Adrenaline Amusements NFS Heat Takedown Installation and operating instructions

Heat Takedown
NFS-43-1001-0
(X can be 1 to 9)
Operation & Service Manual
Version 1.0.2

NFS Heat Takedown V1.0.2
2 | P a g e
* Read this manual before use
General Remark
If you encounter any difficulties or if you need support on how to update and/ or install your
Hot Wheels King of the Road product, we invite you to contact your local distributor or reach us
at [email protected] or by calling our support line [phone]
Adrenaline Amusements Team
Adrenaline Amusements
2273 Antonio-Héroux street
Terrebonne, QC
Canada
J6X 4R3

NFS Heat Takedown V1.0.2
3 | P a g e
Table of Contents
Contents
General Remark..................................................................................................2
Table of Contents................................................................................................3
Chapter 01 - Preface ...........................................................................................4
Chapter 02 - Game Features................................................................................6
Chapter 03 –Unit Features .................................................................................7
Chapter 04 –Unit Installation .............................................................................9
Chapter 05 –Operator Menu............................................................................13
Chapter 06 - Parts .............................................................................................18
Chapter 07 –Diagrams & Schematics................................................................34
Chapter 08 –Software Recovery.......................................................................45
Chapter 09 –Card Reader .................................................................................46
Chapter 10 –Troubleshooting...........................................................................47
Limited Warranty Policies ......................................................................55

NFS Heat Takedown V1.0.2
Chapter 01 - Preface
4 | P a g e
Chapter 01 - Preface
Please read this page before preparing your NFS Heat Takedown Arcade product
for game play.
The following safety instructions apply to all game operators and service personnel. Specific
warnings and cautions will be included throughout this manual.
Use the following safety guidelines to help protect the system from potential damage and to
ensure your personal safety:
•Electronic components in the game cabinet run on 110V AC 60Hz (220V/ 50Hz in most of
Europe, the Middle East and the Far East delivered units).
•To help prevent electric shock, plug the system into a properly grounded power source.
These cables are equipped with 3-prong plugs to help ensure proper grounding. Do not
use adapter plugs or remove the grounding prong from a cable. If you must use an
extension cable, use a 3-wire cable with properly grounded plugs. We do recommend a
15A rated current or higher power cord.
•To help protect your system from sudden increases and decreases in electrical power,
use a surge suppressor, line conditioner or Uninterruptible Power Supply (UPS).
•Be sure nothing rests on the system’s cables and that the cables are not located where
they can be stepped on or tripped over.
•Keep your system far away from radiators and other heat sources.
•Do not block cooling vents.
Precaution for Game Operation
Adrenaline Amusements Inc. assumes no liability for injuries incurred while playing our games.
Operators should be aware that certain health and physical conditions may make people
susceptible to injury when playing video games.

NFS Heat Takedown V1.0.2
Chapter 01 - Preface
5 | P a g e
Safety
To avoid electrical shock, unplug the cabinet before performing
installation or service procedures.
If a power cord is damaged, it must be replaced by the equivalent
power cord available from your distributor.
Adrenaline Amusement Inc. assumes no liability for any damages or
injuries incurred while setting up or servicing the cabinet. Only qualified
service personnel should perform installation or service procedures.
Environmental Conditions
Cabinet is intended for indoor use only. Be sure to keep the cabinet dry and maintain operating
temperatures of 59° - 86°F (15° - 30°C).
Operating & Voltage
This game cabinet is shipped configured as either 120V or 240V and is not user switchable. Do not
attempt to change the voltage switches on the power supplies to change the required voltage.
Voltage
Operating
120V AC
8 AMP
220V AC
4 AMP

NFS Heat Takedown V1.0.2
Chapter 02 –Game Features
6 | P a g e
Chapter 02 - Game Features
Are you fast enough to scape the cops? Do you have the skills to take the wheels and drift?
Push the Nitrous and takedown your enemies on the streets and become the king of Palm City.
How to Play
•Use the steering wheel to drive the racetracks
•Use the pedals to accelerate and drift
•Collide with other players and the cops to take them down
•Collect and push the nitrous to escape and win the race

NFS Heat Takedown V1.0.2
Chapter 03 –Unit Features
7 | P a g e
Chapter 03 – Unit Features
Hardware Features
•1 to 4 Players Game
•Steering wheels & accelerator pedals for each player
•43 inches LCD Screen
Cabinet Facts –1 player version
Cabinet Dimensions
Height = 91.35” [2320.3mm]
Depth = 65.87” [1673.1mm] Width = 40.31” [1023.9mm]
Shipping Dimensions
Width = 45”Depth = 58”Height = 83”
Weight = 650 lbs

