Rabbids Hollywood - 65”
RHW-65-1001
Operation & Service Manual
Version 5.0
* Read this manual before use

Rabbids Hollywood Manual V5.0
2 | P a g e
General Remark
If you encounter any difficulties or if you need support on how to update and/ or install your
Rabbids Hollywood product, we invite you to contact your local distributor or reach us at
[email protected] or by calling our support line [phone]
Adrenaline Amusements Team
Adrenaline Amusements
2273 Antonio-Héroux street
Terrebonne, Qc
Canada
J6X 4R3

Rabbids Hollywood Manual V5.0
3 | P a g e
Table of Contents
Contents
General Remark..................................................................................................2
Table of Contents................................................................................................3
Chapter 01 - Preface ...........................................................................................5
Precaution for Game Operation.................................................................................................. 5
Safety........................................................................................................................................... 6
Environmental Conditions........................................................................................................... 6
Operating & Voltage.................................................................................................................... 6
Chapter 02 - Game Features................................................................................7
Chapter 03 –Unit Features .................................................................................8
Hardware Features...................................................................................................................... 8
Cabinet Facts............................................................................................................................... 8
Chapter 04 –Unit Installation .............................................................................9
Assembling your Rabbids Hollywood 65” Unit ........................................................................... 9
How to slide out the Screen Module: ......................................................................................... 9
Header Assembly....................................................................................................................... 11
How to open the Dash Board:................................................................................................... 14
Chapter 05 –Operator Menu............................................................................15
Operator Menu ......................................................................................................................... 15
Chapter 06 –Service & Repair...........................................................................17
Computer Connections ............................................................................................................. 17
Gun tracking Hardware Troubleshooting Guide....................................................................... 18
Plunger Controller ID Configuration.......................................................................................... 19
Troubleshooting ........................................................................................................................ 21
Video Troubleshooting........................................................................................................................21
Audio Troubleshooting .......................................................................................................................21

Rabbids Hollywood Manual V5.0
4 | P a g e
RGB Led Troubleshooting.......................................................................................................... 22
Replacing RGB LED PCBs............................................................................................................ 26
Wireless Internet Configuration................................................................................................ 27
Operator Settings keeps resetting trouble ............................................................................... 28
Computer not powering at boot............................................................................................... 29
Chapter 07 - Parts .............................................................................................32
Cabinet Parts ............................................................................................................................. 32
Computer & Electronics ............................................................................................................ 34
Header & LEDs........................................................................................................................... 37
Cabling....................................................................................................................................... 38
Wiring Harness .......................................................................................................................... 39
Misc. Parts................................................................................................................................. 39
Chapter 08 –Diagrams & Schematics................................................................40
I/0 Board ADR-04-1003 ............................................................................................................. 40
I/O Board –Detailed Wiring................................................................................................................42
Tickets Wiring......................................................................................................................................46
Speakers Wiring Colors .......................................................................................................................47
Power Distribution Schematics ................................................................................................. 48
RGB LED Schematics................................................................................................................. 51
Channel 1................................................................................................................................... 52
Channel 2................................................................................................................................... 53
Chapter 09 –Software Recovery.......................................................................54
Chapter 10 –Card Reader .................................................................................55
Limited Warranty Policies ......................................................................56

Rabbids Hollywood Manual V5.0
Chapter 01 - Preface
5 | P a g e
Chapter 01 - Preface
Please read this page before preparing your Rabbids Hollywood Arcade product
for game play.
The following safety instructions apply to all game operators and service personnel. Specific
warnings and cautions will be included throughout this manual.
Use the following safety guidelines to help protect the system from potential damage and to
ensure your personal safety:
•Electronic components in the game cabinet run on 110V AC 60Hz (220V/ 50Hz in most of
Europe, the Middle East and the Far East delivered units).
•To help prevent electric shock, plug the system into a properly grounded power source.
These cables are equipped with 3-prong plugs to help ensure proper grounding. Do not
use adapter plugs or remove the grounding prong from a cable. If you must use an
extension cable, use a 3-wire cable with properly grounded plugs. We do recommend a
15A rated current or higher power cord.
•To help protect your system from sudden increases and decreases in electrical power,
use a surge suppressor, line conditioner or Uninterruptible Power Supply (UPS).
•Be sure nothing rests on the system’s cables and that the cables are not located where
they can be stepped on or tripped over.
•Keep your system far away from radiators and other heat sources.
•Do not block cooling vents.
Precaution for Game Operation
Adrenaline Amusements Inc. assumes no liability for injuries incurred while playing our games.
Operators should be aware that certain health and physical conditions may make people
susceptible to injury when playing video games.

