ADLINK Technology NuPRO-842 Series User manual

NuPRO-842 Series
Full-Size PICMG 1.0
Single Board Computer
with Pentium 4 CPU
User’s Guide
Recycled Paper

©Copyright 2003 ADLINK Technology Inc.
All Rights Reserved.
Manual Rev. 1.01: October 16, 2003
Part Number: 50-13033-100
The information in this document is subject to change without prior notice in
order to improve reliability, design, and function and does not represent a
commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special,
incidental, or consequential damages arising out of the use or inability to use
the product or documentation, even if advised of the possibility of such
damages.
This document contains proprietary information protected by copyright laws. All
rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic, or other means in any form without prior written
permission of the manufacturer.
Trademarks
NuPRO®is a registered trademark of ADLINK Technology Inc. Other product
names mentioned herein are used for identification purposes only and may be
trademarks and/or registered trademarks of their respective companies.
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN
INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO
THE INSTRUCTIONS.

Getting Service from ADLINK
Customer Satisfaction is top priority for ADLINK TECHNOLOGY INC. If you
need any help or service, please contact us.
ADLINK TECHNOLOGY INC.
Web Site http://www.adlinktech.com
Sales & Service [email protected]
TEL [phone] FAX [phone]
Address 9F, No. 166, Jian Yi Road, Chungho City, Taipei, 235 Taiwan
Please email or FAX your detailed information for prompt, satisfactory, and
consistent service.
Detailed Company Information
Company/Organization
Contact Person
E-mail Address
Address
Country
TEL FAX
Web Site
Questions
Product Model
Environment
OS:
Computer Brand:
M/B: CPU:
Chipset: BIOS:
Video Card:
NIC:
Other:
Detail Description
Suggestions for ADLINK

Table of Contents •i
Table of Contents
How to Use This Guide........................................................................... iii
Chapter 1 Introduction ............................................................................ 1
1.1 Unpacking Checklist........................................................................ 2
1.2 Features3
1.3 Functional Blocks and Main Board.................................................. 4
1.3.1 Intel Pentium 4 Processor................................................. 6
1.3.2 The Intel® 845GV Graphics Chipset Memory Controller
Hub (GMCH)..................................................................... 6
1.3.3 The Intel® 82801DB I/O Controller Hub 4 (ICH4)............. 6
1.3.4 Watchdog Timer................................................................ 6
1.3.5 Video................................................................................. 7
1.3.6 Ethernet Interfaces............................................................ 7
1.3.7 Serial I/O........................................................................... 7
1.3.8 IEEE-1284 Parallel Port/Printer Interface.......................... 7
1.3.9 Universal Serial Bus (USB)............................................... 7
1.3.10 IDE Controller and Floppy Interface Controller ................. 8
1.3.11 Keyboard/Mouse Controller .............................................. 8
1.3.12 Software............................................................................ 8
1.4 Specifications.................................................................................. 9
Chapter 2 Jumpers and Connectors.................................................... 13
2.1 NuPRO-842 Board Outline and Illustration.................................... 14
2.1.1 NuPRO-842 Top View .................................................... 14
2.2.1 VGA Connector............................................................... 17
2.2.2 COM1/COM2 Pin Header............................................... 18
2.2.3 Gigabit Ethernet (RJ-45) Connector................................ 18
2.2.4 Parallel Port Connector................................................... 19
2.2.5 Case Open connector..................................................... 19
2.2.6 CPU Fan1/Fan2 connector ............................................. 19
2.2.7 Integrated PS/2 KBD/MS connector................................ 20
2.2.8 Floppy Disk connector .................................................... 20
2.2.9 Primary/Secondary IDE Connector................................. 21
2.2.10 Front Panel Pin Header .................................................. 22
2.2.11 Mini PCI Socket .............................................................. 23
2.2.12 USB Connector............................................................... 24
2.2.13 AC’97 Connector............................................................. 24
2.2.14 USB Pin Header.............................................................. 24
2.2.15 Thermal Connector......................................................... 24
2.2.16 External KB/MS Connector............................................. 25
2.3 NuPRO-842 Jumper Setting.......................................................... 26
2.3.1 Clear CMOS ................................................................... 26

