ADC HiGain H2TU-C-319 List 4E Original operating instructions
HiGain
HiGain
FCC Class A Compliance
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Limited Warranty
Product warranty is determined by your service agreement. Contact your sales representative or
Customer Service for details.
Modifications
Any changes or modifications made to this device that are not expressly approved by ADC DSL
Systems, Inc. voids the user's warranty.
All wiring external to the products should follow the provisions of the current edition of the National
Electrical Code.
Standards Compliance
This equipment has been tested and verified to comply with the applicable sections of the following
safety standards:
GR 63-CORE - Network Equipment-Building System (NEBS) Requirements
GR 1089-CORE - Electromagnetic Compatibility and Electrical Safety
Binational standard, UL-1950/CSA-C22.2 No. 950-95: Safety of Information Technology
Equipment
Trademark Information
ADC is a registered trademark of ADC Telecommunications, Inc. HiGain is a registered trademark of
ADC DSL Systems, Inc. Other product names mentioned in this installation guide are used for
identification purposes only and may be trademarks or registered trademarks of their respective
companies.
Copyright Information
© 1999 ADC DSL Systems, Inc. All rights reserved. Information contained in this document is company
private to ADC DSL Systems, Inc., and shall not be modified, used, copied, reproduced or disclosed in
whole or in part without the written consent of ADC.
ADC DSL Systems, Inc.
14402 Franklin Avenue
Tustin, CA 92780-7013
Tel: 714.832.9922
Fax: 714.832.9924
Technical Assistance
Tel: 800.638.0031
Tel: 714.730.3222
Fax: 714.730.2400
DNV C ertificatio n, Inc.
REGISTERED FIRM
ISO 9001/TL 9000
THE H2TU-C-319 LIST 1 AND LIST 1C
The ADC®HiGain®HDSL2 product family is the industry’s first practical
implementation of High bit-rate Digital Subscriber Line 2 (HDSL2). When an
H2TU-C-319List 1 orList 1Clineunit is usedin conjunction with aHiGainremote
unit (H2TU-R), the system provides 1.552 Mbps transmission on one unconditioned
copper pair over the full Carrier Service Area (CSA) range. The CSA includes loops
up to 12,000 feet of 24 AWG or 9,000 feet of 26 AWG wire, including bridged taps.
FEATURES
SPECIFICATIONS
•Front-panel status LED, craft port, and
four-character status display (List 1 only) (a)
(a) The List 1C is an HMU-managed model that does not provide the standard front-panel
provisioning features (RS-232 craft port, MOD and SEL buttons, and four-character display).
•Payload or HiGain loopback source
identification
•Ultra-low wander •Bit Error Rate (BER) alarm option
•Three-span range with two regenerators
(36 kft, 24 AWG)
•Bipolar Violation Transparency (BPVT)
option
•Grounded loop detection •Flash download of firmware updates
•Loss of Signal (LOS)/Alarm Indication Signal
(AIS) payload alarm option
•HiGain maintenance screens for inventory,
provisioning, troubleshooting, and
performance monitoring
Operating Temperature -40 °F to +149 °F (-40 °C to +65 °C)
Operating Humidity 5% to 95% non-condensing
HDSL2 Span Voltage 0, -185 Vdc
Mounting 3192 high-density shelf
HDSL2 Line Rate 1.552 Mbps Overlapped Pulse Amplitude Modulation Transmission
with Interlocking Spectra (OPTIS)
HDSL2 Output +16.8 dBm ±0.5 dB, 135 Ω
Maximum Loop Attenuation 35 dB at 196 KHz, 135 Ω
DSX-1 Line Rate 1.544 Mbps ±200 bps
DSX-1 Line Format Alternate Mark Inversion (AMI) or Bipolar with 8-zero Substitution
(B8ZS)
DSX-1 Frame Format Extended SuperFrame (ESF), SuperFrame (SF) or Unframed (UNFR)
DSX-1 Pulse Output 6 V pk-pk, pre-equalized for 0 to 655 feet of ABAM cable
DSX-1 Input Level +1.5 to -7.5 dB DSX
INSTALLATION
To ensure proper installation, align the H2TU-C with the enclosure slot guides and
slide the unit in. The unit should snap into place, indicating that the unit is properly
seated.
POWER-UP SEQUENCE
When the H2TU-C powers up, the four-character display illuminates and reports
status messages.
If the H2TU-C is unable to communicate with the next span device, it displays various
alarm and status messages.
If the H2TU-C is able to communicate with the next span device, the following occurs:
1The Status LED flashes red while acquiring each device in the system, and turns
steady green when the entire system is operating without any alarms. (The T1
signal must be present.)
2The four-character display reports margin (SNR) readings (should be ≥6 dB) and
loop attenuation (should be <35 dB @196 KHz).
3Any alarm conditions that exist after the system powers up are reported on the
display. (The H2TU-C reports alarms if no T1 signal is applied.)
PROVISIONING
After installing the H2TU-C, perform these basic provisioning tasks by accessing the
HiGain HDSL2 logon screen. Refer to the onscreen Help menu for navigational aids.
1Connect a maintenance terminal to the craft port (see front-panel illustration
inside), then press + to refresh the logon screen, if necessary. For
List 1C, connect to the HMU craft port to access the logon screen.
2Select the Config menu, Date and Time, then type the date and time.
3Select the Inventory menu, then type in the unit ID numbers.
4Change the settings of any system parameters, if necessary, by selecting the
Config menu, Standard Options or PairGain Options. (List 1 configuration
options can also be set from the front panel using the MODE and SEL buttons.
See the “Front-panel Configuration Options”table inside.)
5Once the H2TU-C is successfully installed and provisioned, access the Monitor,
Performance or Event Log screens to clear these screens individually or select
Master Clear from the Config menu to clear all screens to ensure useful data.
Continued
CTRL R
Þ
SETUP
STATUS
R
S
2
3
2
HiGain
O
U
T
I
N
B
R
G
B
R
G
L
I
N
E
L
I
N
E
H
2
T
U
*
C
3
1
9
H
D
S
L
2
L
1C
S
E
L
M
O
D
E
SETUP
STATUS
R
S
2
3
2
HiGain
O
U
T
I
N
B
R
G
B
R
G
L
I
N
E
L
I
N
E
H
2
T
U
*
C
3
1
9
H
D
S
L
2
L
1
H2TU-C-319 LIST 1 AND LIST 1C
LINE UNITS
QUICK INSTALLATION
´,-~¶5#¨
1213945
December 17, 1999
Product Catalog: H2TU-C-319-L1L1C
CLEI: VACHDN0C, VACHKNZC
Document: 352-319-100-03, Issue 3
