ADC AD-360X2 User manual

AD-360X2 Installation Manual
Phase 7
ADC Part No. 113234-3
American Dryer Corporation
88 Currant Road
Fall River MA 02720-4781 USA
Telephone: [phone] / Fax: [phone]
e-mail: [e-mail]
www.amdry.com
AVERTISSEMENT: Assurez-vous de
bien suivre les instructions données
dans cette notice pour réduire au
minimum le risque d’incendie ou
d’explosionoupourévitertoutdommage
matériel, toute blessure ou la mort.
—Ne pas entreposer ni utiliser d’essence
ni d’autres vapeurs ou liquides
inflammables à proximité de cet
appareil ou de tout autre appareil.
—QUE FAIRE SI VOUS SENTEZ UNE
ODEUR DE GAZ:
●Ne pas tenter d’allumer d’appareils.
●Ne touchez à aucun interrupteur. Ne
pas vous servir des téléphones se
trouvant dans le bâtiment.
●Évacuez la pièce, le bâtiment ou la
zone.
●Appelez immédiatement votre
fournisseur de gaz depuis un voisin.
Suivez les instructions du fournisseur.
●Si vous ne pouvez rejoindre le
fournisseur de gaz, appelez le service
des incendies.
—L’installation et l’entretien doivent être
assurés par un installateur ou un
service d’entretien qualifié ou par le
fournisseur de gaz.
WARNING: For your safety the
information in this manual must be
followed to minimize the risk of fire or
explosion and to prevent property
damage, personal injury or death.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
●Do not try to light any appliance.
●Do not touch any electrical switch;
do not use any phone in your
building.
●Clear the room, building or area of
all occupants.
●Immediately call your gas supplier
from a neighbor’s phone. Follow
the gas supplier’s instructions.
●If you cannot reach your gas
supplier, call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.

Retain This Manual In ASafe Place For Future Reference
AmericanDryerCorporationproducts embody advanced concepts in engineering, design, and safety. If this product is properly
maintained, it will provide many years of safe, efficient, and trouble free operation.
ONLY qualified technicians should service this equipment.
OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation manual included with
the dryer.
The following “FOR YOUR SAFETY” caution must be posted near the dryer in a prominent location.
“IMPORTANT NOTE TO PURCHASER”
Information must be obtained from your local gas supplier on the
instructionstobe followedif theusersmells gas. These instructionsmust
be posted in a prominent location near the dryer.
We have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the right to
make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to
change or discontinue models. The illustrations included in this manual may not depict your particular dryer exactly.
Important
For your convenience, log the following information:
DATE OF PURCHASE _______________________________ MODEL NO. __________________________________________
RESELLER’S NAME _______________________________________________________________________________________
Serial Number(s) ________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
Replacement parts can be obtained from your reseller or the ADC factory. When ordering replacement parts from the
factory, you can FAX your order to ADC at [phone] or telephone your order directly to the ADC Parts Department
at [phone]. Please specify the dryer model number and serial number in addition to the description and part
number, so that your order is processed accurately and promptly.
AD-360X2 Phase 7
POUR VOTRE SÉCURITÉ
Ne pas entreposer ni utiliser d’essence
ni d’autres vapeurs ou liquides
inflammables à proximité de cet
appareil ou de tout autre appareil.
FOR YOUR SAFETY
Do not store or use gasoline
or other flammable vapors
and liquids in the vicinity of
this or any other appliance.

WARNING
CHILDREN SHOULD NOT BE ALLOWED TO PLAY ON OR NEAR THE
DRYER(S).
CHILDREN SHOULD BE SUPERVISED IF NEAR DRYERS IN OPERATION.
CAUTION
DRYERS SHOULD NEVER BE LEFT UNATTENDED WHILE IN OPERATION.
IMPORTANT
YOU MUST DISCONNECTAND LOCKOUTTHE ELECTRIC SUPPLYANDTHE
GAS SUPPLY OR THE STEAM SUPPLY BEFORE ANY COVERS OR GUARDS
ARE REMOVED FROM THE MACHINE TOALLOWACCESS FOR CLEANING,
ADJUSTING, INSTALLATION, OR TESTING OF ANY EQUIPMENT PER OSHA
(Occupational Safety and Health Administration) STANDARDS.
“Caution: Label all wires prior
to disconnection when servicing
controls.Wiring errors can cause
improper operation.”
«Attention:Aumoment del’entretien des commandes,
étiquetez tous les fils avant de les débrancher. Des
erreurs de câblage peuvent entraîner un
fonctionnement inadéquat et dangereux.»
Proposition 65
Use of this product could expose you to substances from fuel combustion
that contain chemicals known to the State of California to cause cancer,
birth defects and other reproductive harm.
▲ WARNING
!
Inthe Stateof Massachusetts,thefollowinginstallationinstructions apply:
■Installationsand repairs mustbe performed by a qualifiedor licensed contractor,
plumber,orgasfitterqualifiedorlicensed by the State of Massachusetts.
■Ifusinga ball valve, it shall be aT-handle type.
■Aflexiblegasconnector, when used, must not exceed 3 feet.