ii •Table of Contents
2.3.2 FSB Frequency............................................................... 27
2.3.3 COM2 Function Selection............................................... 27
2.3.4 COM2 Mode Selection.................................................... 28
Chapter 3 Getting Started ..................................................................... 29
3.1 CPU Installation ........................................................................... 29
3.2 Memory Installation....................................................................... 30
3.2.1 Memory Configuration Options ....................................... 30
3.2.2 Installing Memory Modules ............................................. 30
3.3 Connecting IDE Devices to the NuPRO-842................................. 31
3.4 BIOS Configuration Overview ....................................................... 32
3.5 Operating System Installation ....................................................... 33
Chapter 4 Device Driver Installation..................................................... 35
4.1 Intel® 845GV Chipset ................................................................... 35
4.1.1 System Requirements..................................................... 35
4.1.2 Hardware Configuration File Installation ......................... 36
4.2 Driver Installation .......................................................................... 36
4.2.1 VGA Driver Installation.................................................... 36
4.2.2 LAN Driver Installation.................................................... 38
Chapter 5 Watchdog Timer ................................................................... 41
5.1 Watchdog Timer Overview............................................................ 41
5.1.1 Using the Watchdog in an Application ............................ 42
Warranty Policy...................................................................................... 43

How To Use This Guide •iii
How to Use This Guide
This manual is intended to assist users to configure the NuPRO-842 Full-Size
PICMG 1.0 Single Board Computer with Pentium 4/Pentium 4 Mobile CPU. It
is divided into 5 chapters.
Chapter 1 Introduction
Gives an overview of the product features, applications, and
specifications.
Chapter 2 Connectors and Jumpers
Outlines all the connectors with pin definitions.
Chapter 3 Getting Started
Summarizes requirements to setup an operational system using
the NuPRO-842. Hardware installation and BIOS overview is
discuss.
Chapter 4 Driver Installation
Provides driver installation instructions.
Chapter 5 Watch Timer
Explains WDT operation.

Introduction •1
1
Introduction
The NuPRO-842 is a full-size PICMG 1.0 Pentium 4-based Single Board
Computer (SBC) with Intel 845GV chipset. It supports both PCI and ISA buses.
The CPU module supports a front side bus (FSB) of 533MHz and a maximum
CPU clock of 3.06 GHz featuring 32-bit/33MHz PCI/ISA bus with up to 2GB
high performance DDR host SDRAM support.
It provides standard I/Os, including RS-232, Printer Port, USB 2.0, EIDE,
Ethernet, and video interfaces. The NuPRO-842 is designed to meet the needs
of applications that require the highest computing performance and reliability. It
is designed to run on Windows 2000/XP, Linux, etc. operating system, as well
as embedded real time applications. It is the ideal solution for
Telecommunications, Internet, and Industrial Networking Applications.
This chapter is designed to give you an overview of the NuPRO-842 SBC. The
chapter covers the following topics:
•Unpacking and Checklist
•Features
•Specifications

2•Introduction
1.1 Unpacking Checklist
Check the shipping carton for any damage. If the shipping carton and contents
are damaged, notify the dealer for a replacement. Retain the shipping carton
and packing material for inspection by the dealer. Obtain authorization before
returning any product to ADLINK.
Check that the following items are included in the package, if there are any
missing items, contact your dealer:
•The NuPRO-842 module (may be equipped with different speed or
capacity CPU, RAM, and HDD)
•This User’s Manual
•ADLINK CD
•Y Cable for PS/2 Keyboard & Mouse
•Printer Port cables with bracket
•Com cables with bracket
•USB cables with bracket
•Cooling kit
•Floppy cable
•ATA-100 Cables x 2
•CPU Cooler
Note: The NuPRO-842 OEM version package may contain a
non-standard configuration, unique functionality, or different
packaging according to configuration requests
CAUTION: This board must be protected from static discharge and
physical shock. Never remove any of the socketed parts
except at a static-free workstation. Use the anti-static bag
shipped with the product to handle the board. Wear a wrist
strap grounded through one of the system's ESD Ground
jacks when servicing system components.
!

Introduction •3
1.2 Features
•PICMG 1.0 Rev. 1.0 PCI/ISA Specification compliant.
•PCI Local Bus Specification, Rev 2.2 compliant.
•Intel mPGA478 Socket Pentium 4 FC-PGA2 CPU processor.
•Supports Front Side Bus frequency of 533/400MHz
•Two 184-pin DIMM sockets, support 144-bit, 266MHz, DDR DRAM.
Supports a maximum of 2GB of memory.
•Two 10BaseT/100BaseTx/1000Base Ethernet jacks (Intel
82540EM).
•Integrated Intel Extreme Graphics supports Analog Display. Max
Dynamic Video Memory64MB (64MB if system memory is 256MB or
greater, 32MB if less than 256MB).
•Supports all standard features, including VGA, serial, USB,
keyboard, and mouse ports.
•Built-in system monitoring for CPU temperature, FAN speed, system
temperature, CPU voltage, and DC voltages.
•Supports Intel®Pre-boot Execution Environment (PXE).

