ADLINK Technology AmITX-AL-I User manual

Leading EDGE COMPUTING
AmITX-AL-I
User’s Manual
Thin Mini-ITX Embedded Motherboard with
Intel®Atom™, Pentium®, and Celeron®SoC
Manual Revision: 0.10 preliminary
Revision Date: April 6, 2017
Part Number: 50-1J087-1000

AmITX-AL-I
2
Leading EDGE COMPUTING
Revision History
Revision Description Date By
0.10 Preliminary release 2017-04-06 JC

AmITX-AL-I
3
Leading EDGE COMPUTING
Preface
Copyright 2017 ADLINK Technology, Inc.
This document contains proprietary information protected by copyright. All rights are reserved. No part of this manual may be reproduced by
any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.
Disclaimer
The information in this document is subject to change without prior notice in order to improve reliability, design, and function and does not
represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such
damages.
Environmental Responsibility
ADLINK is committed to fulfill its social responsibility to global environmental preservation through compliance with the European Union's
Restriction of Hazardous Substances (RoHS) directive and Waste Electrical and Electronic Equipment (WEEE) directive. Environmental
protection is a top priority for ADLINK. We have enforced measures to ensure that our products, manufacturing processes, components, and
raw materials have as little impact on the environment as possible. When products are at their end of life, our customers are encouraged to
dispose of them in accordance with the product disposal and/or recovery programs prescribed by their nation or company.
AmITX-AL-I is a RoHS compliant and lead-free product
Trademarks
Product names mentioned herein are used for identification purposes only and may be trademarks and/or registered trademarks of their
respective companies.

AmITX-AL-I
4
Leading EDGE COMPUTING
Table of Contents
Revision History ............................................................................................................ 2
Preface............................................................................................................................ 3
1. Introduction .......................................................................................................... 7
1.1. Packing List ............................................................................................................................8
1.2. Optional Accessories .............................................................................................................8
2. Specifications........................................................................................................ 9
2.1. Core System...........................................................................................................................9
2.2. Rear I/O Connectors ..............................................................................................................9
2.3. Internal Headers and Connectors..........................................................................................9
2.4. Form Factor ........................................................................................................................ 10
2.5. SEMA Board Controller....................................................................................................... 10
2.6. Debug Header..................................................................................................................... 10
2.7. Video................................................................................................................................... 10
2.8. Audio................................................................................................................................... 10
2.9. LAN...................................................................................................................................... 10
2.10. Power Specification ............................................................................................................ 11
2.11. Temperatures ..................................................................................................................... 11
2.12. Environmental .................................................................................................................... 11
2.13. Operating Systems.............................................................................................................. 11
2.14. Functional Diagram............................................................................................................. 12
3. Mechanical Layout ............................................................................................. 13
3.1. Connector Locations ........................................................................................................... 13
3.1.1. Rear I/O .............................................................................................................................................13
3.1.2. Top Side Connectors..........................................................................................................................13
3.1.3. Bottom Side Connectors....................................................................................................................14
3.2. Mechanical Dimensions...................................................................................................... 15
4. Connectors and Jumpers ................................................................................... 16
4.1. Rear IO Connectors............................................................................................................. 16
4.1.1. DC Power Inlet...................................................................................................................................16
4.1.2. DisplayPort ........................................................................................................................................17
4.1.3. HDMI Connector................................................................................................................................17
4.1.4. Ethernet Connectors (LAN1, LAN2) ...................................................................................................18
4.1.5. USB 3.0 Connectors (USB1-4) ............................................................................................................18
4.1.6. Audio Connectors (Line-out, Mic-in) .................................................................................................19
4.2. Internal Connectors ............................................................................................................ 19