WARNING
The dryer must never be operated with any of the back guards, outer tops, or service
panels removed. PERSONALINJURY OR FIRE COULD RESULT.
IMPORTANT
PLEASEOBSERVEALLSAFETYPRECAUTIONSdisplayedontheequipmentand/
or specified in the installation manual included with the dryer.
WARNING
DRYER MUST NEVER BE OPERATED WITHOUT THE LINT FILTER/SCREEN
IN PLACE, EVEN IFAN EXTERNAL LINT COLLECTION SYSTEM IS USED.
Dryer must not be installed or stored in an area where it will be exposed to water or
weather.
The wiring diagram for the dryer is located in the front electrical control box area.
IMPORTANT
Dryer must be installed in a location/environment, which the ambient temperature
remains between 40° F(4.44° C) and 130° F (54.44° C).
WARNING
UNDER NO CIRCUMSTANCES should thedryerdoorswitches,lintdrawerswitches,
or heat safety circuit ever be disabled.
FORYOURSAFETY
DONOTDRYMOPHEADSINTHEDRYER.
DONOTUSEDRYERINTHEPRESENCEOFDRYCLEANING FUMES.

SECTION I
SAFETY PRECAUTIONS.......................................................................................... 3
SECTION II
SPECIFICATIONS...................................................................................................... 5
SECTION III
INSTALLATION PROCEDURES............................................................................. 7
A. Unpacking/Setting Up............................................................................................................... 7
B. Location of the Dryer ............................................................................................................... 8
C. Dryer Enclosure Requirements ................................................................................................. 8
D. FreshAir Supply Requirements ................................................................................................ 9
E. Exhaust Requirements ............................................................................................................ 10
F. Electrical Information ............................................................................................................. 15
G. Gas Information ...................................................................................................................... 18
H. Preparation For Operation ...................................................................................................... 21
I. Preoperational Tests................................................................................................................ 22
J. Shutdown Instructions ............................................................................................................ 23
SECTION IV
PREOPERATIONAL INSTRUCTIONS................................................................. 24
A. Coin Mode .............................................................................................................................. 24
B. Free Mode............................................................................................................................... 24
SECTION V
SERVICE/PARTS INFORMATION ....................................................................... 25
A. Service .................................................................................................................................... 25
B. Parts ........................................................................................................................................ 25
Table of Contents

SECTION VI
WARRANTY INFORMATION ............................................................................... 26
A. ReturningWarrantyCards......................................................................................................... 26
B. Warranty.................................................................................................................................. 26
C. Returning Warranty Parts........................................................................................................ 26
SECTION VII
ROUTINE MAINTENANCE ................................................................................... 28
A. Cleaning .................................................................................................................................. 28
B. Adjustments ............................................................................................................................ 29
C. Lubrication.............................................................................................................................. 29
SECTION VIII
DATA LABEL INFORMATION .............................................................................. 30
SECTION IX
PROCEDURE FOR FUNCTIONAL CHECK
OF REPLACEMENT COMPONENTS .................................................................. 32

