ADJ wifly bar qa5 User manual

User Instructions
Rev. 8/15
WIFLY BAR QA5
©2015 ADJ Products, LLC all rights reserved. Information,
specications, diagrams, images, and instructions herein are
subject to change without notice. ADJ Products, LLC logo and
identifying product names and numbers herein are trademarks
of ADJ Products, LLC. Copyright protection claimed includes all
forms and matters of copyrightable materials and information
now allowed by statutory or judicial law or hereinafter granted.
Product names used in this document may be trademarks or
registered trademarks of their respective companies and are
hereby acknowledged. All non-ADJ Products, LLC brands and
product names are trademarks or registered trademarks of their
respective companies.
ADJ Products, LLC and all aliated companies hereby dis-
claim any and all liabilities for property, equipment, building, and
electrical damages, injuries to any persons, and direct or indi-
rect economic loss associated with the use or reliance of any
information contained within this document, and/or as a result
of the improper, unsafe, unsucient and negligent assembly,
installation, rigging, and operation of this product.
Europe Energy Saving Notice
Energy Saving Matters (EuP 2009/125/EC)
Saving electric energy is a key to help protecting the enviroment.
Please turn o all electrical products when they are not in use. To
avoid power consumption in idle mode, disconnect all electrical
equipment from power when not in use. Thank you!

ADJ Products, LLC - www.adj.com - WiFLY Bar QA5 User Manual Page 3
• Rechargeable Lithium Battery
• Multi-Colors
• Five Operating Modes
• Electronic Dimming 0-100%
• Built in Microphone
• DMX-512 protocol
• 3-Pin DMX Connection
• 6 DMX Channel Modes: 4 Channel Mode, 6 Channel Mode, 7
Channel Mode, 8 Channel Mode, 9 Channel Mode, & 22 Channel
Mode
• Built-In ADJ’s WiFly TransCeiver Wireless DMX
• ADJ RFC compatiable (Not Included)
• Power Cord Daisy Chain (See page 14)
WiFLY Bar QA5 Warranty Registration
WiFLY Bar QA5 Features
The WiFLY Bar QA5 carries a 2 year limited warranty. Please fill out
the enclosed warranty card to validate your purchase. All returned
service items whether under warranty or not, must be freight pre-paid
and accompany a return authorization (R.A.) number. The R.A. number
must be clearly written on the outside of the return package. A brief
description of the problem as well as the R.A. number must also be
written down on a piece of paper included in the shipping carton. If
the unit is under warranty, you must provide a copy of your proof of
purchase invoice. You may obtain a R.A. number by contacting our
customer support team on our customer support number. All pack-
ages returned to the service department not displaying a R.A. number
on the outside of the package will be returned to the shipper.
The unit should be mounted using a mounting clamp (not provided),
axing it to the mounting bracket that is provided with the unit.
Always ensure that the unit is rmly xed to avoid vibration and slip-
ping while operating. Always ensure that the structure to which you
are attaching the unit is secure and is able to support a weight of 10
times the unit’s weight. Also, always use a safety cable that can hold
12 times the weight of the unit when installing the xture.
The equipment must be installed by a professional, and it must be
installed in a place where it is out of the reach of people’s grasp.
WiFLY Bar QA5 Installation
WiFLY Bar QA5 Introduction
ADJ Products, LLC - www.adj.com - WiFLY Bar QA5 User Manual Page 2
Unpacking: Thank you for purchasing the WiFLY Bar QA5 by ADJ
Products, LLC. Every WiFLY Bar QA5 has been thoroughly tested and
has been shipped in perfect operating condition. Carefully check the
shipping carton for damage that may have occurred during shipping.
If the carton appears to be damaged, carefully inspect your xture for
any damage and be sure all accessories necessary to operate the unit
has arrived intact. In the case damage has been found or parts are
missing, please contact our toll free customer support number for fur-
ther instructions. Do not return this unit to your dealer without rst con-
tacting customer support.
