Advance acoustic Advenger 56601000 User manual

Advenger™
2800ST, 3400ST
Instructions For Use
Instrucciones de uso
Advance MODELS 56601000, 56601001, 56601002, 56601003, 56601004
56601005, 56601006, 56601007, 56601008, 56601009, 56601010, 56601011
56601012, 56601013, 56601019, 56601020
12/08 revised 1/10 Form No. 56041735
A-English
B-Español

A-2 / ENGLISH
A-2 - FORM NO. 56041735 - Advenger™
TABLE OF CONTENTS
Page
Introduction........................................................................................... A-2
Cautions and Warnings ........................................................................ A-3
Consignes de prudence et de sécurité................................................. A-4
Know Your Machine.....................................................................A-5 – A-6
Control Panels.............................................................................A-7 – A-8
Prepare the Machine for Use
Install the Batteries............................................................................... A-9
Install the Brushes.............................................................................. A-10
Install the Squeegee........................................................................... A-11
Fill the Solution Tank .......................................................................... A-11
Detergent System....................................................................A-12 – A-13
Operating the Machine
Scrubbing ........................................................................................... A-14
Wet Vacuuming .................................................................................. A-15
After Use............................................................................................. A-16
Maintenance Schedule....................................................................... A-16
Lubricating the Machine ..................................................................... A-16
Charging the Batteries (Wet).............................................................. A-17
Check the Battery Water Level...........................................................A-17
Charging the Batteries (Gel)............................................................... A-17
Squeegee Maintenance...................................................................... A-18
Squeegee Adjustment ........................................................................ A-18
Side Skirt Maintenance....................................................................... A-19
Side Skirt Maintenance....................................................................... A-19
Troubleshooting.................................................................................. A-20
Technical Specifications ..................................................................... A-21
INTRODUCTION
This manual will help you get the most from your Advance Rider Scrubber. Read it thoroughly before operating the machine.
Note: Bold numbers in parentheses indicate an item illustrated on pages A-5 – A-8.
This product is intended for commercial use only.
PARTS AND SERVICE
Repairs, when required, should be performed by your Authorized Advance Service Center, who employs factory trained service personnel, and maintains an
inventory of Advance original replacement parts and accessories.
Call the ADVANCE DEALER named below for repair parts or service. Please specify the Model and Serial Number when discussing your machine.
(Dealer, affix service sticker here.)
NAME PLATE
The Model Number and Serial Number of your machine are shown on the Nameplate on the machine. This information is needed when ordering repair parts for
the machine. Use the space below to note the Model Number and Serial Number of your machine for future reference.
MODEL NUMBER ______________________________________________________
SERIAL NUMBER ______________________________________________________
UNCRATE THE MACHINE
When the machine is delivered, carefully inspect the shipping packaging and the machine for damage. If damage is evident, save the shipping carton (if
applicable) so that it can be inspected. Contact the Advance Customer Service Department immediately to file a freight damage claim. Refer to the unpacking
instruction sheet included with the machine to remove the machine from the pallet.
revised 1/10