3
SECTIONI
SAFETYPRECAUTIONS
WARNING: Foryoursafety,the informationin thismanualmustbefollowedtominimizetheriskof
fireor explosion ortoprevent property damage,personalinjury, or lossoflife.
WARNING: Thedryermust never be operatedwithanyof the backguards, outer tops,or
servicepanels removed. PERSONALINJURYORFIRECOULD RESULT.
1. DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
2. Purchaser/user should consult the local gas supplier for proper instructions to be followed in the event the
user smells gas. The instructions should be posted in a prominent location.
3. WHAT TO DO IF YOU SMELL GAS:
a. DO NOT try to light any appliance.
b. DO NOT touch any electrical switch.
c. DO NOT use any phone in your building.
d. Clear the room, building, or area of ALLoccupants.
e. Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.
f. If you cannot reach your gas supplier, call the fire department.
4. Installation and service must be performed by a qualified installer, service agency, or gas supplier.
5. Dryer(s) must be exhausted to the outdoors.
6. Although ADC produces a very versatile dryer, there are some articles that, due to fabric composition or
cleaning method, should not be dried in it.
WARNING: Dryonly water washed fabrics. DONOT dry articles spotted or washed indrycleaning
solvents,a combustibledetergent,or“allpurpose”cleaner.
EXPLOSIONCOULDRESULT.
WARNING: DONOT dry rags or articles coated orcontaminatedwithgasoline,kerosene, oil, paint,
orwax.
EXPLOSIONCOULDRESULT.
WARNING: DONOT dry mop heads. Contaminationbywax or flammablesolventwillcreate a fire
hazard.

4
WARNING: DONOTuseheatfordrying articles that containplastic,foam,spongerubber,or
similarlytexturedrubbermaterials. Dryingina heatedbasket (tumbler)may damage
plasticsorrubberand may be a fire hazard.
7. A program should be established for the inspection and cleaning of lint in the heating unit area, exhaust
ductwork, and inside the dryer. The frequency of inspection and cleaning can best be determined from
experience at each location.
WARNING: Thecollectionof lintinthe burnerareaandexhaust ductworkcancreate apotentialfire
hazard.
8. For personal safety, the dryer must be electrically grounded in accordance with local codes and/or the
National Electrical Code ANSI/NFPA NO. 70-LATEST EDITION or in Canada, the Canadian Electrical
Codes Parts 1 & 2 CSA C22.1-1990 or LATEST EDITION.
NOTE: Failureto electricallyground thedryerproperlywillVOIDTHEWARRANTY.
9. UNDER NO CIRCUMSTANCES should the dryer door switches, lint drawer switches, or heat safety
circuit ever be disabled.
WARNING: PERSONALINJURYORFIRECOULDRESULTshould the dryer door switch,
lintdoor switch, orheatsafety circuit everbedisabled.
10. This dryer is not to be used in the presence of dry cleaning solvents or fumes.
11. Remove articles from the dryer as soon as the drying cycle has been completed.
WARNING: Articlesleftinthedryer afterthedrying andcoolingcycles havebeen completedcan
createafire hazard.
12. READ AND FOLLOW ALL CAUTION AND DIRECTION LABELS ATTACHED TO THE
DRYER.
13. For safety, proper operation, and optimum performance, the dryer must not be operated with a load less
than sixty-six percent (66%), 39 lbs (17 kg) of its rated capacity.
WARNING: YOUMUSTDISCONNECTANDLOCK OUTTHEELECTRICSUPPLY
ANDTHE GAS SUPPLYBEFOREANYCOVERSORGUARDSARE
REMOVEDFROMTHE MACHINETOALLOWACCESS FOR CLEANING,
ADJUSTING,INSTALLATION,ORTESTINGOFANYEQUIPMENTPER
OSHA(OccupationalSafety andHealthAdministration)STANDARDS.
IMPORTANT: Dryer must be installed in a location/environment, which the ambient
temperatureremainsbetween 40º F (4.44ºC)and 130º F (54.44ºC).

5
SECTIONII
SPECIFICATIONS
Shaded areas are stated in metric equivalents. 12/16/03
* 30 lbs (13.6 kg) each pocket/tumbler.
** Size of piping varies with installation conditions. Contact factory for assistance.
NOTE: ADCreservestherighttomake changesinspecifications atanytime withoutnoticeor
obligation.
MAXIMUM CAPACITY* ( DRY WEIGHT )60lbs 27.2 kg
BASKET
( TUMBLER ) DIAMETER 30” 76.2 cm
BASKET
( TUMBLER ) DEPTH 26-1/8” 66.4 cm
BASKET
( TUMBLER ) MOTOR ( 2 PLACES )1/4hp 0.186 kW
BLOWER (
FAN ) MOTOR ( 2 PLACES )1/4hp
0.186 kW
DOOR OPENING
(D IAMETER ) 21-1/2” 54.6 cm
BASKET
( TUMBLER ) VOLUME ( PER POCKET )10.7cuft 0.304 cu m
DRYERS PER 20’/40’ CONTAINER 11/22
DRYERS PER 48’/53’ TRUCK 27/30
VOLTAGE AVAILABLE 120-240 / 1ø / 2w / 60 Hz
APPROX. NET WEIGHT 790 lbs 358.3 kg
APPROX. SHIPPING WEIGHT 850 lbs 385.6 kg
HEAT INPUT 176,000 Btu/hr 44,352 kcal/hr
AIRFLOW (
TOTAL BOTH BASKETS ) 1,040 cfm 29.5 cmm
INLET PIPE CONNECTION** 3/4” F.N.P.T.
Gas