Introduction: The WiFLY Bar QA5 is a rechargeable lithium battery
powered, DMX intelligent, LED bar fixture with ADJ’s WiFly TransCeiver
with wireless DMX built-in. This unit give you the freedom to set up
your fixture where ever you wish without the restrictions of power or
DMX cabling. The built-in battery will keep charge for up to 6 hours (full
on) from a full, single charge. This xture can be used in a stand alone
mode or connected in a Master/Slave conguration. This wash has five
operating modes: Sound Active mode, Auto mode, RGB mode, Static
Color mode, and DMX control mode.
Customer Support: ADJ Products, LLC provides a customer support
line, to provide set up help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.adj.com for any comments or sugges-
tions. Service Hours are Monday through Friday 8:00 a.m. to 4:30 p.m.
Pacic Standard Time.
Voice: [phone]
Fax: [phone]
E-mail: [e-mail]
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
ADJ Products, LLC.
PLEASE recycle the shipping carton when ever possible.

ADJ Products, LLC - www.adj.com - WiFLY Bar QA5 User Manual Page 5
1. Handling of Batteries
1.1 Do Not Short Circuit the Battery
Try to never short circuit the battery. It generates a very high
current which could cause the battery to overheat which may
result in electrolyte gel leakage, harmful fumes, or explosion.
The LIR tabs may easily short-circuit by placing them on con-
ductive surface. A short circuit may lead to heat build up and
damage of the battery. An appropriate circuitry with PCM is
employed to protect accidental short circuit of the battery pack.
1.2 Mechanical shock
Droping the unit, impact hit, bending, etc. may cause failure or
shortend life of the LIR battery.
3. Other
3.1 Battery connection
1). Direct soldering of wire leads or devices to the battery is
strictly prohibited.
2). Lead tabs with pre-soldered wiring shall be spot welded to
the batteries. Direct soldering may cause damage of compo-
nents, such as separator and insulator, by heat build up.
3.2 Prevention of short circuit within a battery pack
There is enough insulation layers between wiring and the bat-
teries to provide extra safety protection. The battery pack is
constructed in a way that no short circuit will occur which may
cause smoke or re.
3.3 Do No Disassemble the Batteries
1). Never disassemble the batteries.
Doing this may cause a internal short circuit in the battery,
which may lead to harmful fumes, re, explosion, or other prob-
lems.
2). Electrolyte Gel is harmful
Electrolyte Gel should not leak from the LIR battery. Should the
electrolyte gel come into contact with the skin or eyes, ush the
WiFLY Bar QA5 Battery PrecautionsWiFLY Bar QA5 Safety Precautions
ADJ Products, LLC - www.adj.com - WiFLY Bar QA5 User Manual Page 4
• To reduce the risk of electrical shock or re, do not expose this unit
rain or moisture
• Do not spill water or other liquids into or on to your unit.
• Do not attempt to operate this unit if the power cord has been
frayed or broken. Do not attempt to remove or break o the ground
prong from the electrical cord. This prong is used to reduce the risk
of electrical shock and re in case of an internal short.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user
serviceable parts inside.
• Never operate this unit when it’s cover is removed.
• Never plug this unit in to a dimmer pack
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit, if it becomes damaged.
• This unit is intended for indoor use only, use of this product out`
doors voids all warranties.
• During long periods of non-use, disconnect the unit’s main power.
• Always mount this unit in safe and stable matter.
• Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them,
paying particular attention to the point they exit from the unit.
• Cleaning -The fixture should be cleaned only as recommended by
t he manufacturer. See page 30 for cleaning details.
• Heat -The appliance should be situated away from heat sources
such as radiators, heat registers, stoves, or other appliances (inclu-
d ing amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain or water.
D. The appliance does not appear to operate normally or exhibits a
marked change in performance.
CAUTION: This unit like any wireless device is highly susceptible
to static electricity. Static electricity can severly damage the unit.
Before touching the antenna, please ground/discharge yourself.

ADJ Products, LLC - www.adj.com - WiFLY Bar QA5 User Manual Page 7
life expectancy of the battery maybe shortened or the device
in which the battery is used may be damaged by electrolyte
gel leakage. If the batteries cannot maintain a charge for long
periods of time, even when they are charged correctly, this may
indicate it is time to change the battery.
