butane Gas
The following conversion allows the dryer to be operated with
either propane, butane, or other liquefied petroleum gases.
The use of gas valve kit (ADC P/N 140414) disables the
internal regulator of the gas valve. Therefore, the gas supply
is ungoverned and an external regulator must be provided at
the source of the supply (example propane tank) or the gas
supply line to the dryer. The type of conversion kit supplied
will depend on the country the dryer is installed in.
Parts Required for Conversion:
Description ADC P/N Qty
Unregulated Gas Conversion Kit** 140414 1
OR
Regulated Propane Gas
Conversion Kit*** 140416 1
Burner Orifice (Injector) *1
Propane Conversion Label 114515 1
*Refer to page 14 for orifice (injector) size.
** Required for unregulated propane or butane only.
*** Required for regulated propane or other liquefied petroleum gases only.
Instructions
Disconnect electrical power to the dryer.
Close all shutoff valves in dryer’s gas supply line.
Open the panel located just below the loading door.
Locatethe gas trainand disconnectthe union,three electrical
plugs, and the gas train mounting screws from the burner.
Carefully slide the gas train out of the gas train enclosure.
(The carbon ignitor located at the far end of the gas train is
very fragile.)
Removetwo burnertube mountingscrews andremove burner
tube in order to gain access to the orifice.
Using a 3/8” wrench or socket, remove the existing orifice
and replace it with an orifice from the kit.
IMPORTANT: Use extreme care when removing and
replacing orifice (injector). This orifice (injector) is made of
brass, which is easily damaged.
Reinstall the burner tube onto the burner base.
Use a flat screwdriver to remove the regulator vent cap.
•For unregulated propane gas (most countries): install
blocking pin (ADC P/N 140414).
•For regulated propane gas (some countries): remove
the white plastic regulator adjustment screw (under vent
cap). Remove spring under screw and replace with
spring from kit (ADC P/N 140416). Replace regulator
adjustment screw.
Install the gas train back into the dryer gas train enclosure.
Be sure the tab at the rear of the gas train engages into the
mounting slot.
Connect the union and the three electrical plugs.
Affix Propane Conversion Label (ADC P/N 114515) to the
dryer’s data label.
Complete Propane Kit Conversion Confirmation Label (ADC
P/N 114083) and affix this label as close as possible to the
dryer’s existing dryer rating (data) label/plate.
Unregulated Gas Valve
Regulate (govern) gas externally (refer to “Supply Pressure”
in chart on page 14) to the correct gas pressure for the gas
being used. Operate dryer through one complete cycle to
ensure proper operation.
Regulated Gas Valve
Refer to “Gas Pressure Adjustment” on page 16 to adjust
the gas valve to the appropriate burner pressure listed on
page 14. The supply pressure must also match what is listed
on page 14 for the type of gas to be used.
IMPORTANT: Conversions done improperly can result in a
fire or explosion!
Conversion from Propane
or Butane Gas to Natural Gas
The following conversion allows the dryer to be operated with
natural gas.
Parts Required for Conversion:
Description ADC P/N Qty
Vent Cap and Spring 140415 1
Burner Orifice (Injector) *1
*Refer to page 14 for orifice (injector) size.
Non-CE Dryers
Affix Propane Conversion Rating Label Addendum (ADC
P/N 114090) as close as possible to the dryer’s existing dryer
rating (data) label/plate.
CE Dryers
Affix new data plate label that came with the conversion kit.
Open all shutoff valves, reconnect electrical power to the
dryer, and test for leaks.
IMPORTANT: Never test for leaks with an open flame!!!
Use a soapy water solution or product intended for that
purpose.

16 American Dryer Corp. 113279-9
!
WARNING (CE Dryers)
This appliance must only be operated with the gas
type indicated on the dryer’s data plate. If the
appliance is converted (gas type changed), a data
plate amendment must be obtained from American
Dryer Corporation.
Conversions done improperly can result in a fire or
explosion!
Gas Pressure Testing
For proper operation, the gas pressure must be correct,
consistent and maintained at the gas pressure rates shown
on page 14. Provisions are made at the gas valve for taking
gas pressure readings.
