ADTRAN NetVanta 7000 Series Manual

NetVanta 7000 Series
Hardware Installation Guide
1700706G1 NetVanta 7060 PoE
1200796E1 NetVanta 7100 PoE
1200690E1 NetVanta Quad FXS Voice Interface Module
1202691G1 NetVanta Quad FXO Voice Interface Module
1202692G1 NetVanta Dual FXS/FXO Voice Interface Module
1200695L1 NetVanta T1/PRI Voice Interface Module
1200696G1 NetVanta E1/PRI Voice Interface Module
1202862L1 NetVanta T1/FT1 Network Interface Module
1200872L1 NetVanta Dual T1 Network Interface Module
1200868E1 NetVanta E1/FE1 Network Interface Module
1200878E1 NetVanta E1/FE1 + G.703 Network Interface Module
1202869E1 NetVanta ADSL Network Interface Module, Annex A
1200852G1 CompactFlash®, 1 GB
61200796L1-34L
August 2014

Trademarks NetVanta 7000 Series Hardware Installation Guide
2 Copyright © 2014 ADTRAN, Inc. 61200796L1-34L
Trademarks
Any brand names and product names included in this manual are trademarks, registered trademarks, or trade
names of their respective holders.
To the Holder of the Manual
The contents of this manual are current as of the date of publication. ADTRAN reserves the right to change the
contents without prior notice.
In no event will ADTRAN be liable for any special, incidental, or consequential damages or for commercial
losses even if ADTRAN has been advised thereof as a result of issue of this publication.
Software Licensing Agreement
Each ADTRAN product contains a single license for ADTRAN-supplied software. Pursuant to the Licensing
Agreement, you may: (a) use the software on the purchased ADTRAN device only and (b) keep a copy of the
software for backup purposes. This Agreement covers all software installed on the system, as well as any
software available on the ADTRAN website. In addition, certain ADTRAN systems may contain additional
conditions for obtaining software upgrades.
901 Explorer Boulevard
P.O. Box 140000
Huntsville, AL 35814-4000
Phone: [phone]
Copyright © 2014 ADTRAN, Inc.
All Rights Reserved.
Printed in U.S.A.
Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.

NetVanta 7000 Series Hardware Installation Guide Conventions
61200796L1-34L Copyright © 2014 ADTRAN, Inc. 3
Conventions
Notes provide additional useful information.
Cautions signify information that could prevent service interruption or damage to the
equipment.
Warnings provide information that could prevent injury or endangerment to human
life.

Safety Instructions NetVanta 7000 Series Hardware Installation Guide
4 Copyright © 2014 ADTRAN, Inc. 61200796L1-34L
Safety Instructions
When using your telephone equipment, please follow these basic safety precautions to reduce the risk of fire,
electrical shock, or personal injury:
1. Do not use this product near water, such as a bathtub, wash bowl, kitchen sink, laundry tub, in a
wet basement, or near a swimming pool.
2. Avoid using a telephone (other than a cordless type) during an electrical storm. There is a remote
risk of shock from lightning.
3. Do not use the telephone to report a gas leak in the vicinity of the leak.
4. Use only the power cord, power supply, and batteries indicated in the manual. Do not dispose of
batteries in a fire. They may explode. Check with local codes for special disposal instructions.
5. The socket-outlet shall be installed near the equipment and shall be easily accessible.
If any of the following conditions occur, unplug the product from the electrical outlet and replace the part or
contact your qualified service personnel:
1. The power cable, extension cable, or plug is damaged.
2. An object has fallen into the product.
3. The product has been exposed to water.
4. The product has been dropped or damaged.
5. The product does not operate correctly when you follow the operating instructions.
Save These Important Safety Instructions
These units contain no user-serviceable parts. They should only be serviced by qualified
service personnel.
This equipment incorporates double pole/neutral fusing. If the neutral fuse opens and the
line fuse does not open, voltage could still be present in the unit.
Additional safety guidelines, such as Waste Electrical and Electronic Equipment (WEEE),
are given in the document NetVanta Safety and Regulatory Information available online at
http://supportforums.adtran.com.

