ADLINK Technology NuPRO-935A User manual

Advance Technologies; Automate the World.
Manual Rev.: 2.04
Revision Date: April 26, 2011
Part No: 50-13060-1030
NuPRO-935A
Full-Sized PICMG 1.0 SBC
Intel® Q35/ICH9 Chipset
User’s Manual

Revision History
Revision Release Date Description of Change(s)
2.00 2008/08/29 Initial release
2.01 2008/10/29 Correct Board Layout (COM1/2)
2.02 2009/05/13 Update OS support, driver locations, add TPM
driver installation
2.03 2010/07/03
Correct BIOS Power Button Mode description;
correct CPU Fan connector, GbE connector,
Floppy connector pin definitions; correct COM1
connector label (CN6); correct memory and
heatsink/fan installation instructions; update
addresses
2.04 2011/04/26 Remove Mini-DIN PS/2 KB/MS and legacy cables for boards with ordering numbers ending
in “xx40” and higher; update addresses

Preface iii
NuPRO-935A
Preface
Copyright 2008-2011 ADLINK Technology Inc.
This document contains proprietary information protected by copy-
right. All rights are reserved. No part of this manual may be repro-
duced by any mechanical, electronic, or other means in any form
without prior written permission of the manufacturer.
Disclaimer
The information in this document is subject to change without prior
notice in order to improve reliability, design, and function and does
not represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, spe-
cial, incidental, or consequential damages arising out of the use or
inability to use the product or documentation, even if advised of
the possibility of such damages.
Environmental Responsibility
ADLINK is committed to fulfill its social responsibility to global
environmental preservation through compliance with the Euro-
pean Union's Restriction of Hazardous Substances (RoHS) direc-
tive and Waste Electrical and Electronic Equipment (WEEE)
directive. Environmental protection is a top priority for ADLINK.
We have enforced measures to ensure that our products, manu-
facturing processes, components, and raw materials have as little
impact on the environment as possible. When products are at their
end of life, our customers are encouraged to dispose of them in
accordance with the product disposal and/or recovery programs
prescribed by their nation or company.
Trademarks
Product names mentioned herein are used for identification pur-
poses only and may be trademarks and/or registered trademarks
of their respective companies.

iv Preface
Using this Manual
Audience and Scope
The NuPRO-935A User’s Manual is intended for hardware
technicians and systems operators with knowledge of installing,
configuring and operating industrial grade single board computers.
Manual Organization
This manual is organized as follows:
Preface: Presents important copyright notifications, disclaimers,
trademarks, and associated information on the proper understand-
ing and usage of this document and its associated product(s).
Chapter 1, Introduction: Introduces the NuPRO-935A, its fea-
tures, applications, and specifications, including functional
descriptions and board layout.
Chapter 2, Hardware Information: Provides technical informa-
tion on connectors, jumpers and pin assignments for configuring
the NuPRO-935A.
Chapter 3, Getting Started: Illustrates how to install components
on the NuPRO-935A.
Chapter 4, Driver Installation: Provides information on how to
install the NuPRO-935A device drivers.
Chapter 5, BIOS Setup: Describes basic navigation for the
AMIBIOS®8 BIOS setup utility.
Appendix A, Watchdog Timer: Presents information on under-
standing and configuring the watchdog timer.
Appendix B, System Resources: Presents information on I/O
mapping, IRQ routing, and resource allocation.
Important Safety Instructions: Presents safety instructions all
users must follow for the proper setup, installation and usage of
equipment and/or software.
Getting Service: Contact information for ADLINK’s worldwide
offices.

Preface v
NuPRO-935A
Conventions
Take note of the following conventions used throughout this
manual to make sure that users perform certain tasks and
instructions properly.
NOTE:
NOTE:
Additional information, aids, and tips that help users perform
tasks.
CAUTION:
Information to prevent minor physical injury, component dam-
age, data loss, and/or program corruption when trying to com-
plete a task.
WARNING:
Information to prevent serious physical injury, component
damage, data loss, and/or program corruption when trying to
complete a specific task.

vi Preface
This page intentionally left blank.

