ADLINK Technology cPCI-6530BLV User manual

Leading EDGE COMPUTING
Manual Rev.: 1.0
Revision Date: July 12, 2018
Part Number: 50-15100-2000
cPCI-6530BL Series
Performance 6U CompactPCI®
Intel® Core™ i7/i5 Processor Blade
User’s Manual

ii Revision History
Leading EDGE COMPUTING
Revision History
Revision Release Date Description of Change(s)
1.0 July 12, 2018 Initial release

Preface iii
cPCI-6530BL
Preface
Copyright 2018 ADLINK Technology, Inc.
This document contains proprietary information protected by copy-
right. All rights are reserved. No part of this manual may be repro-
duced by any mechanical, electronic, or other means in any form
without prior written permission of the manufacturer.
Disclaimer
The information in this document is subject to change without prior
notice in order to improve reliability, design, and function and does
not represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, spe-
cial, incidental, or consequential damages arising out of the use or
inability to use the product or documentation, even if advised of
the possibility of such damages.
Environmental Responsibility
ADLINK is committed to fulfill its social responsi-
bility to global environmental preservation
through compliance with the European Union's
Restriction of Hazardous Substances (RoHS)
directive and Waste Electrical and Electronic
Equipment (WEEE) directive. Environmental
protection is a top priority for ADLINK. We have
enforced measures to ensure that our products,
manufacturing processes, components, and raw
materials have as little impact on the environment as possible.
When products are at their end of life, our customers are encour-
aged to dispose of them in accordance with the product disposal
and/or recovery programs prescribed by their nation or company.
Battery Labels (for products with battery)
ᑜ㔚ᳰ⺧࿁ᡴ

iv Preface
Leading EDGE COMPUTING
California Proposition 65 Warning
WARNING: This product can expose you to chemicals
including acrylamide, arsenic, benzene, cadmium,
Tris(1,3-dichloro-2-propyl)phosphate (TDCPP), 1,4-Diox-
ane, formaldehyde, lead, DEHP, styrene, DINP, BBP, PVC, and
vinyl materials, which are known to the State of California to cause
cancer, and acrylamide, benzene, cadmium, lead, mercury,
phthalates, toluene, DEHP, DIDP, DnHP, DBP, BBP, PVC, and
vinyl materials, which are known to the State of California to cause
birth defects or other reproductive harm. For more information go
to www.P65Warnings.ca.gov.
Trademarks
Product names mentioned herein are used for identification pur-
poses only and may be trademarks and/or registered trademarks
of their respective companies.
Conventions
Take note of the following conventions used throughout this
manual to make sure that users perform certain tasks and
instructions properly.
NOTE:
NOTE:
Additional information, aids, and tips that help users perform
tasks.
CAUTION:
Information to prevent minor physical injury, component dam-
age, data loss, and/or program corruption when trying to com-
plete a task.
WARNING:
Information to prevent serious physical injury, component
damage, data loss, and/or program corruption when trying to
complete a specific task.

Table of Contents v
cPCI-6530BL
Table of Contents
Revision History...................................................................... ii
Preface.................................................................................... iii
List of Figures........................................................................ ix
List of Tables.......................................................................... xi
1 Introduction ........................................................................ 1
1.1 Overview.............................................................................. 1
1.2 Features............................................................................... 2
1.3 Package Contents ............................................................... 3
2 Specifications..................................................................... 5
2.1 cPCI-6530BL Processor Blade Specifications..................... 5
2.2 Block Diagrams.................................................................... 8
2.3 I/O Connectivity Table ......................................................... 9
2.4 Power Requirements......................................................... 10
3 Functional Description .................................................... 13
3.1 Processors......................................................................... 13
3.2 Chipset............................................................................... 15
3.3 PMC/XMC.......................................................................... 16
3.4 Intel® Turbo Boost Technology......................................... 16
3.5 Intel® Hyper-Threading Technology.................................. 17
3.6 Trusted Platform Module ................................................... 17
3.7 Battery ............................................................................... 18
4 Board Interfaces............................................................... 19
4.1 cPCI-6530BLV Board Layout............................................. 19
4.2 cPCI-6530BL Board Layout............................................... 20