Thereare twotypes ofdevicesused tomeasure gaspressure.
They are the spring/mechanical type gauge and the
manometer. The use of the spring/mechanical type gauge is
not recommended because they are very easily damaged
and are not always accurate. The preferred type of gauge is
the manometer because it is a simple device to use and is
highlyaccurate. Amanometer issimply aglass ortransparent
plastictube witha scalegraduated ininches ormillibar. When
it is filled with water and pressure is applied, the water in the
tube rises, showing the exact gas pressure.
Gas Pressure Test Procedure
Turn gas cock in gas supply line to “OFF” position.
50 Hz dryers: Back out miniature screw inside pressure tap
and attach manometer (refer to the illustration on page 15).
60Hz dryers:Installpressure tap andattachmanometer(refer
to the illustration on page 15).
Turn gas cock to “ON” position.
Start the dryer in Heat Mode and wait for ignition. Gas
manifold pressure should be as shown on page 14.
If the gas pressure needs to be adjusted, refer to “Gas
Pressure Adjustment” on this page.
Once test is complete, turn gas cock to “OFF” position.
Remove manometer. Tighten screw inside the pressure tap
or install plug.
Turn gas cock to “ON” position and check for leaks with soap
solution with main burner “ON.”
Preparation for Operation / Start-Up _
The following items should be checked before attempting to
operate the dryer:
•Read all “CAUTION,” “WARNING,” and “DIRECTION”
labels attached to the dryer.
•Check incoming supply voltage to be sure that it is the
same as indicated on the data label. In the case of 208
VAC or 240 VAC, the supply voltage must match the
electric service exactly.
•GAS MODELS – Check to ensure that the dryer is
connected to the type of heat/gas indicated on the dryer
data label.
•GAS MODELS – Be sure that all gas shutoff valves are
in the open position.
Instructions
Disconnect electrical power to the dryer.
Close all shutoff valves in dryer’s gas supply line.
Open the panel located just below the loading door.
Locatethe gas trainand disconnectthe union,three electrical
plugs, and the gas train mounting screws from the burner.
Carefully slide the gas train out of the gas train enclosure.
(The carbon ignitor located at the far end of the gas train is
very fragile.)
Removetwo burnertube mountingscrews andremove burner
tube in order to gain access to the orifice.
Using a 3/8” wrench or socket, remove the existing orifice
and replace it with an orifice from the kit.
IMPORTANT: Use extreme care when removing and
replacing orifice (injector). This orifice (injector) is made of
brass, which is easily damaged.
Reinstall the burner tube onto the burner base.
Select from the following three options, the conversion to be
performed:
•Converting from unregulated propane to regulated
natural gas: use a flat screwdriver to remove the cap
with blocking pin and install the regulator vent cap from
the kit (ADC P/N 140415).
•Converting from unregulated propane to unregulated
natural gas: no change to the regulator is required.
•Converting from regulated propane to regulated
natural gas: remove the white plastic regulator
adjustment screw (under vent cap). Remove spring
under screw and replace with spring from kit (ADC P/N
140415). Replace regulator adjustment screw.
Install the gas train back into the dryer gas train enclosure.
Be sure the tab at the rear of the gas train engages into the
mounting slot.
Connect the union and the three electrical plugs.
Open all shutoff valves, reconnect electrical power to the
dryer, and test for leaks.
Operate the dryer through one complete cycle to ensure
proper operation.
With dryer operating, check the manifold (burner) pressure
at the tap on the gas valve to ensure proper operating
pressure (refer to chart on page 14).
Gas Pressure Adjustment
Disconnect electrical power to the dryer.
To adjust gas valve’s internal regulator, remove the regulator
vent cap. Once vent cap is removed, turn the plastic
adjustment screw in the valve. Turn the screw clockwise to
raise pressure and counterclockwise to lower pressure.
Gas (burner) pressures are measured with the burner in
operation for all burner adjustment conditions. Therefore
once the necessary adjustments have been made, the dryer
must be operated in a heating cycle to verify that the pressure
is correct. If it is not correct, you must discontinue the power
tothe unit andmake furtheradjustments. Repeat thesesteps
as many times as necessary to achieve the correct burner
pressure. Once the adjustment of the valve is complete, the
vent cap must be replaced and sealed with, for example,
paint to prevent maladjustment by the user.