NFS Heat Takedown V1.0.2
Chapter 03 –Unit Features
8 | P a g e
Cabinet Facts –4 players assembly
Cabinet Dimensions
Height = 91.35” [2320.3mm]
Depth = 65.87” [1673.1mm] Width = 161.27” [4.096.3mm]

NFS Heat Takedown V1.0.2
Chapter 04 –Unit Installation
9 | P a g e
Chapter 04 – Unit Installation
How to assemble your NFS Heat Takedown
1) Remove the four screw who hold the two steel bars inside and take them out..
2) Install back the steel bars as show on the picture.
3) Move the seat module towards the large cabinet.Connect all three cables coming from
the seat to the cabinet.

NFS Heat Takedown V1.0.2
Chapter 04 –Unit Installation
10 | P a g e
4) In order to secure the seat to the cabinet, Push the seat until the steel bars are
completely inserted. Using the ¼-20 screws, secure the seat in each side.
5) Push the screen up and secure it by installing the two 1/4 screws from the inside.

NFS Heat Takedown V1.0.2
Chapter 04 –Unit Installation
11 | P a g e
How to assemble and connect two or more NFS Heat Takedown
1) Place the machines beside each one. The first arcade to the left will be the player #1.
2) When you are pleased by the arrangement of the machines, secure them by fixing all
the leveling mounts of each arcade.
1
2
3
4

NFS Heat Takedown V1.0.2
Chapter 04 –Unit Installation
12 | P a g e
Multiplayer network connection
3) connect all the arcades to the network hub.
4) start the arcades, access to the operator menu, and change one by one the Machine ID.
(To know how to get access to the operator menu, go to chapter 5.)
4
1
2
3

NFS Heat Takedown V1.0.2
Chapter 05 –Operator Menu
13 | P a g e
Chapter 05 – Operator Menu
Operator Menu
Access the Operator Menu by pressing the white operator menu button behind the coin door.

NFS Heat Takedown V1.0.2
Chapter 05 –Operator Menu
14 | P a g e
SETTINGS
Operator Menu
Values
What It Does
Game Audio Volume
1-20
Adjusts the in-game audio volume. “0” will mute the game.
Attract Audio Volume
0-20
Adjusts the volume of the voice attract loop. “0” will mute
Language
English/Français
Switches the game and the menu’s language
Take Picture
On / Off
Takes pictures of each player at the start of the game
Toggle Music
On / Off
Toggles in-Game Music On or Off
Toggle SFX
On / Off
Toggles in-Game Sound Effects On or Off
Toggle VO
On / Off
Toggles in-Game Voices On or Off
Speed Format
MPH / KPH
Toggles speed indicator from MPH to KPH
Use Seat Motion
On / Off
On Motion cabinets to toggle motion Off
Machine ID
1-4
Sets the Machine ID, Set games 1-4 (left to right)
Payment Type
Credit / Card
Changes the credit type. “Credits” = Coins and
“Card” = Card Reader. This will change the in-game text
accordingly.
Clear Credits
Resets the Inserted credits to 0 if more than 40 credits are
entered.
Resume Game
Exits the Operator Menu and returns to the game.
Quit Game
Exits the game and returns to the Windows desktop.

NFS Heat Takedown V1.0.2
Chapter 05 –Operator Menu
15 | P a g e
PAYMENT
Operator Menu
Values
What It Does
Credit per Game
1-20
Set Price per Play
Payment Type
Credit / Card
Changes the credit type. “Credits” = Coins and
“Card” = Card Reader. This will change the in-game text
accordingly.
Clear Credits
Resets the Inserted credits to 0 if more than 40 credits are
entered.
Resume Game
Exits the Operator Menu and returns to the game.
Quit Game
Exits the game and returns to the Windows desktop.

NFS Heat Takedown V1.0.2
Chapter 05 –Operator Menu
16 | P a g e
Network Connections
The left menu
The left menu is a quick status overview of the state of the cabinet.
BUILD
This is the version number of the game software
DEVICE ID
The unique ID of your machine
TYPE
This will tell you if this machine is the server or a client
MULTIPLAYER
If the cabinet is connected or not to other games.
HEADER
If the computer sees a header connected to its video cable
PLAYER ID
The position of the cabinet. Cabinet 1 must be the completely at the left of the setup and
cabinet 4 at the right end. Each game must have a different ID.
I/O FIRMWARE
The firmware version of the I/O board
Network connections sections
The game is using a local wired network for Multiplayer play. It is strongly recommended to connect
each game to your local Wi-Fi internet access. This will enable the game to download updates
automatically.

