Parts Breakdown G12010R
Page 1 of 21 2/8/2008

Parts Breakdown G12010R
Page 2 of 21 2/8/2008

Parts Breakdown G12010R
Page 3 of 21 2/8/2008

Parts Breakdown G12010R
Page 4 of 21 2/8/2008

Parts Breakdown G12010R
Page 5 of 21 2/8/2008

Parts Breakdown G12010R
Page 6 of 21 2/8/2008

Parts Breakdown G12010R
Page 7 of 21 2/8/2008

Parts Breakdown G12010R
Page 8 of 21 2/8/2008

Parts Breakdown G12010R
Page 9 of 21 2/8/2008

Parts Breakdown G12010R
Page 10 of 21 2/8/2008

Parts Breakdown G12010R
Page 11 of 21 2/8/2008

Parts Breakdown G12010R
Page 12 of 21 2/8/2008

Parts Breakdown G12010R
Page 13 of 21 2/8/2008

Parts Breakdown G12010R
Page 14 of 21 2/8/2008

Parts Breakdown G12010R
Fig # Part ID Part Name Quantity
1 2631011101 CRANKCASE CP, G12010R 1
2 2631421103 VLAVE GUIDE, G12010R 2
3 0565100050 CLIP, G6100R 1
4 2631421103 VLAVE GUIDE, G12010R 2
5 0565100050 CLIP, G6100R 1
6 13207AA050 SEAL-INTAKE VALVE, G12000R 1
7 13207AA050 SEAL-INTAKE VALVE, G12000R 1
8 2633534103 RETAINER PLATE, G12010R 1
9 2633534103 RETAINER PLATE, G12010R 1
10 2631580203 MAIN BEARING, G12010R 1
11 0052608180 DOWEL PIN, G5501R 2
12 1425560103 PIPE KNOCK, G3511R 2
13 0105080290 STUD, G2800R 4
14 0105080290 STUD, G2800R 4
15 0440080010 OIL SEAL, G12000R 1
16 0401140030 PLUG, G2800R 2
17 2351542103 BLIND PLUG, G12010R 1
18 0211140020 GASKET, G2800R 2
19 1596540103 PIPE (PULSE), G12000R 1
20 2631590103 UNION, G12000R 1
21 2487630101 SWITCH OIL PRESSURE, G12000R 1
22 2631110121 MAIN BEARING COVER,G12010R 1
23 0440420030 OIL SEAL, G12010R 1
24 2631580203 MAIN BEARING, G12010R 1
25 2634500301 GOVERNOR GEAR CP.,G12010R 1
26 26346215A3 THRUST BEARING, G12010R 1
27 26346214A3 WASHER, G12000R 2
28 2774190103 GOVERNOR SLEEVE, G2800L 1
29 26316002A3 GASKET, G12010R 1
30 0110080220 FLANGE BOLT, G12010R 10
31 2631321101 CYLINDER HEAD 1, G12010R 1
32 2631331101 CYLINDER HEAD 2 1
33 2631502111 GASKET 1,G12010R 1
34 2631512101 GASKET 2, G12010R 1
35 0110100070 FLANGE BOLT, G12010R 8
36 28015501A3 ROCKER COVER, G12010R 1
37 26315501A3 ROCKER COVER, G12010R 1
38 26316101A3 GASKET, G12010R 2
39 0310060020 DOWEL PIN, G2800R 4
40 0110060101 FLANGE BOLT, G1100 8
41 28019001A3 HOOK, G12010R 2
42 2631430103 BREATHER COVER, G12000R 1
43 28014401A1 BREATHER PLATE CP,G12010R 1
44 2631600603 GASKET, BREATHER PLATE, G12000R 2
45 0110060030 FLANGE BOLT, G2800R 2
46 2639900127 GASKET SET, G12010R 1
47 2632120111 CRANKSHAFT CP.,G12010R 1
48 26325012A3 SPACER 0.8T, G12010R 1
48 26325013A3 SPACER 1.0T, G12010R 1
48 26325014A3 SPACER 1.2T, G12010R 1
49 0180180010 FLANGE NUT, G4300L 1
50 0053205401 WOODRUFF KEY, G5710R 1
51 2632260100 N/A 2
51 2632260200 CONNECTING ROD AY,G12010R 2
52 0010508400 FLANGE BOLT, G12010R 4
53 2632330103 PISTON PIN, G12000R 2
54 2632340103 PISTON (STD), G12000R 2
54 2632340203 PISTON (OVER SIZE 0.25MM),G12000R 2
54 2632340303 PISTON (OVER SIZE 0.50MM)G12000R 2
55 2632350117 PISTON RING SET(STD),G12010R 2
Page 15 of 21 2/8/2008

