Candy Crush (Ticket)
CT-42-1001
Operation & Service Manual
Version 1.0
* Read this manual before use

Candy Crush Ticket Manual V1.0
2
General Remark
If you encounter any difficulties or if you need support on how to update and/ or install your
Candy Crush product, we invite you to contact your local distributor or reach us at
[email protected] or by calling our support line [phone]
Adrenaline Amusements Team
Adrenaline Amusements
1150 Levis, Suite 302
Terrebonne, Qc
Canada
J6W 5S6

Candy Crush Ticket Manual V1.0
3
Table of Contents
Contents
General Remark..................................................................................................2
Table of Contents................................................................................................3
Chapter 01 - Preface ...........................................................................................5
Precaution for Game Operation.................................................................................................. 5
Safety........................................................................................................................................... 6
Environmental Conditions........................................................................................................... 6
Chapter 02 - Game Features................................................................................7
How to Play ................................................................................................................................. 7
Chapter 3 –Unit Features ...................................................................................8
Hardware Features...................................................................................................................... 8
Cabinet Facts ............................................................................................................................... 8
Voltage ........................................................................................................................................ 9
Chapter 04 - Unit Installation ............................................................................10
Assembling your Candy Crush Tickets Unit............................................................................... 10
Chapter 05 –Operator Menu ............................................................................13
Operator Menu ......................................................................................................................... 13
Chapter 06 - Service & Repair............................................................................15
Computer Connections ............................................................................................................. 15
Troubleshooting ........................................................................................................................ 16
Video Troubleshooting........................................................................................................................16
Audio Troubleshooting ....................................................................................................................... 17
Chapter 07 - Parts .............................................................................................18
Cabinet Parts ............................................................................................................................. 18
Electronics ................................................................................................................................. 19
Thermoplastic............................................................................................................................ 20

Candy Crush Ticket Manual V1.0
4
Wheel Assembly........................................................................................................................ 21
Computer Parts ......................................................................................................................... 22
Cabling....................................................................................................................................... 22
Wiring Harness .......................................................................................................................... 22
Misc. Parts ................................................................................................................................. 23
I/0 board LC-04-1001 ................................................................................................................ 24
Chapter 08 –Diagrams & Schematics................................................................25
Power Distribution .................................................................................................................... 25
IO Board Wiring Diagram .......................................................................................................... 26
Chapter 09 –Software Recovery .......................................................................27

Candy Crush Tickets Manual V1.0
Chapter 01 - Preface
5
Chapter 01 - Preface
Please read this page before preparing your Candy Crush product for game play.
The following safety instructions apply to all game operators and service personnel. Specific
warnings and cautions will be included throughout this manual.
Use the following safety guidelines to help protect the system from potential damage and to
ensure your personal safety:
Electronic components in the game cabinet run on 110V AC 60Hz (220V/ 50Hz in most of
Europe, the Middle East and the Far East delivered units).
To help prevent electric shock, plug the system into a properly grounded power source.
These cables are equipped with 3-prong plugs to help ensure proper grounding. Do not
use adapter plugs or remove the grounding prong from a cable. If you must use an
extension cable, use a 3-wire cable with properly grounded plugs.
To help protect your system from sudden increases and decreases in electrical power,
use a surge suppressor, line conditioner or Uninterruptible Power Supply (UPS).
Be sure nothing rests on the system’s cables and that the cables are not located where
they can be stepped on or tripped over.
Keep your system far away from radiators and other heat sources.
Do not block cooling vents.
Precaution for Game Operation
Adrenaline Amusements Inc. assumes no liability for injuries incurred while playing our games.
Operators should be aware that certain health and physical conditions may make people
susceptible to injury when playing video games.