vi Table of Contents
Leading EDGE COMPUTING
4.3 cPCI-6530BL Series Front Panel....................................... 21
4.4 Connector Pin Assignments............................................... 24
4.5 Switches and Buttons ........................................................ 40
5 Getting Started.................................................................. 47
5.1 CPU and Heatsink ............................................................. 47
5.2 mSATA Module Installation................................................ 48
5.3 2.5" SATA Drive Installation............................................... 49
5.4 PMC/XMC Installation........................................................ 53
5.5 Installing the cPCI-6530BL to the Chassis......................... 55
6 Driver Installation.............................................................. 57
6.1 cPCI-6530BL Drivers......................................................... 57
7 Utilities............................................................................... 59
7.1 Watchdog Timer................................................................. 59
8 BIOS Setup Utility............................................................. 65
8.1 Starting the BIOS............................................................... 65
8.2 Main Setup......................................................................... 70
8.3 Advanced BIOS Setup....................................................... 72
8.3.1 CPU Configuration.........................................................73
8.3.2 Trusted Computing ........................................................74
8.3.3 PCH-FW Configuration..................................................75
8.3.4 Intel Anti-Theft Technology Configuration .....................76
8.3.5 AMT Configuration.........................................................77
8.3.6 IT8783 Super IO Configuration......................................78
8.3.7 Serial Port Console Redirection.....................................79
8.3.8 Intel TXT Information.....................................................82
8.3.9 Platform Misc Configuration...........................................83
8.3.10SATA Configuration.......................................................84
8.3.11Network Stack Configuration .........................................87
8.3.12CSM Configuration ........................................................88
8.3.13USB Configuration.........................................................90

Table of Contents vii
cPCI-6530BL
8.3.14Hardware Monitor..........................................................91
8.4 Chipset Setup.................................................................... 92
8.4.1 System Agent (SA) Configuration..................................93
8.4.2 PCH-IO Configuration....................................................98
8.5 Boot Settings ................................................................... 101
8.6 Security Setup ................................................................. 103
8.7 Save & Exit Menu............................................................ 104
9 Checkpoints & Beep Codes .......................................... 107
9.1 Checkpoint Ranges ......................................................... 107
9.2 Standard Checkpoints ..................................................... 107
9.3 OEM-Reserved Checkpoint Ranges................................ 116
10IPMI User Guide.............................................................. 117
10.1 Introduction...................................................................... 117
10.2 Summary of Commands Supported by BMR-AVR-cPCI. 117
10.3 CompactPCI Address Map .............................................. 121
10.4 Communications with IPMC............................................. 121
10.5 IPMI Sensors List............................................................. 122
10.6 Relevant Documents ....................................................... 122
Important Safety Instructions............................................ 123
Getting Service.................................................................... 125

viii Table of Contents
Leading EDGE COMPUTING
This page intentionally left blank.

List of Figures ix
cPCI-6530BL
List of Figures
Figure 2-1: cPCI-6530BL Blade Functional Block Diagram...............8
Figure 4-1: cPCI-6530BLV Series Board Layout .............................19
Figure 4-2: cPCI-6530BL Series Board Layout................................20
Figure 4-3: cPCI-6530BL Series Front Panel Layout.......................21
Figure 4-4: cPCI-6530BL Series LED Labels...................................23
Figure 4-5: Solder-side switch and button locations ........................41
Figure 4-6: Component-side switch locations..................................41

xListofFigures
Leading EDGE COMPUTING
This page intentionally left blank.

List of Tables xi
cPCI-6530BL
List of Tables
Table 2-1: cPCI-6530BL Processor Blade Specifications.................5
Table 2-2: cPCI-6530BL I/O Connectivity.........................................9
Table 4-1: cPCI-6530BL Front Panel System LED Descriptions....22
Table 4-2: USB 2.0 Pin Definition...................................................24
Table 4-3: DVI-I Connector Pin Definition.......................................25
Table 4-4: RJ-45 GbE Pin Definitions.............................................26
Table 4-5: LAN LED Status Definitions...........................................26
Table 4-6: Front Panel COM Pin Definitions...................................27
Table 4-7: COM RJ-45 to DB-9 Cable Pin Definitions....................27
Table 4-8: Serial ATA 7-pin Connector Pin Definition.....................28
Table 4-9: Serial ATA Connector with power Pin Definition............28
Table 4-10: SATA Board-to-Board Connector Pin Definition............29
Table 4-11: CFast Socket Pin Definition...........................................30
Table 4-12: PMC Connector Pin Definitions.....................................32
Table 4-13: XMC1 Connector Pin Definition.....................................33
Table 4-14: XMC2 Connector Pin Definition.....................................34
Table 4-15: CompactPCI J1 Connector Pin Definition......................35
Table 4-16: CompactPCI J2 Connector Pin Definition......................36
Table 4-17: CompactPCI J3 Connector Pin Definition......................37
Table 4-18: CompactPCI J4 Connector Pin Definition......................38
Table 4-19: CompactPCI J5 Connector Pin Definition......................39

xii List of Tables
Leading EDGE COMPUTING
This page intentionally left blank.