Parts Breakdown G12010R
55 2632350217 PISTON RING SET(0.25),G12010R 2
55 2632350317 PISTON RING SET(0.50),G12010R 2
56 0565210020 CLIP, G5710R 4
57 2803170113 CAMSHAFT, G12010R 1
58 26333301A3 TAPPET, G12010R 4
59 2463361103 VALVE SPRING, G5710R 4
60 2463371113 SPRING RETAINER, G6100R 4
61 2633340103 INTAKE VALVE, G12000R 2
62 2633350213 EXHAUST VALVE, G12010R 2
63 2463550103 COLLET VALVE, G5710R 8
64 26335321B1 N/A 4
65 2673610113 ROCKER ARM, G12010R 4
66 2613580113 BOLT (PIVOT),G12010R 4
67 2673570103 PIVOT, G12010R 4
68 0170060110 NUT, G12010R 4
69 26337001A3 GUIDE PLATE, G12010R 2
70 26330102A1 MUFFLER ASS'Y, G12000R 1
71 26337321A2 SPARK ARRESTER, G12000R 1
72 26337001A1 BRACKET MUFFLER, G12000R 1
73 2703520101 GASKET CP. G12010R 2
74 0180080010 FLANGE NUT, G5711R 4
75 0011408200 BOLT & WASHER, G2800R 2
76 0110060030 FLANGE BOLT, G2800R 2
77 26337302A3 CLAMP ASS'Y G12000R 1
78 28033001C3 INTAKE MANIFOLD, G12010R 1
79 28032601A0 AIR CLEANER AY,G12010R 1
80 28032620A1 CLEANER BASE CP.,G12010R 1
81 2633263003 CLEANER COVER, G12000R 1
82 2633264001 WING NUT, G12000R 1
83 26332610A1 CLEANER ELEMENT CPL, G12000R 1
84 26335503A3 GASKET, G12010R 2
85 0110060020 FLANGE BOLT, G2800R 3
86 0023808000 FLANGE NUT, G2800R 4
87 2631800303 RUBBER PIPE, G12010R 1
88 0561200020 HOSE CLAMP, G12010R 2
89 0732005000 LABEL, G6101R 1
90 26342301B3 GOVERNOR LEVER, G12010R 1
91 26342201A3 GOVERNOR SHAFT, G12010R 1
92 X230080150 SPACER, G12000R 1
93 0031008000 WASHER, G3501R 2
94 26342701A3 GOVERNOR ROD, G12010R 1
95 2634280103 ROD SPRING, G12000R 1
96 0051106001 SNAP PIN, G12000R 1
97 0011406300 BOLT & WASHER ASS'Y, G5710R 1
98 0186060020 NUT, G2800R . 1
99 2634250513 GOVERNOR SPRING, G12010R 1
100 26343301A3 SPEED CONTROL LEVER,G12010R 1
101 2274350113 STOP PLATE, G2410R 1
102 2634500203 SPRING WASHER, G12000R 1
103 0217060030 FRICTION WASHER, G12000R 2
104 0115050020 BOLT, (M5X35MM), G12000R 1
105 0022705000 NUT M5, RBC230 1
106 0176060020 SELF-LOCK NUT, MAC6000 1
107 2634501102 BRACKET UNIT, SPEED CTRL.,G12000R 1
108 0110060020 FLANGE BOLT, G2800R 2
109 26351121B2 BLOWER HOUSING UNIT,G12010R 1
110 0110060030 FLANGE BOLT, G2800R 5
111 0110060140 FLANGE BOLT, G2410R 2
112 0011106350 BOLT & WASHER, G3511R 1
113 26352612A1 CYLINDER BAFFLE 1, G12010R 1
114 26352704A1 CYLINDER BAFFLE 2, G12010R 1
Page 16 of 21 2/8/2008