AmITX-AL-I
5
Leading EDGE COMPUTING
4.2.1. ATX Power Connector 4-pin (ATX_PWR1) .........................................................................................19
4.2.2. SATA Connectors (SATA1, SATA2, CN22-23) .....................................................................................20
4.2.3. SATA Power Connector (ST_PWR, CN24) ..........................................................................................20
4.2.4. USB 2.0 Header (CN17)......................................................................................................................21
4.2.5. PS/2 Keyboard and Mouse Connector (CN19) ..................................................................................22
4.2.6. Internal Audio Connector (CN16) ......................................................................................................22
4.2.7. CPU Fan and System Fan Connectors (CPU: CN36, SYS: CN37) .........................................................23
4.2.8. Serial COM Port Connectors (CN29-CN34)........................................................................................23
4.2.9. LVDS Connector (CN13).....................................................................................................................25
4.2.10. LVDS Auxiliary Connector (CN14) ....................................................................................................26
4.2.11. Front Panel Connector (CN27).........................................................................................................27
4.2.12. Feature Connector (CN28)...............................................................................................................28
4.2.13. SPI Header (CN40) ...........................................................................................................................29
4.2.14. DB40 Debug Board Connector.........................................................................................................30
4.3. Jumper and Switch Settings................................................................................................ 31
4.3.1. ATX/AT Mode Jumper Selection (JP1) ...............................................................................................31
4.3.2. Clear CMOS (JP6) ...............................................................................................................................31
4.3.3. SATA1/mSATA Select (JP11) ..............................................................................................................31
4.3.4. LVDS Backlight Power Jumper Selection (JP2)...................................................................................31
4.3.5. LVDS Panel Power Jumper Selection (JP3, JP5) .................................................................................32
4.3.6. LVDS Backlight Enable Jumper Selection (JP4) ..................................................................................32
4.3.7. Serial Port Mode Switch Setting (SW4, SW5)....................................................................................33
4.3.8. Serial Port Power Selection (JP7, JP8, JP9, JP10)...............................................................................33
4.3.9. BIOS Switch Setting (BSW1)...............................................................................................................34
4.4. Onboard Connector Information........................................................................................ 35
5. Smart Embedded Management Agent (SEMA) .............................................. 36
5.1. Board Specific SEMA Functions .......................................................................................... 36
5.1.1. Voltages.............................................................................................................................................36
5.1.2. Main Current .....................................................................................................................................37
5.1.3. BMC Status ........................................................................................................................................37
5.1.4. Exception Codes ................................................................................................................................37
5.1.5. BMC Flags ..........................................................................................................................................38
6. System Resources............................................................................................... 39
6.1. System Memory Map ......................................................................................................... 39
6.2. I/O Map............................................................................................................................... 39
6.2.1. I/O Map .............................................................................................................................................39
6.2.2. IRQ Lines PIC mode............................................................................................................................40
6.2.3. IRQ Lines APIC mode .........................................................................................................................41

AmITX-AL-I
6
Leading EDGE COMPUTING
6.3. PCI Configuration Space Map ............................................................................................. 42
6.4. PCI Interrupt Routing Map.................................................................................................. 43
6.5. SMBus Slave Address.......................................................................................................... 43
7. BIOS Setup .......................................................................................................... 44
7.1. Menu Structure................................................................................................................... 44
7.2. Main.................................................................................................................................... 45
7.2.1. BIOS Information ...............................................................................................................................45
7.2.2. System Information ...........................................................................................................................45
7.2.3. Board Information .............................................................................................................................46
7.2.4. System Date and Time.......................................................................................................................46
7.3. Advanced ............................................................................................................................ 47
7.3.1. CPU Configuration .............................................................................................................................47
7.3.2. Graphics Configuration......................................................................................................................49
7.3.3. Power Management..........................................................................................................................50
7.3.4. System Management.........................................................................................................................51
7.3.5. Thermal Management.......................................................................................................................52
7.3.6. Watchdog Timer ................................................................................................................................53
7.3.7. CSM Configuration.............................................................................................................................54
7.3.8. IT8783 Super IO Configuration ..........................................................................................................54
7.3.9. Serial Console Redirection.................................................................................................................55
7.3.10. USB ..................................................................................................................................................57
7.3.11. Network...........................................................................................................................................57
7.3.12. Miscellaneous..................................................................................................................................57
7.3.13. Trusted Computing..........................................................................................................................57
7.3.14. AMI Graphic Output Protocol Policy ...............................................................................................58
7.3.15. SDIO Configuration..........................................................................................................................58
7.4. Chipset ................................................................................................................................ 59
7.4.1. North Bridge ......................................................................................................................................59
7.4.2. South Bridge ......................................................................................................................................59
7.4.3. Uncore Configuration ........................................................................................................................60
7.4.4. South Cluster Configuration ..............................................................................................................61
7.5. Security ............................................................................................................................... 66
7.5.1. Password Description ........................................................................................................................66
7.6. Boot .................................................................................................................................... 66
7.6.1. Boot Configuration ............................................................................................................................66
Safety Instructions ...................................................................................................... 67
Getting Service ............................................................................................................ 68