6
NOTE: ADCreservestherighttomake changesinspecifications atanytime withoutnoticeor
obligation.
Specifications

7
SECTIONIII
INSTALLATIONPROCEDURES
Installation should be performed by competent technicians in accordance with local and state codes. In the
absence of these codes, the installation must conform to applicable American National Standards: ANSI
Z223.1-LATEST EDITION (National Fuel Gas Code) or ANSI/NFPA NO. 70-LATEST EDITION (National
Electrical Code) or in Canada, the installation must conform to applicable Canadian Standards: CAN/CGA-
B149.1-M91 (Natural Gas) or CAN/CGA-B149.2-M91 (Liquid Propane [L.P.] Gas) or LATEST EDITION
(for General Installation and Gas Plumbing) or Canadian Electrical Codes Parts 1 & 2 CSA C22.1-1990 or
LATEST EDITION (for Electrical Connections).
A. UNPACKING/SETTING UP
Remove protective shipping material (i.e., plastic wrap and/or optional shipping box) from dryer.
NOTE: Theaccess keys fortheservicedoors are includedinthe information packetshippedinthe
basket (tumbler). These keys shouldberemoved and put in a safe place, yet made
accessiblebecause somewill beneeded throughoutvariousphases intheinstallation ofthe
dryer.
Dryers are shipped with a coin box and coin box faceplate ONLY. The coin box lock is not included and
must be purchased elsewhere or the lock can be ordered as a parts order from the ADC factory.
IMPORTANT: Forshippingpurposes, the 10-inch (25.40cm)exhaustadapter is shipped insideone
(1)ofthedryer’s baskets (tumblers). This exhaust adapter shouldeitherbeleft
insidethebasket (tumbler) or removed and putinasafeplace, andmustbeinstalled
oncethe dryer isinplace priortomaking any exhaustductconnections.
The dryer can be moved to its final location while still attached to the skid or with the skid removed. With the
skid removed, to make it easier to slide the dryer into its final position, slightly lower ALLfour (4) leveling legs,
so that the dryer will slide on the legs instead of the base frame. The dryer is equipped with four (4) leveling legs,
one (1) at each corner of the dryer base. The legs can be adjusted by either tilting and properly supporting the
dryer, and adjusting from underneath with an open end wrench (or adjustable wrench). Or, by removing the rear
lower back panel and/or front lower service panel and adjusting the leveling leg with a 1/4” socket.
IMPORTANT: Whentilting the dryertoadjust thelevelinglegs, besureto properly supportthe
bottomofthedryerwithablockofwoodorsimilarobject. Failure to do so can
causepersonalinjury.

8
B. LOCATION OF THE DRYER
Before installing the dryer, be sure the location conforms to local codes and ordinances. In the absence of such
codes or ordinances the location must conform with the National Fuel Gas Code ANSI.Z223.1 LATEST
EDITION, or in Canada, the installation mustconform to applicable Canadian Standards: CAN/CGA-B149.1-
M91 (Natural Gas) or CAN/CGA-B149.2-M91 (Liquid Propane [L.P.] Gas) or LATEST EDITION (for General
Installation and Gas Plumbing).
1. The dryer must be installed on a sound level floor capable of supporting its weight. Carpeting must be
removed from the floor area that the dryer is to rest on.
IMPORTANT: “Thedryer mustbeinstalledonnoncombustiblefloorsonly.”
2. Even though a 12-inch (30.48 cm) clearance is acceptable, it is recommended that the rear of the dryer be
positioned approximately 2 feet (0.61 meters) away from the nearest obstruction, i.e., wall, for ease of
installation, maintenance, and service.
3. The dryer must be installed with a proper exhaust duct connection to the outside.
4. The dryer must be installed with provisions for adequate combustion and make-up air supply.
CAUTION: Thisdryerproduces combustible lint andmustbeexhaustedto the outdoors. Every
6months,inspecttheexhaustductingandremoveanylintbuildup.
IMPORTANT: Dryer must be installed in a location/environment, which the ambient
temperatureremainsbetween 40º F (4.44ºC)and 130º F (54.44ºC).
C. DRYER ENCLOSURE REQUIREMENTS
Bulkheads and partitions should be made of noncombustible materials and must be located a minimum of
24-inches (60.96 cm) above the dryer outer top, except along the front of the dryer which may be closed in if
desired.

