ADLINK Technology M-322 User manual

Advance Technologies; Automate the World.
Manual Rev.: 2.02
Revision Date: Mar 23, 2011
Part No: 50-1Z052-1020
M-322
ATX Industrial Motherboard with
Intel® Q35 Chipset
User’s Manual

Revision History
Revision Release Date Description of Change(s)
2.00 2010/06/23 Initial Release
2.01 2010/09/27 Correct System Panel Pin Header drawing
2.02 2011/05/23 Correct misc. typos; update addresses

Preface iii
M-322
Preface
Copyright 2010-2011 ADLINK Technology Inc.
This document contains proprietary information protected by copy-
right. All rights are reserved. No part of this manual may be repro-
duced by any mechanical, electronic, or other means in any form
without prior written permission of the manufacturer.
Disclaimer
The information in this document is subject to change without prior
notice in order to improve reliability, design, and function and does
not represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, spe-
cial, incidental, or consequential damages arising out of the use or
inability to use the product or documentation, even if advised of
the possibility of such damages.
Environmental Responsibility
ADLINK is committed to fulfill its social responsibility to global
environmental preservation through compliance with the Euro-
pean Union's Restriction of Hazardous Substances (RoHS) direc-
tive and Waste Electrical and Electronic Equipment (WEEE)
directive. Environmental protection is a top priority for ADLINK.
We have enforced measures to ensure that our products, manu-
facturing processes, components, and raw materials have as little
impact on the environment as possible. When products are at their
end of life, our customers are encouraged to dispose of them in
accordance with the product disposal and/or recovery programs
prescribed by their nation or company.
Trademarks
Product names mentioned herein are used for identification pur-
poses only and may be trademarks and/or registered trademarks
of their respective companies.

iv Preface
Using this Manual
Audience and Scope
The M-322 User’s Manual is intended for hardware technicians
and systems operators with knowledge of installing, configuring
and operating industrial grade computers.
Manual Organization
This manual is organized as follows:
Preface: Presents copyright notifications, disclaimers, trade-
marks, and associated information on the proper usage of this
document and its associated product(s).
Chapter 1, Introduction: Introduces the M-322, its features,
applications, and specifications, including functional descriptions
and board layout.
Chapter 2, Connectors & Jumpers: Provides technical informa-
tion on connectors, jumpers and pin assignments for configuring
the M-322.
Chapter 3, Getting Started: Describes how to install components
and drivers on the M-322.
Chapter 4, BIOS Setup: Presents information aid in configuring
the system BIOS.
Appendix A, Watchdog Timer: Presents information on under-
standing and configuring the watchdog timer.
Appendix B, System Resources: Presents information on I/O
mapping, IRQ routing, and resource allocation.
Important Safety Instructions: Presents safety instructions all
users must follow for the proper setup, installation and usage of
equipment and/or software.
Getting Service: Contact information for ADLINK’s worldwide
offices.

Preface v
M-322
Conventions
Take note of the following conventions used throughout this
manual to make sure that users perform certain tasks and
instructions properly.
NOTE:
NOTE:
Additional information, aids, and tips that help users perform
tasks.
CAUTION:
Information to prevent minor physical injury, component dam-
age, data loss, and/or program corruption when trying to com-
plete a task.
WARNING:
Information to prevent serious physical injury, component
damage, data loss, and/or program corruption when trying to
complete a specific task.

vi Preface
This page intentionally left blank.