AmITX-AL-I
7
Leading EDGE COMPUTING
1. Introduction
The AmITX-AL-I is a low-profile Thin Mini-ITX embedded board supporting an Intel®Atom™ processor E3900 series, Intel®Pentium®
processor N4200, and Intel®Celeron®processor N3350 system-on-chip (SoC). The AmITX-AL-I is specifically designed for customers who
need optimized processing and graphics performance with low power consumption in a long product life solution.
The Intel® Atom™ processor, Intel® Pentium® processor, and Intel® Celeron® processor support non-ECC type DDR3L dual-channel
memory at 1600/1867 MHz to provide excellent overall performance. Integrated Intel® Gen9 LP Graphics includes features such as OpenGL
4.3, DirectX 12, OpenCL 2.0; and support for H.265/HEVC, H.264, MPEG2, VC1, VP9, MVC, JPEG/MJPEG hardware decode. Up to three
independent displays are available from DDI ports supporting HDMI/DisplayPort, optional single/dual-channel 18/24-bit LVDS, and optional
eDP.
The AmITX-AL-I supports dual stacked SODIMM sockets for up to 16 GB non-ECC type DDR3L memory, and graphics outputs include
DisplayPort, HDMI, and optional eDP and optional dual-channel 18/24-bit LVDS. I/O features include HD Audio, dual Gigabit Ethernet port,
4x USB 3.0 ports and 3x USB 2.0 ports, 6x COM ports, PCIe x1 slot, Mini PCIe slot, mSATA slot, and 2x SATA 6 Gb/s ports. A feature
connector provides 10 GPIO, SMBus, and I2C, and optional SIM card slot and microSD card slot are available. The AmITX-AL-I is equipped
with SPI AMI EFI BIOS, supporting embedded features such as hardware monitor and watchdog timer.
The Thin Mini-ITX form factor is the “premier standard for designing and assembling all-in-one PCs,” according to Intel. Measuring 170 mm
square and less than 25 mm thick, Thin Mini-ITX fulfills requirements for applications in digital signage, infotainment, medical, and industrial
automation that are running in limited-space environments. ADLINK’s thin Mini-ITX board also follows the Form, Fit, Function design
principle to offer standardized pinout locations and is compatible with the Micro-ATX and regular ATX chassis. The AmITX-AL-I provides an
easy and fast path to creating industrial computing solutions.
Model Intel “Braswell” SoC Core Speed (HFM/Burst) Thermal Design
Power (TDP) Scenario Design Power (SDP)
AmITX-AL-I-E3950 Atom™ x7-E3950 (4 cores) 1.60/2.00 GHz 12W
AmITX-AL-I-E3940 Atom™ x5-E3940 (4 cores) 1.60/1.80 GHz 9.5W
AmITX-AL-I-E3930 Atom™ x5-E3930 (2 cores) 1.30/1.80 GHz 6.5W
AmITX-AL-I-N4200 Pentium® N4200 (4 cores) 1.10/2.50 GHz 6W 4W
AmITX-AL-I-N3350 Celeron® N3350 (2 cores) 1.10/2.40 GHz 6W 4W
Latest revision of the datasheet, user’s manual, BIOS, drivers, and board support packages, can be downloaded from the product webpage:
http://www.adlinktech.com/PD/web/PD_detail.php?cKind=&pid=1667#