Table of Contents vii
NuPRO-935A
Table of Contents
Revision History...................................................................... ii
Preface.................................................................................... iii
List of Figures........................................................................ xi
List of Tables........................................................................ xiii
1 Introduction ........................................................................ 1
1.1 Overview.............................................................................. 1
1.2 Features............................................................................... 1
1.3 Specifications....................................................................... 2
1.4 Power Consumption ............................................................ 4
1.5 Block Diagram ..................................................................... 5
1.6 Functional Description ......................................................... 6
1.7 Mechanical Drawing ............................................................ 9
1.8 I/O Connectivity ................................................................. 10
1.9 Package Contents ............................................................. 11
2 Hardware Information...................................................... 13
2.1 Rear Panel I/O Ports.......................................................... 13
2.2 Board Layout ..................................................................... 16
2.3 Onboard Connectors ......................................................... 18
2.4 Jumpers............................................................................. 25
3 Getting Started ................................................................. 27
3.1 Installing the CPU.............................................................. 27
3.2 Installing the CPU Fan and Heatsink................................. 31
3.3 Installing the Power Connectors........................................ 34
3.4 Installing Memory Modules................................................ 35

viii Table of Contents
4 Driver Installation.............................................................. 37
4.1 Intel® Q35 Express Chipset Driver.................................... 37
4.2 Display Driver..................................................................... 38
4.3 LAN Driver ......................................................................... 38
4.4 ISA Driver........................................................................... 39
4.5 TPM Driver......................................................................... 39
4.6 Audio Driver....................................................................... 40
5 BIOS Setup........................................................................ 41
5.1 Starting the BIOS............................................................... 41
5.2 Main Setup......................................................................... 45
5.3 Advanced BIOS Setup....................................................... 46
5.3.1 CPU Configuration.........................................................47
5.3.2 IDE Configuration ..........................................................48
5.3.3 Floppy Configuration......................................................49
5.3.4 Super IO Configuration..................................................50
5.3.5 Hardware Health Configuration .....................................52
5.3.6 Remote Access Configuration.......................................53
5.3.7 Trusted Computing........................................................55
5.3.8 USB Configuration.........................................................56
5.4 Advanced PCI/PnP Settings.............................................. 59
5.4.1 IRQ/DMA .......................................................................59
5.4.2 ISA Plug and Play..........................................................60
5.5 Boot Settings ..................................................................... 61
5.5.1 Boot Settings Configuration...........................................61
5.5.2 Boot Device Priority.......................................................63
5.5.3 Boot Device Groups.......................................................63
5.6 Security Setup.................................................................... 64
5.7 Chipset Setup .................................................................... 67
5.7.1 South Bridge Configuration............................................68
5.7.2 Advanced Chipset Settings............................................69
5.8 Exit Menu........................................................................... 70

Table of Contents ix
NuPRO-935A
A Appendix: Watchdog Timer..............................................73
A.1 Sample Code..................................................................... 73
B Appendix: System Resources..........................................77
B.1 System Memory Map......................................................... 77
B.2 Direct Memory Access Channels....................................... 78
B.3 IO Map............................................................................... 79
B.4 Interrupt Request (IRQ) Lines............................................ 81
Important Safety Instructions.............................................. 87
Getting Service...................................................................... 89

xTableofContents
This page intentionally left blank.

List of Figures xi
NuPRO-935A
List of Figures
Figure 1-1: NuPRO-935A Block Diagram ..........................................5
Figure 1-2: NuPRO-935A Board Dimensions (top view)....................9
Figure 2-1: Rear Panel I/O Ports......................................................13
Figure 2-2: Connectors and Jumpers Pt. 1......................................16
Figure 2-3: Connectors and Jumpers Pt. 2......................................17

xii List of Figures
This page intentionally left blank.

List of Tables xiii
NuPRO-935A
List of Tables
Table 1-1: NuPRO-935A General Specifications..............................3
Table B-1: System Memory Map.....................................................77
Table B-2: Direct Memory Access Channels...................................78
Table B-3: IO Map...........................................................................80
Table B-4: IRQ Lines PIC Mode......................................................81
Table B-5: IRQ Lines APIC Mode ...................................................83
Table B-6: PCI Interrupt Request Routing.......................................85
Table B-7: PCI Interrupt Routing Map.............................................86

xiv List of Tables
This page intentionally left blank.