9
D. FRESH AIR SUPPLYREQUIREMENTS
Air supply (make-up air) must be given careful consideration to ensure proper performance of each dryer. An
unrestricted source of 1,040 cfm (29.44 cmm) is necessary for each dryer (total for both baskets [tumblers]).
An unrestricted air entrance from the outdoors (atmosphere) of a minimum of 1-1/2 square feet (0.14 square
meters) is required for each dryer. This area must be enlarged if louvers or registers cover the opening. It is
not necessary to have a separate make-up air opening for each dryer. Common make-up air openings are
acceptable. However, they must be set up in such a manner that the make-up air is distributed equally to the
dryers. For example, for a bank of eight (8) dryers, a total make-up air opening of 12 square feet
(1.15 square meters) is required. Two (2) openings measuring 2 feet by 3 feet (0.61 meters by 0.91 meters)
(6 square feet [0.58 square meters]) are acceptable. The dryer must be installed with provisions for adequate
combustion and make-up air supply.
Allowances must be made for remote or constricting passageways or where dryers are located at excessive
altitudes or predominantly low-pressure areas.
IMPORTANT: Make-upairmustbe provided from asourcefreeof dry cleaning solventfumes.
Make-upairthatiscontaminatedbydrycleaningsolvent fumeswill resultin
irreparabledamageto the motors andotherdryercomponents.
IMPORTANT: Make-upair openingsshouldnotbelocated near ductwork exhaust outlets. If
make-upairopenings are toocloseto the exhaustoutlet,lintand fumes maybedrawn
backinto the dryerareathroughthese openings.
NOTE: ComponentfailureduetodrycleaningfumeswillVOIDTHEWARRANTY.

10
E. EXHAUST REQUIREMENTS
Exhaust ductwork shouldbedesigned and installed by a qualified professional. Improperly sized ductwork will
create excessive back pressure which will result in slow drying, increased use of energy, overheating of the
dryer, and shutdown of the burner by the airflow (sail) switches, burner hi-limits, or basket (tumbler) hi-limit
thermostats. The dryer must be installed with a proper exhaust duct connection to the outside.
CAUTION: Thisdryerproduces combustible lint andmustbeexhausted to theoutdoors.
When possible, it is suggested to provide a separate exhaust duct for each dryer.
CAUTION: IMPROPERLYSIZEDOR INSTALLEDEXHAUSTDUCTWORK CAN
CREATEAPOTENTIALFIREHAZARD.
The exhaust ductwork must be laid out in such a way that the ductwork travels as directly as possible to the
outdoors with as few turns as possible. The shape of the ductwork is not critical provided that the minimum
cross-sectional area is maintained.
When single dryer venting is used, for horizontal or vertical venting the minimum duct size is 10-inches
(25.40 cm) in diameter and the ductwork from the dryer to the outside exhaust outlet must not exceed a
distance of 35 feet (10.67 meters) and have no more than two (2) elbows (including both connection to dryer and
outside protection).
In the case of multiple (common) venting, using the applicable duct size (diameter) noted in this manual, for
horizontal venting the distance from the last dryer to the outside outlet must not exceed 15 feet (4.57 meters)
and have no more than one (1) elbow (including outside protection). In the case of common vertical venting, the
distance from the last dryer to the outside outlet must not exceed 25 feet (7.62 meters) and have no more than
three (3) elbows (including outside protection).
IMPORTANT: Exhaust back pressure measuredby a manometer at thedryer exhaust duct area must
beno less than 0 and mustnotexceed 0.3 inches (0.74 mb) of water column
(W.C.).
It is suggested that the use of 90º turns in ducting be avoided; use 30º or 45º angles instead. The ductwork
should be smooth inside with no projections from sheet metal screws or other obstructions, which will collect
lint. When adding ducts, the duct to be added should overlap the duct to which it is to be connected. ALL
ductwork joints must be taped to prevent moisture and lint from escaping into the building. Also, inspection
doors should be installed at strategic points in the exhaust ductwork for periodic inspection and cleaning.
When the exhaust ductwork passes through a wall, ceiling, or roof made of combustible materials, the opening
must be 2-inches (5.08 cm) larger than the duct (all the way around). The duct must be centered within this
opening.
If the ductwork run (distance) or the amount of elbows required exceeds the limits noted in this manual, the size
(diameter/cross-sectional area) of the ductwork must be increased in proportion to the length or number of
elbows added. When the ductwork approaches the maximum limits as noted in this manual, a professional
heating, ventilating, and air-conditioning (HVAC) firm must be consulted for proper venting information.
1. Dryer exhaust connection. The dryer is shipped with a 10-inch (25.40 cm) exhaust adapter, which for
shipping purposes is shipped inside of the dryer’s basket (tumbler). This exhaust adapter must beinstalled
(with screws provided) once the dryer is in place prior to making any exhaust connections.

