ADTRAN TSU LT User manual

TSU LT P/N 1203060L1
For more detailed documentation, visit us online at www.adtran.com
Quick Start Guide
Quick Start Guide, 61203060L1-13A, May 2003 Technical Support 1-888-4ADTRAN (1-888-423-8726) Copyright 2003 ADTRAN, All Rights Reserved
NETWORK CONNECTION PINOUT
Pin Name Description
1 R1 RXDATA Receive data from the Network - Ring
2 T1 RXDATA Receive data from the Network - Tip
3, 6, 7, 8 UNUSED n/a
4 R TXDATA Transmit data towards the Network - Ring
5 T TXDATA Transmit data towards the Network - Tip
INSTALLATION INFORMATION
• An eight-position modular jack (labeled NETWORK) connects to the T1
network circuit. The pinout is shown below, right, on this Quick Start
Guide. See Chapter 2 of the TSU LT User Manual (P/N 612003060L1-1A)
for more information.
• The rear panel contains a single V.35 interface for connecting to DTE
equipment. The pinout for this interface is provided on the back of this
Quick Start Guide.
• When shipped from the factory, the TSU LT is uninitialized and set to
factory default conditions. When first powered up, the unit automatically
executes self-tests, followed by an initialization sequence.
• The TSU LT can be configured and controlled using the local front panel
of the unit, by a direct or remote serial connection via the control port, or
by ADTRAN’s PC-based management software package,
T-Watch PRO®. A limited menu tree is provided on the back of this sheet.
For more detailed menu information, refer to Appendix A of the TSU LT
User Manual.
• The product CD contains additional information such as the TSU LT User
Manual, FAQs, Data Sheets, Applications, and White Papers.
REAR PANEL DESCRIPTIONS
Network Connector Connects to T1 circuit
Test Interface Bantam jacks for monitoring and testing
a T1 circuit
Control Chain-In/Chain-Out Connects to a VT100 terminal
V.35 Connector High-speed DTE interface
115 VAC Connection Power cord connection for a reliably
grounded 115 VAC, 60 Hz power source
(power cord ships with unit).
NETWORK TEST JACKS
CONTROL
CHAIN IN
IN OUT MON
CHAIN OUT
V.35 Nx56/64 115VAC 60HZ .15A

TSU LT P/N 1203060L1
Quick Start Guide
Quick Start Guide, 61203060L1-13A, May 2003 Technical Support 1-888-4ADTRAN (1-888-423-8726) Copyright 2003 ADTRAN, All Rights Reserved
MENU TREE - OVERVIEW
1) NI PERF RPRTS
1) STATUS 2) CURR ERR/ALM
3) ERR/ALM HIST
1) NETWORK (NI)
2) CONFIG 2) UNIT
MAIN MENU 3) PORT
1) SOFTWARE REV
2) REINIT UNIT
3) UTIL 3) ADDRESS
4) SET PASSCODE
5) KEYPAD
6) FACT RESTORE
1) NETWORK TESTS
4) TEST 2) RUN SELF–TEST
3) PORT TESTS
V.35 CONNECTOR PINOUT
Pin CCITT Description
A 101 Protective ground (PG)
B 102 Signal ground (SG)
C 105 Request to send (RTS) from DTE
D 106 Clear to send (CTS) to DTE
E 107 Data set ready (DSR) to DTE
F 109 Received line signal detector (DCD) to DTE
H — Data terminal ready (DTR) from DTE
J — Ring indicator (RI)
L — Local loopback (LL)
N — Remote loopback (RL)
R 104 Received data (RD-A) to DTE
T 104 Received data (RD-B) to DTE
V 115 RX clock (RC-A) to DTE
X 115 RX clock (RC-B) to DTE
P 103 Transmitted data (TD-A) from DTE
S 103 Transmitted data (TD-B) from DTE
Y 114 TX clock (TC-A)
AA 114 TX clock (TC-B)
U 113 External TX clock (ETC-A) from DTE
W 113 External TX clock (ETC-B) from DTE
NN&K — Test mode (TM) to DTE
COMPLIANCE
Double pole/neutral fusing.
The socket-outlet shall be installed near the equipment and shall be easily
accessible.