Introduction 1
NuPRO-935A
1 Introduction
1.1 Overview
The ADLINK NuPRO-935A is a PICMG 1.0 industrial SBC
supporting the next-generation Intel® Core 2 Quad/Duo and Intel®
Celeron® processors in the LGA775 package to deliver a high
performance platform for a wide array of industrial automation
applications. The NuPRO-935A supports processing speeds up to
3.0 GHz and high-bandwidth network connectivity with PCI
Express®-based gigabit LAN.
These advanced features, coupled with a dual-channel DDR2 sys-
tem memory architecture and diverse I/O storage make the
NuPRO-935A suitable for industrial automation and automation
control applications requiring a standardize, easy-to-deploy, and
cost-effective SBC.
1.2 Features
XSupports Intel® Core™2 Duo/ Core™2 Quad, processors in
LGA775 package
XTPM hardware security chip (NuPRO-935A/DV only)
XDual 10/100/1000Mbps Ethernet (NuPRO-935A/LV supports
single GbE)
XOptional HD audio kit (DB-Audio2 daughter board)
X5 USB 2.0 ports
XSupports 2 SATA II ports
XWatchdog Timer, Hardware Monitor
XRoHS compliant
NOTE:
NOTE:
To purchase the optional DB-Audio2 daughter board, please
contact your ADLINK sales representative.

2Introduction
1.3 Specifications
System
CPU/Cache • Intel® Core™2 Quad, Core™2 Duo, Celeron® in
LGA775 Socket
FSB • 800/1066/1333 MHz
Chipset • Intel® 82Q35 Graphics Memory Controller Hub
• Intel® ICH9 I/O Controller Hub
Memory • Two 240-pin DIMM sockets support 667/800MHz
DDR2 (up to 4GB)
BIOS • AMI BIOS in 16-Mbit SPI Flash
Audio • Intel® High Definition Audio support via
DB-Audio2 daughter board
Watch Dog Timer • 1-255 second or 1-255 minute programmable and
can generate system reset.
Hardware
Monitor • CPU/System temperature, fan speed and onboard DC voltage
TPM • Infineon SLB 9635 TT 1.2 (NuPRO-935A/DVonly)
I/O Interfaces
IDE • One-channel UDMA 33, ATA-66/100 support
• One 40-pin IDE connector (1 device only)
Serial ATA • Two SATA ports, data rate up to 3 Gb/s
I/O Ports
• 1 USB 2.0 port on rear panel, four onboard
• 2 Serial ports (one RS-232, one
RS232/422/485/485+, by onboard pin-header)
• 2 Gigabit Ethernet RJ45 ports (optional)
• 1 VGA port
• PS/2 Keyboard/Mouse*
• 1 Parallel port
• 1 Floppy port
ISA • PCI-to-ISA Bridge: IT8888 (DMA not supported)
NOTE:
NOTE:
* A Mini-DIN PS/2 KB/MS connector is not supported on
boards with ordering numbers ending in “xx40” and higher. See
“PS/2 Keyboard/Mouse Port” on page 14 for more information.

Introduction 3
NuPRO-935A
Table 1-1: NuPRO-935A General Specifications
Display
VGA • GMA 3100 integrated in Q35 GMCH
VRAM • Shared system memory up to 256 MB
CRT • External Dsub-15 connector, resolution up to
2048 x 1536 @ 75 Hz
Ethernet
Controller • Intel® 82566DM and Intel® 82573L
(NuPRO-935A/LV supports 82566DM only)
Ports • Two RJ-45 Ethernet ports
(NuPRO-935A/LV supports 1x GbE)
Mechanical and Environment
Form Factor • Standard full-size PICMG 1.0 SBC
Dimensions • 338 x 122 mm (L x W)
Operating Temp. • 0ºC to 60ºC
Storage Temp. • -20ºC to 80ºC
Relative Humidity • 5% to 90% non-condensing both operating and
non-operating
Safety • CE, FCC Class A