11
IMPORTANT: Minimumductsizefor dryer is 10-inches (25.40cm)roundduct. Ductsize mustnot
bereducedanywheredownstream of dryer.
IMPORTANT: Itisrecommendedthatexhaustorboosterfansnotbeusedin the exhaust ductwork
system.
NOTE: AspertheNational Fuel Gas Code, “Exhaust ducts fortype2clothesdryersshall be
constructedof sheetmetalorothernoncombustible material. Suchductsshallbeequivalent in
strengthand corrosion resistancetoducts madeofgalvanized sheet steelnotless than
26gauge(0.0195-inches [0.50 mm])thick.”
2. Venting Layout
a. Single DryerVenting
When single dryer venting is used, for horizontal or vertical venting the minimum duct size is 10-inches
(25.40 cm) in diameter and the ductwork from the dryer to the outside exhaust outlet must not exceed
a distance and the number of elbows (including both connection to dryer and outside protection shown
in the illustration below).
IMPORTANT: Exhaustbackpressuremeasuredbya manometer at the dryer exhaust duct area must
beno less than 0 and mustnotexceed 0.3 inches (0.74 mb) of water column
(W.C.).
CAUTION: IMPROPERLYSIZEDOR INSTALLEDEXHAUSTDUCTWORK CAN
CREATEAPOTENTIALFIREHAZARD.

12
It is suggested that the use of 90º turns in ducting be avoided; use 30º or 45º angles instead. The
ductwork should be smooth inside with no projections from sheet metal screws or other obstructions,
which will collect lint. When adding ducts, the duct to be added should overlap the duct to which it is to
be connected. ALL ductwork joints must be taped to prevent moisture and lint from escaping into the
building. Also, inspection doors should be installed at strategic points in the exhaust ductwork for
periodic inspection and cleaning.
IMPORTANT: Minimumductsizefor dryer is 10-inches (25.40cm)roundduct. Ductsize mustnot
bereducedanywheredownstream of dryer.
When the exhaust ductwork passes through a wall, ceiling, or roof made of combustible materials, the
opening must be 2-inches (5.08 cm) larger than the duct (all the way around). The duct must be
centered within this opening.
IMPORTANT: Ifthe ductwork run(distance)or theamountofelbows requiredexceedsthe limits
notedin thismanual,the size(diameter/cross-sectionalarea) oftheductworkcanonly
beincreased to anextent. Whenthe ductwork approachesthemaximum limits as
notedinthismanual,aprofessionalheating,ventilating,andair-conditioning(HVAC)
firmmustbeconsultedforproperventinginformation.
b. CommonVenting
If it is not feasible to provide separate exhaust ducts for each dryer, ducts from individual dryers may be
channeled into a “common main duct.” The individual ducts should enter the bottom or the side of the
main common duct at an angle not more than 45º in the direction of airflow. The main duct should be
tapered, with the diameter increasing before each individual duct 10-inches (25.40 cm) is added.
IMPORTANT: No more than four (4) dryers or eight (8) pockets total shouldbeconnected to one
(1)common duct.
Minimum duct size between dryer and common duct is 10-inches (25.40 cm) in diameter. This duct
must not travel more than 15 feet (4.57 meters) and include no more than three (3) elbows (which
includes both dryer and common duct connections).
NOTE: Refertoillustrationson page13andpage14forexamplesof multiple dryer (common)
venting.
In the case of multiple (common) venting, using the applicable duct size (diameter) noted in this manual,
for horizontal venting the distance from the last dryer to the outside outlet must not exceed 15 feet
(4.57 meters) and have no more than one (1) elbow (including outside protection). In the case of
common vertical venting, the distance from the last dryer to the outside outlet must not exceed 25 feet
(7.62 meters) and have no more than three (3) elbows (including outside protection).
IMPORTANT: Exhaustbackpressuremeasuredbyamanometeratthedryerexhaustductareamustbe
nolessthan0and mustnotexceed0.3inches(0.74mb) ofwatercolumn(W.C.).
CAUTION: IMPROPERLYSIZEDOR INSTALLEDEXHAUSTDUCTWORK CAN
CREATEAPOTENTIALFIREHAZARD.