6. Battery Disposal
Please dispose of battery according to local regulations.
WiFLY Bar QA5 Battery Precautions
ADJ Products, LLC - www.adj.com - WiFLY Bar QA5 User Manual Page 6
area of contact immediately with fresh water and seek medical
attention immediately.
3.4 Do Not Expose the Battery to Heat or Fire
Never incinerate or dispose of the batteries in re. This may
cause an explosion, which would be very dangerous.
3.5 Do Not Expose the Battery to water or liquids
Never soak/drop the batteries in liquids such as water, seawa-
ter, drinks such as soft drinks, juices, coee or other.
3.6 Battery Replacement
For battery replacement please contact ADJ customer support
[phone].
3.7 Do Not use a damaged Battery
The battery could be damaged during shipping, caused by
shock. Should the battery be found damaged, including dam-
ages to the plastic casing of the battery, deformation of the
battery package, smelling of an electrolyte, or leakage of the
electrolyte gel, or other, DO NOT use the battery. A battery with
a odor of electrolyte or a gel leakage should be placed away
from re to avoid re or explosion.
4. Battery Storage
When storing the battery, it should be stored at room tempera-
ture, with a charge of at least 50%. We recommend that during
long periods of storage that the battery be charged every 6
months. Doing this will prolong the life of the battery and will
also make sure that the battery charge does not fall below the
30% mark.
5. Other Chemical Reaction
Because batteries utilize a chemical reaction, battery per-
formance will deteriorate over time even if stored for a long
period of time without being used. In addition, if the various
usage conditions such as charge, discharge, ambient tempera-
ture, etc. are not maintained within the specied ranges, the
WiFLY Bar QA5 Battery Precautions

ADJ Products, LLC - www.adj.com - WiFLY Bar QA5 User Manual Page 9
Notice: Be sure to follow gures two and three when making your own
cables. Do not use the ground lug on the XLR connector. Do not con-
nect the cable’s shield conductor to the ground lug or allow the shield
conductor to come in contact with the XLR’s outer casing. Grounding
the shield could cause a short circuit and erratic behavior.
WiFLY Bar QA5 Set Up
DMX512 IN
3-PIN XLR
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
DMX512
DMX+,DMX-,COMMON
1
2
3
Termination reduces signal errors and
avoids signal transmission problems
and interference. It is always advisable
to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)
and PIN 3 (DMX +) of the last fixture.
1
2
3
1
2
3
DMX +
DMX -
COMMON
DMX512 OUT
3-PIN XLR
Figure 2
Figure 3
1 Ground 1 Ground
XLR Male Socket
XLR Pin Conguration
3 Hot
2 Cold 2 Cold
3 Hot
XLR Female Socket
Pin 3 = Data True (positive)
Pin 2 = Data Compliment (negative)
Pin 1 = Ground
Special Note: Line Termination. When longer runs of cable are
used, you may need to use a terminator on the last unit to avoid erratic
behavior. A terminator is a 110-120 ohm 1/4 watt resistor which is con-
nected between pins 2 and 3 of a male XLR connector (DATA + and
DATA -). This unit is inserted in the female XLR connector of the last
unit in your daisy chain to terminate the line. Using a cable terminator
(ADJ part number Z-DMX/T) will decrease the possibilities of erratic
behavior.
DMX512 IN
3-PIN XLR
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
DMX512
DMX+,DMX-,COMMON
1
2
3
Termination reduces signal errors and
avoids signal transmission problems
and interference. It is always advisable
to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)
and PIN 3 (DMX +) of the last fixture.
1
2
3
1
2
3
DMX +
DMX -
COMMON
DMX512 OUT
3-PIN XLR
Figure 4
5-Pin XLR DMX Connectors. Some manufactures use 5-pin DMX-
512 data cables for DATA transmission in place of 3-pin. 5-pin DMX
xtures may be implemented in a 3-pin DMX line. When inserting stan-
dard 5-pin data cables in to a 3-pin line a cable adaptor must be used,
these adaptors are readily available at most electric stores. The chart
below details a proper cable conversion.
