Adrenaline Amusements Blackout Prize Installation and operating instructions

BO-46-1000 –Blackout Prize
Operation & Service Manual
Prize with IR sensors- Version 1.2
* Read this manual before use

BO-46-1000 –Blackout Manual –Prize - V1.2
2
General Remark
If you encounter any difficulties or if you need support on how to update and/ or install your
Blackout product, we invite you to contact your local distributor or reach us at
[email protected] or by calling our support line [phone]
Adrenaline Amusements Team
Adrenaline Amusements
1150 Levis, Suite 302
Terrebonne, Qc
Canada
J6W 5S6

BO-46-1000 –Blackout Manual –Prize - V1.2
3
Table of Contents
Contents
General Remark..................................................................................................2
Table of Contents................................................................................................3
Chapter 01 - Preface ...........................................................................................4
Precaution for Game Operation.................................................................................................. 4
Safety........................................................................................................................................... 5
Environmental Conditions........................................................................................................... 5
Chapter 02 - Unit Features ..................................................................................6
Hardware Features...................................................................................................................... 6
Cabinet Facts ............................................................................................................................... 6
Voltage ........................................................................................................................................ 6
Chapter 03 - Unit Installation ..............................................................................7
Assembling your Blackout Unit ................................................................................................... 7
Chapter 04 –Procedure to refill Prizes ................................................................7
Refilling Prize Dispensers Steps................................................................................................... 8
Chapter 05 - Operator Menu, Game Setup..........................................................9
Chapter 06 - Parts .............................................................................................13

BO-46-1000 –Blackout Manual –Prize - V1.2
4
Chapter 01 - Preface
Please read this page before preparing your Blackout product for game play.
The following safety instructions apply to all game operators and service personnel. Specific
warnings and cautions will be included throughout this manual.
Use the following safety guidelines to help protect the system from potential damage and to
ensure your personal safety:
Electronic components in the game cabinet run on 110V AC 60Hz (220V/ 50Hz in most of
Europe, the Middle East and the Far East delivered units).
To help prevent electric shock, plug the system into a properly grounded power source.
These cables are equipped with 3-prong plugs to help ensure proper grounding. Do not
use adapter plugs or remove the grounding prong from a cable. If you must use an
extension cable, use a 3-wire cable with properly grounded plugs.
To help protect your system from sudden increases and decreases in electrical power,
use a surge suppressor, line conditioner or Uninterruptible Power Supply (UPS).
Be sure nothing rests on the system’s cables and that the cables are not located where
they can be stepped on or tripped over.
Keep your system far away from radiators and other heat sources.
Do not block cooling vents.
Precaution for Game Operation
Adrenaline Amusements Inc. assumes no liability for injuries incurred while playing our games.
Operators should be aware that certain health and physical conditions may make people
susceptible to injury when playing video games.

BO-46-1000 –Blackout Manual –Prize - V1.2
5
Safety
To avoid electrical shock, unplug the cabinet before performing
installation or service procedures.
If a power cord is damaged, it must be replaced by the equivalent
power cord available from your distributor.
Adrenaline Amusement Inc. assumes no liability for any damages or
injuries incurred while setting up or servicing the cabinet. Only qualified
service personnel should perform installation or service procedures.
Environmental Conditions
Cabinet is intended for indoor use only. Be sure to keep the cabinet dry and maintain operating
temperatures of 59° - 86° (15° - 30°C).

BO-46-1000 –Blackout Manual –Prize - V1.2
6
Chapter 02 - Unit Features
Hardware Features
Multitouch Screen
46’’ transparent Monitor
Windows based computer
12 Prize dispensers
InfraRed Sensors
Cabinet Facts
Cabinet Dimensions
Length = 30’’ Depth = 32’’ Height = 86’’
Weight = 450 lbs
Shipping Dimensions
Length = 30’’ Depth = 36’’ Height = 80’’
Weight = 450 lbs.
Voltage
Voltage
Operating
110V AC
4 AMP
220V AC
2 AMP

BO-46-1000 –Blackout Manual –Prize - V1.2
7
Chapter 03 - Unit Installation
Assembling your Blackout Unit
1. Carefully remove the Cabinet from the shipping container, giving yourself enough space.
2. Move the cabinet to the desired location.
3. Lift the top Header to upright position. To do so you will need to press on the spring pins
on each side of the hinge.
4. Plug in the power cord on the back of the cabinet.
Chapter 04 – Procedure to refill Prizes
* Very important to perform step 6 and 7
1. Unlock and open front door.
2. Unscrew the pin in the middle of the prize dispenser.
3. Install prizes on dispenser.
4. Re-install the middle pin to secure the prize in the unit
5. Lock the front door.
6. Access the operator menu using the Operator Button located inside the coin door.
7. Enable all dispensers Loaded by pressing the prize dispenser icon (number 1 to 12). The
icon is yellow when enabled and grey when disabled. (see figure 5.1 below).
8. Only the prize dispenser in yellow will be available to players if they win.
9. You can test the sensor using rotor #5. (See figure 5.3 below).
10. Press icon “return to Game” when finished.