Parts Breakdown G12010R
115 2635280103 CYLINDER BAFFLE 3, G12000R 1
116 26352912A2 CYLINDER BAFFLE 4 UN.,G12010R 1
117 0110060020 FLANGE BOLT, G2800R 2
118 0110060020 FLANGE BOLT, G2800R 2
119 0110060020 FLANGE BOLT, G2800R 2
120 0110060020 FLANGE BOLT, G2800R 2
121 2635410102 COOLING BLOWER UNIT, G12000R 1
122 0011406160 BOLT & WASHER, G2800R 4
123 0566000250 CLAMP (ELEC STARTER),G2800R 1
124 26368006B3 RUBBER PIPE, G12010R 1
125 2636850103 HOSE CLAMP, G12000R 2
126 2636238500 CARBURETOR AY, G12010R 1
127 2636253508 THROTTLE VALVE, G12000R 1
128 2616235208 SCREW, VALVE SET, G12000R 2
129 2616235208 SCREW, VALVE SET, G12000R 3
130 2586252508 CHOKE VALVE, G12000R 1
131 2586255508 SCREW, VALVE SET, G12000R 2
132 2586242008 JET, SLOW (#60), G12000R 1
133 2636252308 SHAFT ASS'Y CHOKE, G12000R 1
134 2636253408 THROTTLE SHAFT ASS'Y, G12000R 1
135 2586255108 RING, CHOKE LEVER, G12000R 1
136 2266250108 VALVE FLOAT, G12000R 1
137 2586251508 FLOAT PIN, G12000R 1
138 2806254508 GASKET, G12010R 1
139 2806250508 FLOAT, G12010R 1
140 2636240008 MAIN JET (#132), G12000R 1
141 2156235308 SCREW DRAIN, G12000R 1
142 2156244608 SPRING DRAIN, G12000R 1
143 2586255608 SCREW, FLOAT PIN SET, G12000R 1
144 2636245108 SCREW, G12010R 1
145 2586244508 SPRING, ADJUST SCREW, G12000R 1
146 2586245008 SCREW, AIR HORN SET, G12000R 2
147 2636258408 SCREW, G12010R 2
148 2636256008 O RING, AIR HORN, G12000R 1
149 2806255108 COLLAR(CHOKE), G12010R 1
150 2586255408 FILTER, CHOKE SHAFT, G12000R 1
151 2636252708 LEVER ASS'Y, CHOKE, G12000R 1
152 2636244708 SPRING CHOKE, G12000R 1
153 2266258008 FILTER, THROTTLE SHAFT, G12000R 1
154 2586257008 COLLAR, THROTTLE SHAFT, G12000R 1
155 2636255608 VALVE CP, G12010R 1
156 2586254608 GASKET, G12000R 1
157 2586256608 CLAMP, SOLENOID WIRE, G12000R 1
158 2636255508 GASKET, G12000R 1
159 2636255208 PLUG, G12010R 1
160 2636250608 ARM CHOKE, G12000R 1
161 2636259108 FILTER, AIR, G12000R 1
162 1616234508 SCREW, G12000R 1
163 2636236008 OPENER AY, G12010R 1
164 2636256608 PIPE(RUBBER), G12010R 1
165 2636258308 N/A 1
166 2636235308 ROD, CHOKE PISTON, G12000R 1
167 2636259608 WASHER,G12000R 1
168 2636259608 WASHER,G12000R 1
169 1076237708 E-CLIP, G12000R 1
170 1076237708 E-CLIP, G12000R 1
171 1076237608 COVER ASSY, THERMOSTAT, G12000R 1
172 1076237308 GASKET, G12000R 1
173 1076237508 PLATE, G12000R 1
174 2636256208 HOLDER COMPLETE, G12000R 1
175 2636258908 SCREW, HOLDER SET, G12000R 2
Page 17 of 21 2/8/2008