NFS Heat Takedown V1.0.2
Chapter 05 –Operator Menu
17 | P a g e
Multiplayer status
The upper part of this screen will indicate the status of your cabinets.
Red cabinet indicates that this cabinet is not plugged to the rest of the network via the network switch
and green indicates that everything is fine.
Available wi-fi
The lower part of the screen will allow you to connect to an available WIFI network.
The network must be password protected. You move to the network you want to connect to, press the
pedal, then enter the network’s password. The icon below the “Internet” label will tell you if you are
connected or not to the WIFI network and the signal strength.

NFS Heat Takedown V1.0.2
Chapter 06 –Parts
18 | P a g e
Chapter 06 - Parts
Seat base
Ref
Part Description
Part #
QTY
1
Seat Melamine Black Top
NFS-02-0002-04
1
2
Top Rear Bracket, Seat Cabinet
NFS-01-0017
1
3
Seat Printed Melamine Back
NFS-02-0002-05
1
4
Angle Leg Support, 1/2-13
RAC-01-0140
4
5
Seat Melamine Black Inside Sides R/L
NFS-02-0002-07
2
6
Seat Printed Melamine Left Side
NFS-02-0002-02
1
7
Seat Plywood Floor
NFS-02-0002-01
1
8
Steel Plate, Need for Speed
NFS-01-0024
2
9
Seat Melamine Black Front
NFS-02-0002-06
1
10
Seat Printed Melamine Right Side
NFS-02-0002-03
1
11
Multi-Position Wide Corner Bracket, 1'' x 1-3/4''
SB-1-3/4X1X1
12

NFS Heat Takedown V1.0.2
Chapter 06 –Parts
19 | P a g e
Seat base

NFS Heat Takedown V1.0.2
Chapter 06 –Parts
20 | P a g e
Ref
Part Description
Part #
QTY
1
Cabinet Melamine Top
NFS-02-0010-05
1
2
Cabinet Melamine Front Up
NFS-02-0010-06
1
3
Cabinet Melamine Back Thin Screen
NFS-02-0010-31
1
4
Cabinet Printed Melamine Right Side
NFS-02-0010-09
1
5
Cabinet Melamine Front Screen Bottom Mounting
NFS-02-0010-23
1
6
Cabinet Melamine Speaker Mounting
NFS-02-0010-02
1
7
Cabinet Melamine Cash Door Side Panel
NFS-02-0010-11
1
8
Cabinet Melamine Cash Door Mounting Panel
NFS-02-0010-10
1
9
Cabinet Melamine Center Floor Support
NFS-02-0010-03
2
10
Cabinet Plywood Floor Facing
NFS-02-0010-04
1
11
Cabinet Plywood Top Floor
NFS-02-0010-07
1
12
Cabinet Melamine Pedal Panel
NFS-02-0010-12
1
13
Cabinet Printed Melamine Left Side
NFS-02-0010-08
1
14
Dash Upper Plywood 3/8 Shim
NFS-02-0010-29
2
15
Bottom Screen Holder
NFS-02-0010-30
2
16
Cabinet Melamine Camera Mounting
NFS-02-0010-27
1
17
Cabinet Melamine Upper Shim
NFS-02-0010-26
1
18
Cabinet Melamine Screen Upper Mounting
NFS-02-0010-28
4
19
Cabinet Melamine Back Fan Mounting
NFS-02-0010-16
1
20
Cabinet Melamine Inside Shelf
NFS-02-0010-13
1
21
Cabinet Melamine Up Center Back Panel
NFS-02-0010-24
1
22
Cabinet Melamine Up Back Access Door
NFS-02-0010-20
1
23
Cabinet Melamine Bottom Inside Brace
NFS-02-0010-25
1
24
Cabinet Plywood Bottom Floor
NFS-02-0010-01
1
25
Cabinet Melamine Back EMI Mounting
NFS-02-0010-21
1
26
Cabinet Melamine Bottom Back Access Door Held Up
NFS-02-0010-22
1
27
Cabinet Melamine Bottom Back Access Door
NFS-02-0010-19
1
28
Cabinet Melamine Up Back Access Door Held Up
NFS-02-0010-18
1
29
Cabinet Melamine Up Back Access Door
NFS-02-0010-17
1
30
Cabinet Melamine Bottom Sides Lining
NFS-02-0010-14
2
31
Cabinet Melamine Up Sides Lining
NFS-02-0010-15
2