Conductor 5-Pin XLR Male (In)3-Pin XLR Female (Out)
Pin 1
Do Not Use
Do Not Use
Pin 3
Pin 2
Pin 1
Pin 3
Pin 2
Not Used
Not Used
Data True (+ signal)
Data Compliment (- signal)
Ground/Shield
3-Pin XLR to 5-Pin XLR Conversion
ADJ Products, LLC - www.adj.com - WiFLY Bar QA5 User Manual Page 8
Power Supply: The ADJ WiFLY Bar QA5 contains a automatic volt-
age switch, which will auto sense the voltage when it is plugged into
the power source. With this switch there is no need to worry about the
correct power voltage, this unit can be plugged in anywhere.
DMX-512: DMX is short for Digital Multiplex. This is a universal pro-
tocol used as a form of communication between intelligent fixtures
and controllers. A DMX controller sends DMX data instructions from
the controller to the fixture. DMX data is sent as serial data that trav-
els from fixture to fixture via the DATA “IN” and DATA “OUT” XLR ter-
minals located on all DMX fixtures (most controllers only have a DATA
“OUT” terminal).
DMX Linking: DMX is a language allowing all makes and models of
dierent manufactures to be linked together and operate from a single
controller, as long as all xtures and the controller are DMX compli-
ant. To ensure proper DMX data transmission, when using several
DMX fixtures try to use the shortest cable path possible. The order
in which fixtures are connected in a DMX line does not influence the
DMX addressing. For example; a fixture assigned a DMX address of 1
may be placed anywhere in a DMX line, at the beginning, at the end,
or anywhere in the middle. When a fixture is assigned a DMX address
of 1, the DMX controller knows to send DATA assigned to address 1
to that unit, no matter where it is located in the DMX chain.
Data Cable (DMX Cable) Requirements (For DMX Operation):
The WiFLY Bar QA5 can be controlled via DMX-512 protocol. The WiFLY
Bar QA5 has 6 DMX channel modes, please see page 12-13 for the dif-
ferent modes. The DMX address is set on the back panel of the WiFLY
Bar QA5. Your unit and your DMX controller require a standard 3-pin XLR
connector for data input and data output (Figure
1). We recommend Accu-Cable DMX cables.
If you are making your own cables, be sure to
use standard 110-120 Ohm shielded cable (This
cable may be purchased at almost all pro lighting
stores). Your cables should be made with a male
and female XLR connector on either end of the
cable. Also remember that DMX cable must be
daisy chained and cannot be split.
WiFLY Bar QA5 Set Up
Figure 1

ADJ Products, LLC - www.adj.com - WiFLY Bar QA5 User Manual Page 11
WiFLY Bar QA5 Operating Instructions
Static Color Mode:
1. Press the MODE button until “CO.XX” is displayed.
2. There are 15 colors to choose from. Select your desired color by
pressing the UP and DOWN buttons. After you have selected your
desired color you can activate strobing by pressing the SET UP but-
ton to enter the Flash (strobe) mode.
3. “FS.XX” will be displayed, this is Flash mode. The Flash can be
adjusted between “FS.00” (flash off) to “FS.15” (fastest flash).
RGBA Dimmer Mode:
1. Press the MODE button until:
2. When “r.XXX” is displayed you are in Red dimming mode. Press the
UP and DOWN buttons to adjust intensity.
3. When “G.XXX” is displayed you are in Green dimming mode.
Press the UP and DOWN buttons to adjust intensity.
4. When “b.XXX” is displayed you are in Blue dimming mode. Press
the UP and DOWN buttons to adjust intensity.
5. When “U.XXX” is displayed you are in Amber dimming mode.
Press the UP and DOWN buttons to adjust intensity.
6. After you have adjusted the RGBA colors to make your desired
color you can then activate strobing by pressing the SET UP but-
ton to enter the Flash (strobe) mode.
7. “FS.XX” will be displayed, this is Flash mode. The Flash can be
adjusted between “FS.00” (flash off) to “FS.15” (fastest flash).