Parts Breakdown G12010R
176 0851030110 RUBBER PIPE, G12010R 1
177 2067550101 CLAMP COMP., G2410R 2
178 2636360301 OIL GAUGE COMPL., G12000R 1
179 26366201A3 GASKET (CARB.),G12010R 1
180 2676220110 FUEL PUMP AY, G12010R 1
181 26365002A3 BRACKET(FUEL PUMP), G12010R 1
182 26368008B3 RUBBER PIPE, G12010R 1
183 2636850103 HOSE CLAMP, G12000R 2
184 0110060020 FLANGE BOLT, G2800R 3
185 0110060020 FLANGE BOLT, G2800R 2
186 0110080110 FLANGE BOLT (M8X80MM), G12000R 2
187 2636390103 INNER ROTOR, G12000R 1
188 2636390203 OUTER ROTER, G12000R 1
189 2636400111 OIL PUMP COVER, G12010R 1
190 0440350170 OIL SEAL, G12010R 1
191 X240890030 O RING, G12010R 1
192 0110060030 FLANGE BOLT, G2800R 4
193 2636430202 OIL PUMP FILTER UN.,G12010R 1
194 26365011A3 FLANGE BOLT, G12010R 1
195 2486580100 OIL FILTER ASSY 1
196 2636500113 PLUG, OIL RELIEF, G12000R 1
197 0037014000 GASKET, ALUMINUM,G12000R 1
198 2636600103 SPRING, G12010R 1
199 0069030800 STEEL BALL, G12000R 1
200 28063602A3 OIL FILLER CAP,G12010R 1
201 26364414A3 O RING, G12010R 1
202 2637720211 FLYWHEEL CP.,G12010R 1
203 2637820211 IGNITION COIL, G12000R 2
204 26379403D1 CHARGE COIL CP.,G12010R 1
205 2637100103 RING GEAR, G12000R 1
206 0011406250 BOLT & WASHER, G2800R 4
207 0011705200 BOLT ASS'Y M5X20, G12010R 4
208 2637301601 WIRE 4, COMPL., G12000R 1
209 2637301701 WIRE 5, COMPL., G12000R 1
210 2067550101 CLAMP COMP., G2410R 1
211 0659000010 PLUG TERMINAL, G5710R 2
212 0650140280 SPARK PLUG(BPR5ES),G12010R 2
213 X655100010 SPARK PLUG CAP, G12010R 2
214 26370502A0 STARTING MOTOR ASS'Y, G12000R 1
215 2557058008 YOKE ASS'Y, G12000R 1
216 2557055108 BRUSH SET, G12000R 1
217 2287051608 BRUSH SPRING, G12000R 4
218 2557053108 BRUSH HOLDER, G12000R 1
219 2637051008 ARMATURE ASS'Y, G12000R 1
220 2557052108 PINION ASS'Y, G12000R 1
221 2107053408 PINION STOPPER SET, G12000R 1
222 2637050008 GEAR CASE ASS'Y, G12000R 1
223 2287051408 BRUSH, G12000R 2
224 2637050508 REAR COVER ASS'Y, G12000R 1
225 2437052508 SHIFT LEVER KIT, G12000R 1
226 2637051508 MAGNETIC SWITCH ASS'Y, G12000R 1
227 2077052408 THROUGH BOLT, G12000R 2
228 2637055008 THRUST WASHER KIT, G12000R 1
229 2557057008 DUST COVER KIT, G12000R 1
230 2637055108 BOLT, G12000R 2
231 2077052608 RUBBER CAP, G12000R 1
232 0023808000 FLANGE NUT, G2800R 1
233 0110080100 FLANGE BOLT, G2800R 2
234 2637190101 REGULATOR, G12000R 1
235 0110060140 FLANGE BOLT, G2410R 2
236 2637311201 WIRE 6, COMPL., G12000R 1
Page 18 of 21 2/8/2008