AmITX-AL-I
8
Leading EDGE COMPUTING
1.1. Packing List
AmITX-AL-I Thin Mini-ITX Embedded Board
SATA dual power cable (P/N: 30-20875-0000)
SATA cable (P/N: 30-10057-0600)
Standard rear I/O shield (P/N: TBD)
1.2. Optional Accessories
COM port cable, 1 port (P/N: 30-20876-0000)
PS/2 KB/MS cable (P/N: 30-20873-0000)
USB 2.0 cable, 2 ports (P/N: 30-20874-1000)
Low profile rear I/O shield (P/N: TBD)

AmITX-AL-I
9
Leading EDGE COMPUTING
2. Specifications
2.1. Core System
zCPU: Dual or quad-core Intel® Atom™, Pentium®, and Celeron®Processor SoC
AtomTM x7-E3950 1.60/2.00 (Burst) GHz 12W (4C/1866)
AtomTM x7-E3940 1.60/1.80 (Burst) GHz 9.5W (4C/1866)
AtomTM x5-E3930 1.30/1.80 (Burst) GHz 6.5W (2C/1866)
Pentium®N4200 1.10/2.50 (Burst) GHz 6W (4W SDP) (4C/1866)
Celeron® N3350 1.10/2.40 (Burst) GHz, 6W (4W SDP) (2C/1866)
Supports: Dual or quad Out-of-Order Execution (OOE) processor cores, Intel® VT-x, Intel® VT-d, Intel® SSE4.1 and SSE4.2, Intel® 64
architecture, Intel® Turbo Boost Technology 2.0, Intel AES-NI, Intel® TXT, PCLMULQDQ instruction DRNG
Note: Availability of features may vary between processor SKUs and operating systems.
Note: Only Atom™ SKUs can support extreme temperature operating range.
zCache: 2MB for all SKUs
zMemory: Dual channel non-ECC 1600/1333 MHz DDR3L memory up to 8GB in dual stacked SODIMM sockets
zEmbedded BIOS: AMI EFI in 8MB SPI BIOS
2.2. Rear I/O Connectors
zDisplay: 1x DisportPort (2x DisplayPort by build option, in place of HDMI), 1x HDMI (co-lay with DP)
zLAN: Dual GbE RJ-45
zUSB: 4x USB 3.0
zAduio: Line-Out, Mic-In
zPower: Screw Jack for 12V DC-in
2.3. Internal Headers and Connectors
zPCIe x1 slot
z2x Mini PCIe slots: one PCIe + USB; one mSATA
zUSB: 2x USB 2.0 via onboard header, 1x USB 2.0 via front panel connector
zSATA: 2x SATA 6Gb/s (SATA0, SATA1)
zSATA Power Connector
zSerial: 2x RS-232/422/485 headers with 0V/5V/12V power, 4x RS-232 headers
zLVDS (optional): dual-channel 18/24-bit, switched from eDP (build option)
zeDP (optional): build option, not available concurrently with LVDS
zSIM Card slot (build option)
zmicroSD Card slot (build option)
zFront Panel Header
zAudio Header
zFeature Connector Header
zPS/2 KB/MS Connector
zTPM Header
zSPI Header
zATX Power Connector (4-pin)