NetVanta 7000 Series Hardware Installation Guide FCC-Required Information
61200796L1-34L Copyright © 2014 ADTRAN, Inc. 5
FCC-Required Information
FCC regulations require that the following information be provided in this manual:
1. This equipment complies with Part 68 of Federal Communications Commission (FCC) rules and
requirements adopted by America’s Carriers Telecommunications Association (ACTA). Each
registered interface has a label that contains, among other information, a product identifier in the
format US:AAAEQ##TXXXX. If requested, provide this information to the telephone company.
2. If this equipment causes harm to the telephone network, the telephone company may temporarily
discontinue service. If possible, advance notification is given; otherwise, notification is given as
soon as possible. The telephone company will advise the customer of the right to file a complaint
with the FCC.
3. The telephone company may make changes in its facilities, equipment, operations, or procedures
that could affect the proper operation of this equipment. Advance notification and the opportunity
to maintain uninterrupted service are given.
4. If experiencing difficulty with this equipment, please contact ADTRAN for repair and warranty
information. The telephone company may require this equipment to be disconnected from the
network until the problem is corrected, or it is certain the equipment is not malfunctioning.
5. This unit contains no user-serviceable parts.
6. This equipment is designed to connect to the telephone network or premises wiring using an
FCC-compatible modular jack, which is compliant with Part 68 and requirements adopted by
ACTA.
7. The following information may be required when applying to the local telephone company for
leased line facilities
8. The ringer equivalence number (REN) is useful in determining the quantity of devices you may
connect to your telephone line and still have all of those devices ring when your number is called.
In most areas, the sum of the RENs of all devices should not exceed five. To be certain of the
number of devices you may connect to your line as determined by the REN, call your telephone
company to determine the maximum REN for your calling area.
9. This equipment may not be used on coin service provided by the telephone company. Connection
to party lines is subject to state tariffs. Contact your state public utility commission or corporation
commission for information.
Part Number Registration Number Service Type REN/SOC FIC USOC
1202862L1 US: HDCDENAN1202862L1 1.544 Mbps - SF
1.544 Mbps - SF and B8ZS
1.544 Mbps - ESF
1.544 Mbps - ESF and B8ZS N/A/6.0N
04DU9-BN
04DU9-DN
04DU9-1KN
04DU9-1SN RJ-48C
1202872L1 US: HDCDENAN1200872L1
1200695L1 US: HDCDENAN1200695L1
1202869E1 US: HDCDL01A1200869L1 ADSL, ADSL2, ADSL2+ 0.1A Metallic RJ-11C
1202691G1 US: HDCMM01B1200691L1
Analog Loop Start/Ground
Start 0.1B 02LS2/02GS2 RJ-11C
1202692G1 US: HDCMM01B1200691L1
1200796E1 US: HDCIS01B1200796L1
1700706G1 US: HDCIS01B1700706G1

Industry Canada Compliance Information NetVanta 7000 Series Hardware Installation Guide
6 Copyright © 2014 ADTRAN, Inc. 61200796L1-34L
FCC Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio frequencies. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interference at his own expense.
Electromagnetic Compatibility (EMC) Table
Industry Canada Compliance Information
This product meets the applicable Industry Canada technical specifications.
The Ringer Equivalence Number (REN) is an indication of the maximum number of devices allowed to be
connected to a telephone interface. The termination of an interface may consist of any combination of
devices subject only to the requirement that the sum of the RENs of all the devices not exceed five.
Le présent matériel est conforme aux specifications techniques applicables d'Industrie Canada.
L'indice d'équivalence de la sonnerie (IES) sert à indiquer le nombre maximal de terminaux qui peuvent
être raccordés à une interface téléphonique. La terminaison d'une interface peut consister en une
combinaison quelconque de dispositifs, à la seule condition que la somme d'indices d'équivalence de la
sonnerie de tous les dispositifs n'excède pas cinq.
Canadian Emissions Requirements
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus as set
out in the interference-causing equipment standard entitled “Digital Apparatus,” ICES-003 of the Department of
Communications.
NetVanta Module P/N and Name NetVanta 7060 NetVanta 7100
1202862L1 T1/FT1 NIM FCC Part 15 Class A
EN 300 386 FCC Part 15 Class A EN 300 386
1202872L1 Dual T1 NIM FCC Part 15 Class A
EN 55022 Class A FCC Part 15 Class A EN 55022 Class A
1200868E1 E1/FE1 NIM FCC Part 15 Class A
EN 55022 Class A
EN 55024
FCC Part 15 Class A
EN 55022 Class A
EN 55024
1200878E1 E1/FE1 + G.703 NIM FCC Part 15 Class A
EN 55022 Class A
EN 55024
FCC Part 15 Class A
EN 55022 Class A
EN 55024
1202869E1 ADSL NIM, Annex A FCC Part 15 Class A
EN 300 386 FCC Part 15 Class A EN 300 386
1200690E1 Quad FXS VIM FCC Part 15 Class A
EN 300 386 FCC Part 15 Class A EN 300 386
1202691G1 Quad FXO VIM FCC Part 15 Class A
EN 300 386 FCC Part 15 Class A EN 300 386
1202692G1 Dual FXS/FXO VIM FCC Part 15 Class A
EN 300 386 FCC Part 15 Class A EN 300 386
1200695L1 T1/PRI VIM FCC Part 15 Class A
EN 55022 Class A
EN 55024
FCC Part 15 Class A
EN 55022 Class A
EN 55024
1200696G1 E1/PRI VIM FCC Part 15 Class A
EN 300 386 FCC Part 15 Class A EN 300 386

