ADLINK Technology cPCI-6930 User manual

Advance Technologies; Automate the World.
Manual Rev.: 2.02
Revision Date: November 13, 2014
Part No: 50-15080-1020
cPCI-6930
6U CompactPCI® Server Class Eight-Core
Intel® Xeon® E5 Processor Blade
User’s Manual

Revision History
Revision Release Date Description of Change(s)
2.00 2013/04/15 Initial release
2.01 2014/01/21 Add IPMI user’s guide
2.02 2014/11/13 Add PMC slot -12V support note

Preface iii
cPCI-6930
Preface
Copyright 2013-14 ADLINK Technology Inc.
This document contains proprietary information protected by copy-
right. All rights are reserved. No part of this manual may be repro-
duced by any mechanical, electronic, or other means in any form
without prior written permission of the manufacturer.
Disclaimer
The information in this document is subject to change without prior
notice in order to improve reliability, design, and function and does
not represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, spe-
cial, incidental, or consequential damages arising out of the use or
inability to use the product or documentation, even if advised of
the possibility of such damages.
Environmental Responsibility
ADLINK is committed to fulfill its social responsibility to global
environmental preservation through compliance with the Euro-
pean Union's Restriction of Hazardous Substances (RoHS) direc-
tive and Waste Electrical and Electronic Equipment (WEEE)
directive. Environmental protection is a top priority for ADLINK.
We have enforced measures to ensure that our products, manu-
facturing processes, components, and raw materials have as little
impact on the environment as possible. When products are at their
end of life, our customers are encouraged to dispose of them in
accordance with the product disposal and/or recovery programs
prescribed by their nation or company.
Trademarks
Product names mentioned herein are used for identification pur-
poses only and may be trademarks and/or registered trademarks
of their respective companies.

iv Preface
Using this Manual
Audience and Scope
The cPCI-6930 User’s Manual is intended for hardware
technicians and systems operators with knowledge of installing,
configuring and operating industrial grade computer systems.
Manual Organization
This manual is organized as follows:
Chapter 1, Introduction: Introduces the cPCI-6930, its features,
block diagrams, and package contents.
Chapter 2, Specifications: Presents detailed specification infor-
mation.
Chapter 3, Functional Description: Describes the cPCI-6930
main functions.
Chapter 4, Board Interfaces: Describes the cPCI-6930 board
interfaces.
Chapter 5, Getting Started: Describes the installation of compo-
nents to the cPCI-6930 and rear transition modules.
Chapter 6, Driver Installation: Provides information on how to
install the cPCI-6930 device drivers.
Chapter 7, Utilities: Describes the utilities of the cPCI-6930.
Chapter 8, BIOS Setup: Describes basic navigation for the AMI
BIOS setup utility.
Chapter 9, Checkpoints & Beep Codes: Describes the AMI
BIOS setup utility Checkpoints & Beep Codes.
Chapter 10, IPMI User Guide: Describes the Intelligent Platform
Management Interface (IPMI) specification rev. 1.5.
Important Safety Instructions: Presents safety instructions all
users must follow for the proper setup, installation and usage of
equipment and/or software.
Getting Service: Contact information for ADLINK’s worldwide
offices.

Preface v
cPCI-6930
Conventions
Take note of the following conventions used throughout this
manual to make sure that users perform certain tasks and
instructions properly.
NOTE:
NOTE:
Additional information, aids, and tips that help users perform
tasks.
CAUTION:
Information to prevent minor physical injury, component dam-
age, data loss, and/or program corruption when trying to com-
plete a task.
WARNING:
Information to prevent serious physical injury, component
damage, data loss, and/or program corruption when trying to
complete a specific task.

vi Preface
This page intentionally left blank.