113279-9www.adclaundry.com 17
•Be sure all back panels (guards) and electric box covers
are in place.
•Be sure the service doors are closed and securely in
place.
•Be sure the lint door/drawer is securely in place.
•Rotate the tumbler (drum) by hand to be sure it moves
freely.
•Check bolts, nuts, screws, terminals, and fittings for
tightness and security.
•Check that the vent is connected to the dryer and is
exhausted to the outdoors.
Preoperational Test __________________
All dryers are thoroughly tested and inspected before leaving
the factory. However, a preoperational test should be
performed before the dryer is publicly used. It is possible
that adjustments have changed in transit or due to marginal
location (installation) conditions. Installer must instruct the
user on how to correctly operate the dryer before leaving.
Turn on electric power to the dryer.
Refer to the Operating Instructions for starting your particular
model dryer.
Gas Dryers
Open all shutoff valves.
When a gas dryer is first started (during initial start-up), it
has a tendency not to ignite on the first ignition attempt. This
is because the gas supply piping is filled with air, so it may
take a few minutes for the air to be purged from the lines.
NOTE: During the purging period, check to be sure that all
gas shutoff valves are open.
Agas pressure test should be taken at the gas valve pressure
tap of each dryer to ensure that the water column pressure is
correct and consistent.
NOTE: Water column pressure requirements (measured at
the pressure tap of the gas valve body) must be verified.
IMPORTANT: In most cases there is no regulator provided
in a propane dryer. The water column pressure must be
regulated at the source (propane tank), or an external
regulator must be added to each dryer.
Electrical Dryers
Check to ensure that electric oven/contactor assembly is
activating.
Safety Related Circuits
Make a complete operational check of all safety related
circuits:
•Door Switch(es)
•Hi-Limit Thermostats
Make a complete operational check of all operating controls.
Tumbler Coating
The tumbler is treated with a protective coating. We suggest
dampening old garments or cloth material with a solution of
water and nonflammable mild detergent and tumbling them
in the tumbler to remove this coating.
Microprocessor Programs / Selections
Each microprocessor controller (computer) has been
preprogrammed by the factory with the most commonly used
parameter (program) selections. If computer program
changes are required, refer to the computer programming
manual, which was shipped with the dryer.
Preoperational Instructions __________
IMPORTANT: For more detailed information regarding the
microprocessor controller (computer), refer to the
microprocessor user’s manual included with the dryer.
Coin Models
Microprocessor Controller (Computer)
Whenthe microprocessorcontroller (computer)is inthe ready
state, the L.C.D. screen will display “FILL” and (XX.XX)
Amount.
Insert coin(s). Once the correct “Amount to Start” has been
inserted, the L.C.D. will display “PUSH”.
Selecttemperature bypressing “HI,”“LO,”or “PERMPRESS.”
The cycle will start and the L.C.D. will display the temperature
cycle selected and the remaining time.
The dryer will continue through the drying and cooling cycles,
until the vended time has expired.
NOTE: To stop the dryer, open main door. Continuation of
the cycle will resume only after the door has been closed
and any one of the three temperature selections is
pressed.
Non-Coin Models
Microprocessor Controller (Computer)
The L.E.D. display reads “FILL” (no cycle in progress).
Selecttemperature bypressing “HI,”“LO,”or “PERMPRESS.”
The dryer will then start (i.e. blower, tumbler, and heat).
The L.E.D. will display the temperature cycle selected and
the remaining time.
NOTE: The dryer can be stopped at any time by opening
the main door or the lint door.
When the programmed drying time has expired, the non-
coin microprocessor controller (computer) will proceed into
the Cool Down Cycle.

18 American Dryer Corp. 113279-9
Shutdown Instructions _______________
If the dryer is to be shutdown (taken out of service) for a
period of time, the following must be performed:
Discontinue power to the dryer either at the external
disconnect switch or the circuit breaker.