NetVanta 7000 Series Hardware Installation Guide Toll Fraud Liability
61200796L1-34L Copyright © 2014 ADTRAN, Inc. 7
Cet appareil numérique respecte les limites de bruits radioelectriques applicables aux appareils numériques de
Class A prescrites dans la norme sur le materiel brouilleur: “Appareils Numériques,” NMB-003 edictee par le
ministre des Communications.
Toll Fraud Liability
Be advised that certain security risks are inherent in the use of any telecommunications or networking
equipment, including but not limited to, toll fraud, Denial of Service (DoS) attacks, loss or theft of data, and the
unauthorized or illegal use of said equipment. ADTRAN OFFERS NO WARRANTIES, EITHER
EXPRESSED OR IMPLIED, REGARDING THE PREVENTION, DETECTION, OR DETERRENCE OF
TOLL FRAUD, NETWORKING ATTACKS, OR UNAUTHORIZED, ILLEGAL, OR IMPROPER USE OF
ADTRAN EQUIPMENT OR SOFTWARE. THEREFORE, ADTRAN IS NOT LIABLE FOR ANY LOSSES
OR DAMAGES RESULTING FROM SUCH FRAUD, ATTACK, OR IMPROPER USE, INCLUDING, BUT
NOT LIMITED TO, HUMAN AND DATA PRIVACY, INTELLECTUAL PROPERTY, MATERIAL
ASSETS, FINANCIAL RESOURCES, LABOR AND LEGAL COSTS. Ultimately, the responsibility for
securing your telecommunication and networking equipment rests with you, and you are encouraged to review
documentation regarding available security measures, their configuration and implementation, and to test such
features as is necessary for your network.
Third-Party Software
The software included in this product contains copyrighted software that is licensed under the GNU
General Public License (GPL). For a list of third-party software and their licenses, go to
http://www.adtran.com/software/EULA. You can obtain the complete corresponding source code of such
software components from ADTRAN for a period of three years after our last shipment of this product by
sending a money order or check for $5 to:
ADTRAN, Inc, P.O. Box 933638, Atlanta, GA 31193-3638
Please write GPL Source for product NetVanta 7100 in the memo line of your payment.
This offer is valid to anyone in receipt of this information.
Service and Warranty
For information on the service and warranty of ADTRAN products, visit the Support section of the
ADTRAN website at http://www.adtran.com.

Service and Warranty NetVanta 7000 Series Hardware Installation Guide
8 Copyright © 2014 ADTRAN, Inc. 61200796L1-34L

61200796L1-34L Copyright © 2014 ADTRAN, Inc. 9
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
NetVanta 7060 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
NetVanta 7100 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Power Over Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
SFP Module Slots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Unpacking and Inspecting the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Product Features and Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Physical Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Front Panel RJ-45 Ports and LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
NetVanta 7000 Series Rear Panel Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Option Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Network Interface Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Voice Interface Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Unit Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Mounting Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Supplying Power to the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Installing Network Interface and Voice Interface Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Installing a CompactFlash Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Appendix A. Connector Pin Definitions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Table of Contents NetVanta 7000 Series Hardware Installation Guide
10 Copyright © 2014 ADTRAN, Inc. 61200796L1-34L