Rabbids Hollywood Manual V5.0
Chapter 01 - Preface
6 | P a g e
Safety
To avoid electrical shock, unplug the cabinet before performing
installation or service procedures.
If a power cord is damaged, it must be replaced by the equivalent
power cord available from your distributor.
Adrenaline Amusement Inc. assumes no liability for any damages or
injuries incurred while setting up or servicing the cabinet. Only qualified
service personnel should perform installation or service procedures.
Environmental Conditions
Cabinet is intended for indoor use only. Be sure to keep the cabinet dry and maintain operating
temperatures of 59° - 86°F (15° - 30°C).
Operating & Voltage
Voltage
Operating
110V AC
4.0 AMP
220V AC
2.0 AMP

Rabbids Hollywood Manual V5.0
Chapter 02 –Game Features
7 | P a g e
Chapter 02 - Game Features
Are you a sharp shooter?
Then feast your eyes and take aim on Rabbids Hollywood, a four-player shooting gallery experience
filled with boss fights, power-ups and (of course!) your favourite edgy Rabbids humour!
Compete with buddies on the Rabbids takeover of Hollywood movie sets!
How to Play
•Shoot the Rabbids!
•Shoot the power-ups and get an automatic plunger shooter!
•Shoot all the crazy creatures during a four-player adventure and explore 3 different movie sets!

Rabbids Hollywood Manual V5.0
Chapter 03 –Unit Features
8 | P a g e
Chapter 03 – Unit Features
Hardware Features
•4 Players Game
•65 inches LCD Screen
•Unique Sensor Tracker “Gun” Technology!
Cabinet Facts
Cabinet Dimensions
Height = 102.95” [2614.93mm]
Depth = 52.83” [1341.98mm] Width = 66.48” [1688.67mm]
Shipping Dimensions
Width = 45” Depth = 68” Height = 84”
Weight = 650 lbs

Rabbids Hollywood Manual V5.0
Chapter 03 –Unit Installation
9 | P a g e
Chapter 04 – Unit Installation
Assembling your Rabbids Hollywood 65” Unit
**You need to be 2 persons to assemble the unit**
1. Carefully remove the cabinet from the shipping skid, giving you enough space.
2. Move the cabinet to the desired location.
How to slide out the Screen Module:
3. Remove the 4x bolts #10-24 x 1-¼” (2x per side) holding the monitor cabinet assembly to the front
cabinet assembly. (see symbol on picture below)
4. Slide out the 2 cabinets and align the bracket holes with the center part holes.
5. Re-insert the 4x bolts and tighten them. (see symbol on picture below)

Rabbids Hollywood Manual V5.0
Chapter 03 –Unit Installation
10 | P a g e
6. Lower the Level adjustors until the Pivot Wheels are slightly above the floor.

Rabbids Hollywood Manual V5.0
Chapter 03 –Unit Installation
11 | P a g e
Header Assembly Installation
The following operations replace previous pages 11-13 of the installation manual
**You need to be 2 persons to install the header on the monitor*
1) Install hardware for the logo header
Install 2 nuts and 1 coupling nut on each bolt
2) Install the background header
Secure the background header with the provided ¼-20 x ¾ bolts and washers

Rabbids Hollywood Manual V5.0
Chapter 03 –Unit Installation
12 | P a g e
3) Install the header on the machine
Position the header in the slot, insert the 3 mending plates and secure them with the
provided screws
X3
X3

Rabbids Hollywood Manual V5.0
Chapter 03 –Unit Installation
13 | P a g e
4) Connect the header 12V barrel connectors together.

Rabbids Hollywood Manual V5.0
Chapter 05 –Operator Menu
14 | P a g e
How to open the Dash Board:
-To open the dash and access the electronics, open the cash box doors to get access to the 2 Draw
Latches inside the cabinet.

Rabbids Hollywood Manual V5.0
Chapter 05 –Operator Menu
15 | P a g e
Chapter 05 – Operator Menu
Operator Menu
Access the Operator Menu by pressing the Operator button located inside the drawer on the I/O board
directly.
Oper: Open the Operator Menu
Up: Scroll Up & Increase Value
Down: Scroll Down & Decrease Value
Select Button: Select/Deselect