Built-In Program Mode:
1. Press the MODE button until “Pr.XX” is displayed. “XX” represents
a number from 1-22. Use the UP or DOWN buttons to scroll through
the 22 programs. Programs 21 and 22 have adjustable colors. Once
you have found your desired program press the SET UP button.
2. Pressing the SET UP button will display “SP.XX”. When this is dis-
played you can adjust the running speed of your desired program.
Use the UP or DOWN button to adjust the speed between “SP.01”
(slowest) and “SP.99” (fastest). Once you have set your desired run-
ning speed, you can press the SET UP button to to enter the Fade
adjustment mode.
2. Pressing the SET UP button will display “Fd.XX”. When this is dis-
played you can adjust the fade speed of your desired program.
Use the UP or DOWN button to adjust the speed between “Fd.01”
(fastest) and “Fd.99” (slowest) or “Fd.00” (Off). Once you have set
your desired fade speed, you can press the SET UP button to to
WiFLY Bar QA5 Operating Instructions
Operating Power:
There are two ways to supply power to this unit; battery power or AC
power.
• AC Power - To run the unit using AC power, plug the unit into a power
source, and put the Load Switch into the ON position. When using AC
power make sure the Battery Switch is in the OFF position.
• Battery Power - To run the unit using Battery power, put the Load and
Battery Switches in the ON position.
LED Display On/Off:
To set the LED display to turn off after 60 seconds, press the MODE but-
ton until “don” is displayed, press the UP button to display “doff”. Now
the display will disappear after 60s. Press any button to turn the display
on again. Be advised though that the display will turn off automatically
after 10 seconds.
To set the display press the MODE button until “dXX” is displayed. Use
the UP or DOWN buttons to select either:
“don” = LED display on at all times.
“doFF” = LED display shuts off after 60 seconds.
LED Display Inversion:
Follow these instructions to flip the display 180°so that the display can
be read upside down.
1. Press the MODE button until “dXX” is displayed. “XX” represents
either “on” or “oFF”.
2. Press the SET UP button until “Stnd” or “rev” is displayed.
3. Press the UP or DOWN buttons to reverse the display 180°.
Operating Modes:
The WiFLY Bar QA5 has five operating modes:
• Static Color Mode - There are 15 colors to choose from.
• RGBA Mode - Choose one of the four colors to remain static or adjust
the intensity of each color to make your desired color.
• Built-In Program - There are 22 built-in programs to choose from.
• Auto Mode - A auto program will run with adjustable fade speed.
• Sound-Active mode - The unit will react to sound, chasing through the
built in programs.
• DMX control mode - This function will allow you to control each
individual fixtures traits with a standard DMX 512 controller.
ADJ Products, LLC - www.adj.com - WiFLY Bar QA5 User Manual Page 10

ADJ Products, LLC - www.adj.com - WiFLY Bar QA5 User Manual Page 13
WiFLY Bar QA5 Operating Instructions
18-25 for each modes’ DMX traits.
1. This function will allow you to control each individual fixture’s traits
with a standard DMX 512 controller.
2. To run your fixture in DMX mode press the MODE button until
“d.XXX” is displayed. “XXX” represents the current displayed ad-
dress. Use the UP or DOWN buttons to select your desired DMX
address. then press the SET UP button to select your DMX Channel
mode.
3. When you press SET UP “ChXX” should be displayed. “XX” repre-
sent the current DMX Channel Mode.
4. Use the UP or DOWN buttons to scroll through the DMX Channel
modes. The Channel modes are listed below:
• To run the 4 Channel Mode, press the MODE button until “Ch04” is
displayed.
• To run the 6 Channel Mode, press the MODE button until “Ch06” is
displayed.
• To run the 7 Channel Mode, press the MODE button until “Ch07” is
displayed.
• To run the 8 Channel Mode, press the MODE button until “Ch08” is
displayed.
• To run the 9 Channel Mode, press the MODE button until “Ch09” is
displayed.
• To run the 22 Channel Mode, press the MODE button until “Ch22” is
displayed.