Parts Breakdown G12010R
237 0563000010 WIRE BAND, G12010R 4
238 0566000250 CLAMP (ELEC STARTER),G2800R 2
239 2637530101 SOLENOID, COMPL., G12000R 1
240 2807540101 N/A 1
241 2807540201 N/A 1
242 0011406120 BOLT AND WASHER ASSY, G12000R 1
243 2637544203 ROD, G12000R 1
244 2354470103 HOLDER ROD, G12000R 1
245 0230060350 SPACER, G12000R 1
246 0140030020 SCREW (M3X8MM), G12000R 4
247 0170030010 NUT, G12000R 4
248 2637546203 SPRING, G12000R 1
249 2807542201 N/A 1
250 2264310101 LINK PIVOT CP.,G12010R 1
251 0217100020 FRICTION WASHER, G12000R 1
252 26346214A3 WASHER, G12000R 1
253 2637310211 WIRE AY, G12010R 1
254 2067550101 CLAMP COMP., G2410R 2
255 31G5201501 STATOR COMPL., G12000R 1
256 31G5200101 ROTOR COMPL., G12000R 1
257 3335820608 BEARING, G12000R 1
258 31F5400201 THROUGH BOLT(5/16-24X265MM),G12000R 1
259 0032008000 SPRING WASHER, G2800R 1
260 0031008000 WASHER, G3501R 1
261 31F5300103 FRONT BRACKET, G12000R 1
262 31F5400101 BOLT (3/8-16X25M) G12000R 4
263 0032010000 SPRING WASHER, G3510R 4
264 0031010000 WASHER, G12000R 4
265 31F5400301 STATOR COVER,G12000R 1
266 31F5400501 BOLT (M4X18MM),G12000R 2
267 0021704000 NUT, G2800R 2
268 31G5301201 REAR COVER, G12000R 1
269 3655800608 COVER BOLT (M8X220MM), G12000R 4
270 0032008000 SPRING WASHER, G2800R 4
271 0031008000 WASHER, G3501R 4
272 31F5400401 BRUSH COVER, G12000R 1
273 31H5400201 BRUSH HOLDER, G12000R 1
273 31G7400101 BRUSH HOLDER, COMPL., G12000R 1
274 3565995308 BOLT & WASHER ASSY(M5X12MM)G12000R 2
275 31G6200101 SCREW & WASHER ASSY(M5X20MM)G12000R 2
276 3535750608 BUSHING, G12000R 1
277 31G8100713 LABEL (SPEC), G12010R 1
278 31G6100201 PIPE FRAME, COMPL., G12000R 1
279 31F6102401 BAFFLE PLATE, G12000R 1
280 31G6102401 COVER PLATE,G12000R 1
281 0110060080 FLANGE BOLT, G2400R 2
282 0110060080 FLANGE BOLT, G2400R 4
283 31G6200201 FLANGE BOLT (M6X12MM) G12000R 4
284 31F6100201 GENERATOR BASE, G12000R 1
285 31F3500101 MOUNT COMPL., G12000R 2
286 31F3500101 MOUNT COMPL., G12000R 2
287 0023810000 FLANGE NUT, G5501R 4
288 0023810000 FLANGE NUT, G5501R 4
289 31F6102201 STOPPER PLATE, G12000R 1
290 0016610400 BOLT (M10X40MM), G12000R 1
291 0032010000 SPRING WASHER, G3510R 1
292 0031010000 WASHER, G12000R 1
293 0021710000 NUT, G12000R 1
294 31F6201601 EARTH CORD, G12000R 1
295 0566000250 CLAMP (ELEC STARTER),G2800R 1
296 0110060020 FLANGE BOLT, G2800R 1
Page 19 of 21 2/8/2008