ENGLISH / A-3
FORM NO. 56041735 - Advenger™- A-3
CAUTIONS AND WARNINGS
SYMBOLS
Advance uses the symbols below to signal potentially dangerous conditions. Always read this information carefully and take the
necessary steps to protect personnel and property.
DANGER!
Is used to warn of immediate hazards that will cause severe personal injury or death.
WARNING!
Is used to call attention to a situation that could cause severe personal injury.
CAUTION!
Is used to call attention to a situation that could cause minor personal injury or damage to the machine or other property.
Read all instructions before using.
GENERAL SAFETY INSTRUCTIONS
Specific Cautions and Warnings are included to warn you of potential danger of machine damage or bodily harm.
WARNING!
*This machine shall be used only by properly trained and authorized persons.
* While on ramps or inclines, avoid sudden stops when loaded. Avoid abrupt sharp turns. Use low speed down hills. Clean only
while ascending (driving up) the ramp.
*Keep sparks, flame and smoking materials away from batteries. Explosive gases are vented during normal operation.
*Charging the batteries produces highly explosive hydrogen gas. Charge batteries only in well-ventilated areas, away from open
flame. Do not smoke while charging the batteries.
*Remove all jewelry when working near electrical components.
*Turn the key switch off (O) and disconnect the batteries before servicing electrical components.
*Never work under a machine without safety blocks or stands to support the machine.
*Do not dispense flammable cleaning agents, operate the machine on or near these agents, or operate in areas where flammable
liquids exist.
*Do not clean this machine with a pressure washer.
*Only use the brushes provided with the appliance or those specified in the instruction manual. The use of other brushes may
impair safety.
CAUTION!
*This machine is not approved for use on public paths or roads.
*This machine is not suitable for picking up hazardous dust.
*Do not use scarifier discs and grinding stones. Advance will not be held responsible for any damage to floor surfaces caused by
scarifiers or grinding stones (can also cause damage to the brush drive system).
*When operating this machine, ensure that third parties, particularly children, are not endangered.
*Before performing any service function, carefully read all instructions pertaining to that function.
*Do not leave the machine unattended without first turning the key switch off (O), removing the key and applying the parking
brake.
*Turn the key switch off (O) and remove the key, before changing the brushes, and before opening any access panels.
*Take precautions to prevent hair, jewelry, or loose clothing from becoming caught in moving parts.
*Use caution when moving this machine in below freezing temperature conditions. Any water in the solution, recovery or
detergent tanks or in the hose lines could freeze, causing damage to valves and fittings. Flush with windshield washer fluid.
*The batteries must be removed from the machine before the machine is scrapped. The disposal of the batteries should be
safely done in accordance with your local environmental regulations.
*Do not use on surfaces having a gradient exceeding that marked on the machine.
*All doors and covers are to be positioned as indicated in the instruction manual before using the machine.
SAVE THESE INSTRUCTIONS

A-4 / ENGLISH
A-4 - FORM NO. 56041735 - Advenger™
CONSIGNES DE PRUDENCE ET DE SÉCURITÉ
SYMBOLES
Les symboles reproduits ci-dessous sont utilisés pour attirer l’attention de l’opérateur sur des situations dangereuses. Il est donc conseillé de lire
attentivement ces indications et de prendre les mesures adéquates en vue de protéger le personnel et le matériel.
DANGER!
Ce symbole est utilisé pour mettre l’opérateur en garde contre les risques immédiats pouvant provoquer des dommages corporels graves, voire
entraîner la mort.
ATTENTION!
Ce symbole est utilisé pour attirer l’attention sur une situation susceptible d’entraîner des dommages corporels graves.
PRUDENCE!
Ce symbole est utilisé pour attirer l’attention de l’opérateur sur une situation qui pourrait entraîner des dommages corporels minimes, ou des
dommages à la machine ou à d’autres équipements.
Lire toutes les instructions avant d’utiliser l’appareil.
CONSIGNES GENERALES DE SECURITE
Les consignes spécifiques de prudence et de sécurité mentionnées ici ont pour but de vous informer de la survenance de tout risque de
dommages matériels ou corporels.
ATTENTION!
*Cette machine ne pourra être utilisée que par du personnel parfaitement entraîné et dûment autorisé.
*Evitez les arrêts subits lorsque la machine est chargée et se trouve sur des rampes ou des plans inclinés. Evitez les virages serrés. Adoptez une
vitesse réduite lorsque la machine est en descente. Ne nettoyez que lorsque la machine monte la pente.
*Eloignez les batteries de toutes flammes, étincelles ou substance fumigène. Les gaz explosifs sont ventilés pendant le fonctionnement normal.
*De plus, du gaz hydrogène explosif s’échappe des batteries lorsqu’elles sont en charge. Ne procédez au chargement des batteries que dans une
zone bien ventilée, loin de toute flamme. Ne fumez pas à proximité des batteries lorsqu’elles sont en charge.
*Otez tous vos bijoux lorsque vous travaillez à proximité de composants électriques.
*Positionnez la clé de contact sur off (O) et déconnectez les batteries avant de procéder à l’entretien des composants électriques.
*Ne travaillez jamais sous une machine sans y avoir placé, au préalable, des blocs de sécurité ou des étais destinés à soutenir la machine
*Ne déversez pas d’agents nettoyants inflammables, ne faites pas fonctionner la machine à proximité de ces agents ou d’autres liquides
inflammables.
*Ne nettoyez pas cette machine avec un nettoyeur à pression.
*Utilisez uniquement les brosses fournies avec l’appareil ou celles spécifiées dans le manuel d’instructions. L’utilisation d’autres brosses peut mettre
la sécurité en péril.
PRUDENCE!
*Cette machine n’est pas conçue pour une utilisation sur les chemins ou voies publics.
*Cette machine n’est pas conçue pour le ramassage des poussières dangereuses.
*N’utilisez pas de disques de scarificateur ni de meules. Advance ne pourra en aucun cas être tenue pour responsable des dommages occasionnés
à vos sols par ce type d’équipement (vous risquez également d’endommager le système d’entraînement des brosses).
*Lors de l’utilisation de cette machine, assurez-vous que des tiers, et notamment des enfants, ne courent pas le moindre risque.
*Avant de procéder à toute opération d’entretien, veuillez lire attentivement toutes les instructions qui s’y rapportent.
*Ne laissez pas la machine sans surveillance sans avoir, au préalable, coupé le contact, enlevé la clé de contact (O) et tiré le frein à main.
*Positionnez la clé de contact sur off (O) avant de remplacer les brosses ou d’ouvrir tout panneau d’accès.
*Prenez toutes les mesures nécessaires pour éviter que les cheveux, les bijoux ou les vêtements amples ne soient entraînés dans les parties mobiles
de la machine.
*Faites attention lorsque vous déplacez cette machine dans un endroit où la température peut descendre sous 0°. L’eau contenue dans les
réservoirs de détergent, de récupération ou de solution ou dans les conduites risquerait de geler et par là même d’endommager les valves et
raccords de la machine. Rincez avec un liquide de lave-glace.
*Prenez soin d’enlever les batteries de la machine avant de mettre cette dernière au rebut. Pour ce qui est de l’élimination des batteries, conformez-
vous aux réglementations locales en matière d’environnement.
*N’utilisez pas sur des surfaces dont la pente dépasse celle mentionnée sur la machine.
*Toutes les portes et couvercles doivent être dans la position mentionnée dans le manuel d’instruction avant de mettre la machine en service.
CONSERVEZ SOIGNEUSEMENT CES INSTRUCTIONS