Table of Contents vii
cPCI-6930
Table of Contents
Revision History...................................................................... ii
Preface.................................................................................... iii
List of Figures........................................................................ xi
List of Tables........................................................................ xiii
1 Introduction ........................................................................ 1
1.1 Overview.............................................................................. 1
1.2 Features............................................................................... 2
1.3 Block Diagram ..................................................................... 3
1.4 Product List.......................................................................... 4
1.5 Package Contents ............................................................... 5
2 Specifications..................................................................... 7
2.1 cPCI-6930 Blade Specifications .......................................... 7
2.2 I/O Connectivity ................................................................. 10
2.3 Power Requirements......................................................... 11
3 Functional Description .................................................... 15
3.1 Processors......................................................................... 15
3.2 Chipset............................................................................... 17
3.3 PMC/XMC Site................................................................... 17
3.4 Intel® Turbo Boost Technology......................................... 18
3.5 Intel® Hyper Threading Technology.................................. 18
3.6 TPM................................................................................... 19
3.7 Battery ............................................................................... 19
4 Board Interfaces............................................................... 21
4.1 cPCI-6930 Board Layout ................................................... 21
4.2 cPCI-6930 Assembly Layout ............................................. 22

viii Table of Contents
4.3 cPCI-6930 Front Panel ...................................................... 23
4.4 Connector Pin Assignments............................................... 24
4.5 Switches............................................................................. 37
5 Getting Started.................................................................. 39
5.1 CPU and Heatsink ............................................................. 39
5.2 2.5" SATA Drive Installation............................................... 40
5.3 CompactFlash Card Installation......................................... 47
5.4 CFast Card Installation ...................................................... 51
5.5 PMC/XMC Module Installation........................................... 54
5.6 Installing the cPCI-6930 to the Chassis............................. 59
6 Driver Installation.............................................................. 61
7 Utilities............................................................................... 63
7.1 Watchdog Timer................................................................. 63
7.2 Preboot Execution Environment (PXE).............................. 68
8 BIOS Setup........................................................................ 69
8.1 Starting the BIOS............................................................... 69
8.2 Main Setup......................................................................... 74
8.3 Advanced BIOS Setup....................................................... 75
8.4 Chipset Configuration ........................................................ 93
8.5 Boot Settings ..................................................................... 99
8.6 Security Setup.................................................................. 101
8.7 Save & Exit Menu ............................................................ 102
9 Checkpoints & Beep Codes........................................... 105
9.1 Checkpoint Ranges.......................................................... 105
9.2 Standard Checkpoints...................................................... 105
9.3 OEM-Reserved Checkpoint Ranges................................ 114
10IPMI User Guide .............................................................. 115
10.1 Introduction...................................................................... 115
10.2 Summary of Commands Supported by BMR-AVR-cPCI. 115

Table of Contents ix
cPCI-6930
10.3 OEM Commands Summary Table................................... 117
10.4 CompactPCI Address Map .............................................. 121
10.5 Communications with IPMC............................................. 122
10.6 IPMI Sensors List............................................................. 122
10.7 Relevant Documents ....................................................... 123
Important Safety Instructions............................................ 125
Getting Service.................................................................... 127

xTableofContents
This page intentionally left blank.

List of Figures xi
cPCI-6930
List of Figures
Figure 1-1: cPCI-6930 Functional Block Diagram..............................3
Figure 4-1: cPCI-6930 Board Layout ...............................................21
Figure 4-2: cPCI-6930 Assembly Layout .........................................22
Figure 4-3: cPCI-6930 Front Panel..................................................23

xii List of Figures
This page intentionally left blank.

List of Tables xiii
cPCI-6930
List of Tables
Table 2-1: cPCI-6930 Blade Specifications ......................................7
Table 2-2: cPCI-6930 I/O Connectivity ...........................................10
Table 4-1: cPCI-6930 Front Panel Status LED Descriptions..........23

xiv List of Tables
This page intentionally left blank.