Table of Contents vii
M-322
Table of Contents
Revision History...................................................................... ii
Preface.................................................................................... iii
List of Figures........................................................................ xi
List of Tables........................................................................ xiii
1 Introduction ........................................................................ 1
1.1 Package Contents ............................................................... 1
1.2 Overview.............................................................................. 2
1.3 Features............................................................................... 2
1.4 Specifications....................................................................... 3
1.5 Power Consumption ............................................................ 5
1.6 Block Diagram ..................................................................... 6
1.7 Functional Description ......................................................... 7
1.8 Board Layout ....................................................................... 9
1.9 Mechanical Drawings......................................................... 11
2 Connectors & Jumpers.................................................... 13
2.1 Rear I/O Connectors.......................................................... 13
2.2 Onboard Connectors ......................................................... 17
2.3 Jumpers............................................................................. 24
3 Getting Started ................................................................. 27
3.1 Installing the CPU.............................................................. 27
3.2 Installing the CPU Fan and Heatsink................................. 31
3.3 System Memory................................................................. 32
3.4 Driver Installation............................................................... 34

viii Table of Contents
4 BIOS Setup........................................................................ 37
4.1 Starting the BIOS............................................................... 37
4.2 Main Setup......................................................................... 41
4.3 Advanced Setings.............................................................. 45
4.3.1 USB Configuration.........................................................46
4.3.2 Trusted Computing........................................................48
4.3.3 Intel TXT (LT) Configuration..........................................49
4.3.4 Intel VT-d Configuration.................................................49
4.3.5 CPU Configuration.........................................................50
4.3.6 Chipset Settings.............................................................52
4.3.7 Onboard Device Configuration ......................................54
4.3.8 PCI/PnP Settings...........................................................55
4.4 Power Settings................................................................... 56
4.4.1 APM Configuration.........................................................58
4.4.2 Hardware Health Configuration .....................................59
4.5 Boot Settings ..................................................................... 60
4.5.1 Boot Device Priority.......................................................60
4.5.2 Boot Device Groups.......................................................60
4.5.3 Boot Settings Configuration...........................................61
4.5.4 Security..........................................................................62
4.6 Exit Menu........................................................................... 63
A Appendix: Watchdog Timer..............................................65
A.1 Sample Code..................................................................... 65
B Appendix: System Resources..........................................67
B.1 System Memory Map......................................................... 67
B.2 Direct Memory Access Channels....................................... 68
B.3 Fixed I/O Map .................................................................... 69
B.4 Variable I/O Map................................................................ 71
B.5 Interrupt Request (IRQ) Lines............................................ 72
B.6 PCI Configuration Space Map ........................................... 75
B.7 PCI Interrupt Routing Map................................................. 76

Table of Contents ix
M-322
Important Safety Instructions.............................................. 77
Getting Service...................................................................... 79

xTableofContents
This page intentionally left blank.

List of Figures xi
M-322
List of Figures
Figure 1-1: M-322 Block Diagram......................................................6
Figure 1-2: M-322 Board Layout........................................................9
Figure 1-3: M-322 Rear I/O Layout..................................................10
Figure 1-4: M-322 Board Dimensions..............................................11
Figure 1-5: M-322 I/O Shield Dimensions........................................12

xii List of Figures
This page intentionally left blank.

List of Tables xiii
M-322
List of Tables
Table 1-1: M-322 General Specifications..........................................4
Table 1-2: M-322 Board Layout Legend.........................................10
Table 2-1: COM Serial Port Connector Pin Definition.....................14
Table B-1: System Memory Map.....................................................67
Table B-2: Direct Memory Access Channels...................................68
Table B-3: Fixed I/O Map................................................................70
Table B-4: Variable I/O Map............................................................71
Table B-5: IRQ Lines PIC Mode......................................................72
Table B-6: IRQ Lines APIC Mode ...................................................74
Table B-7: PCI Configuration Space Map.......................................75
Table B-8: PCI Interrupt Routing Map.............................................76

xiv List of Tables
This page intentionally left blank.