ENGLISH / A-5
FORM NO. 56041735 - Advenger™- A-5
KNOW YOUR MACHINE
As you read this manual, you will occasionally run across a bold number or letter in parentheses - example: (2). These numbers refer to an item shown on these
pages unless otherwise noted. Refer back to these pages whenever necessary to pinpoint the location of an item mentioned in the text. NOTE: Refer to the
service manual for detailed explanations of each item illustrated on the next 4 pages.
1 Operator’s Seat
2 Solution Tank Drain Hose
3 Drive Pedal, Directional/Speed
4 Drive Wheel
5 Drive Wheel Circuit Breaker (70 Amp)
6 Control Circuit Circuit Breaker (10 Amp)
7 Emergency Stop
8 Scrub Deck
9 Rear Wheel
10 Battery Compartment (under seat)
11 Squeegee Assembly
12 Detergent Cartridge Access Cover (EcoFlex models only)
13 Detergent Cartridge (EcoFlex models only)
14 Scrub Deck Raise/Lower Lever (ST models only)
15 Deck Skirt Removal Knobs
16 Battery Charger Access Door
17 Battery Charger (optional)
18 Seat Adjustment Knob (optional on ST models)
19 Deck Skirt Height Adjustment Knob
20 Front Roller Bumper
revised 1/10

A-6 / ENGLISH
A-6 - FORM NO. 56041735 - Advenger™
KNOW YOUR MACHINE
21 Solution Shutoff Valve
22 Squeegee Raise/Lower Lever (ST models only)
23 Steering Wheel Tilt Adjust Knob
24 Control Panel
25 Solution Tank Fill Cover
26 Recovery Tank Cover
27 Vacuum Motor Filter Housing
28 Strainer Basket (optional on ST models)
29 Recovery Tank Shutoff Float
30 Squeegee Storage Hook
31 Recovery Tank Drain Hose
32 Squeegee Tilt Adjustment Knob
33 Seat Prop-Rod
34 Machine Battery Connector
35 Rear Squeegee Blade Removal Latch
36 Hopper (Cylindrical models only)
37 Recovery Hose
38 Solution Solenoid Valve
39 Front Squeegee Blade Removal Thumb Nut
40 Solution Filter
revised 1/10

