ADTRAN Total Access 3000 Instruction Manual

Total Access 3000/3010
4-Pair Line Power Unit
Installation and Maintenance Practice
Document Number: 61181500L2-5B
CLEI: SIPQ0CTF_ _
April 2007
LPU
POWER
UNDER VOLTAGE
GROUND FAULT
OVERLOAD
UNDER CURRENT
1181500L2
®

Total Access 3000/3010 4-Pair Line Power Unit Installation and Maintenance Practice
ii 61181500L2-5B
Front Matter
Trademarks
Any brand names and product names included in this document are trademarks, registered
trademarks, or trade names of their respective holders.
To the Holder of this Document
The contents of this document are current as of the date of publication. ADTRAN®reserves the
right to change the contents without prior notice.
In no event will ADTRAN be liable for any special, incidental, or consequential damages or
for commercial losses even if ADTRAN has been advised thereof as a result of issue of this
document.
901 Explorer Boulevard
P.O. Box 140000
Huntsville, AL 35814-4000
[phone]
©2007 ADTRAN, Inc.
All Rights Reserved.
®

61181500L2-5B iii
Revision History
Conventions
The following typographical conventions are used in this document:
This font indicates a cross-reference link.
This font indicates screen menus, fields, and parameters.
THIS FONT indicates keyboard keys (ENTER, ESC, ALT). Keys that are to be pressed simultaneously
are shown with a plus sign (ALT+Xindicates that the ALT key and Xkey should be pressed at the
same time).
This font indicates references to other documentation and is also used for emphasis.
This font indicates on-screen messages and prompts.
This font indicates text to be typed exactly as shown.
This font indicates silk-screen labels or other system label items.
This font is used for strong emphasis.
NOTE
Notes inform the user of additional, but essential, information or
features.
CAUTION
Cautions inform the user of potential damage, malfunction, or
disruption to equipment, software, or environment.
WARNING
Warnings inform the user of potential bodily pain, injury, or death.
Revision Date Description
AAugust 2005 Initial Release
BApril 2007 Second Issue. Updated product description.

Total Access 3000/3010 4-Pair Line Power Unit Installation and Maintenance Practice
iv 61181500L2-5B
Training
ADTRAN offers training courses on our products. These courses include overviews on product
features and functions while covering applications of ADTRAN product lines. ADTRAN
provides a variety of training options, including customized training and courses taught at our
facilities or at customer sites.
For inquiries concerning training, contact ADTRAN:
Training Phone: [phone], ext. 6996
Training Fax: [phone]
Training Email: [email protected]

61181500L2-5B v
Contents
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installation Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Shipping Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Instructions for Installing the Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Powering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Deployment Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Front Panel LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
System Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Craft Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Logging on to the Total Access 3000/3010 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
User Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Menu Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Menu Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
General Keyboard Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Menu Tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Menu Descriptions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Configuration Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Provisioning Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Status Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Alarms Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Software Download Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Total Access 3000/3010 4-Pair Line Power Unit Installation and Maintenance Practice
vi 61181500L2-5B
Appendix A
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Warranty and Customer Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
ADTRAN Sales . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
ADTRAN Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
ADTRAN Repair/CAPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Repair and Return Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Figures
Figure 1. LPU Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Figure 2. Total Access System Logon Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Figure 3. Total Access Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Figure 4. Access Modules Menus Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Figure 5. LPU Menu Tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Figure 6. LPU Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Figure 7. Configuration Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Figure 8. Provisioning Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Figure 9. Status Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Figure 10. Alarms Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Figure 11. Software Download Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Tables
Table 1. Compliance Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Table 2. Wiring Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Table 3. Span Powered Pair Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Table 4. Current and Voltage Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Table 5. Front Panel LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Table 6. Alarm Descriptions and Causes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Table 7. General Keyboard Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Table 8. LPU Main Menu Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Table 9. Configuration Screen Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Table 10. Provisioning Menu Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Table 11. Status Screen Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Table 12. Alarms Screen Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Table 13. Software Download Menu Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Table 14. Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

61181500L2-5B 1
Total Access 3000/3010
4-Pair Line Power Unit
GENERAL
This practice is an installation and maintenance guide for the ADTRAN Total Access®3000/
3010 4-Pair Line Power Unit (LPU). Figure 1 illustrates the LPU (P/N 1181500L2) front panel.
Figure 1. LPU Front Panel
LPU
POWER
UNDER VOLTAGE
GROUND FAULT
OVERLOAD
UNDER CURRENT
1181500L2