Candy Crush Tickets Manual V1.0
Chapter 01 - Preface
6
Safety
To avoid electrical shock, unplug the cabinet before performing
installation or service procedures.
If a power cord is damaged, it must be replaced by the equivalent
power cord available from your distributor.
Adrenaline Amusement Inc. assumes no liability for any damages or
injuries incurred while setting up or servicing the cabinet. Only qualified
service personnel should perform installation or service procedures.
Environmental Conditions
Cabinet is intended for indoor use only. Be sure to keep the cabinet dry and maintain operating
temperatures of 59°F - 86°F (15°C - 30°C).

Candy Crush Tickets Manual V1.0
Chapter 02 –Game Features
Chapter 02 - Game Features
Win a lot of tickets!
How to Play
Explore the sweet and colourful world of Candy Crush Saga in this fun match-3 game!
Switch and match your way through 15 of levels in this delicious puzzle adventure.
100% Skill game.
Clear all the jelly to spin the wheel.
Win the 15 Levels and get the Ticket Super Bonus!

Candy Crush Tickets Manual V1.0
Chapter 03 - Unit Features
8
Chapter 3 –Unit Features
Hardware Features
Multitouch Screen
LED Adjustable Super Bonus
Ticket Bonus Motorized Wheel
Cabinet Facts
Cabinet Dimensions
Height = 99,2” / 2.52m
Depth = 28,1’’ / 0,71m Width = 46’’ /1,18m
Shipping Dimensions
Width = 50” Height = 48”
Weight = 700 lbs

Candy Crush Tickets Manual V1.0
Chapter 03 - Unit Features
9
Voltage
Voltage
Operating
110V AC
4 AMP
220V AC
2 AMP

Candy Crush Tickets Manual V1.0
Chapter 04 - Unit Installation
10
Chapter 04 - Unit Installation
Assembling your Candy Crush Tickets Unit
1. Carefully remove the 2 Cabinet parts from the shipping container, giving you enough
space.
2. Move the bottom cabinet to the desired location.
** For your security, minimum 2 persons are needed to complete the installation **
Fig. 1
3. Adjust the legs leveler.

Candy Crush Tickets Manual V1.0
Chapter 04 - Unit Installation
11
4. Before installing the upper cabinet, locate the 5 bolt holes on the bottom cabinet and
the 5 bolts inserts on the upper cabinet.
5. Remove the upper cabinet back service door, install the upper cabinet on the bottom
one, align the bolt holes with the bolt inserts, affix and tighten the 5 bolts.
Fig. 2

Candy Crush Tickets Manual V1.0
Chapter 04 - Unit Installation
12
6. Connect the Power Supply AC cable from the top cabinet to AC the power bar.
Also connect the 10-pins connectors together as seen on figure 2.
Re-install the back service doors.
Fig. 3

Candy Crush Tickets Manual V1.0
Chapter 05 –Operator Menu
13
Chapter 05 –Operator Menu
Operator Menu
Access the Operator Menu by pressing the switch button located inside the coin door.
Fig. 4

Candy Crush Tickets Manual V1.0
Chapter 05 –Operator Menu
14
Operator Menu
Values
What it does
Credits Per Game
0 –20
Adjusts the number of credits required to play. “0”
sets the unit in free play mode.
Game Audio Volume
0 –20
Adjusts the in-game audio volume. “0” will mute
the game.
Attract Audio Volume
0 –20
Adjusts the audio volume of the attract loop. “0”
will mute the attract loop.
TicketValue
1 –2
Adjusts the value of physical tickets. Physical tickets
are either worth “1” ticket or “2” tickets.
PaymentType
Credit/Card
Changes the credit type. “Credits” = Coins and
“Card” = Card Reader. This will change the in-game
text accordingly
Redemption Mode
Yes/No
Adjusts the redemption mode. This will change the in-
game text accordingly.
Checkmarked is Yes while No Checkmark is No.
Redemption Units Name
Tickets/Coupons
Adjusts the in-game text accordingly.
Super Jackpot Payout Tickets
500-5000
Adjusts the LED display and the number of tickets
given when Super Bonus is won.
Minimum Tickets Payout
0-20
Adjusts the minimum number of tickets dispensed per
play.
Payout Adjustment
1-9
Adjusts the payout of tickets given. 1 will give less tickets
while 9 will give more tickets per play.
Undo
N/A
Press on Undo to clear the last change made and bring it
back to default.
Clear Credits
N/A
Press on Clear Credits to clear the inserted credits.
Stats
N/A
Shows the Stats Screen.
Resume Game
N/A
Exit from the Operator Menu and go back to the
game.
Exit to Windows
N/A
Exit the game and return to the Operating System
desktop.