BO-46-1000 –Blackout Manual –Prize - V1.2
8
Refilling Prize Dispensers Steps
1. Unscrew and pull out the prize Rod 2. Hang the Prize on the Spiral
3 Insert&Screw the Prize Rod 4. The Prize Dispenser is refilled
*NOTE: PLEASE DO NOT HANG THE PRIZE ON THE ROD

BO-46-1000 –Blackout Manual –Prize - V1.2
9
Chapter 05 - Operator Menu, Game Setup
This chapter describes how to use and navigate the Operator Menu to set up your product and
adjust all of the game’s parameters. To access the operator Menu, use the Operator Button
located inside the coin door. To navigate the menu, you can touch the arrows to change the
option’s value.
Figure 5.1
Operator Menu
What it does
Credits per Games
Number of credits needed to
start a game
Game Volume
Game sound volume
Attract Mode Volume
Attract Mode Volume
Payment type
Display ‘Swipe card’ instead of
‘Insert credits’ in the game
Enable Dispensers
Each number represents a prize
dispenser inside the cabinet. The
prize dispenser needs to be
enabled to allow the winner to
select this prize slot. Yellow
enable/grey Disabled.
Return to game
Press to exit the operator menu
and return to the game
Payout setting
Press to access the payout setting
page (see figure 5.2)
Manage Dispenser
Press to access the manage
dispenser page (see figure 5.3)
Stats
Press to access the stats page
(see figure 5.4)
Exit to Windows
Press to close the game and go to
windows

BO-46-1000 –Blackout Manual –Prize - V1.2
10
Figure 5.2
Payout Settings
What it does
Average payout Minor
Payout adjustable from 1/5 to
1/2500.
Average payout Major
Payout adjustable from 1/25 to
1/2500.
Back
Press to return to the operator
menu

BO-46-1000 –Blackout Manual –Prize - V1.2
11
Figure 5.3
Manage dispensers
What it does
Number 1 to 12
Press on the number to select
which prize dispenser is minor or
Major
Test
Press to activate a prize
dispenser to test if the
mechanism is working
adequately
Test IR #5
This will enable rotor #5 and will
stop turning when the prize fall
in the chute
Back
Press to return to the operator
menu

BO-46-1000 –Blackout Manual –Prize - V1.2
12
Figure 5.4
Stats Menu
What it does
Total Games
Number of game plays
Total credits
Number of credits inserted in the
unit.
Minor prize wins
Minor prizes dispensed
Major prize wins
Major prizes dispensed
Avg. % per game
Average score obtained by the
player.
Date last reset
Date of the last manual reset of
the stats
Result xx% - xx%
Number of games ended in that
% range
Back
Press to return to the operator
menu
Logs
View Prize dispensers date/time
logs
Reset stats
Press to reset the stats
Clear Logs
Press to reset the Dispensers logs

BO-46-1000 –Blackout Manual –Prize - V1.2
13
Chapter 06 - Parts
Ref
Part Description
Part Number
1
Header
INV-09-1004
2
Dispenser
INV-14-0005
3
Prize Chute
INV-07-1010
4
Prize Door
INV-01-0000
5
Caster
INV-62805K-39
6
Leveling
INV-62805K-39
7
Coin Door
ADR-40-3000
8
Speaker&Grill
INV-04-0004
9
Side Glass
INV-07-1020
10
Sensor Kit
INV-25-115-0020

BO-46-1000 –Blackout Manual –Prize - V1.2
14
Ref
Part Description
Part Number
1
3 Side Decal Kit
INV-09-1001
2
Door Decal
INV-09-1003
3
Decal Window Right
INV-09-1006
4
Back Decal
INV-09-1008
5
Throw to Win
INV-09-1002
6
Header
INV-09-1004
7
Decal Window Left
INV-09-1007

BO-46-1000 –Blackout Manual –Prize - V1.2
15
Screen Assembly INV-01-0001
Ref
Part Description
Part Number
1
Steel Sheet Door.
16GA
INV-01-1020
2
Transparent LCD
INV-00-1300
3
TV Bracket Vertical
INV-01-1010
4
Side Screen Frame
INV-01-1011
5
Top Screen Frame
INV-01-1012
6
Plastic Spacer,
Vertical
INV-07-1002
7
Plastic Horizontal
Spacer,
INV-07-1001
8
Plastic Spacer,
Vertical
INV-07-1003
9
T-Handle Lock
ADR-30-1838-
00
10
LED Strip
INV-14-1006
(07 for
Horizontal)
11
Tempered Glass
INV-07-1021
12
Touch Screen
Sensor
INV-10-0002

BO-46-1000 –Blackout Manual –Prize - V1.2
16
Ref
Part Description
Part Number
1
ADRIO FX + Board
INV-04-1200
2
Computer
INV-11-1001
3
Power Inlet
ADR-05-1241
4
Audio Amplifier
ADR-310-308
5
Power Strip
ADR-05-1240
6
24V Power Supply
ADR-80-1206-00
7
5V-12V Power Supply
ADR-80-0210-00
N
Video AD Board
INV-14-0010

BO-46-1000 –Blackout Manual –Prize - V1.2
17
Electronic Wiring
Power Distribution Diagram

BO-46-1000 –Blackout Manual –Prize - V1.2
18
Detailed Wiring Diagram