Introduction 1
cPCI-6530BL
1 Introduction
1.1 Overview
The ADLINK cPCI-6530BL Series is a 6U CompactPCI® proces-
sor blade with soldered DDR3L-1600 ECC memory up to 16GB
and DDR3L-1600 ECC socket type memory up to 16GB. The
ADLINK cPCI-6530BL features an Intel® Core™ i7/i5 processor
with Mobile Intel® QM87 Express Chipset.
The cPCI-6530BL Series is a 6U CompactPCI blade in single-slot
(4HP) width form factor. Front panel I/O for the cPCI-6530BLV
includes 1x DVI-I, 2x GbE and 2x USB 3.0 ports, 1x USB 2.0 port,
1x RJ-45 COM port and 1x PCI/XMC slot. The cPCI-6530BL front
panel includes 2x GbE and 1x USB 3.0 port and 1x USB 2.0 port
and 2x PMC/XMC slots.
Graphics support is integrated on the CPU and supports 3 inde-
pendent displays when mated with selected rear transition mod-
ules (cPCI-R6700 and cPCI-R6500). Storage for both
cPCI-6530BLV and cPCI-6530BL versions includes an mSATA
slot and a SATA 7-pin connector. The cPCI-6530BLV supports an
additional SATA connector to support onboard 2.5" SATA drive or
CFast adapter.
For expansion, both cPCI-6530BL and cPCI-6530BLV are
equipped with one 64-bit/33, 66,133MHz PMC site or one PCIe x8
Gen 2 XMC site with rear I/O. The cPCI-6530BL is equipped with
one additional PMC/XMC slot supporting PCI
64-bit/33,66,133MHz PMC site or one PCIe x8 Gen 2 XMC site.
Rear I/O signals to RTM include 2x GbE by Intel I210 LAN control-
lers, 1x DVI-I, 1x PCIe x4 (configurable to 4x PCIe x1), 3x SATA 3
Gb/s, and 6x USB 2.0., 5x GPIO, high definition audio, KB/MS,
and 2x serial ports (one supports Tx/Rx only). The PMC/XMC sig-
nals on the cPCI-6530BL can also be routed to RTM.
The cPCI-6530BL Series offers outstanding performance provided
by 5th generation Intel® Core™ processor family, and is an ideal
solution for military, aerospace, transportation and other industrial
applications that require best value per watt computing power. The
ADLINK cPCI-6530BL Series provides higher flexibility, supporting
operation in peripheral slots with CompactPCI bus communication

2Introduction
Leading EDGE COMPUTING
(Universal mode) and as a standalone computer if there is no CPU
blade in the host slot. Internet remote manageability includes IPMI
for system health monitoring over Internet and a GbE port on the
faceplate supports Intel® AMT 9.0 for remote monitoring.
1.2 Features
X6U CompactPCI blade in 4HP width form factor
XIntel® Core™ i7-5850EQ Processor (4 cores, 8 threads, 6M
cache, 2.7/3.4 GHz) and Mobile Intel® QM87 Express Chipset
XGraphics and memory controllers integrated in processor
XOne channel DDR3L soldered onboard memory with ECC up
to 16GB and one channel DDR3L ECC socket memory up to
16GB (total 32GB). When equipped with 8GB onboard mem-
ory, the frequency is 1600MHz; when equipped with 16GB
onboard memory, the frequency is reduced to 1067MHz.
X64bit/66MHz CompactPCI Interface based on PCI specifica-
tions, universal V(I/O)
XSupports Universal mode operation as a slave in peripheral
slots and operation as a standalone computer if no CPU blade
in host slot
XOne 64-bit/33,66,133MHz PMC or PCIe x8 Gen2 XMC site on
cPCI-6530BLV with rear I/O; one additional PMC/XMC site on
cPCI-6530BL
XSupports IPMI over LAN for system health monitoring
X DVI-I port on front panel, additional DVI-I and eDP routed to rear
XTwo PCIe Gigabit Ethernet egress ports supported by Intel
LAN controller on front panel, one supports Intel® AMT 9.0 by
Intel® Ethernet Controller I210 (PHY)
XTwo additional PCIe Gigabit Ethernet by Intel® Ethernet Con-
troller I210 routed to J2 (PICMG 2.16 compliant)
XAdditional two Gigabit Ethernet ports with selected rear transi-
tion module (cPCI-R6100 Series)
XHigh definition audio routed to RTM
XOnboard mSATA for SATA interface storage
XOptional onboard 2.5" SATA SSD or CFast storage on
cPCI-6530BLV
XOptional Atmel AT97SC3204 TPM support