Total Access 3000/3010 4-Pair Line Power Unit Installation and Maintenance Practice
261181500L2-5B
Description
The LPU is a span powering Total Access 3000/3010 module, which is used to supply 100
watts of DC power over multiple twisted pairs of various standard gauges to a Total Access
11xx OSP Digital Subscriber Line Access Multiplexer (DSLAM). The LPU can be installed
either at a Central Office (CO) or a remote facility in close proximity to the associated DSLAM.
The LPU provides ±145 VDC power and can span distances up to 60 kft (approximately 11
miles).
Features
The basic features of the LPU include the following:
• Provides 100 watts of power
• Provides power to remote DSLAMs for distances up to 60 kft
• Provides ±145 VDC power rails
• Provides powering over any combination of the four available pairs
• Provides alarms for Under Voltage, Ground Fault, Overload, and Under Current
• Provides five LEDs: POWER, UNDER VOLTAGE, GROUND FAULT, OVERLOAD, and UNDER
CURRENT
• LPU can be provisioned In Service, Out of Service-Maintenance, or Out of Service-
Unassigned.
• Meets Total Access 3000/3010 dual module form factor
• Provides SNMP management
• Provides TL1 Network Management Access alarm support
• Menu access via the Total Access 3000/3010 Controller Unit
• Application software can be upgraded in the field
• Meets all requirements over an ambient temperature range of –40ºC to +70ºC

General
61181500L2-5B 3
Compliance
WARNING
The span voltages are up to ±145 VDC with respect to ground and
up to 290 VDC between the tip/ring pairs.
CAUTION
Electrostatic Discharge (ESD) can damage electronic modules.
When handling modules, wear an antistatic discharge wrist strap
to prevent damage to electronic components. Place modules in
antistatic packing material when transporting or storing. When
working on modules, always place them on an approved antistatic
mat that is electrically grounded.
Table 1 lists the compliance codes for the LPU. The LPU is NRTL Listed to the applicable UL
standards. The LPU meets or exceeds all the applicable requirements of NEBS, Telcordia GR-
63-CORE, and GR-1089-CORE.
The LPU is intended for deployment in Central Office type facilities, EEEs and EECs. Install
the LPU in a Total Access 3000/3010 Chassis located in a restricted access location.
This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference
2. This device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by ADTRAN could void the user’s authority
to operate this equipment.
Table 1. Compliance Codes
Configuration Code Input Output
Power Code (PC) F C
Telecommunication Code (TC) – X
Installation Code (IC) A –
C A U T I O N !
SUBJECT TO ELECTROSTATIC DAMAGE
OR DECREASE IN RELIABILITY.
HANDLING PRECAUTIONS REQUIRED.

Total Access 3000/3010 4-Pair Line Power Unit Installation and Maintenance Practice
461181500L2-5B
CAUTION
Per GR-1089-CORE the Total Access 3000/3010 System is
designed and intended for installation as part of a Common
Bonding Network (CBN). The Total Access 3000/3010 System is
not designed nor intended for installation as part of an Isolated
Bonding Network (IBN).
CAUTION
Per GR-1089-CORE Section 9, the LPU does not have an internal
DC connection between –48 VR and frame ground. The LPU can be
installed in a DC-I (isolated) or DC-C (common) installation. For
installations where other cards or the host system have internal
connections between –48 VR and frame ground, the system would
be intended for deployment only in a DC-C installation.
CAUTION
The Total Access 3000/3010 Chassis frame ground terminal must
be connected to an earth ground to ensure that the front panel of
the LPU is properly grounded via the backplane connector.
NOTE
The powering ports of the LPU are classified as Type 1, 3, and 5, as
defined in Appendix B of GR-1089-CORE Issue 4, and meet the
lightning and power fault criteria with primary protectors that meet
any of the voltage limits of GR-974-CORE or GR-1361-CORE (for
example, carbon blocks, gas tubes, solid states).
NOTE
Current limiting protectors are not required.
NOTE
The LPU is designed to operate with a nominal operating voltage of
–48 VDC and a minimum operating voltage of –40 VDC. The LPU
will not be damaged by any steady state voltage below –56.7 VDC.

