ADLINK Technology NuPRO-A40H User manual

Advance Technologies; Automate the World.
Manual Rev.: 2.00
Revision Date: September 11, 2013
Part No: 50-13072-1010
NuPRO-A40H
Full-Size PICMG 1.0 Intel® Core™ i7/i5/i3
LGA1155 SHB
User’s Manual

ii Revision History
Revision History
Revision Release Date Description of Change(s)
1.00 2013/07/19 Preliminary release
2.00 2013/09/11 Initial release (add BIOS, WDT, system
resources)

Preface iii
NuPRO-A40H
Preface
Copyright 2013 ADLINK Technology, Inc.
This document contains proprietary information protected by copy-
right. All rights are reserved. No part of this manual may be repro-
duced by any mechanical, electronic, or other means in any form
without prior written permission of the manufacturer.
Disclaimer
The information in this document is subject to change without prior
notice in order to improve reliability, design, and function and does
not represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, spe-
cial, incidental, or consequential damages arising out of the use or
inability to use the product or documentation, even if advised of
the possibility of such damages.
Environmental Responsibility
ADLINK is committed to fulfill its social responsibility to global
environmental preservation through compliance with the Euro-
pean Union's Restriction of Hazardous Substances (RoHS) direc-
tive and Waste Electrical and Electronic Equipment (WEEE)
directive. Environmental protection is a top priority for ADLINK.
We have enforced measures to ensure that our products, manu-
facturing processes, components, and raw materials have as little
impact on the environment as possible. When products are at their
end of life, our customers are encouraged to dispose of them in
accordance with the product disposal and/or recovery programs
prescribed by their nation or company.
Trademarks
Product names mentioned herein are used for identification pur-
poses only and may be trademarks and/or registered trademarks
of their respective companies.

iv Preface
Using this Manual
Audience and Scope
The NuPRO-A40H User’s Manual is intended for hardware
technicians and systems operators with knowledge of installing,
configuring and operating industrial grade single board computers.
Manual Organization
This manual is organized as follows:
Preface: Presents important copyright notifications, disclaimers,
trademarks, and associated information on the proper understand-
ing and usage of this document and its associated product(s).
Chapter 1, Introduction: Introduces the NuPRO-A40H, its fea-
tures, applications, and specifications, including functional
descriptions and board layout.
Chapter 2, Hardware Information: Provides technical informa-
tion on connectors and jumpers for configuring the NuPRO-A40H.
Chapter 3, Getting Started: Illustrates how to install components
on the NuPRO-A40H such as CPU, heatsink, and memory mod-
ules.
Chapter 4, Driver Installation: Provides information on how to
install the NuPRO-A40H device drivers.
Chapter 5, BIOS Setup: Describes basic navigation for the
AMIBIOS®8 BIOS setup utility.
Appendix A, Watchdog Timer: Presents information on imple-
menting the watchdog timer.
Appendix B, System Resources: Presents information on I/O
mapping, IRQ routing, and resource allocation.
Important Safety Instructions: Presents safety instructions all
users must follow for the proper setup, installation and usage of
equipment and/or software.
Getting Service: Contact information for ADLINK’s worldwide
offices.

Preface v
NuPRO-A40H
Conventions
Take note of the following conventions used throughout this
manual to make sure that users perform certain tasks and
instructions properly.
NOTE:
NOTE:
Additional information, aids, and tips that help users perform
tasks.
CAUTION:
Information to prevent minor physical injury, component dam-
age, data loss, and/or program corruption when trying to com-
plete a task.
WARNING:
Information to prevent serious physical injury, component
damage, data loss, and/or program corruption when trying to
complete a specific task.

vi Preface
This page intentionally left blank.

Table of Contents vii
NuPRO-A40H
Table of Contents
Revision History...................................................................... ii
Preface.................................................................................... iii
List of Figures........................................................................ xi
List of Tables........................................................................ xiii
1 Introduction ........................................................................ 1
1.1 Overview.............................................................................. 1
1.2 Features............................................................................... 2
1.3 Specifications....................................................................... 3
1.4 Block Diagram ..................................................................... 5
1.5 Functional Description ......................................................... 6
1.6 Mechanical Drawing ............................................................ 8
1.7 I/O Connectivity ................................................................... 9
1.8 Power Consumption .......................................................... 10
1.9 Package Contents ............................................................. 11
2 Hardware Information...................................................... 13
2.1 Rear Panel I/O Ports.......................................................... 13
2.2 Board Layout ..................................................................... 15
2.3 Onboard Connectors ......................................................... 16
2.4 Jumpers ............................................................................. 24
3 Getting Started ................................................................. 27
3.1 Installing the CPU .............................................................. 27
3.2 Installing the CPU Fan and Heatsink................................. 31
3.3 Installing Memory Modules ................................................ 32
3.4 Installing the Power Connectors ........................................ 34