AmITX-AL-I
10
Leading EDGE COMPUTING
2.4. Form Factor
zMini-ITX: 170mm x 170mm
2.5. SEMA Board Controller
zADLINK Smart Embedded Management Agent (SEMA)
Voltage/Current monitoring
Power sequence debug support
AT/ATX mode control
Logistics and Forensic information
Flat Panel Control
General Purpose I2C
Failsafe BIOS (dual BIOS )
Watchdog Timer and Fan Control
2.6. Debug Header
z40-pin Multipurpose Flat Cable Connector:, used in combination with DB-40 debug module providing BIOS POST code LED, BMC
access, SPI BIOS flashing, Power Testpoints, Debug LEDs
2.7. Video
zGPU Feature Support: Intel® 9th generation LP graphics core architecture with up to 18 execution units supporting three independent
displays
3D graphics hardware acceleration
Support for DirectX12/11.3/10/9.3, OCL 2.0, OGL ES 3.0, OGL 4.3
Video decode hardware acceleration including support for H.265 (HEVC), H.264, MVC, MPEG-2, VC-1, WMV9, VP8/VP9,
JPEG/MJPEG formats
Video encode hardware acceleration including support for H.265 (HEVC), H.264, VP8/VP9, JPEG/MJPEG formats
Supports content protection using PAVP 2.0 and HDCP 1.4/2.0
Note: Availability of features dependent on processor SKU and may vary between operating systems.
zDisplay Interface Support
DisplayPort: Supports DP1.2, maximum resolution: 4096x2160 @ 60Hz (2x DisplayPort by build option, in place of HDMI)
HDMI: Supports HDMI 1.4b, maximum resolution: 3840x2160 @ 30Hz (co-lay with DP)
LVDS (optional): Supports single/dual channel 18/24-bit, up to 1920x1200 @ 60 Hz
eDP (optional): Supports eDP 1.3, maximum resolution: 3840x2160 @ 60Hz
Note: The configuration of triple display support is DP + HDMI + LVDS/eDP (2x DP + LVDS/eDP by build option)
2.8. Audio
zAudio Codec: ALC888S
2.9. LAN
zIntel MAC/PHY: Intel® i211AT (MAC/PHY) Ethernet Controller (Intel® i210 by build option for extreme operating temperature range
support)
zInterface: 10/100/1000 GbE connection

AmITX-AL-I
11
Leading EDGE COMPUTING
2.10. Power Specification
zPower Modes: AT and ATX mode (AT mode start controlled by BMC)
zStandard Voltage Input: 12VDC ±5%
zPower Management: ACPI 4.0 compliant
zPower States: Supports C0, C1, C1E, C6C, C6, C7, S0, S1, S3, S4, S5 (Wake-on-USB S3/S4, WoL S3/S4/S5)
2.11. Temperatures
zStandard Operating Temperature: 0°C to 60°C
zExtreme Rugged Operating Temperature: -40°C to 85°C (build option, supported by Atom™ SKUs only)
2.12. Environmental
zHumidity: 10-90% RH operating, non-condensing
5-95% RH storage (and operating with conformal coating)
zShock and Vibration: IEC 60068-2-64 and IEC-60068-2-27
MIL-STD-202F, Method 213B, Table 213-I, Condition A and Method 214A, Table 214-I, Condition D
zHALT: Thermal Stress, Vibration Stress, Thermal Shock and Combined Test
2.13. Operating Systems
zStandard Support: Windows 10 Enterprise 64-bit, Linux 64-bit, (VxWorks 64-bit is TBD)
zExtended Support (BSP): Linux 64-bit, (VxWorks 64-bit is TBD)