Introduction 3
cPCI-6530BL
1.3 Package Contents
The cPCI-6530BL is packaged with the following components. If
any of the following items are missing or damaged, retain the ship-
ping carton and packing material and contact the dealer for
inspection. Please obtain authorization before returning any prod-
uct to ADLINK. The packing contents of cPCI-6530BL Series
non-standard configurations will vary depending on customer
requests.
CPU module
XThe cPCI-6530BL Series Processor Blade
ZCPU and memory specifications will differ depending on
options selected
ZThermal module is assembled on the board
XRJ-45 to DB-9 COM adapter cable (cPCI-6530BLV)
X2.5” SATA drive accessory pack (cPCI-6530BLV)
XmSATA accessory pack
Rear Transition Module
XDependent on the module selected
Optional Accessories
XDB-CFAST adapter board for CFast card assembly (Part
No. 91-37572-010E)
NOTE:
NOTE:
The contents of non-standard cPCI-6530BL configurations
may vary depending on the customer’s requirements.
CAUTION:
This product must be protected from static discharge and phys-
ical shock. Never remove any of the components except at a
static-free workstation. Use the anti-static bag shipped with the
product when putting the board on a surface. Wear an
anti-static wrist strap properly grounded on one of the system's
ESD ground jacks when installing or servicing system compo-
nents.

4Introduction
Leading EDGE COMPUTING
This page intentionally left blank.

Specifications 5
cPCI-6530BL
2 Specifications
2.1 cPCI-6530BL Processor Blade Specifications
CompactPCI®
Standards • PICMG® 2.0 CompactPCI® Rev. 3.0 • PICMG® 2.1 Hot Swap Specification Rev. 2.0
• PICMG® 2.9 System Management Rev. 1.0
• PICMG® 2.16 Packet Switching Backplane Rev. 1.0
Mechanical • Standard 6U CompactPCI®
• Board size: 233mm x 160mm
• Single slot (4HP, 20.32mm)
• CompactPCI® connectors: J1, J2, J3, J4, J5
Processor • uFC-BGA quad-core Intel® Core™ i7-5850EQ processor,
2.7/3.4GHz, 6MB L3 cache, 47/37W by cTDP, Intel® Iris Pro
Graphics 6200
• uFC-BGA quad-core Intel® Core™ i7-5700EQ processor,
2.6/3.4GHz, 6MB L3 cache, 47/37W by cTDP
• Passive heatsink
Chipset • Mobile Intel® QM87 Express Chipset
Memory • Dual channel DDR3L ECC memory, max. support 32GB
• One channel DDR3L soldered onboard memory with ECC up
to 16GB
• One channel DDR3L ECC socket memory up to 16GB
• When equipped with 8GB onboard memory, the frequency is
1600MHz; when equipped with 16GB onboard memory, the
frequency is reduced to 1067MHz
CompactPCI
Bus • PCI 64-bit/66MHz; 3.3V, 5V universal V I/O • Supports operation in system slot as master or in peripheral
slot with connectivity to CompactPCI bus (Universal mode)
• Supports operation in peripheral slot as standalone CPU
board when no host blade in host slot
Gigabit
Ethernet • One PCIe x1 Intel® I217 GbE PHY and three PCIe x1 Intel® I210 Gigabit Ethernet controllers
• Two egress 10/100/1000BASE-T ports on front panel, one
supporting Intel® AMT 9.0 by I217 controller
• Two egress 10/100/1000BASE-T ports routed to rear
transition module
Table 2-1: cPCI-6530BL Processor Blade Specifications