13
It is suggested that the use of 90º turns in ducting be avoided; use 30º or 45º angles instead. The
ductwork should be smooth inside with no projections from sheet metal screws or other obstructions,
which will collect lint. When adding ducts, the duct to be added should overlap the duct to which it is to
be connected. ALL ductwork joints must be taped to prevent moisture and lint from escaping into the
building. Also, inspection doors should be installed at strategic points in the exhaust ductwork for
periodic inspection and cleaning.
When the exhaust ductwork passes through a wall, ceiling, or roof made of combustible materials, the
opening must be 2-inches (5.08 cm) larger than the duct (all the way around). The duct must be
centered within this opening.
IMPORTANT: Ifthe ductwork run(distance)or theamountofelbows requiredexceedsthe limits
notedin thismanual,the size(diameter/cross-sectionalarea) oftheductworkcanonly
beincreased to anextent. Whenthe ductwork approachesthemaximum limits as
notedinthismanual,aprofessionalheating,ventilating,andair-conditioning(HVAC)
firmmustbeconsulted forproper ventinginformation.

14
c. Outside Ductwork (Vent) Protection
To protect the outside end of the horizontal ductwork from the weather, a 90º elbow turned downward
should be installed where the exhaust duct exits the building. If the ductwork travels vertically up
through a roof, it should be protected from the weather by using a 180º turn (goose neck) to point the
opening downward. In either case, allow at least twice the diameter of the duct between the duct
opening and the nearest obstruction.
IMPORTANT: DONOTusescreens,louvers,orcapsontheoutsideopeningoftheexhaust
ductwork.

15
When the exhaust ductwork passes through a wall, ceiling, or roof made of combustible materials, the
opening must be 2-inches (5.08 cm) larger than the duct (all the way around). The duct must be
centered within this opening.
F. ELECTRICAL INFORMATION
1. Electrical Requirements
It is your responsibility to have ALL electrical connections made by a properly licensed and competent
electrician to ensure that the electrical installation is adequate and conforms to local and state regulations or
codes. In the absence of such codes, ALL electrical connections, materials, and workmanship must
conform to the applicable requirements of the National Electrical Code ANSI/NFPA NO. 70-LATEST
EDITION or in Canada, the Canadian Electrical Codes Parts 1 & 2 CSAC22.1-1990 or LATEST EDITION.
IMPORTANT: Failureto complywiththese codesorordinances,and/or therequirementsstipulated
inthismanual, can resultinPERSONALINJURYOR COMPONENTFAILURE.
NOTE: ComponentfailureduetoimproperinstallationwillVOIDTHEWARRANTY.
A separate circuit servicing each basket (tumbler) must be provided. The dryer must be connected to
copper wire ONLY. DO NOT use aluminum wire, it could create a fire hazard.
NOTE: TheuseofaluminumwirewillVOIDTHEWARRANTY.
2. Electrical Connections
A wire diagram is included with each dryer showing the wiring connection sequence. The electrical
connections are made in the wiring box located at the rear top area of the dryer.
Each pocket must be provided with a separate circuit. The external power connection for the top pocket
is made to a terminal block and the lower external power connection is made to a wire harness, both are
located in the above mentioned wire box.

16
If local codes permit, power to the dryer can be made by the use of a flexible U.L. listed power cord/pigtail
(wire size must conform to rating of dryer), or the dryer can be hard wired directly to the service breaker
panel. In both cases, a strain relief must be installed where the wiring enters the dryer.
Electrical power connection examples:
IMPORTANT: Fora120vinstallation, a 2-wire service(L1andNeutral)and a ground is requiredfor
each basket (tumbler)/pocket. In the case of a 208v or 230/240v 1-phase (1ø)
service,3-wires(L1,L2andNeutral)andaground is required for each basket
(tumbler)/pocket.