AmITX-AL-I
12
Leading EDGE COMPUTING
2.14. Functional Diagram
TPM
(optional)
COM1
SIM
card slot
eDP to
LVDS
NXP
PTN3460IBS
Intel® Atom™
Celeron®
Pentium®
(formerly
“Apollo Lake”
“Apollo Lake-I”)
SoC
USB 2.0 port 2
USB 2.0 port 1
SEMA
TI
TM4C123
SMBus
GPIO
NXP PCA9535
CPU Fan
Feature Connector
System Signals
SPI 0/1
GPIO
SPI header
SYS Fan
RJ-45
10/100/1000
Line-out
Mic-in
Audio Header
HDMI
DP
(optional)
GbE
Intel I211AT
PCIe x1 Port 3
HDA
Codec
ALC888S
2x RS-232/422/485
0/5/12V
COM1, 2
Super
I/O
LPC
PS/2 MS/KB
PS/2
PCIe x1 slot
mSATA
full size
Mini PCIe
full size
USB 2.0
SATA
Switch
SATA
SATA SATA
SATA 0 6Gb/s
SATA 1 6Gb/s
1x USB 2.0
front panel header
USB 2.0
header
Horizontal SODIMM Low (Channel A)
DDR3L at 1867/1600 MHz (non ECC)
Horizontal SODIMM High (Channel B)
DDR3L at 1867/1600 MHz (non ECC)
USB 3.0 port 0, 1
PWM
switch
eDP
4 lanes
LVDS (eDP)
Single/Dual Channel
18/24-bit
LVDS control
LVDS AUX
Connector
DDC
PWM from SEMA BMC Brightness
GbE
Intel I211AT
LVDS Dat/Clk
4x RS-232
PCIe x1Port4
PCIe x1 port 2
SPI1
Sensor
LM73
LPC
microSD Card
DP
DDI0
DDI1
RJ-45
10/100/1000
USB 3.0 port 2, 3
SATA
USB 3.0
USB 3.0
USB 3.0
USB 3.0
PCIe x1 port 1
USB 2.0 port 3
COM2
COM3
COM4
COM5
COM6
Rear I/O
Internal I/O
eDP (optional)
SPI0 socket
(optional)

AmITX-AL-I
13
Leading EDGE COMPUTING
3. Mechanical Layout
3.1. Connector Locations
3.1.1. Rear I/O
3.1.2. Top Side Connectors
12V DC-in HDMI
DP Line-out
Mic-in
4x USB 3.0 DP
(optional)
Dual LAN
P
C
I
e
x1
mSATA Slot
2 Stacked
SODIMM
SATA
Mini PCIe
Front Panel
Connector
Audio
12V DC
-
in
6
x
RS
-
232
A
TX P
o
w
er
e
DP
S
PI
Soc
k
et
TPM Header
P
S/
2 KB
/
M
S
Feature
Connector
USB Header
LVD
S
System Fan
C
P
U
F
a
n
2x
S
ATA
SP
I
Header

AmITX-AL-I
14
Leading EDGE COMPUTING
3.1.3. Bottom Side Connectors
SIM Card
Slot
microSD
Card Slot
DB40 Connector

AmITX-AL-I
15
Leading EDGE COMPUTING
3.2. Mechanical Dimensions
Top View
Side View
Dimensions: mm

AmITX-AL-I
16
Leading EDGE COMPUTING
4. Connectors and Jumpers
See 3.1 Connector Locations on page 13 for connector locations.
4.1. Rear IO Connectors
4.1.1. DC Power Inlet
The AmITX-AL-I supports a screw-type external 12V DC-in power connector. Maximum current draw is 10A.
Note: Either the DC Power Inlet or the internal ATX Power Connector (ATX_PWR) must be used to supply the motherboard with +12V ±5%.
JACK1
PWR-JACK_P1
VCC 1
GND1 2
GND2 3
Caution:
Hot-plugging the power supply is not supported. Doing so may damage the board.
Only connect ONE power supply to the board. Connecting power to both the 12V
DC-inlet and the internal ATX Power Connector ma
y
dama
g
e the board.