Installation
61181500L2-5B 5
INSTALLATION
After unpacking the Total Access 3000/3010 LPU, inspect it for damage. If damage has
occurred, file a claim with the carrier then contact ADTRAN Customer Service.
Refer to “Appendix A, Warranty” for further information. If possible, keep the original shipping
container for returning the LPU for repair or for verification of shipping damage.
Installation Considerations
The number of LPUs installed in a system is significant, because overloading the Total Access
3000/3010 shelf with too many LPUs can cause the 20 amp current limit to be reached or
exceeded. An LPU producing 100 watts draws approximately 2.6 amps of current from the
Total Access 3000/3010 backplane. A fully loaded Total Access 3000/3010 shelf with
fourteen LPUs, each drawing 2.6 amps, would draw a total of 36.4 amps of current from the
Total Access 3000/3010 backplane. This is over the Total Access 3000/3010 shelf limit and
can cause the shelf fuse to blow. Therefore, it is recommended for safety reasons that no more
than seven LPUs be placed into a Total Access 3000/3010 shelf supplying power to the
DSLAMs with sub-full rate ADSL modules. If deployed in a configuration which requires
heavier loads, this maximum number of seven LPUs should be reduced to keep the Total
Access 3000/3010 backplane current at ≤20 amps.
The gauge and length of the wire used to transfer power is significant, because impedance
increases as the gauge and length of the wire increases and a greater impedance causes power
to be wasted during transmission.
Shipping Contents
The contents include the following items:
• Total Access 3000/3010 4-Pair Line Power Unit
•Total Access 3000/3010 4-Pair Line Power Unit Job Aid (P/N 61181500L2-22)
•Total Access 3000/3010 4-Pair Line Power Unit Compliance Notice (P/N 61181500L2-17)
Instructions for Installing the Module
The LPU installs in any two adjacent slots in a Total Access 3000/3010 chassis. The Total
Access 3000/3010 backplane connectors allow for either odd-even or even-odd slot insertion.
For installations residing in a CO or other controlled environment, fan cooling is not required.
However, a heat baffle is required directly above each Total Access 3000/3010 chassis. For
installations in remote locations, fan cooling is required for each two-stack arrangement of
Total Access 3000/3010 chassis.
If heat-generating equipment is installed below the Total Access 3000/3010 chassis, an
additional heat baffle may be required between the heat-generating unit and the bottom of the
Total Access 3000/3010 chassis.

Total Access 3000/3010 4-Pair Line Power Unit Installation and Maintenance Practice
661181500L2-5B
CAUTION
Installations in a CO or other controlled environment require heat
baffles.
CAUTION
Installations in remote locations require fans.
NOTE
A maximum of seven LPUs with a nominal load of about 0.3 amps
can currently be inserted into the Total Access 3000/3010 shelf.
This limitation is due in part to the 30 amp fuse used with the
Total Access 3000/3010 shelf and because the Total Access 3000/
3010 backplane traces that supply the –48 VDC current cannot
handle more than a consistent 20 amps.
To install the LPU, perform the following steps:
1. If present, remove the Access Module Blank (P/N 1181953L1) from the appropriate access
module slot of the Total Access 3000/3010 chassis.
2. Pull the ejector latch, located on the lower left-hand side of the LPU front panel, from its
closed position.
3. Hold the LPU by the front panel while supporting the bottom edge of the module with the
ejector latch opened to engage the chassis edge.
4. Align the module edges to fit in the lower and upper guide grooves for the access module
slot.
5. Slide the module into the access module slot. Simultaneous thumb pressure at the top
(above the POWER LED) and at the bottom (below the electrostatic caution symbol) of the
module ensures that the module is firmly positioned against the backplane of the chassis.
6. Secure the LPU in place by pushing in on the ejector latch.
Upon installation, the LPU initiates a self-test. Once the power up self-test is completed, the
front panel LEDs reflect the true state of the hardware. For LED descriptions, refer to “Front
Panel LEDs” on page 9.

Installation
61181500L2-5B 7
Wiring
WARNING
Disconnect power at the source and provision the service state as
Out of Service before making power connections.
Each LPU 96-pin edge connector inserts into a 96-pin backplane socket. The main edge
connector has pins for ground, alarms, provisioning, and card input power, plus output power
for the remote DSLAM. The daughter card has pins for ground and input power. Output power
is available on the 64-pin amphenol connectors on the Total Access 3000/3010 backplane.
The Total Access 3000/3010 chassis has eight 64-pin amphenols on the backplane. They are
labeled as follows:
• PAIR 1
• PAIR 2
• PAIR 3
• PAIR 4
• PAIR 5
• PAIR 6
• PAIR 7
• PAIR 8
As shown in Table 2, if the LPU inserts into slots 1 and 2 of the Total Access 3000/3010, the
power pairs appear at loop connections 1 through 4 of slot 1. If the LPU inserts into slots 9
and 10, the power pairs appear at loop connections 1 through 4 of slot 9. If the LPU inserts
into slots 20 and 21, the power pairs appear at loop connections 1 through 4 of slot 20, etc.
for a maximum allowable number of LPUs based on the Total Access 3000/3010 amperage
input limit.
Table 2. Wiring Example
LPU Slots Used Slot Where Power
Pairs Appear
11, 2 1
29, 10 9
320, 21 20