viii Table of Contents
4 Driver Installation.............................................................. 35
4.1 Chipset Driver .................................................................... 35
4.2 Display Driver..................................................................... 35
4.3 Ethernet Driver................................................................... 36
4.4 Audio Driver ....................................................................... 36
5 BIOS Setup........................................................................ 37
5.1 Starting the BIOS............................................................... 37
5.2 Main Setup......................................................................... 41
5.3 Advanced BIOS Setup ....................................................... 43
5.3.1 ACPI Settings ................................................................ 44
5.3.2 CPU Configuration......................................................... 45
5.3.3 SATA Configuration ....................................................... 47
5.3.4 USB Configuration ......................................................... 48
5.3.5 Super IO Configuration .................................................. 50
5.3.6 Serial Port Console Redirection..................................... 51
5.3.7 CPU PPM Configuration ................................................ 55
5.4 Chipset Setup .................................................................... 56
5.4.1 PCH-IO Configuration.................................................... 57
5.4.2 System Agent (SA) Configuration.................................. 60
5.5 Boot Configuration ............................................................. 63
5.6 Security Setup.................................................................... 66
5.7 System Management ......................................................... 68
5.8 Exit Menu ........................................................................... 69
A Appendix: Watchdog Timer..............................................71
A.1 Sample Code ..................................................................... 71
B Appendix: System Resources..........................................75
B.1 System Memory Map ......................................................... 75
B.2 Direct Memory Access Channels....................................... 75
B.3 IO Map ............................................................................... 76
B.4 Interrupt Request (IRQ) Lines............................................ 77

Table of Contents ix
NuPRO-A40H
Important Safety Instructions.............................................. 83
Getting Service...................................................................... 85

xTableofContents
This page intentionally left blank.

List of Figures xi
NuPRO-A40H
List of Figures
Figure 1-1: NuPRO-A40H Block Diagram.......................................... 5
Figure 1-2: NuPRO-A40H Board Dimensions.................................... 8
Figure 2-1: Rear Panel I/O Ports...................................................... 13
Figure 2-2: Connectors and Jumpers............................................... 15

xii List of Figures
This page intentionally left blank.

List of Tables xiii
NuPRO-A40H
List of Tables
Table 1-1: NuPRO-A40H I/O Connectivity........................................ 9
Table 1-2: Core™ i7-3770 Processor Power Consumption............ 10
Table B-1: System Memory Map..................................................... 75
Table B-2: Direct Memory Access Channels................................... 75
Table B-3: IO Map........................................................................... 77
Table B-4: IRQ Lines PIC Mode...................................................... 78
Table B-5: IRQ Lines APIC Mode ................................................... 79
Table B-6: PCI Configuration Space Map ....................................... 80
Table B-7: PCI Interrupt Routing Map............................................. 81

xiv List of Tables
This page intentionally left blank.

Introduction 1
NuPRO-A40H
1 Introduction
1.1 Overview
The ADLINK NuPRO-A40H is a PICMG 1.0 Single Board
Computer (SBC) supporting the 3rd generation Intel®
Core™ i7/i5/i3 and Pentium® processors in LGA1155 package to
deliver a scalable high performance platform for a wide array of
industrial applications. The NuPRO-A40H supports 22nm process
CPUs at up to 3.4 GHz with integrated graphics and memory
controllers, Direct Media Interface (DMI) and Flexible Display
Interface (FDI) connectivity to the Intel® H61 Express Chipset.
Dual-channel DDR3 1333/1600 MHz memory is supported up to a
maximum of 16GB in two DIMM slots.
These advanced features, coupled with dual PCI Express®-based
Gigabit Ethernet, SATA 3 Gb/s and USB 2.0 support make the
NuPRO-A40H ideal for automation control applications.

2Introduction
1.2 Features
XSupports 3rd Generation Intel® Core™ i7/i5/i3, and Pen-
tium® processors in LGA1155 package
XIntegrated Intel® HD Graphics with VGA and DVI-D output
XDual Gigabit Ethernet
X8x USB 2.0 ports (2x faceplate, 6x onboard pin headers)
X4x SATA 3 Gb/s ports
X6x COM ports (including 1x RS-232/422/485 with auto flow
control)
XWatchdog Timer, Hardware Monitor
XOptional HD audio kit (DB-Audio2 daughter board)
XRoHS compliant
NOTE:
NOTE:
To purchase the optional DB-Audio2 daughter board, please
contact your ADLINK sales representative.

