ADC HiGain HDU-407 User manual
ADC DSL Systems, Inc.
14402 Franklin Avenue
Tustin, CA 92780-7013
Tel: 714.832.9922
Fax: 714.832.9924
Technical Assistance
800.638.0031
714.730.3222
Product Number: 150-1576-02
CLEI Code: T1R6AH0C
HGI AIN
Quick Installation Guide
H
I
G
AIN
HDU-407 List 2
Micro Doubler Unit
L
STATUS
HDU-407
HiGain
DOUBLER
FCC Class A Certification
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to correct the interference at his
own expense.
Limited Warranty
Product warranty is determined by your service agreement. Contact your sales representative or Customer
Service for details.
Modifications
Any changes or modifications made to this device that are not expressly approved by ADC DSL Systems, Inc.
voids the user's warranty.
All wiring external to the products should follow the provisions of the current edition of the National Electrical
Code.
Standards Compliance
The HDU-407 List 2 has been tested and verified to comply with the applicable sections of the following
standards:
GR 63-CORE - Network Equipment-Building System (NEBS) Requirements
GR 1089-CORE - Electromagnetic Compatibility and Electrical Safety
Trademark Information
ADC is a registered trademark of ADC Telecommunications, Inc. HiGain and PG-Flex are registered
trademarks of PairGain Technologies, Inc. Other product names mentioned in this installation guide are used
for identification purposes only and may be trademarks or registered trademarks of their respective companies.
Copyright Information
©Copyright 2000 ADC DSL Systems, Inc. All rights reserved. Information contained in this document is
company private to ADC DSL Systems, Inc., and shall not be modified, used, copied, reproduced or disclosed
in whole or in part without the written consent of ADC.
THE HDU-407 LIST 2
The HiGain®HDU-407 List 2 is a low-power micro doubler unit that extends the
range of a HiGain repeaterless T1 transmission system. The doubler units are installed
between any doubler-compatible HiGain Line Unit (HLU), HiGain Doubler
Unit (HDU), or HiGain Remote Unit (HRU). Each doubler allows 1.544 Mbps
transmission over an additional Carrier Service Area (CSA) range. The HDU-407 is
compatible with both the HiGain and PG-Flex product lines. The CSA includes loops
up to 12,000 feet (3.657 km) of 24 AWG or 9,000 feet (2.743 km) of 26 AWG loops.
FEATURES
SPECIFICATIONS
•Occupies one DDS or ISDN mechanics slot •Extremely low latency
•Powered by any doubler-compatible
HiGain or PG-Flex line unit •Compatible with PG-Flex List 3x line units in
configurations with up to three spans
•Extremely low power dissipation •Minimal wander and jitter
•Lightning and power-cross protection on
both sides of the High-bit-rate Digital
Subscriber Line (HDSL) interface
•Used in four-span line-powered HiGain circuits
(three doublers and one remote) or five-span locally
powered circuits (four doublers and one remote)
•Front-panel status display Light Emitting
Diode (LED)
Operating Temperature -40 °F (-40 °C) to +149 °F (+65 °C)
Operating Humidity 5% to 95% non-condensing
Operating Temperature in Outside Enclosures Complies with Section 10.2.1.3 of TA-NWT-001210
Operating Elevation 200 feet (60.96 m) below sea level to 13,000 feet
(3.96 km) above sea level
Mounting Standard DDS or ISDN mechanics slot
HDSL Line Code 784 kbps, Two Binary, One Quaternary (2B1Q) full
duplex
HDSL Output +13.0 dBm, 135 Ω
Maximum Provisioning Loss 35 dB at 196 KHz, 135 Ω
Line Clock Rate Internal Stratum 4 clock
Power Consumption 3.0 W (nominal)
Resistive Signature Input/Output 25 Ω(maximum)
BEFORE YOU BEGIN
1Verify that you are installing the HDU-407 with the following compatible
HiGain outdoor enclosures. For a list of compatible non-ADC enclosures, see the
HDU-407 List 2 technical practice, section number 150-407-102-xx.
2Verify that you are installing the HDU-407 with compatible line and remote
circuit modules (see Table 1 inside).
3Determine the number of doublers the circuit can support based upon:
•the model of the HLU and HRU in the circuit (see Table 1)
•whether the HRU is locally powered or line-powered (see Table 1)
•whether you are installing ina HiGain (see “HiGain Doubler Applications”)
or PG-Flex application (see “PG-Flex Doubler Applications”).
4Observe the following deployment rules for enclosure placement:
•Rule 1. Place the enclosures at the electrical limits (35 dB) of each span.
•Rule 2: Make all spans the same electrical length (same 196 kHz loss) to
achieve optimum performance if Rule 1 is not applicable.
•Rule 3: To minimize power consumption and dissipation of the HLU,
confirm that the spans closest to the HLU are as short as possible and the
spans furthest from the HLU are as long as possible.
5Determine the enclosure model based upon doubler and repeater capacities of
occupied slots as shown in Table 2 “Outdoor Enclosure Capacities with Full
Solar Load”.
Continued
•HRE-458, 10-slot unit •HRE-506, 6-slot unit
•HRE-500, 1-slot unit •HRE-602, 1-slot unit
•HRE-504, 4-slot unit •HRE-712, 12 slot unit
Þ
™350-407-102-01x¨
Section Number: 350-407-102-01