AmITX-AL-I
17
Leading EDGE COMPUTING
4.1.2. DisplayPort
DisplayPort v1.2 specification ports up to 4096x2160 @ 60Hz (2x DisplayPort by build option, in place of HDMI)
Pin # Signal Pin # Signal
1 CN_DP0_P 2 Ground
3 CN_DP0_N 4 CN_DP1_P
5 Ground 6 CN_DP1_N
7 CN_DP2_P 8 Ground
9 CN_DP2_N 10 CN_DP3_P
11 Ground 12 CN_DP3_N
13 CN_CAD-L 14 CN_CEC
15 CN_AUX_P 16 Ground
17 CN_AUX_N 18 DDP_HPD
19 Ground 20 P3V3
4.1.3. HDMI Connector
Supports HDMI 1.4b, maximum resolution: 3840x2160 @ 30Hz (co-lay with DP)
Pin # Signal Pin # Signal
1 TMDS Data2+ 2 TMDS Data2 Shield
3 TMDS Data2– 4 TMDS Data1+
5 TMDS Data1 Shield 6 TMDS Data1–
7 TMDS Data0+ 8 TMDS Data0 Shield
9 TMDS Data0– 10 TMDS Clock+
11 TMDS Clock Shield 12 TMDS Clock–
13 CEC 14 Reserved
15 SCL 16 SDA
17 DDC/CEC Ground 18 +5 V Power
19 Hot Plug Detect
12
19 20

AmITX-AL-I
18
Leading EDGE COMPUTING
4.1.4. Ethernet Connectors (LAN1, LAN2)
Intel® i211AT (MAC/PHY) Ethernet controller (Intel® i210 is build option for extreme temperature operating range support)
Pin # 10BASE-T/100BASE-TX 1000BASE-T
1 TX+ LAN_MDI0+
2 TX- LAN_MDI0-
3 RX+ LAN_MDI1+
4 -- LAN_MDI2+
5 -- LAN_MDI2-
6 RX- LAN_MDI1-
7 -- LAN_MDI3+
8 -- LAN_MDI3-
LED1 (Speed) LED2 (Link/Activity)
Status Description Status Description
Off 10 Mb connection Off No Link
Green 100 Mb connection Orange Linked
Orange 1 Gb connection Blinking Data Activity
4.1.5. USB 3.0 Connectors (USB1-4)
Pin # Signal
1 USB3.0_P5VA
2 USB2_CMAN
3 USB2_CMAP
4 GND
5 USB3A_CMRXN
6 USB3A_CMRXP
7 GND
8 USB3A_CMTXN
9 USB3A_CMTXP

AmITX-AL-I
19
Leading EDGE COMPUTING
4.1.6. Audio Connectors (Line-out, Mic-in)
Audio Codec: Realtek ALC888S
Jack Contact Signal
Tip FRONT-OUT-L
Ring FRONT-OUT-R
Line-out
Sleeve GND
Tip MIC1-L
Ring MIC1-R
Mic-in
Sleeve GND
Note: Shared with onboard Audio Header; un-amplified codec output.
4.2. Internal Connectors
4.2.1. ATX Power Connector 4-pin (ATX_PWR1)
AmITX-AL-I supports a proprietary internal ATX Power Connector (4-pin).
Note: Either the DC Power Inlet or the internal ATX Power Connector (4-pin) must be used to supply the motherboard with +12V ±5%.
Pin # Signal
1 GND
2 GND
3 +12V DC
4 +12V DC
CAUTION
Only connect ONE power supply to the board. Connecting power to both the 12V DC-inlet and the internal ATX Power
Connector may damage the board.

AmITX-AL-I
20
Leading EDGE COMPUTING
4.2.2. SATA Connectors (SATA1, SATA2, CN22-23)
Two SATA ports are available on the AmITX-AL-I and support SATA Gen3 (6.0/3.0/1.5Gb/s).
Note: If mSATA is installed, SATA1 is disabled. See 4.3.3 SATA1/mSATA Select (JP11).
Pin # Signal
1 GND
2 TXP
3 TXN
4 GND
5 RXN
6 RXP
7 GND
4.2.3. SATA Power Connector (ST_PWR, CN24)
Pin # Signal
1 12V
2 GND
3 5V
4 GND
5 3.3V
SATA Power Cable: ADLINK Part. No.: 30-20875-0000 (length 200 mm)
5 4 3 2 1
HDD/SSD
P
o
w
er
Motherboard
SATA Power
Connector
HDD/SSD
Power