Introduction 3
NuPRO-A40H
1.3 Specifications
System
CPU
3rd Gen Intel® Core™ processors in LGA1155 package:
• Intel® Core™ i7-3770, 3.4 GHz, 8M Cache, 22nm, 95W
• Intel® Core™ i5-3550, 3.0 GHz, 6M Cache, 22nm, 95W
• Intel® Core™ i3-3220, 3.3 GHz, 3M Cache, 22nm, 65W
• Intel®
Pentium® G2120, 3.1 GHz, 3M Cache, 22nm, 55W
Chipset • Intel® H61 Platform Controller Hub
Memory • Two 240-pin DIMM sockets support dual-channel
1333/1600 MHz DDR3 (up to 16GB)
BIOS • AMI BIOS in 64-Mbit SPI Flash
Audio • Intel® High Definition Audio support via DB-Audio2
daughter board
Watch Dog Timer • 1-255 second/minute programmable and can generate
system reset.
Hardware
Monitor
• CPU/System temperature, fan speed and onboard DC
voltage by ADLINK Smart Embedded Management
Agent (SEMA)
Operating
Systems • Windows® XP, Windows® 7, 32/64-bit; Fedora™ 17, Red Hat Enterprise Linux
I/O Interfaces
Serial ATA • 4x SATA 3 Gb/s ports onboard
I/O Ports
• 2x USB 2.0 port on rear panel, 6x via onboard header
• 6x serial ports via onboard pin-header
(5x RS-232; 1x RS-232/422/485 with auto flow control,
BIOS selectable)
• 2x GbE RJ-45 ports
• VGA port (Dsub-15)
• DVI-D (onboard header)
• PS/2 Keyboard/Mouse (onboard header)
• 1 Parallel port (onboard header)
Expansion • PCI 32-bit/33MHz, PCIe-to-PCI Bridge: ITE IT8892E
• PCI-to-ISA Bridge: ITE IT8888G (DMA not supported)
Display
Integrated
Graphics
• Integrated Intel® HD Graphics on processor
• VGA: to 2048x 1536 @ 75 Hz
• DVI: 1x internal pin header

4Introduction
Ethernet
Controller • Dual Intel® I211-AT Gigabit Ethernet Controller • Supports Preboot Execution Environment (PXE),
Wake-On-LAN, 9KB Jumbo Frames
Ports • Two RJ-45 Ethernet ports
Mechanical and Environment
Form Factor • Standard full-size PICMG 1.0 SBC
Dimensions • 338 x 122 mm (L x W)
Operating Temp. • 0ºC to 60ºC
Storage Temp. • -20ºC to 80ºC
Relative Humidity • 10% to 90% non-condensing
Safety • CE, FCC Class A

Introduction 5
NuPRO-A40H
1.4 Block Diagram
Figure 1-1: NuPRO-A40H Block Diagram
8 USB 2.0 Ports
4 SATA Ports
at 3.0Gb/s
x4 DMI
x2 Display Link
VGA
BIOS
LPC
SPI
Dual Channel
DDR3 1333/1600
Max. 16GB
Intel
I211-AT Dual
GbE
Intel
I211-AT
PCI Bus
(4x Master)
Audio 6 COM
Pin Header
for KB/MS
Intel
Intel
H61
H61
PCH
PCH
PCIe to
PCI
Bridge
DVI-D
PCI to
ISA
Bridge
ISA Bus
LEMT
LPT
3rd Gen
3rd Gen
Intel Core
Intel Core
i7/i5/i3
i7/i5/i3
dual/quad
dual/quad
core
core
32/22nm
32/22nm
Super
I/O

6Introduction
1.5 Functional Description
Processor Support
The NuPRO-A40H is PICMG 1.0 Single Board Computer support-
ing the 3rd Generation Intel® Core™ processor family (Intel®
Core™ i7/i5/i3, Pentium®) in LGA1155 socket. An integrated
memory controller supports dual channel 1333/1600 MHz DDR3
and Intel® HD Graphics is integrated onboard the CPU. Direct
Media Interface (DMI) and Flexible Display Interface (FDI) provide
connectivity to the Intel® H61 Express Chipset.
Intel® H61 Express Chipset
The Intel® BD82H61 Platform Controller Hub (PCH) combines
with the processor to provide a compact yet powerful 2-chip solu-
tion. Direct Media Interface (DMI) is the chip-to-chip connection
between the processor and PCH. Intel® Flexible Display Interface
carries display traffic from the integrated graphics in the processor
to the legacy display connectors in the PCH. The PCH supports all
other required interfaces including PCI Express, SATA 3 Gb/s,
USB 2.0, LPC, and SPI.
Dual-Channel DDR3 Memory
To meet the requirements of memory-intensive applications, the
NuPRO-A40H has a dual-channel memory architecture supporting
DDR3 1333/1600 MHz DIMMs. The key advantages of DDR3 are
the higher bandwidth and the increase in performance at lower
power than DDR2. DDR3 memory technology meets the require-
ments of the latest 3D graphics, multimedia, and network applica-
tion, and boosts system performance by eliminating bottlenecks.
Gigabit Ethernet
The NuPRO-A40H utilizes dual Intel® I211-AT Gigabit Ethernet
Controllers connected to the PCI-E bus of the H61 PCH.
Wake-on-LAN, PXE, and 9KB Jumbo Frames are supported.