Discontinue the heat supply:
Gas Models – Discontinue the gas supply.
Shut off external gas supply shutoff valve.
Shut off internal gas supply shutoff valve located in the gas
valve burner area.
Service / Parts Information ___________
Service
Service must be performed by a qualified trained technician.
If service is required, contact the reseller from whom the
equipmentwas purchased. Ifthe resellercannot becontacted
or is unknown, contact the Service Department for a reseller
in your area.
NOTE: When contacting the Service Department, be sure
to give them the correct model number and serial number
so that your inquiry is handled in an expeditious manner.
Parts
Replacement parts should be purchased from the reseller
from whom the equipment was purchased. If the reseller
cannot be contacted or is unknown, contact the Parts
Department for a reseller in your area. Parts may also be
purchased directly from the factory by calling the Parts
Department at [phone] or you may FAX in your
order at [phone].
NOTE: When ordering replacement parts from the reseller
or the manufacturer, be sure to give them the correct
model number and serial number so that your parts order
can be processed in an expeditious manner.
Warranty Information _________________
Returning Warranty Cards
Before any dryer leaves the factory test area, a warranty card
isplaced onthe insideof themain doorglass. Thesewarranty
cards are intended to serve the customer where we record
the individual installation date and warranty information to
better serve you should you file a warranty claim.
If a warranty card did not come with your dryer, contact the
Warranty Department or the Service Department at +1 (269)
923-3000.
IMPORTANT: Aseparate warranty card must be completed
and returned for each individual dryer.
NOTE: Be sure to include the installation date when
returning the warranty card(s).
Warranty
Fora copyof thecommercialwarranty coveringyour particular
dryer(s), contact the reseller from whom you purchased the
equipment and request a dryer warranty form. If the reseller
cannot be contacted or is unknown, warranty information can
be obtained from the factory by contacting the Warranty
Department at [phone].
NOTE: Whenever contacting the factory for warranty
information, be sure to have the dryer’s model number and
serial number available so that your inquiry can be
handled in an expeditious manner.
Returning Warranty Parts
All dryer or parts warranty claims or inquiries should be
addressed to the Warranty Parts Department. To expedite
processing, the following procedures must be followed:
No parts are to be returned without prior written authorization
(R.M.A.) from the factory.
NOTE: An R.M.A. is valid for only 30 days from date of
issue.
The R.M.A. issued by the factory, as well as any other
correspondence pertaining to the returned part(s), must be
included inside the package with the failed merchandise.
Each part must be tagged with the following information:
Model number and serial number of the dryer from which
part was removed.
Nature of failure (be specific).
Date of dryer installation.
Date of part failure.
Specify whether the part(s) being returned is for a credit,
replacement, or a refund.
NOTE: If a part is marked for a credit or a refund, the
invoice number covering the purchase of the replacement
part must be provided.
Warranty tags (Part No. 450064) are available at “no
charge” from ADC upon request.
The company returning the part(s) must clearly note the
complete company name and address on the outside of the
package.
All returns must be properly packaged to ensure that they
are not damaged in transit. Damage claims are the
responsibility of the shipper.
IMPORTANT: No replacements, credits, or refunds will be
issued for merchandise damaged in transit.
All returns should be shipped to the factory in such a manner
that they are insured and a proof of delivery can be obtained
by the sender.
Shippingcharges arenot theresponsibility ofADC. Allreturns
should be “prepaid” to the factory. Any “C.O.D.” or
“COLLECT” returns will not be accepted.

113279-9www.adclaundry.com 19
IMPORTANT: No replacements, credits, or refunds will be
issued if the claim cannot be processed due to insufficient
information. The party filing the claim will be notified in
writing, either by “FAX” or “CERTIFIED MAIL – Return
Receipt Requested,” as to the information necessary to
process claim. If a reply is not received by the Warranty
Department within 30 days from the FAX/letter date, then
no replacements, credits, or refunds will be issued, and the
merchandise will be discarded.