Introduction 1
cPCI-6930
1 Introduction
1.1 Overview
The cPCI-6930 is a 6U CompactPCI® single board computer fea-
turing a single 32nm Intel® Xeon® Processor E5-2400 Series with
8/6/4-cores in LGA1356 socket mated with the Intel® C604 Series
Platform Controller Hub. The cPCI-6930 supports three channels
of DDR3-1333/1600 ECC registered SDRAM in three RDIMMs
channel up to total 48GB capacity. Graphics is provided by a Sili-
con Motion SM750 2D GPU supporting up to 1920x1440 resolu-
tion. Four front panel 10/100/1000BASE-T ports are provided by
the Intel® 82580EB Gigabit Ethernet controller.
The cPCI-6930 Series supports a 64bit/66MHz CompactPCI bus
with optional PMC site with 32/64-bit 133MHz PCI bus or
PCI-Express x8 XMC site. The 8HP cPCI-6930 provides four GbE
ports, one VGA port, three USB 2.0 ports, two USB 3.0 ports, one
DB-9 RS-232 serial port on the front panel. Onboard storage capa-
bilities include 4GB of soldered SATA NAND flash and a SATA 6
Gb/s port convertible to direct connector for an onboard 2.5" SATA
drive, CFast adapter, or CompactFlash adapter, with an onboard
2.5” SAS drive supported by BOM option (only 1
SATA/CFast/CF/SAS device supported).
A selection of optional Rear Transition Modules (RTM) provides
additional I/O functionality including two GbE ports for PICMG
2.16 support, USB 2.0 ports, PS/2 keyboard/mouse port, serial
ports, High Definition Audio, SATA ports, additional VGA/ DVI
interfaces (dependent on selected RTM), and optional CF or SD
socket. Up to eight SAS ports supporting hardware RAID via two
mini-SAS x4 connectors are available when mated with the
cPCI-R6200 RTM, and signals for two SAS ports are available on
J5 by BOM option.
For dense computing requirements, the cPCI-6930 supports oper-
ation in both a system slot and in a peripheral slot as a standalone
blade. The cPCI-6930 is compliant with the PICMG 2.9 specifica-
tion and supports system management functions based on the
Intelligent Platform Management Interface (IPMI) as well as hard-
ware monitoring of physical characteristics such as CPU and sys-
tem temperature, DC voltages and power status.

2Introduction
The cPCI-6930 is ideal for server-grade applications, providing
datacom equipment providers, system integrators, robust com-
puter makers and security sectors a flexible, cost-optimized solu-
tion for mission critical applications with a reliable, smooth path for
scalability and expansion.
1.2 Features
X6U CompactPCI® blade in 8HP width form factor
XSupports Intel® Xeon® Processor E5-2400 Series in
LGA1356 socket, up to 8-core Xeon® E5-2448L 1.8GHz,
20MB LLC
XIntel® C604 Platform Controller Hub
XThree channels of DDR3-1333/1600 ECC registered
SDRAM via three 240-pin RDIMM, up to 48GB
X64bit/66MHz CompactPCI® Interface based on PCI specifi-
cations, universal V(I/O)
XSupports Satellite Mode operation as a standalone blade in
peripheral slots
XOne 32/64-bit, 33/66/133MHz PMC or PCI-Express x8XMC
site
XTwo USB 3.0 ports via discrete controller
X4GB SATA NAND flash soldered onboard
XSATA 6 Gb/s direct connector for onboard 2.5" drive
XOptional CFast, CompactFlash or 2.5" SAS drive support
XEight general purpose user programmable LEDs on front
panel for (default Port 80 status)
XDual independent RGB outputs on front panel and rear I/O
XFour Gigabit Ethernet ports on front panel
XCompliant with PICMG 2.0, 2.1, 2.9, 2.16 standards
XInfineon SLB 9635 TT1.2 TPM support upon request

Introduction 3
cPCI-6930
1.3 Block Diagram
Figure 1-1: cPCI-6930 Functional Block Diagram
DMI
PCIe x4
Pericom
PI7C9X13
PMC1 XMC 1
PCIX
64b/133M
J1/J2 J3/J5
Intel® C600 PCH
Intel® Xeon® E5 Processor Family
2x USB 2.0
PCIe x4
PCIe x4
Pericom
PI7C9X13
USB 3.0
Intel
82580
USB 3.0
2
VGA
SSD
SATA
1
TPM
PCIe x4
LPC
COM1
2.5” HDD
SAS/
SATA
SM750
IPMC
IPMB 0/1
COM4
COM2/3
SATA 2/3/4
SAS1/2
PCI 64b/66M
BIOS
SPI
SIO
KB/MS
6x USB,
HDA,
5xGPIO,
RTC
PCIe x1
PCIe x8
GbE 1/2/3/4
CF/CFAST
PCIe x1
PCIe x8 vRAM
SATA0
82574
82574
2.16 2.16
RGB
DVI
RGB
vBIOS
vRAM
1x USB 2.0
Front Panel
DD3-1333/1600 RDIMM DD3-1333/1600 RDIMM DD3-1333/1600 RDIMM