4•Introduction
1.3 Functional Blocks and Main Board
The NuPRO-842 functional block and main board diagrams are provided
below:
Functional Block Diagram
Functional Block Diagram

Introduction •5
Main Board Drawing
Main Board Drawing

6•Introduction
1.3.1 Intel Pentium 4 Processor
The NuPRO-842 is a full-sized single board computer (SBC) that supports a
single mPGA478 Intel® Pentium® 4 processor or a 478-pin Micro Flip-Chip
Pin Grid Array (Micro-FCPGA) Mobile Intel® Pentium® 4 Processor – M.
The Pentium 4 processor runs at a core speed of up to 3.06GHz and the
Mobile Intel® Pentium® 4 Processor – M runs at a core speed of up to 2.4Ghz.
The 845GV chipset keeps the FSB operation at 400/533 MHz (auto-selected).
Intel Pentium 4 Processor and Mobile Intel Pentium 4 Processor-M have an
on-die 512kB L2 Advanced Transfer Cache (ATC). The on-die cache has a
256-bit data bus from the processor core.
The design for using Pentium 4 processor required an upgraded Voltage
Regulator Module circuit implementation (VRM 9.0) to handle tighter voltage
tolerances.
1.3.2 The Intel® 845GV Graphics Chipset Memory Controller
Hub (GMCH)
The central hub for all data passing through core system elements is through
the Intel 845GV Graphics Chipset Memory Controller Hub. To balance the
performance offered by the processor and memory interfaces, the GMCH
allows several high-bandwidth I/O configuration options. This chipset delivers
balanced, high-throughput system performance for dual processor server
platforms.
1.3.3 The Intel® 82801DB I/O Controller Hub 4 (ICH4)
Connection to the MCH is done through a point-to-point Hub Interface 1.5
connection. The ICH4 provides legacy I/O interfaces through integrated
features including a two-channel Ultra ATA/100 bus master IDE controller and
an USB controller for two USB ports. The ICH4 also offers an integrated
System Manageability Bus 2.0 (SMBus 2.0) controller, as well as a PCI
2.2-compliant interface.
1.3.4 Watchdog Timer
The watchdog timer optionally monitors system operations. It can be
programmed for different timeout periods (from 1 to 255 seconds or 1 to 255
minutes). The watchdog is capable generating a Reset signal. Failure to strobe
the watchdog timer within the programmed time period may result in a reset
request. A register bit can be enabled to indicate if the watchdog timer caused
the reset event. This watchdog timer register is cleared on power-up, enabling
system software to take appropriate action if the watchdog generated the
reboot.

Introduction •7
1.3.5 Video
The NuPRO-842 provides two display ports. One analog port is output on rear
IO panel. The analog port uses an integrated 350 MHz RAMDAC of the 845GV
GMCH that can directly drive a standard progressive scan monitor up to a
resolution of 2048x1536 pixels with 32-bit color at 60 Hz. The NuPRO-842 has
a high-speed interface to a digital display use daughter board DB-842DVI. The
Intel 845GV chipset implements Dynamic Video Memory Technology (DVMT)
to ensure the most efficient use of system memory, allowing up to 64MB of
system memory to be shared among OS, applications, and graphics display.
1.3.6 Ethernet Interfaces
The NuPRO-842 provides two 10/100/1000Mbps Ethernet ports supplied via
an Intel 82540EM chip, which are connected to the 82801DB. Each Ethernet
interface is routed to an RJ45/LED all in one Connector on the rear panel. Each
LAN chip will be assigned a unique static MAC Address. LED drive signals for
Ethernet link status and activity are routed to the same connector. The
onboard Ethernet is Wired For Management 2.0 compliance. This port is
available on the real panel.
1.3.7 Serial I/O
Two serial ports are supported by the NuPRO-842. The EIA232 drivers and
receivers reside on board. COM1 and COM2 are available as a 10-pin header
on the motherboard. Both ports will be configured as DTE. Firmware will
initialize the two serial ports as COM1 and COM2 with ISA I/O base addresses
of 3F8h and 2F8h respectively. This default configuration also assigns COM1
to IRQ4 and COM2 to IRQ3. The NuPRO-842 serial controller resides in the
W83627HF Super I/O device.
1.3.8 IEEE-1284 Parallel Port/Printer Interface
The parallel I/O interface signals are routed to a 26-pin connector on the board.
This port supports the full IEEE-1284 specifications and provides the basic
printer interface.
Firmware will initialize the parallel port as LPT1 with ISA I/O base address of
378h. This default configuration also assigns the parallel port to IRQ7. The
printer interface mode (Normal, Extended, EPP, or ECP) is selectable through
the BIOS SETUP utility with the W83627HF Super I/O device managing the
NuPRO-842’s parallel port.
1.3.9 Universal Serial Bus (USB)
NuPRO-842 supports 6 USB2.0 serial ports backward compatible to
USB1.x.One USB port is on the faceplate and others with pin header. USB
allows for the easyaddition of peripherals such as mouse, keyboard, speakers,
etc. Transfer rates up to 480Mb/s are supported. Full-speed connections