61200796L1-34L Copyright © 2014 ADTRAN, Inc. 11
List of Figures
Figure 1. NetVanta 7000 Series Front Panel Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Figure 2. NetVanta 7000 Series Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Figure 3. NetVanta T1/FT1 NIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Figure 4. NetVanta Dual T1 NIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Figure 5. NetVanta E1/FE1 NIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Figure 6. NetVanta E1/FE1 + G.703 NIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Figure 7. NetVanta ADSL NIM, Annex A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Figure 8. NetVanta T1/PRI VIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Figure 9. NetVanta E1/PRI VIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Figure 10. NetVanta Quad FXS VIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Figure 11. NetVanta Quad FXO VIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Figure 12. NetVanta Dual FXS/FXO VIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Figure 13. Wallmount Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Figure 14. NIM and VIM Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Figure 15. CompactFlash Card Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

List of Figures NetVanta 7000 Series Hardware Installation Guide
12 Copyright © 2014 ADTRAN, Inc. 61200796L1-34L

61200796L1-34L Copyright © 2014 ADTRAN, Inc. 13
List of Tables
Table 1. Front Panel LED Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Table A-1. CONSOLE Port Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Table A-2. SFP Slot Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Table A-3. 10/100Base-T Ethernet Port Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Table A-4. 1000Base-T Gigabit Ethernet Port Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Table A-5. Analog - Onboard FXS and FXO Port Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Table A-6. T1/E1 Connector Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Table A-7. DSX-1 Connector Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Table A-8. G.703 Connector Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Table A-9. ADSL NIM Connector Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Table A-10. Analog Station (FXS) and Analog Trunk (FXO) Port Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . 44

List of Tables NetVanta 7000 Series Hardware Installation Guide
14 Copyright © 2014 ADTRAN, Inc. 61200796L1-34L

61200796L1-34L Copyright © 2014 ADTRAN, Inc. 15
1. INTRODUCTION
The NetVanta 7000 Series provides an innovative Voice over Internet Protocol (VoIP) communication solution
for small- to medium-sized businesses that simplifies the migration to VoIP and resolves complicated network
assessments and equipment interoperability issues. The NetVanta 7000 Series includes the NetVanta 7060 and
the NetVanta 7100.
This hardware installation guide lists the NetVanta 7000 Series specifications, describes the physical
characteristics of the units, introduces basic functionality, and provides installation instructions.
NetVanta 7060
The NetVanta 7060 is an IP private branch exchange (PBX). It is a cost-effective product built on the ADTRAN
Operating System (AOS) platform that is ideal for business locations that already have an IP data network
established with routing and virtual private network (VPN) functionality. The NetVanta 7060 comes equipped
with 24 Power over Ethernet (PoE) 10/100 Ethernet ports capable of supplying the full 15.4 watts described in
the 802.3af specification. The NetVanta 7000 Series front panel contains two Gigabit Ethernet interfaces that
provide two fixed RJ-45 connectors and two standard small form-factor pluggable (SFP) slots for
connectivity over fiber. The NetVanta 7060 is a 1U rack-mountable chassis that supplies the user with VoIP
capability for up to 100 SIP user registrations. The unit is also equipped with several integrated ports, including
analog trunks (FXO), analog stations (FXS), door relays, console, CompactFlash (for voicemail storage), wide
area network (WAN) Ethernet port, music on hold (MOH), paging, auto-sensing AC power, as well as two
network interface module/voice interface module (NIM/VIM) slots.
NetVanta 7100
The NetVanta 7100 is an integrated IP data networking and telephony solution that combines multiple data and
voice functions into a single platform. It is a cost-effective product built on the AOS platform, and includes the
AOS built-in IP router, VPN, and firewall features. The NetVanta 7100 comes equipped with 24 PoE 10/100
Ethernet ports capable of supplying the full 15.4 watts described in the 802.3af specification. The NetVanta
7000 Series front panel contains two Gigabit Ethernet interfaces that provide two fixed RJ-45 connectors
and two standard small form-factor pluggable (SFP) slots for connectivity over fiber. The NetVanta 7100 is
a 1U rack-mountable chassis that supplies the user with VoIP capability for up to 100 SIP user registrations. The
unit is also equipped with several integrated ports, including analog trunks (FXO), analog stations (FXS), door
relays, console, CompactFlash (for voicemail storage), WAN Ethernet port, music on hold (MOH), paging,
auto-sensing AC power, as well as two network interface module/voice interface module (NIM/VIM) slots.
The NetVanta 7000 Series contains two NIM/VIM slots on the rear panel that support the following modules in
data applications:
• 1202862L1 T1/FT1 NIM
• 1200872L1 Dual T1 NIM
• 1200868E1 E1/FE1 NIM
• 1200878E1 E1/FE1 + G.703 NIM
• 1200869E1 ADSL NIM, Annex A
In this document, the term NetVanta 7000 Series means both of the units collectively. If a
statement only applies to one particular unit, the text refers to that unit individually.