5. Please see pages 18-25 for DMX values and traits.
6. After you have chosen your desired DMX Channel mode plug in the
fixture via the XLR connections to any standard DMX controller.
DMX State:
This mode can be used as a precaution mode, that in case the DMX signal
is lost, the operating mode chosen in the setup is the running mode the
xture will go into when the DMX signal is lost. You can also set this as the
operating mode you would like the unit to return to when power is applied.
1. Press the MODE button until “d.XXX” is displayed. “XXX” represents
the current displayed DMX address.
2. Press the SET UP button so that “nodn” is displayed. Use the UP
and DOWN buttons to scroll through the DMX states.
• “bLAC” (Blackout) - If the DMX signal is lost or interrupted, the unit
will automatically go into stand by mode.
• “LASt” (Last State) - If the DMX signal is lost or interrupted, the xture
ADJ Products, LLC - www.adj.com - WiFLY Bar QA5 User Manual Page 12
WiFLY Bar QA5 Operating Instructions
enter the Flash (Strobe) mode.
3. After pressing SET UP, “FS.XX” will be displayed, this is Flash mode.
The Flash can be adjusted between “FS.00” (flash off) to “FS.15”
(fastest flash).
• PROGRAMS 21 & 22 - If you have chosen programs 21 or 22, after
the Flash mode, press the SET UP button. “C1.XX” will be displayed.
This is the base color, use the UP and DOWN buttons to scroll
through the 15 colors. Once you have chosen your base color, press
the SET UP button again so that“C2.XX” is displayed. This is the
moving color, use the UP and DOWN buttons to scroll through the 15
colors.
Sound Active Mode:
In this mode the WiFLY Bar QA5 will react to sound, and chase through
the different colors.
1. Press the MODE button until “SU.XX” is displayed. “XX” represents
the sound sensitivity level (0-31) currently displayed.
2. The fixture will now change via sound.
3. Press the SET UP button to enter the Flash (strobe) mode.
4. “FS.XX” will be displayed, this is Flash mode. The Flash can be
adjusted between “FS.00” (flash off) to “FS.15” (fastest flash).
Auto Run Mode:
In this mode the WiFly Bar QA5 will run a auto program.
1. Press the MODE button until “AUTO” is displayed.
2. After you have activated Auto Run mode, press the SET UP button to
adjust the fade time.
3. Once you press SET UP “Fd.XX” should be displayed. Use the UP or
DOWN buttons to set the fade speed to either “Fd.00” (fade off) or
between “Fd.01” (fastest speed) and “Fd.99” (slowest speed). After
adjusting the fade speed, press SET UP if you wish to activate the
Flash mode.
4. “FS.XX” will now be displayed, this is Flash mode. The Flash can be
adjusted between “FS.00” (flash off) to “FS.15” (fastest flash).
DMX Mode:
Operating through a DMX controller gives the user the freedom to create
their own programs tailored to their own individual needs. This function
also allows you to use your fixtures as spot lights. The WiFLY Bar QA5
has 6 DMX modes: 4 Channel mode, 6 Channel mode, 7 Channel mode,
8 Channel mode, 9 Channel mode, and a 22 Channel mode, See pages

ADJ Products, LLC - www.adj.com - WiFLY Bar QA5 User Manual Page 15
WiFLY Bar QA5 Master-Slave Configuration
Master-Slave Configuration:
This function will allows you to link units together to run in a Master-
Slave mode. In a Master-Slave set up one unit will act as the controlling
unit and the others will react to the controlling units built-in programs.
Any unit can act as a Master or as a Slave however, only one unit can be
programmed to act as the “Master.”
Master-Slave Connections and Settings:
1. Daisy chain your units via the XLR connector on the rear of the unit.
Use standard XLR data cables to link your units together. Remember
that the Male XLR connector is the input and the Female XLR con-
nector is the ouput. The first unit in the chain (master) will use the
female XLR connector only. The last unit in the chain will use the
male XLR connector only.
2. Set the “Master” unit to your desired mode of operation.
3. On the “Slave” units press the MODE button until “SLAu” is dis-
played. The unit is now set as the “Slave” unit. Each slave unit must
be set to the same setting.