ENGLISH / A-7
FORM NO. 56041735 - Advenger™- A-7
CONTROL PANEL (ADVENGER MODELS)
A Key Switch
B Solution Increase Switch
C Solution ON/OFF Switch
C1 Solution Flow Indicators (Normal, Heavy & Extreme)
D Solution Decrease Switch
E Detergent ON/OFF Switch
F Display
F1 Hour Meter
F2 Solution Tank Level Indicator
F3 Fault Codes
F4 Detergent Indicator (if so equipped)
F5 Detergent Ratio Indicator
F6 Battery Indicator
F7 Recovery Tank FULL Indicator
F8 Battery Low Indicator
G Scrub Pressure Increase Switch
H Scrub ON/OFF Switch
H1 Scrub Pressure Indicators (Normal, Heavy and Extreme)
I Scrub Pressure Decrease Switch
J EcoFlex Switch
K Horn Switch
L Vacuum/Wand Switch
revised 1/10
!
!
F
F7
F8
A
C
B
C1
D
J
E
G
H
H1
I
K
L
FF1 F2 F3
F4 F5 F6

A-8 / ENGLISH
A-8 - FORM NO. 56041735 - Advenger™
CONTROL PANEL (ST MODELS)
A Key Switch
B Solution Increase Switch
C Solution ON/OFF Switch
C1 Solution Flow Indicators (Normal, Heavy & Extreme)
D Solution Decrease Switch
K Horn
M Battery Indicator
N Fault Indicator
N
B
C
C1
D
A
K
M

ENGLISH / A-9
FORM NO. 56041735 - Advenger™- A-9
BATTERIES
If your machine shipped with batteries installed do the following:
Check that the batteries are connected to the machine (34).
Turn ON the Key Switch (A) and check the Battery Indicator (F6 or M). If the gauge is completely filled or the green light is ON, the batteries are ready for
use. If the gauge is less than full or the green light is OFF, the batteries should be charged before use. See the “Charging The Batteries” section.
IMPORTANT!: IF YOUR MACHINE HAS AN ONBOARD BATTERY CHARGER REFER TO THE OEM PRODUCT MANUAL FOR INSTRUCTIONS
REGARDING SETTING THE CHARGER FOR BATTERY TYPE.
See TSBUS2008-984 for the latest battery charger algorithms.
If your machine shipped without batteries installed do the following:
Consult your Authorized Advance dealer for recommended batteries.
Install the batteries by following the instructions below.
DO NOT install two 12 volt batteries in your machine. This affects the stability of the machine.
IMPORTANT!: IF YOUR MACHINE HAS AN ONBOARD BATTERY CHARGER REFER TO THE OEM PRODUCT MANUAL FOR INSTRUCTIONS
REGARDING SETTING THE CHARGER FOR BATTERY TYPE.
See TSBUS2008-984 for the latest battery charger algorithms.
INSTALL THE BATTERIES
WARNING !
Use extreme caution when working with batteries. Sulfuric acid in batteries can cause severe injury if allowed to contact the skin or
eyes. Explosive hydrogen gas is vented from inside the batteries through openings in the battery caps. This gas can be ignited by
any electrical arc, spark or flame.
When Servicing Batteries...
* Remove all jewelry.
* Do not smoke.
* Wear safety glasses, a rubber apron and rubber gloves.
* Work in a well-ventilated area.
* Do not allow tools to touch more than one battery terminal at a time.
*ALWAYS disconnect the negative (ground) cable first when replacing batteries to prevent
sparks.
*ALWAYS connect the negative cable last when installing batteries.
CAUTION !
Electrical components in this machine can be severely damaged
if the batteries are not installed and connected properly. Batteries
should be installed by Advance or by a qualified electrician.
1 Turn the Key Switch (A) off (O) and remove the key. Then swing open the
Battery Compartment Cover (10) and set the Prop-Rod (33).
2 Using (2) people and an appropriate lifting strap, carefully lift the batteries into
the compartment tray exactly as shown. Refer to decal 56601416 battery
cable layout.
3 See Figure 1. Install battery cables as shown and tighten the nuts on the
battery terminals.
4 Install the battery boots and secure tightly to the battery cables with the
supplied tie straps.
5 Connect the battery pack connector to the machine connector (34) and close
the battery compartment cover.
CAUTION !
Before changing batteries, consult TSBUS2008-984 or call Technical
Service at USA: 800-989-2235 / Canada: 800-668-8400 / Mexico:
[phone] ext.228
FIGURE 1