Rabbids Hollywood Manual V5.0
Chapter 05 –Operator Menu
16 | P a g e
Operator Menu
Values
What It Does
Credits Per Game
1-20
Adjusts the number of credits required to play. “0” sets
the unit in free play mode.
Game Audio Volume
0-20
Adjusts the in-game audio volume. “0” will mute the
game.
Attract Audio Volume
0-20
Adjusts the audio volume of the attract loop. “0” will
mute the attract loop.
Payment Type
Credit / Card
Changes the credit type. “Credits” = Coins and
“Card” = Card Reader. This will change the in-game text
accordingly.
Electronic Ticket
On/Off
“On”will enable the card reader’s electronic tickets.
“Off”will enable paper tickets.
Credit Sharing
1_2 / 3_4
On / Off
Adjusts the credit sharing option between each player.
(Off: Sharing Disabled // On: Sharing Enabled)
If you have Card Reader (4X) please use OFF.
Difficulty
1-5
Adjusts the Difficulty Level (1 is Easiest, 5 is Hardest).
Redemption Mode
On / Off
Adjusts the redemption mode. This will change the in-
game text accordingly.
Minimum Ticket
0-20
Adjusts the minimum number of tickets dispensed per
play.
Ticket Value
1-2
Adjusts the value of physical tickets. Physical tickets are
either worth “1” ticket or “2” tickets.
Points Per Ticket
500-5000
Adjusts the value by which the final score is divided to
determine ticket redemption.
Gun Frequency
1
If you have 2 units close to each other select a different
frequency.
Gun P1
On / Off
Gun Operating Mode (On: Working Off: Not Working)
Gun P2
On / Off
Gun Operating Mode (On: Working Off: Not Working)
Gun P3
On / Off
Gun Operating Mode (On: Working Off: Not Working)
Gun P4
On / Off
Gun Operating Mode (On: Working Off: Not Working)
Gun tool
Calibration tool to test the gun’s response to the player’s
movements
Aim Calibration
Opens a calibration tool for each player’s target
Error Logs
Displays the previous errors
Diagnostics
Test for each gun’s triggers and vibration
Test for each button
Clear Credits
Resets the Inserted credits to 0 if more than 40 credits
are entered.
Game Stats
Shows the Stats Screen.
Resume Game
Exits the Operator Menu and returns to the game.
Quit Game
Exits the game and returns to the Windows desktop.

Rabbids Hollywood Manual V5.0
Chapter 06 –Service & repair
17 | P a g e
Chapter 06 – Service & Repair
Computer Connections
No.
Description
1.
PCI-e Video Adapter DVI to Monitor DVI
2.
Audio Jack to Amplifier #1
3.
USB to Gun Controller 1
4.
USB to Gun Controller 2
5.
USB to Gun Controller 3
6.
USB to Gun Controller 4
7.
USB to STEM Base
8.
USB to USB Hub Inlet
9.
AC Inlet Power Supply
10.
AC Power Switch
11.
Power Button

Rabbids Hollywood Manual V5.0
Chapter 06 –Service & repair
18 | P a g e
Gun tracking Hardware Troubleshooting Guide
The gun tracking system consists of 3 main components.
1. Gun base board, under center plastic console
2. Tracking coil, which is connected to the base board
3. Gun stem stick, inside the gun
Issue: Aims moves left or right when you approach the gun closer to the screen.
Problem: There is a big metal structure behind the cabinet that makes electromagnetic interference.
Solution: Move the cabinet about 45cm (18’') in front away from the interference.
Issue: Aim is not accurate on gun 1 or gun 4. It is even worse when the gun is closer to the side panel.
Problem: There is a metal structure on the side of the cabinet that makes electromagnetic interference.
Solution: Move the cabinet about 45cm (18'') away from the interference.
Issue: Aim on one gun locks randomly in place during game play.
Problem: USB communication between gun and computer is erratic.
Solution: Change the USB extension from gun harness to the USB hub, if that does not work you can
change the gun hose harness or the complete gun assembly.
Issue: Aim is completely erratic or even not present on one of the guns.
Problem: Tracking hardware in gun defective.
Solution: Change the gun.
Issue: Aim is completely erratic on all 4 guns.
Problem: Coil is disconnected from base board or base board is defective.
Solution: Check if coil connection is ok, change the base board.

Rabbids Hollywood Manual V5.0
Chapter 06 –Service & repair
19 | P a g e
Plunger Controller ID Configuration
Instructions for Controller ID Configuration
Each controller has an ID to be identified as Player 1 to Player 4. If a Stem Stick is replaced and has a
wrong ID, it needs to be remapped.
Quit the game on the Windows desktop.
On the Windows desktop you have an icon shortcut called “Controller ID Configuration”.
Double click on it to start the program.
When you pick up a Gun controller from its holster it should display which device has been picked up. If
you have 2x Stem Stick with the Same ID, you can find the one that needs to be remapped to its good ID.

Rabbids Hollywood Manual V5.0
Chapter 06 –Service & repair
20 | P a g e
To remap an ID, double click with the mouse to select the Stem Stick ID.
Click in the “Change ID (1-4)” box with your mouse and enter the good ID number (1 to 4) that matches
the good player position.
In this example, the Device B is wrongly set to ID#2 but is in fact in player-1 position physically, so we
enter the number “1” and click on Set to change it to Player 1.