6 Specifications
Leading EDGE COMPUTING
Graphics • Intel® Core™ i7-5850EQ: Intel® Iris Pro Graphics 6200
• Intel® Core™ i7-5700EQ: Intel® HD Graphics 4600
• One DVI-I port on front panel, one DVI, eDP routed to J3 & J5
(RTM)
• Up to three independent display with selected rear transition
module (cPCI-R6700 & cPCI-R6500)
Serial Ports • Up to three serial ports
• One RS-232/422/485 serial port on front panel
(cPCI-6530BLV)
• Up to two RS-232 COM port routed to RTM
USB 2.0 • One USB 2.0 port on front panel
• Up to six USB 2.0 ports routed to rear transition module
USB 3.0 • One USB 3.0 for cPCI-6530BL version, additional one USB
3.0 for cPCI-6530BLV version
PMC/XMC • One 64-bit/33,66,133 MHz PMC site or PCIe x8 Gen 2 XMC
site for cPCI-6530BLV version with rear I/O
• Two 64-bit/33,66,133 MHz PMC sites or PCIe x8 Gen 2 XMC
sites on cPCI-6530BL version
Audio • High definition audio routed to rear
TPM Atmel AT97SC3204 TPM (upon request) supporting:
• Over/Under voltage detection
• Low/High frequency sensor/filter
• Reset filter
• Memory encryption/decryption
Storage
Interfaces1• One mSATA slot
• One onboard 2.5” SATA connector supporting SATA 6Gb/s
drive on cPCI-6530BLV
• Optional CFast socket by adapter board on cPCI-6530BL
(space shared with 2.5” SATA drive)
• One SATA 7-pin 3Gb/s connector onboard
• Three SATA 3Gb/s channels routed to RTM
BIOS • AMI® EFI BIOS, 64Mbit SPI flash memory, supports
Configurable TDP (can be set as Nominal and Down)
Table 2-1: cPCI-6530BL Processor Blade Specifications

Specifications 7
cPCI-6530BL
1. The storage device limits the operational vibration tolerance. When
the application requires higher specification for anti-vibration, it is
recommended to use a flash storage device.
2. ADLINK-certified thermal design. The thermal performance is depen-
dent on the chassis cooling design. Sufficient forced air-flow is required.
Temperature limits of optional mass storage devices may also affect the
thermal specification.
Faceplate I/O cPCI-6530BLV (4HP)
• 2x 10/100/1000BASE-T Ethernet ports
•1xDVI-Iport
• 2x USB 3.0 ports
• 1x USB 2.0 port
• 1x RJ-45 serial port
• 1x PMC/XMC slot
cPCI-6530BL (4HP)
• 2x 10/100/1000BASE-T Ethernet ports
• 1x USB 3.0 ports
• 1x USB 2.0 port
• 2x PMC/XMC slots
OS
Compatibility • Microsoft Windows 7 32/64-bit • Microsoft Windows 8 32/64-bit
• Red Hat Enterprise Linux 6.4, 64-bit
• Fedora 14, 32-bit
• VxWorks 6.9
• Other OS support upon request
Environmental • Operating Temperature (with forced air flow)2:
Standard: -20°C to +70°C
Extreme temperature: -40°C to +85°C (for Intel®
Core™ 5850EQ and Core™ i7-5700EQ processor with
cTDP down to 37W and forced air flow)
• Storage Temperature: -50°C to 100°C
• Humidity: 95% @60°C non-condensing
• Shock: 20G peak-to-peak, 11ms duration, non-operating
•Vibration
3: 2Grms, 5-500Hz, each axis, operating (w/o hard
drive)
EMI • CE EN55022
• FCC Class A
Table 2-1: cPCI-6530BL Processor Blade Specifications

8 Specifications
Leading EDGE COMPUTING
2.2 Block Diagrams
cPCI-6530BL Blade
Figure 2-1: cPCI-6530BL Blade Functional Block Diagram
DVI
VGA
Front Panel
DMI
J1/J2 J3/J4/J5
PCIe x4
PI7C9X130
mSATA
PCIe x4
Intel
I217
PCIe x1
PCIe x1
6x USB 2.0
3x SATA 3G
HDA
5x GPIO
RTC
PCIe x4
SIO
LPC
KB/MS
COM2/3
COM6
BMC
COM1
SPI
XMC2
DDR3 1600/1067MHz
IPMB 0/1
FDI
GbE2 GbE1
DVI-I
USB1 USB2 USB3 COM1
2.5” HDD
SATA2
PMC2
5th Gen
Intel® Core™
Soldered w/ ECC, max. 16GB
ECC SO-CDIMM, max.
PCI 64b/133M
PCIe x1
BIOS
Intel® QM87 PCH
PI7C9X130
Intel
I210
PCI 64b/66M
2x
USB 3.0
CFast
SATA0
TPM
7-pin
SATA1
TMDS/
DP-B
eDP
USB 2.0
PMC1 XMC1
PCIe x8
GbE 3/4
PCIe x1
VGA
PCIe X8
PCIe X8
Rear I/O
Intel
I210
Intel
I210
PEX8624
DP to
VGA