A-10 / ENGLISH
A-10 - FORM NO. 56041735 - Advenger™
INSTALL THE BRUSHES (DISC SYSTEM)
CAUTION !
Turn the key switch off (O) and remove the key, before changing the brushes, and before opening any access panels.
INSTALL THE BRUSHES (CYLINDRICAL SYSTEM)
CAUTION !
Turn the key switch off (O) and remove the key, before changing the brushes, and before opening any access panels.
1 Make sure the Scrub Deck
is in the RAISED position.
Make sure the Key Switch
(A) is off (O).
2 See Figure 2. Remove
both side skirt assemblies.
NOTE: The skirts are
held in place by two large
Knobs (AA). Loosen these
knobs and slide the Skirt
Assemblies (AB) slightly
forward and then off of the
Scrub Deck.
3 To mount the Brushes (AC)
(or pad holders) align the
Lugs (AD) on the brush with
the holes on the mounting
plate and turn to lock in
place (turn the outside edge
of brush towards the front of
machine as shown (AE)).
FIGURE 2
1 Make sure the Scrub Deck is in the
RAISED position. Make sure the Key
Switch (A) is off (O).
2 See Figure 3. Remove both side
skirt assemblies. NOTE: The skirts
are held in place by two large Knobs
(BA). Loosen these knobs and then
slide the Skirt Assemblies (BB) off of
the Scrub Deck.
3 Loosen the Black Knobs (BC) on
top of the Idler Assemblies (BD) and
remove the assembly
4 Slide the brush into the housing, lift
slightly, push and turn until it seats.
Re-install the Idler Assemblies (BD)
and Skirt Assemblies (BB).
FIGURE 3

ENGLISH / A-11
FORM NO. 56041735 - Advenger™- A-11
INSTALL THE SQUEEGEE
1 See Figure 4. Slide the Squeegee Assembly (11) onto the squeegee mount bracket and tighten the Squeegee Mount Thumb Nuts (AA).
2 Connect the Recovery Hose (AB) to the squeegee inlet.
3 Lower the squeegee, move the machine ahead slightly and adjust the squeegee tilt and height using the Squeegee Tilt Adjust Knob (32) and Squeegee
Height Wheel (AC) so that the rear squeegee blade touches the floor evenly across its entire width and is bent over slightly as shown in the squeegee cross
section.
FIGURE 4
FILL THE SOLUTION TANK
Read the cleaning chemical label and calculate the proper amount of chemical to mix for a tank that holds 28 US gallons (110 liters).
Open the Solution Tank Cover (2), then fill the tank 1/3 full of water, add the cleaning chemical, then fill up the tank the remainder of the way. NOTE: EcoFlex
machines can either be used conventionally with detergent mixed in the tank or the detergent system can be used. When using the detergent dispensing do not
mix detergent in the tank, plain water should be used.
CAUTION!
Use only low-foaming, non-flammable liquid detergents intended for automatic scrubber machine applications. Water temperature
should not exceed 130 degrees Fahrenheit (54.4 degrees Celsius).

A-12 / ENGLISH
A-12 - FORM NO. 56041735 - Advenger™
DETERGENT SYSTEM PREPARATION AND USE (ECOFLEX MODELS ONLY)
COMMON INSTRUCTIONS:
Pressing and releasing the Detergent Switch (E) while the solution system is active will cause the detergent system to alternately turn on and off. The system
should be purged of previous detergent when switching to a different detergent. SERVICE NOTE: Move machine over floor drain before purging because a small
amount of detergent will be dispensed in the process.
To Purge When Changing Chemicals:
1 Disconnect and remove the detergent cartridge.
2 Turn the Key Switch (A) ON. Press and hold the Solution Switch (C) and the Detergent Switch (E) down for 3 seconds. NOTE: Once activated the purge
process takes 20 seconds. See illustration on next page for Detergent System indicators. Normally one purge cycle is adequate to purge the system.
To Purge Weekly:
1 Disconnect and remove the detergent cartridge. Install and connect a Cartridge filled with clean water.
2 Turn the Key Switch (A) ON. Press and hold Solution Switch (C) and the Detergent Switch (E) down for 3 seconds. NOTE: Once activated the purge
process takes 20 seconds. See illustration on next page for Detergent System indicators. Normally one purge cycle is adequate to purge the system.
When the Detergent Cartridge (13) is almost empty a Display Panel (F4) indicator will come on. The “Low Detergent” indicator will remain on until you reset the
system. Once this indicator comes on you should be able to simply pour an entire gallon bottle of detergent into the Cartridge to refill without worrying about
measuring. NOTE: Only reset the system when the cartridge is full. When switching cartridges, the “Low Detergent” indicator is only accurate if the replacement
cartridge is at the same level as the cartridge being replaced.
To Reset:
1 Turn the Key Switch (A) ON. Press and hold the Solution Increase Switch (B) and the Solution Decrease Switch (D) down for 3 seconds. See illustration on
next page for Detergent System indicators.
Detergent Ratio:
1 The detergent ratio is locked at 1:400, except while overriding the EcoFlex cleaning mode. The pre-programmed ratio that is used during EcoFlex override
can be adjusted. With the detergent system OFF, press and hold the Detergent ON/OFF Switch (E) for 2 seconds. The detergent indicator will flash and
each press of the switch will cycle through the available ratios (1:32, 1:50, 1:64, 1:100, 1:128, 1:150, 1:200, 1:256, 1:300, 1:400). Once the desired ratio is
displayed on the screen (F5), stop and it will lock in after 5 seconds.
CARTRIDGE INSTRUCTIONS:
The Detergent Cartridge (13) is located behind the Detergent Cartridge Access Door (12) in the operator’s compartment. Fill the detergent cartridge with a
maximum of 1.25 gallons (4.73 Liters) of detergent. SERVICE NOTE: Remove the detergent cartridge from the detergent box prior to filling to avoid spilling
detergent on the machine.
It is recommended that a separate cartridge be used for each detergent you plan to use. The detergent cartridges have a white decal on them so you can write the
detergent name on each cartridge to avoid mixing them up. When installing a new cartridge, remove the Cap (AA) and place the cartridge in the detergent box.
Install the Dry Break Cap (BB) and detergent hose as shown.
FIGURE 5
revised 1/10