4. Connect the rst “Slave” unit to the “Master”, and the “Slave” unit
should now start follow the “Master”.
With this feature you can connect the xtures to one another using
the IEC input and output sockets. The quantity that can be con-
nected is 10 xtures maximum. After 10 xtures you will need to use
a new power outlet. They must be the same xtures. DO NOT mix
xtures.
NOTE: Fixtures cannot be power cord daisy chained and run by bat-
tery power.
WiFLY Bar QA5 Power Cord Daisy Chain
their respective beginning and ending fade times.
Default Mode:
This is a default mode. When this mode is activated all mode’s will return
to their default settings.
1. Press the MODE button until “dXX” is displayed.
2. Press the SET UP button until “dEFA” is displayed.
3. Press the UP and DOWN buttons simultaneously. Press the MODE
button to exit.
WiFLY Bar QA5 Operating Instructions
ADJ Products, LLC - www.adj.com - WiFLY Bar QA5 User Manual Page 14
will stay in the last DMX set up. If power is applied and this mode is
set, the unit will automatically go into the last DMX set up.
• “ProG” (Auto Run) - If the DMX signal is lost or interrupted,
the unit will automatically go into Auto Run mode.
3. Use the UP and DOWN buttons to nd your desired DMX state and
press SET UP to conrm and exit.
Battery Life:
This menu is used to check/display the battery life.
1. Plug the fixture in and press the MODE button until “bXXX” is dis
played. “XXX” represents a number between 0-100. The number that
is displayed is the remaining battery life. If “b---” is displayed, it
means either the battery is dead or your running the unit on AC
power.
ADJ RFC:
This function is used to activate and deactivate the ADJ RFC (Remote
Control). When this function is activated you can control the fixture
using the ADJ RFC. Please see the next page for ADJ RFC controls
and functions.
1. Plug the fixture in and press the MODE button until “dXX” is dis-
played.
2. Press the SET UP button until “rFXX” is displayed. “XX” repre-
sents either “on” or “oF”.
3. Press the UP or DOWN buttons to either activate the remote func-
tion (On) or deactivate it (Off).
WiFLY Address:
This function is used to set the WiFly address. This address must match
the address that is set to WiFly TransCeiver or WiFly controller.
1. Plug the fixture in and press the MODE button until “rCXX” is dis-
played. “XX” represents a number between 00-14.
2. Press the UP or DOWN buttons to either activate the remote function
(On) or deactivate it (Off).
Dimmer Curve Setting:
1. Plug the fixture in and press the MODE button until “d.XXX” is dis-
played. Now press the SET UP button until “dr-X” is displayed,
“X” representing a number between 0-4.
2. There are 5 dimmer curve settings to choose from. Please see the
Dimmer Curve Diagram Chart on page 28 to see the settings and
WiFLY Bar QA5 Operating Instructions

ADJ Products, LLC - www.adj.com - WiFLY Bar QA5 User Manual Page 17
WiFLY Bar QA5 ADJ RFC Operation
The ADJ RFC remote (sold seperately) has many different functions and
allows you to control your WiFly Par QA5 from long distance. The ADJ
RFC remote can control your system up to 150 ft. To use the RFC you
must first activate the fixtures receiver, to activate the receiver please
see the instructions on page 14.
BLACKOUT - Pressing this button will blackout the fixture.
AUTO RUN -This button will run an automatic program. Press the
FLASH button once to enter Flash mode then use the “+” and “-” but-
tons to adjust the flash rate. Press the FLASH button again to enter Fade
time adjustment use the “+” and “-” buttons to adjust the fade time.
PROGRAM SELECTION - This button will activate 1 of 2 modes; Color
Select mode or Built-In Programs. Each press of this button will switch
between the two modes.
1. In Color Select mode. Use the “+” or “-” to scroll through the 15 col-
ors. Once you have found your color, you can press the Flash Button to
activate strobing and use the “+” or “-” to adjust the Flash rate.