Parts Breakdown G12010R
297 0023806000 FLANGE NUT, G6101R 1
298 3924998708 SCREW & WASHER ASSY(M5X8MM)G12000R 1
299 9782161120 ROD, BATTERY, G12000R 2
300 31F3300101 BATTERY STAY COMPL., G12000R 1
301 0024106000 WING NUT, G12000R 2
302 31F7401601 WIRE CABLE SET, G12000R 1
303 31F3200103 BATTERY TERMINAL, G12000R 1
304 0016608450 BOLT (M8X45MM), G12000R 1
305 0023808000 FLANGE NUT, G2800R 1
306 0031008000 WASHER, G3501R 1
307 0566000170 CLAMP, G2410R 1
308 0563000060 WIRE BAND, G12000R 5
309 31G8102213 LABEL(MAKITA), G12010R 1
310 0732005080 LABEL, G12010R 1
311 0732004860 LABEL(HOT & GAS),G12010R 1
312 31G7100700 CONTROL BOX AY, G12010R 1
313 31G7302501 CONTROL BOX UNIT, G12000R 1
314 31F7300701 PLATE, G12000R 1
315 3664999708 SCREW & WASHER ASSY(M5X10MM)G12000R 4
316 31G7401501 AVR ASS'Y, G12000R 1
317 3924998608 SCREW & WASHER ASSY (M4X6MM)G12000R 4
318 KU31106201 ECU (0/S&R/C) COMPL., G12000R 1
318 KU31106211 ECU COMPLETE,G12000R 1
319 0043606200 SCREW ASSEMBLY, RBL500 2
320 0043606200 SCREW ASSEMBLY, RBL500 2
321 0023806000 FLANGE NUT, G6101R 4
322 0023806000 FLANGE NUT, G6101R 1
323 KU31105501 IDLE CONTROL UNIT, G12000R 1
324 31G7600203 WIRE COMPL., G12000R 1
325 3534720008 CONNECTOR (6P), G12000R 1
326 0043504100 SCREW & WASHER, G2800R 2
327 0021704000 NUT, G2800R 2
328 31G4950103 CONNECTOR CAP, G12000R 1
329 3514992008 SCREW & WASHER ASSY(M4X10MM)G12000R 6
330 3898900103 GROMMET, G3510R 1
331 0241150010 GROMMET, G5500R 1
332 0566000250 CLAMP (ELEC STARTER),G2800R 1
333 0110060020 FLANGE BOLT, G2800R 1
334 31G7200900 CONTROL PANEL AY, G12010R 1
335 31G7302601 CONTROL PANEL,G12000R 1
336 0660000330 KEY SWITCH, G3511R 1
337 0660009980 KEY-103, G4101R,T2 2
338 3444561508 SWITCH, G3510R 1
339 3888500301 AC RECEPTACLE (125V-20A),G6101R 2
340 3804574908 AC RECEPTACLE (125V-30A)G12000R 1
341 31G7501703 AC RECEPTACLE(125/250V-30A)G12000R 1
342 31G7501803 AC RECEPTACLE(125/250V-50A)G12000R 1
343 3514992008 SCREW & WASHER ASSY(M4X10MM)G12000R 2
344 3514992008 SCREW & WASHER ASSY(M4X10MM)G12000R 4
345 31G7501503 SCREW & WASHER ASSY,G12000R 2
346 31G7501503 SCREW & WASHER ASSY,G12000R 2
347 0021704000 NUT, G2800R 6
348 0031004000 WASHER, G6101R 12
349 3914790011 AC VOLT METER, G5710R 1
350 0021703000 NUT, G2800R 2
351 3934065108 HOUR METER, G12000R 1
352 3934310101 LAMP (OIL) G12000R 1
353 31F7501603 PILOT LAMP, G12000R 1
354 3934500601 LAMP, G12010R 1
355 31G7500203 NO FUSE BREAKER (2P-39A),G12000R 1
356 31B7901103 SCREW & WASHER ASSY(M3X5MM)G12000R 4
Page 20 of 21 2/8/2008