4Introduction
1.4 Product List
Products included in the cPCI-6930 series are:
SBC
XcPCI-6930D: 8HP width (dual-slot) 6U CompactPCI blade
featuring single Intel® Xeon® processor with four/six/eight
cores in LGA1356 socket, three channel DDR3-1333/1600
ECC RDIMM, 4x GbE, 1x VGA, 3x USB 2.0, 2x USB 3.0, 1x
RS-232 COM, 4GB onboard NAND flash, SATA direct con-
nector for onboard 2.5" drive (optional CFast/CF/SAS sup-
port), PMC/XMC site
Rear Transition Module
XcPCI-R6002: 6U 4HP width RTM with DVI-I, 2x COM, 3x
USB, 2x GbE, 2x SATA
XcPCI-R6002D: 6U 8HP width RTM with DVI-I, 2x COM, 5x
USB, 2x GbE, 3x SATA, Mic-in, Line-out, PS/2 KB/MS
XcPCI-R6100: 6U 4HP width RTM with 4x GbE, 4x USB, 2x
SATA, VGA, PS/2 KB/MS, CF & SD sockets, (Supports only
3x GbE when mating with cPCI-6930)
XcPCI-R6110: 6U 4HP width RTM with 2x GbE, 4x USB, 3x
SATA, VGA, PS/2 KB/MS, CF, & SD sockets
XcPCI-R6200: 6U 8HP width RTM with 2x GbE, 2x COM, 6x
USB, DVI-I (VGA signal only), 3x SATA, Mic-in, Line-out,
PS/2 KB/MS, 8x SAS
XcPCI-R6700D: 6U 8HP width RTM with onboard ATI E4690
GPU, 2x DVI-I, 2x GbE, 2x COM, 6x USB, Mic-in, Line-in,
Line-out, onboard PS/2 KB/MS, 3x SATA
Adapter Kits
XDB-CFast: CFast socket kit for cPCI-6930, including
adapter board and mounting hardware
XDB-6920CF-H: CompactFlash socket kit for cPCI-6930,
including adapter board, card guide and mounting hardware
XDB-SAS: 2.5" SAS drive adapter kit for cPCI-6930 including
adapter board and mounting hardware (requires BOM
option)

Introduction 5
cPCI-6930
1.5 Package Contents
The cPCI-6930 is packaged with the following components. If any
of the items on the contents list are missing or damaged, retain the
shipping carton and packing material and contact the dealer for
inspection. Please obtain authorization before returning any prod-
uct to ADLINK. The packing contents of the cPCI-6930 are
non-standard configurations and may vary depending on customer
requests.
Processor Blade
XcPCI-6930
ZCPU and memory specifications will differ depending on
options selected
ZThermal module is assembled on the board
X2.5" SATA drive accessory pack
XADLINK All-in-One DVD
XUser’s manual
Optional Accessories
XDB-CFast: CFast socket kit for cPCI-6930, including
adapter board and mounting hardware
XDB-6920CF-H: CompactFlash socket kit for cPCI-6930,
including adapter board, card guide and mounting hardware
XDB-SAS: 2.5" SAS drive adapter kit for cPCI-6930 including
adapter board and mounting hardware (requires BOM
option)
NOTE:
NOTE:
The contents of non-standard cPCI-6930 configurations may
vary depending on the customer’s requirements.
CAUTION:
This product must be protected from static discharge and phys-
ical shock. Never remove any of the components except at a
static-free workstation. Use the anti-static bag shipped with the
product when putting the board on a surface. Wear an
anti-static wrist strap properly grounded on one of the system's
ESD ground jacks when installing or servicing system compo-
nents.

6Introduction
This page intentionally left blank.