2. In Built-In Program mode. Use the “+” or “-” to scroll through the built-
in programs. Once you have found your desired program and you can
press the SPEED button and then use the “+” and “-” buttons to adjust
the program speed. You can press the Flash Button to activate strobing
and use the “+” or “-” to adjust the Flash rate. Press the FLASH button
again to enter Fade time and use the “+” and “-” buttons to adjust the
fade speed.
FLASH - This button will activate the flash (strobe) effect or fade time
adjustment. You can control the flash speed by pressing the “+” and “-”
buttons.
SPEED - Press this button and use the “+” & “-” buttons to adjust the
speed of the Auto run and Programs.
SOUND ACTIVE - This button activates sound active mode. Use the “+”
or “-” to adjust the sound sensitivity.
R G B W/A - Press either one of these buttons and the press the “+” or
“-” to adjust the brightness.
“+” and “-” - Use these buttons to adjust the flash rate, fade time adjust-
ment, speed of the Auto Run and Program, sound sensitivity, and color
select.
ADJ Products, LLC - www.adj.com - WiFLY Bar QA5 User Manual Page 16
WiFLY Bar QA5 WiFly Set Up
WiFLY Bar QA5 WiFly Master-Slave Set Up
With this feature you are able to control the unit with DMX without the need of
XLR cables. Your DMX controller must be connected to a ADJ WiFly TransCeiver
to use this function. You are able to communicate up to 400 feet (open line of
sight).
NOTE: The ADJ RFC control must be set to OFF to use this function. See
pages 13-14 to turn OFF ADJ RFC.
1. Turn on the WiFly function using the WiFly On/Off switch and set the anten-
na to either a up position or down position.
2. Follow the instructions on page 14 to set the Wireless address. The address
must match the address set on the WiFly Transceiver.
3 After you have set the WiFly address, follow the DMX instructions on pages
12-13 to select your desired DMX Channel mode and set your DMX address.
4. Apply power to the ADJ WiFly Transceiver. The fixture must be set up first
before you apply power to WiFly Transceiver.
5. If everything is set up properly and the fixture is receiving a Wireless signal,
Wireless status LED next to LED screen will glow green.
Note: If the sync does not work, switch the WiFly power off then on again.
This feature will let you link units to run in a master-slave mode without the use
of XLR cables.
NOTE: The ADJ RFC control must be set to OFF on all the units to use this
function. See pages 13-14 to turn OFF ADJ RFC.
1. Follow the instructions on page 14 to set the Wireless address. The address-
es on each fixture must be the same.
2. After you have set the WiFly address, select your master unit and set your
desired operating mode.
3. Put the antenna in either a up position or down position then turn the WiFly
On, using the WiFly power switch.
Note: All antennas must be in the same position, they must either be all up or all
down, but never at an angle.
4. For the Slave units, put the unit in Slave mode. See page 15 Master-Slave
configuration when setting the unit as a Slave. Then switch ON the WiFly
power switch.
5. If everything is set up correctly, the Master units WiFly status LED will glow
orange, and the slave units Wireless status LED will glow green.
NOTE: If they do not sync up master-slave, switch the Master fixtures WiFly
power switch off then on again.

ADJ Products, LLC - www.adj.com - WiFLY Bar QA5 User Manual Page 19
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 AMBER
0 - 255 0% - 100%
5 0 - 255 COLOR MACROS
(See the Color Macro Chart on page 25)
6 STROBING
0 - 15 NOTHING
16 - 255 STROBING SLOW - FAST
7 MASTER DIMMER
0 - 255 0% - 100%
WiFLY Bar QA5 7 Channels - DMX Values & Functions
Channels 1, 2, 3, and 4 will not work, when Channel 5 is being
used.
ADJ Products, LLC - www.adj.com - WiFLY Bar QA5 User Manual Page 18
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 AMBER
0 - 255 0% - 100%
5 STROBING
0 - 15 NOTHING
16 - 255 STROBING SLOW - FAST
6 MASTER DIMMER
0 - 255 0% - 100%
WiFLY Bar QA5 6 Channels - DMX Values & Functions
WiFLY Bar QA5 4 Channels - DMX Values & Functions
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 AMBER
0 - 255 0% - 100%