Routine Maintenance _________________
Cleaning
Aprogram and/or schedule should be established for periodic
inspection, cleaning, and removal of lint from various areas
of the dryer, as well as throughout the ductwork system. The
frequency of cleaning can best be determined from
experience at each location. Maximum operating efficiency
is dependent upon proper airflow. The accumulation of lint
can restrict this airflow. If the guidelines in this section are
met, the dryer will provide many years of efficient, trouble
free, and most importantly, safe operation.
!
WARNING
Lint from most fabrics is highly combustible. The
accumulation of lint can create a potential fire hazard.
Keep dryer area clear and free from combustible
materials, gasoline, and other flammable vapors and
liquids.
NOTE: Suggested time intervals shown are for average
usage, which is considered 6 to 8 operational (running)
hours per day.
IMPORTANT: Dryer produces combustible lint and must be
exhausted to the outdoors. Every 6 months, inspect the
exhaust ducting and remove any lint buildup.
Suggested Cleaning Schedule
After Each Load
Clean the lint screen after each load. Aclogged lint screen
will cause poor dryer performance. The lint door is located
just below the loading door of the dryer. Open the lint door,
brush the lint off the lint screen, and remove the lint. Inspect
lint screen and replace if torn.
Weekly
Clean lint accumulation from lint chamber, thermostat, and
microprocessor temperature sensor area.
!
WARNING
To avoid the hazard of electrical shock, discontinue
electrical supply to the dryer.
90 Days
Remove lint from gas valve burner area with a dusting brush
or vacuum cleaner attachment.
Cleanany lintaccumulation inand aroundthe motor(s)casing
opening.
NOTE: To prevent damage, avoid cleaning and/or touching
ignitor/flame-probe assembly.
Every 6 Months
Inspect and remove lint accumulation in customer furnished
exhaust ductwork system and from dryer’s internal exhaust
ducting.
NOTE: To remove the lint drawer from the dryer, pull the
drawer out until it stops. There are two T-20 torx screws on
each side of the lint drawer holding down the lint drawer
catch brackets which must be removed. Once they are
removed the drawer will be able to be pulled completely
out of the machine. To reinstall put the lint drawer back into
the machine, line up the lint drawer catch brackets with the
screws and tighten them down.
The accumulation of lint in the exhaust ductwork can
create a potential fire hazard.
Do not obstruct the flow of combustion and ventilation air.
Check back draft dampers in the exhaust ductwork.
Inspect and remove any lint accumulation, which can
cause the damper to bind or stick.
Aback draft damper that is sticking partially closed can
result in slow drying and shutdown of heat circuit safety
switches or thermostats.
If the hi-limit trips due to a high temperature occurrence,
you must disconnect power before resetting. To reset,
press and release the reset button, which is located on the
top front, left corner of the lint box.
When cleaning the dryer cabinet(s), avoid using harsh
abrasives. Aproduct intended for the cleaning of
appliances is recommended.
7 Days After Installation
and Every 12 Months Thereafter
Acompetent professional should inspect bolts, nuts, screws,
setscrews, grounding connections and nonpermanent gas
connections (unions, shutoff valves, and orifices). Belts
shouldbe examined. Crackedor seriouslyfrayed belts should
be replaced. Complete an operational check of controls and
valves. Complete an operational check of all safety devices
(lint door/drawer switch, door switches, sail switch, and hi-
limit thermostats).

20 American Dryer Corp. 113279-9
Data Label Information _______________
Standard Label
When contacting ADC, the information on the data label is
required to ensure proper service/parts assistance. The data
label is located at the upper left rear of the dryer behind the
back guard.
1. Model Number – This describes the style of dryer and
type of heat (gas, electric, or steam).
2. Serial Number – Allows the manufacturer to gather
information on your particular dryer.
3. Type of Heat– This describes the type of heat for your
particular dryer, gas (either natural gas or propane gas),
electric, or steam.
4. Heat Input (For Gas Dryers) – This describes the heat
input in British thermal units per hour (Btu/hr) or kilowatts
(kW).
5. Orifice Size (For Gas Dryers) – Gives the number drill
size used.
6. Electric Service – This describes the voltage and
current rating for a particular model.
7. Gas Manifold Pressure (For Gas Dryers) – This
describes the manifold pressure taken at the gas valve
tap.
AGA Label
CE Label