Candy Crush Tickets Manual V1.0
Chapter 06 –Service & Repair
Chapter 06 - Service & Repair
Computer Connections

Candy Crush Tickets Manual V1.0
Chapter 06 –Service & Repair
16
Troubleshooting
* NOTE: When requesting a warranty replacement you will be asked to
give the unit’s serial number from the back of the unit.
Video Troubleshooting
No Picture and Sound
To change between Portrait and Landscape mode, press
ALT-P (Portrait) or ALT-L (Landscape) using a USB keyboard.
There are loose or faulty connections between the monitor and the
computer. Make sure the DVI cable is connected properly to both the
computer and to the DVI connector of the LCD monitor.
No power to computer.
Verify the computer is ON.
Open the front service door and press the RED or WHITE power
button.
Make sure that the power plug is well connected.
The Bios settings have changed, If the computer does not power
automatically when the unit is powered on, follow these steps:
Open the cabinet and plug a USB keyboard in one of the remaining
USB ports.
Press and hold the “Delete” key on the keyboard and then turn the
computer on. Keep holding the “Delete” key until the Bios screen
appears.
Using the arrows, select the “Advanced” tab.
Using the arrows, scroll down to the ACPI Configuration option and
press the “Enter” key.
Using the arrows, scroll down to the Restore on AC/Power Loss
option and press the “Enter” key.
Using the arrows, select the Power On option and press the “Enter”
key.
Press the “F10” key then the “Enter” key to exit the Bios screen.

Candy Crush Tickets Manual V1.0
Chapter 06 –Service & Repair
17
Audio Troubleshooting
Low Volume / No
Sound
Increase the volume in the game by pressing the Operator Button and
adjusting the volume options in the Operator Menu. You might also
Quit the game to the desktop and increase the volume via the Speaker
icon.
Verify that the 1/8’’ plug is plugged in the computer’s green sound
input jack and that the other end is plugged in the sound amplifier. To
verify if it’s plugged properly, power up the unit and try touching the
plug at the computer’s end. If you hear a grounding sound it is
connected.
Dongle not found
The USB License Dongle can’t be found. Make sure that the USB
Dongle is connected to the computer in a black USB port.

Candy Crush Tickets Manual V1.0
Chapter 07 –Parts
Chapter 07 - Parts
Cabinet Parts
Ref
Part Description
Part #
1
Wood Cabinet
CA-02-1021
2
LED Digits Display
INV-14-1024
LED Digits Board
CA-04-1200
3
42” Touchscreen Monitor
CA-10-1001
Touchscreen only
CA-10-1001-TCH
4
Speaker
ADR-50-9986-00
5
Ticket Dispenser
ADR-42-1337-00
6
Door
INV-01-2050 rev. A
7
2.5 Dia Pivot Caster
INV-F25083
8
Leg Leveler
INV-62805K39

Candy Crush Tickets Manual V1.0
Chapter 07 –Parts
19
Electronics
Ref
Part Description
Part Number
1
I/O Board
LC-04-1001
2
SuzoHapp 5V/12V Power Supply
ADR-80-021-00
3
Computer
INV-11-CT-CPU
4
Audio Board Amplifier
INV-14-0005
5
SuzoHapp 12V/10A Power Supply
ADR-80-0215-00
6
12V Computer Power Supply
INV-14-0006

Candy Crush Tickets Manual V1.0
Chapter 07 –Parts
20
Thermoplastic
Part Description
Part Number
Kit of 2 side
CA-09-1002
Top Panel
CA-09-1003