Introduction 1
M-322
1 Introduction
This chapter will introduce the M-322, its features, specifications,
functional description, and mechanical layout.
1.1 Package Contents
Please check that your package contains the items below. If
you discover damaged or missing items, please contact your
vendor.
XM-322 Industrial ATX Motherboard
XI/O shield
X2x SATA data cables
X2x SATA power cables
X1x single COM port cable with bracket
X1x dual COM port cable with bracket
XDriver DVD
XUser’s Manual
WARNING:
DO NOT install or apply power to equipment that is damaged
or if there is missing/incomplete equipment. Retain the ship-
ping carton and packing materials for inspection. Please con-
tact your ADLINK dealer/vendor immediately for assistance.
Obtain authorization from your dealer before returning any
product to ADLINK.

2Introduction
1.2 Overview
The ADLINK M-322 is an ATX industrial motherboard supporting
the next-generation Intel® Core™2 Quad/Duo, Pentium® Dual
Core and Celeron® processors in the LGA775 package to deliver
a high performance platform for a wide array of industrial applica-
tions. The M-322 supports processing speeds up to 3.00GHz and
1333 MHz Front Side Bus (FSB). Dual channel DDR2
667/800 MHz memory is supported up to a maximum of 8GB in
four DIMM slots. The M-322 supports a broad range of processor
frequencies, high-speed data transfer rates, diverse I/O functions,
and high-bandwidth network connectivity.
These advanced features, coupled with integrated graphics, one
PCI Express® x16 slot, one PCI Express® x1 slot, five PCI slots,
and audio interfaces make the M-322 suitable for automation con-
trol, medical, test & measurement, and telecom applications
requiring an easy-to-deploy and reliable mainboard.
1.3 Features
XATX form factor (305 mm x 244 mm)
XSupports Intel® Core™2 Quad/Duo, Pentium® Dual Core
and Celeron® processors in LGA775 package
XDual 10/100/1000Mbps Ethernet
X12x USB 2.0 ports (4x faceplate, 8x onboard pin header)
X6x SATA 3 Gbps ports support RAID 0/1/5/10
XIntegrated graphic supports VGA up to 2048 x 1536 @ 75Hz
XOne PCIe x16 slot, one PCIe x1 slot, five PCI slots
XWatchdog Timer, Hardware Monitor
XRealtek ALC888 HD audio codec
XTPM hardware security chip
XRoHS compliant

Introduction 3
M-322
1.4 Specifications
System
CPU/Cache • IIntel® Core™2 Quad Q9400, 2.66GHz, 1333MHz FSB,
6MB L2 Cache, 45nm, 95W TDP
• Intel® Core™2 Duo E8400, 3.0GHz, 1333MHz FSB,
6MB L2 Cache, 45nm, 65W TDP
• Intel® Core™2 Duo E7400, 2.8GHz, 1066MHz FSB,
3MB L2 Cache, 45nm, 65W TDP
• Intel® Core™2 Duo E6400, 2.13GHz, 1066MHz FSB,
2MB L2 Cache, 65nm, 65W TDP
• Intel® Core™2 Duo E4300, 1.8GHz, 800MHz FSB,
2MB L2 Cache, 65nm, 65W TDP
• Intel® Pentium® Dual Core E5300, 2.6GHz, 800MHz FSB,
2MB L2 Cache, 45nm, 65W TDP
• Intel® Pentium® Dual Core E2160, 1.8GHz, 800MHz FSB,
1MB L2 Cache, 65nm, 65W TDP
• Intel® Celeron® 440, 2.0GHz, 800MHz FSB,
512KB L2 Cache, 65nm, 35W TDP
FSB • 800/1066/1333 MHz
Chipset • Intel® Q35 + ICH9DO
Memory • Four 240-pin DIMM sockets
• Dual-Channel DDR2 667/800MHz, up to 8GB
BIOS • AMI BIOS with 32 Mb Flash ROM
TPM • Infineon SLB 9635 TT 1.2
Audio • Realtek ALC888 HD codec
• Supports line-in, line-out and mic-in
Watchdog Timer • 1-255 second/minute programmable
Hardware Monitor • CPU/System temperature, fan speed and onboard DC
voltages
Operating System • Windows XP 32/64-bit edition
• Windows Vista 32-bit edition
• Windows Server 2008 32-bit edition
• Windows 7 32/64-bit edition
• Fedora 12