Introduction NetVanta 7000 Series Hardware Installation Guide
16 Copyright © 2014 ADTRAN, Inc. 61200796L1-34L
The NetVanta 7000 Series NIM/VIM slots on the rear panel support the following modules in voice
applications:
• 1200690E1 Quad FXS VIM
• 1202691G1 Quad FXO VIM
• 1202692G1 Dual FXS/FXO VIM
• 1200695L1 T1/PRI VIM
• 1200696G1 E1/PRI VIM
Power Over Ethernet
The NetVanta 7000 Series PoE interfaces provide the ability to detect attached powered devices (PDs) and
deliver 48 VDC to the PD via existing CAT 5 cabling. The PoE interfaces are fully compliant with the IEEE
802.3af PoE standard. By default, the PoE ports automatically discover and provide power to IEEE-compliant
PDs.
SFP Module Slots
The NetVanta 7000 Series has two small form-factor pluggable (SFP) slots that accept a number of
industry standard SFP modules. The SFP modules provide Gigabit Ethernet fiber connectivity for
high-speed uplinks. For a list of supported SFP modules, visit the ADTRAN website at http://www.adtran.com.
Unpacking and Inspecting the System
Each NetVanta 7000 Series unit is shipped in its own cardboard shipping carton. Open each carton carefully, and
avoid deep penetration into the carton with sharp objects.
After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damaged in transit,
immediately file a claim with the carrier and contact ADTRAN Customer Service (refer to the Support page on
the ADTRAN website at http://www.adtran.com/support).
Contents of ADTRAN NetVanta 7000 Series Shipments
The NetVanta 7000 Series units ship with the following items:
• NetVanta 7000 Series base unit
• A detachable power cable with a grounded, three-prong plug
• Mounting brackets and screws
• Quick start guide

NetVanta 7000 Series Hardware Installation Guide Product Features and Specifications
61200796L1-34L Copyright © 2014 ADTRAN, Inc. 17
2. PRODUCT FEATURES AND SPECIFICATIONS
The NetVanta 7000 Series has the following features:
IP PBX System Features
• Analog trunks (loop start/ground start; FSK capture of caller ID name/number; two integrated,
10 maximum)
• Analog stations (loop start DTMF; 1500 feet over 26 AWG; two integrated, 10 maximum)
• Auto attendant (multilevel, eight-port)
• Shared line appearance (SLA)
• Shared call appearance (SCA)
• FindMe-FollowMe
• Busy lamp field/direct station select (BLF/DSS)
• System scheduler (seven configurable modes: i.e., night, lunch, weekend)
• Public hold
• Call detail records
• Caller ID name/number override (internal and external)
• Classes of service
• CODEC support includes G.711, G.729, G.722 (wideband)
• Configurable dial plan
• Door relay
• Door phone
• Email notification of voicemail message
• Global call coverage lists
• IP stations (100 maximum; SIP hardphone or softphone)
• Least-cost routing
• Operator groups
• Outgoing number substitution
• PRI or integrated voice/data PRI
• Personal phone manager web page
• Ring groups (ring all, circular hunt group, UCD, executive)
• Call queue
• Paging groups
• Park and paging
• System speed dial
• T1 or integrated voice/data T1
• Trunk groups
• Variable length extension numbers (three-digit, four-digit, and five-digit)
• Voicemail (50 hours, eight ports)
• 30 DSP resources
• 64 ms echo cancellation for VoIP calls