Total Access 3000/3010 4-Pair Line Power Unit Installation and Maintenance Practice
861181500L2-5B
Powering
The LPU operates on a –40 VDC to –56.7 VDC input voltage range.
The LPU uses about 10 watts of total power on the board, as follows:
• 2 watts are in the following input circuitries:
– input diodes (A and B diodes)
– inrush limiting Field Effect Transistor (FET)
–inputinductor
–inputfuse
• 1 watt is dissipated in the locally powered micro-controller and power supply components
• 7 watts are in the span supply
The output voltages are ±145 VDC and are provided on the four loop pairs as shown in
Table 3.
The LPU current and voltage limits are shown in Table 4.
NOTE
Both A and B inputs should be wired to limit the amount of current
flowing into the powering pins on the Total Access 3000/3010
backplane connector.
Table 3. Span Powered Pair Assignments
Total Access 3000/3010 Backplane Pair Number Module Edge Connector Pin Number
(Tip, Ring)
Pair 1 C6, B6
Pair 2 C5, C4
Pair 3 B5, A5
Pair 4 B4, A4
Table 4. Current and Voltage Limits
Voltage Supply Minimum Current Maximum Current
290 VDC ±5% 0.004 amps 0.4 amps
–40 VDC to –56.7 VDC N/A 2.6 amps

Installation
61181500L2-5B 9
Deployment Guidelines
The number of powering pairs required for powering a DSLAM is dependent on the total resis-
tance in the loop serving the powering pairs. For more information, refer to “Line Powering” in
the specific DSLAM Installation and Maintenance Practice.
Front Panel LEDs
The 4-Pair Line Power Unit Access Module provides front panel LEDs to display status infor-
mation. The 4-Pair Line Power Unit LEDs and status descriptions are shown in Table 5.
Table 5. Front Panel LEDs
Label Status Description
POWER {
z
z
z
5
Off
Green
Yellow
Red
Flashing
(all colors)
LPU has completely failed or the shelf has no power
LPU is In Service and supplying power
LPU is Out of Service-Maintenance or
Out of Service-Unassigned
LPU has failed self-test
LPU is being accessed (terminal, four-character display,
TFTP, etc.)
UNDER VOLTAGE {
z
Off
Red
Voltage normal: ±145 volts per T/R (±5%)
Less than 115 VDC per T or R
Less than 230 VDC per T/R pair
GROUND FAULT {
z
Off
Red
No ground fault
Ground fault detected
OVERLOAD {
z
Off
Red
No overload
Greater than 0.4 amps at 290 VDC
UNDER CURRENT {
z
Off
Red
Current normal
Less than 0.004 amps

Total Access 3000/3010 4-Pair Line Power Unit Installation and Maintenance Practice
10 61181500L2-5B
Alarms
The faults displayed by the LEDs also produce alarms, which can be reported on the Total
Access 3000/3010 Controller Unit. The Controller Unit supports the following alarms:
• SNMP alarms to be used along with the Total Access EMS
• Local alarm contacts
•TL1NMAalarms
Table 6 shows the alarm descriptions and possible causes.
Table 6. Alarm Descriptions and Causes
Alarm Description Possible Cause
Under Voltage The output voltage is too low. There is damage to the LPU that caused the
output voltage to be lower than 230 VDC
(between tip and ring).
Ground Fault There is a path to ground. There is a connection between one of the
output wires and ground.
Overload LPU is sourcing too much current. The output current is greater than 0.4 amps.
Under Current LPU is sourcing very low current. The LPU is not connected to any load or a
connected load is drawing less than 0.004
amps.

System Management
61181500L2-5B 11
SYSTEM MANAGEMENT
The Controller Unit is the user access point to the Total Access 3000/3010 shelf and the
installed modules. The Controller Unit supports a number of interfaces for system
management as follows:
• Craft interface
• Admin interface
• Network Management interface
• Ethernet interface
• Inband Management interface
Craft Interface
Connection to the Total Access 3000/3010 system menus can be made through the DB-9
connector, labeled CRAFT, on the front panel of the Controller Unit.
Most personal computers or laptops can run communications software that will emulate a
VT100 terminal. Windows programs such as Terminal or HyperTerminal are two such
examples in the Windows format, but there are many other adequate, commercially available
software packages, virtually all of which allow the PC or laptop to emulate a VT100 terminal.
Certain configuration items must be set on a PC or laptop to act as a VT100 terminal for the
Total Access 3000/3010.
1. Set the parameters of the communications software to the following settings:
• 9600 baud rate
• 8 data bits
• No parity
•1stopbit
• No flow control
2. Set the PC for direct connect on the appropriate communications port (as opposed to a
dial-up connection).
3. Plug the male end of the data cable into the Total Access 3000/3010 Controller Unit.
Make connections to the PC or laptop as appropriate to the equipment.