8•Introduction
(480Mb/s) require shielded and tested cables. NuPRO-842 will provide the
standard 0.5A at 5V to the peripherals.
1.3.10 IDE Controller and Floppy Interface Controller
The NuPRO-842 includes an IDE Controller (in the ICH4) and a Floppy Disk
Controller (in the W83627HF). The IDE Controller provides support for internal
or external IDE drives. Signals are available at the IDE connectors CN14 and
CN13 and are routed to a 40-pin header. The FDD Controller provides support
for an external FDD drives. Signals are available at the FDD connector CN12
and are routed to a 34-pin header.
1.3.11 Keyboard/Mouse Controller
The NuPRO-842 includes an onboard PC/AT keyboard and mouse controller.
The keyboard/mouse signals are available through the PS/2 circular DIN on
the panel. Both the keyboard and mouse can be connected at the same time
using ADLINK’s Y cable. An extra pin header connector is available for
connection of an external keyboard. The NuPRO-842 keyboard/mouse
controller resides in the Winbond W83627HF Super I/O device
1.3.12 Software
The NuPRO-842 is compatible with all major PC operating systems. ADLINK
provides support for many popular operating systems, including additional
drivers for ADLINK peripherals. Software device drivers for the NuPRO-842
may be found on the ADLINK CD.

Introduction •9
1.4 Specifications
Compliant Specifications
•PICMG 1.0 Rev. 1.0 PCI-ISA Specification compliant
•PCI Local Bus Specification, Rev 2.2 compliant
Form Factor
•Full-Size Single Board Computer, 388mm x 122mm (15.2”x4.8”)
CPU/Cache
•Single
mPGA478 Intel Pentium 4 processor or a 478-pin Micro
Flip-Chip Pin Grid Array (Micro-FCPGA) Mobile Intel Pentium 4
Processor – M
•Intel Pentium 4 Processor and Mobile Intel Pentium 4 Processor-M have
an on-die an on-die 512KB L2 Advanced Transfer Cache (ATC). The
on-die cache has a 256-bit data bus from the processor core
Chipset
•Intel 82845GV Graphics Memory Control Hub (GMCH)
•Intel 82801DB I/O Control Hub 4 (ICH4)
Host Memory
•Two DDR DIMM sockets
•Unbuffered, unregistered 184-pin non-ECC DDR SDRAM
•Supports up to 2GB
BIOS
•Supports 4/8 Mbit Firmware Hub 82802AB(4Mb) or
SST49LF004A
•Boot block, PNP, DMI, Write Protection and field upgradeable

10 •Introduction
Gigabit Ethernet
•Two Gigabit Ethernet ports with an Intel 82540EM Ethernet controller
•Support 1000Base-T, 100Base-TX and 10Base-T (IEEE 802.3, 802.3u,
and 802.3ab).
•IEEE802.3x compliant flow control, supports auto-negotiation and link
setup
•Speed and Link LEDs on the RJ-45 connector
Graphic Display
•Integrated Intel Extreme Graphics supports Analog Display and
DVI Interface with daughter board “DB-842DVI”
•Max dynamic video memory64MB (If system memory is less than 256MB,
then only 32MB can be allocated as video memory)
USB Interface
•Six USB 2.0 ports, one on faceplate, others with pin header
•USB ports provide 0.5A @ 5V power for peripheral devices with over
current protection
IDE Ports
•Bus master IDE controller supports two ultra ATA-100 / 66 / 33 interfaces
Super I/O and WDT
•Winbond W83627HF
•Two 16C550 UART compatible RS-232 COM ports, Com2 support
RS-232/RS-422/485/485+.
•PS2 keyboard and mouse supported.
•W82782D built-in, monitoring CPU temperature, fan speed, system
temperature, CPU voltage, and DC voltages.
•Watchdog timer: Programmable I/O port on addresses 02Eh and 02FH.
Programmable timer for 1-255 seconds or 1-255 minutes.
Easy-programming libraries for DOS, Windows 95/98/NT are included.