4Introduction
Table 1-1: M-322 General Specifications
I/O Interfaces
Serial ATA • 6x Serial ATA ports with 300 MB/s data transfer
• Supports RAID 0/1/5/10
Onboard I/O • 4x USB 2.0 pin headers (8 ports)
• 2x RS-232 serial port pin headers (COM2-3)
• 1x RS-232/422/485 serial port (COM4)
• 1x printer port
• 1x floppy port
• 1x front panel pin header
Rear I/O • 2x RJ-45 LAN port
• 4x USB 2.0 ports
• 1x D-Sub VGA connector
• 1x DB-9 RS-232 (COM1)
• 2x PS2 keyboard/mouse ports
• 3x audio jacks (line-in, line-out and mic-in)
Expansion Slots • 1x PCIe x16 slot
• 1x PCIe x1 slot
• 5x PCI slotsDisplay
Graphics • GMA 3100 integrated in Q35 GMCH
VRAM • Shared system memory up to 256 MB
VGA • Dsub-15 connector, up to 2048x1536 @ 75 Hz
Ethernet
Controller • Dual Realtek® RTL8111C PCIe network controllers
• 10/100/1000Base-T dual-Gigabit Ethernet
• Wake on LAN, PXE supported
Ports • 2x RJ-45 Ethernet port
Mechanical and Environment
Form Factor • ATX Industrial Motherboard
Dimensions • 305 mm x 244 mm (L x W)
Operating Temp. • 0°C to 60°C
Storage Temp. • -20ºC to 80ºC
Rel. Humidity • 10 - 90% non-condensing
Safety • CE, FCC Class A

Introduction 5
M-322
1.5 Power Consumption
Intel® Core™2 Duo Processor E6400
Test Configuration
CPU Intel® Core™2 Duo Processor E6400 2.13 GHz
Memory ADATA DDR2 667 1G (AD2667001GOU) x1
Graphics Intel ® Q35 Graphics Memory Controller Hub
Hard Drive Seagate Barracuda 7200.10 160GB ST3160815AS
Power Supply Delta 400W, GPS-400AB C Rev. 00F
Power On Boot Sequence
Power Req. +5V +3.3V +12V 5VSB Total
Current 2.12 A 2.14 A 2.84 A 0.62 A —
Power — — — — 54.84 W
Windows XP, Idle
Power Req. +5V +3.3V +12V 5VSB Total
Current 1.64 A 2.08 A 1.16 A 0.59 A —
Power — — — — 31.93 W
Windows XP, Maxpower 100% + 3DMark 2006
Power Req. +5V +3.3V +12V 5VSB Total
Current 2.04 A 2.10 A 2.88 A 0.59 A —
Power — — — — 54.64 W

6Introduction
1.6 Block Diagram
Figure 1-1: M-322 Block Diagram
Southbridge
Intel®ICH9DO
CPU
Core™2 Quad/Duo
Pentium®Dual Core
Celeron®
LGA775 package
Northbridge
Intel®Q35 GMCH
DMI
Interface
2 GB/s
LPC
USB 2.0
SPI BIOS
KB/Mouse
LPT/FDD
1x RS-232/422/485
3x RS-232
CRT
DB-15
Winbond
83627 DHG-A
Super I/O
12x USB 2.0
(4x Bracket, 8x Internal)
800/1066/1333 MHz
FSB
Channel A
Channel B
DDR2 667/800 MHz
PCIe
Controller
PCIex1
PCI Bus PCI
32-bit/33MHz bus
SATA
6x SATA ports
JMicron JMB368
PCIe to PATA controller
4x DIMM
Realtek
ALC888
HD
Codec
PCI
Controller
2x RTL8111C
PCIe GbE
TPM
SPI
PCIe x16 slot
PCIex1
PCI Express x1