Product Features and Specifications NetVanta 7000 Series Hardware Installation Guide
18 Copyright © 2014 ADTRAN, Inc. 61200796L1-34L
IP Station Features
• Call drop
• Call forward (all, busy, no answer)
• Call forward to outside line (cell phone)
• Call hold
• Caller ID name/number
• Call logs
• Call waiting
• Call park/retrieve
• Handsfree intercom
• Call transfer
• Do not disturb
• Conferencing (3-party)
• Headset jack
• Emergency call override
• Missed call indicator
• Message waiting light
• Music on hold
• Multiple call appearances
• Overhead paging
• Mute
• Redial
• Personal call routing
• Speaker phone
• Volume control
Router Features (NetVanta 7100 only)
• RIP V1, RIP V2, and static routes
• BGP
• PPP, PPPoE, Frame Relay WAN protocols
• DHCP client/server
• Class-based weighted fair queuing, priority queuing, weighted fair queuing
• DiffServ aware/mark
• MLPPP/MLFR
Firewall Features (NetVanta 7100 only)
• Stateful packet inspection
• NAT (1:1), NAPT (many:1)
• Denial of service (DoS) protection
• Access control lists
• SIP aware (B2BUA)

NetVanta 7000 Series Hardware Installation Guide Product Features and Specifications
61200796L1-34L Copyright © 2014 ADTRAN, Inc. 19
Content Filtering (NetVanta 7100 only)
• Inherent URL filter
• Top website reports
• Integration with Websense®
VPN Features (NetVanta 7100 only)
• Five tunnels
• IPsec
• DES/3DES/AES encryption
Ethernet Switch Features
• 10/100Base-T (24)
• 10/100/1000Base-T (two)
• Two SFP slots
• Autorate
• Auto-duplex
• Auto-MDI/MDI-X
• 802.1d spanning tree
• 802.1p class of service (CoS) aware/mark
• 802.1Q VLANs
• 802.3af Power over Ethernet (15.4 watts for each of the 24 ports)
Management Features
• Command line interface (CLI) - Telnet, SSH, console port
• Web-based graphical user interface (GUI) - HTTP, HTTPS
Environmental
• Operating Temperature: 0°C to 50°C
• Storage Temperature: -20°C to 70°C
• Relative Humidity: Up to 95 percent, noncondensing
Physical
• Chassis: 1U, 19-inch rack-mountable metal enclosure
• Dimensions: 1.7-inch H x 17.2-inch W x 12.8-inch D
• Weight: 11 lb
• AC Input: 100 to 250 VAC, 50/60 Hz

Physical Description NetVanta 7000 Series Hardware Installation Guide
20 Copyright © 2014 ADTRAN, Inc. 61200796L1-34L
3. PHYSICAL DESCRIPTION
Front Panel RJ-45 Ports and LEDs
The NetVanta 7000 Series front panel is shown below. Table 1 on page 21 describes all of the LEDs, and
Appendix A: Connector Pin Definitions on page 41 shows the pinouts for the connectors.
NetVanta 7000 Series Front Panel Features
10/100Base-T Ethernet Interfaces
The NetVanta 7000 Series front panel contains 24 10/100Base-T Ethernet interfaces (RJ-45). These
interfaces are consecutively numbered 1through 24, from left to right, with the numbers screened
directly above each port. Status LEDs for each of these interfaces are located directly over these
numbers.
The NetVanta 7000 Series also has green and red PoE status LEDs located in the upper-left and
upper-right corners (respectively) of each Ethernet connector.
Gigabit Ethernet Interfaces/SFP Slots
The NetVanta 7000 Series front panel contains two Gigabit Ethernet interfaces that provide two fixed
RJ-45 connectors and two standard small form-factor pluggable (SFP) slots for connectivity over fiber.
(Use either the RJ-45 connectors or the SFP slots. The fiber slots have precedence.) These interfaces
are labeled G1 and G2,and the status LEDs are located above the SFP slots.
Status LEDs
The status LEDs are located to the lower left of RJ-45 port 1. The SLOT 1 LED reflects the status of a
NIM/VIM installed in NIM/VIM option SLOT 1 (located on the rear panel). The SLOT 2 LED reflects
the status of a NIM/VIM installed in NIM/VIM option SLOT 2 (located on the rear panel). The STAT
LED indicates the unit’s status.
Figure 1. NetVanta 7000 Series Front Panel Layout