Total Access 3000/3010 4-Pair Line Power Unit Installation and Maintenance Practice
12 61181500L2-5B
Logging on to the Total Access 3000/3010
At the Total Access 3000/3010 System login screen (Figure 2), enter the account name and
password. The default account name is “ADMIN” and the password is “PASSWORD”. An
account with ADMIN privileges is required to change the account name and password. For
more information, refer to the Controller Unit Installation and Maintenance Practice.
NOTE
The account name and password fields are case-sensitive.
Figure 2. Total Access System Logon Screen
After successful logon, the Total Access Main Menu (Figure 3) displays.
NOTE
Basic menu navigation is accomplished by selecting the desired
option number and then pressing ENTER. To return to the previous
menu, press the ESC (escape) key. To access the System Help
screen, press the question mark (?) key, and press ENTER.
TID: Total Access System MM/DD/YY HH:MM
Unit Number: 1
Total Access System
Account Name :
'?' - System Help Screen

System Management
61181500L2-5B 13
Figure 3. Total Access Main Menu
The Access Module Menus menu (Figure 4) displays the access modules occupying the Total
Access 3000/3010 shelf. To the right of each listed access module, the current alarm state is
indicated. To access the LPU menus, select the corresponding slot number.
NOTE
The LPU may not appear in the same slot as shown in Figure 4.
When accessing the LPU, verify the slot before continuing.
Figure 4. Access Modules Menus Menu
Shelf: 1 Total Access System MM/DD/YY HH:MM
Unacknowledged Alarms: None
Total Access
1. System Controller
2. Common A - [.....]
3. Common B - [.....]
4. Access Modules
5. System Alarms
6. Network Management
7. Logoff
Selection:
'?' - System Help Screen
TID: Total Access System MM/DD/YY HH:MM
Unacknowledged Alarms: NONE Unit Number: 1
Access Module Menus
1 - ............ [None] 15 - ............ [None]
2 - ............ [None] 16 - ............ [None]
3 - ............ [None] 17 - ............ [None]
4 - LPU......... [None] 18 - ............ [None]
5 - ............ [None] 19 - ............ [None]
6 - ............ [None] 20 - ............ [None]
7 - ............ [None] 21 - ............ [None]
8 - ............ [None] 22 - ............ [None]
9 - ............ [None] 23 - ............ [None]
10 - ............ [None] 24 - ............ [None]
11 - ............ [None] 25 - ............ [None]
12 - ............ [None] 26 - ............ [None]
13 - ............ [None] 27 - ............ [None]
14 - ............ [None] 28 - ............ [None]
X - ............ [None]
Enter Channel Slot Number :
Inverse = Busy Modules
'?' - System Help Screen

Total Access 3000/3010 4-Pair Line Power Unit Installation and Maintenance Practice
14 61181500L2-5B
USER INTERFACE
This section provides detailed information on the following:
•“Menu Structure” on page 14
•“Menu Navigation” on page 15
•“Menu Tree” on page 15
Menu Structure
The menu structure for the LPU is a layered menu tree. Each layer of the menu tree is
displayed as a menu or a screen.
Menus
A menu is a display that provides numbered selections that are used to navigate to related
menus, modify provisioning information, or display information screens. A menu can contain
the following objects:
• Menu Option: A menu option is indicated by a number, which when selected navigates the
display to another menu layer or is used to change the option setting.
• Read-only Field: A read-only field displays information that cannot be changed. The
information displayed in a read-only field can be static or can be automatically updated by
the unit.
• Read-write Field: A read-write field displays information that when selected can be
modified.
• Hot Key: A hot key is a key or combination of keys that are assigned to a function. Hot keys
are indicated by the required key(s) and a brief description (i.e., “?” - Help).
Screen
A screen is a display that usually indicates the end of a menu tree path. A screen can contain
the following objects:
• Read-only Field: A read-only field displays information that cannot be changed. The
information displayed in a read-only field can be static or can be automatically updated by
the unit.
• Read-write Field: A read-write field displays information that when selected can be
modified.
• Hot Key: A hot key is a key or combination of keys that are assigned to a function. Hot keys
are indicated by the required key(s) and a brief description (i.e., “?” - Help).