4Introduction
1.4 Power Consumption
Test Configuration
CPU Intel® Core 2 Quad processor Q6600 2.40 GHz
Memory Transcend DDR2 800 1GB x2
Graphics Intel ® 82Q35 Graphics Memory controller
SATA Channel Seagate ST3808110AS Barracuda 7200.9 80GB
Power Supply COOLMAX FL-480ATX 450W
DOS (idle)
Power Req. +5V +12V CPU +12V Total
Current (A) 3.37A 367.9mA 3.24A —
Watts (W) 16.87W 4.42W 38.88 60.17W
Windows XP, Idle
Power Req. +5V +12V CPU +12V Total
Current (A) 3.203A 233,6mA 1.578A —
Watts (W) 16.02W 2.80W 18.94W 37.76W
Windows XP, KPower
Power Req. +5V +12V CPU +12V Total
Current (A) 3.276A 533.0mA 7.616A —
Watts (W) 16.38W 6.4W 91.39W 114.17W
Windows XP, BurnIn Test 5.3
Power Req. +5V +12V CPU +12V Total
Current (A) 3.708A 555.1mA 5.728A —
Watts (W) 18.54W 6.66W 68.74W 93.94W

Introduction 5
NuPRO-935A
1.5 Block Diagram
Figure 1-1: NuPRO-935A Block Diagram
Southbridge
Intel®ICH9
CPU
Core™2 Quad/Duo
Celeron®
LGA775 package
800/1066/1333 MHz FSB
Dual-Core
Hyper-Threading
Northbridge
Intel®Q35 GMCH
DMI
Interface
2 GB/s
LPC
USB 2.0
SPI BIOS
KB/Mouse
LPT/FDD
RS-232
RS-232/
422/485/
485+
CRT
DB-15
ITE8718
LPC Super I/O
USB 2.0
(Bracket x1, Internal x4)
800/1066/1333 MHz
FSB
DDR Channel A
DDR Channel B
DDRII 667/800 MHz
PCIe x1
PCIe
Controller
PCIex1
PCI Bus PCI 32-bit/
33MHz bus
SATA
SATA ports x2
JMicron JMB20330
SATA to IDE Controller
DIMM x2
Header for
DB-Audio2
HD
Codec
Hardware
Monitor
PCI
Controller
Intel 82566DM
RJ-45
IT8888G
ISA Bridge ISA bus
Intel 82573L
RJ-45 (DV only)
TPM
(DV only)
SPI

6Introduction
1.6 Functional Description
Processor Support
The NuPRO-935A is a single processor design for the latest Intel
Yorkfield/Wolfdale/Conroe Processor family, starting from 1.8 GHz
core frequency with future option up to 3.0 GHz. With one LGA775
socket, the CPU connects with Intel Q35 MCH through the
800/1066/1333 MHz Front Side Bus (FSB).
Intel® Q35 + ICH9 Express chipset
The Intel® Q35 Express chipset provides the vital interfaces for
the SBC. The Intel® Q35 comes with purpose-built capabilities
designed specifically to address the key needs of the industrial
computing environment and delivers improved system perfor-
mance and comes with the integrated Intel® Graphics Media
Accelerator 3100 engine that promotes advanced 3D, 2D, and
video capabilities and cost-effective system building. The chipset
also supports high-bandwidth interfaces including as PCI
Express®, Serial ATA, and USB 2.0, as well as dual-channel
DDR2 system memory.
Intel® Graphics Media Accelerator 3100
The Intel® Graphics Media Accelerator (GMA) 3100 revolutionizes
integrated graphics with new capabilities that provide significant
increase in graphics performance. With support for DirectX 9 hard-
ware acceleration, core frequency of 400 MHz, and up to 256 MB
of video memory, the Intel GMA 3100 provides a cost-effective
and high-performance graphics solution.
Dual-channel DDR2 memory
To meet the requirements of memory-intensive applications, the
NuPRO-935A has a dual-channel memory architecture supporting
DDR2 667/800 MHz DIMMs. The high-bandwidth memory
specification, meets the requirements of the latest 3D graphics,
multimedia, and network application, and boosts system
performance by eliminating bottlenecks.
