For Your Own Personal Safety, Please Read and Understand This
Manual Completely Before You Attempt To Install Or Operate
This Unit!
•   To reduce the risk of electrical shock or re, do not expose this unit
   rain or moisture
•   Do not spill water or other liquids into or on to your unit.
•   Be sure that the local power outlet match that of the required volt-
   age for your unit.
•   Do not attempt to operate this unit if the power cord has been
   frayed or broken.
•   Do not attempt to remove or break o the ground prong from
   the electrical cord. This prong is used to reduce the risk of electrical
   shock and re in case of an internal short.
•   Disconnect from main power before making any type of connection.
•   Do not remove the cover under any conditions. There are no user
   serviceable parts inside.
•   Never operate this unit when it’s cover is removed.
•   Always be sure to mount this unit in an area that will allow proper
   ventilation. Allow about 6” (15cm) between this device and a wall.
•   Do not attempt to operate this unit, if it becomes damaged.
•   This unit is intended for indoor use only, use of this product out-
   doors voids all warranties.
•   Always mount this unit in safe and stable matter.
•   Power-supply cords should be routed so that they are not likely to
   be walked on or pinched by items placed upon or against them,
   paying particular attention to cords at plugs, convenience recep-
   tacles, and the point where they exit from the appliance.
•   Cleaning -The fixture should be cleaned only as recommended by
   the manufacturer. See page 20 for cleaning details.
•   Heat -This fixture should be situated away from heat sources such
   as radiators, heat registers, stoves, or other appliances (including
   amplifiers) that produce heat.
•   The fixture should  be serviced by qualified service personnel when:
    A. Objects have fallen, or liquid has been spilled into the appliance.
    B. The appliance has been exposed to rain or water.
    C. The appliance does not appear to operate normally or exhibits a
  marked change in performance.
 Jellyfish IR Safety Precautions
ADJ Products, LLC  -  www.adj.com  - Jellysh IR Instruction Manual Page 5ADJ Products, LLC  -  www.adj.com  - Jellysh IR Instruction Manual Page 4
 Jellyfish IR Set Up
Power Supply: The ADJ Jellysh IR contains an automatic voltage
switch, which will auto sense the voltage when it is plugged into the
power source. With this switch you do not need to worry about wall
voltage, this unit can be plugged in anywhere.
DMX-512: DMX is short for Digital Multiplex. This is a universal pro-
tocol used by most lighting and controller manufactures as a form of
communication between intelligent fixtures and controllers. A  DMX
controller sends DMX data instructions from the controller to the fix-
ture. DMX data is sent as serial data that travels from fixture to fixture
via the DATA “IN” and DATA “OUT” XLR terminals located on all DMX
fixtures (most controllers only have a DATA “OUT” terminal).
DMX Linking: DMX  is  a  language  allowing  all  makes  and  models
of  dierent  manufactures  to  be  linked  together  and  operate  from  a
single  controller,  as  long  as  all  xtures  and  the  controller  are  DMX
compliant. To ensure proper DMX data transmission, when using
several DMX fixtures try to use the shortest cable path possible. The
order in which fixtures are connected in a DMX line does not influence
the DMX addressing. For example; a fixture assigned a DMX address
of 1 may be placed anywhere in a DMX line, at the beginning, at the
end, or anywhere in the middle. Therefore, the first fixture controlled
by the controller could be the last fixture in the chain. When a fixture
is assigned a DMX address of 1, the DMX controller knows to send
DATA assigned to address 1 to that unit, no matter where it is located
in the DMX chain.
Data Cable (DMX Cable) Requirements (For DMX and Master/Slave
Operation): The Jellysh IR can be controlled via DMX-512 protocol.
The  Jellysh  IR  has  two  DMX  Channel  modes.  It  has  a  three  chan-
nel mode and 28 channel mode. The DMX address
is set electronically using the controls on the rear
panel of the unit. Your unit and your DMX control-
ler  require  a  approved  DMX-512  110  Ohm  Data
cable for data input and data output (Figure 1). We
recommend  Accu-Cable  DMX  cables.  If  you  are
making your own cables, be sure to use standard
110-120  Ohm  shielded  cable  (This  cable  may  be
purchased  at  almost  all  professional  sound  and
lighting stores). Your cables should be made with a male and female
Figure 1