ENGLISH / A-13
FORM NO. 56041735 - Advenger™- A-13
DETERGENT SYSTEM PREPARATION AND USE (ECOFLEX MODELS ONLY)
DETERGENT ENABLED
DETERGENT DISABLED
FULL (RESET)
Press and hold (B) & (D) for 3
seconds to Reset.
LOW DETERGENT
PURGE
Press and hold (C) & (E) for 3
seconds to Purge.
Detergent system is ON when indicator is ON.
revised 1/10

A-14 / ENGLISH
A-14 - FORM NO. 56041735 - Advenger™
OPERATING THE MACHINE
WARNING!
Be sure you understand the operator controls and their functions.
While on ramps or inclines, avoid sudden stops when loaded. Avoid abrupt sharp turns. Use low speed down hills. Clean only while
ascending (driving up) the ramp.
To Scrub...
Follow the instructions in “preparing the machine for use” section of this manual.
1 See Figure 6. While seated on the machine, adjust the steering wheel to a comfortable position using the Steering Wheel Tilt Adjust Knob (23). The seat can be adjusted if
necessary by tipping up the seat and using the adjustment knob (18) (Advenger models) or by loosening the mounting hardware (ST models).
2 Turn the Master Key Switch (A) ON (I). This will display the control panel indicator lights. Reference the Battery Condition Indicator (F6) and Hour Meter (F1) (Advenger models)
or Battery Indicator (M) (ST models) before proceeding.
3 To transport the machine to the work area, apply even pressure with your foot on the front of the Drive Pedal (3) to go forward or the rear of the pedal for reverse. Vary the
pressure on the foot pedal to obtain the desired speed.
4 Press and hold the Solution Switch (C) to pre-wet the floor, solution will be dispensed while the switch is held. NOTE: This will help prevent scarring of the floor surface when
starting to scrub with dry brushes. This must be done prior to pressing the Scrub ON Switch (H) (Advenger models) or lowering the scrub deck using Scrub Deck Raise/Lower
Lever (14) (ST models).
5a Advenger models: Press the Scrub ON/OFF Switch (H), the scrub deck and squeegee will automatically be lowered to the floor. The scrub, vacuum, solution and detergent
(EcoFlex models) systems all start when the Drive Pedal (3) is activated.
The scrub pressure will default to Normal (one scrub pressure indicator lit). Use the Scrub Pressure Increase Switch (G) and Scrub Pressure Decrease Switch (I) to change
between Normal, Heavy and Extreme Scrub modes. The solution flow rate will automatically adjust to coincide with the scrub pressure.
NOTE: The solution flow rate can be changed independently of the scrub pressure by pressing the Solution Increase Switch (B) or Solution Decrease Switch (D). Any
subsequent scrub pressure adjustments will reset the solution flow rate to correspond with the scrub pressure.
NOTE: The scrub, solution, vacuum and detergent (EcoFlex models) systems are automatically enabled when the Scrub ON/OFF Switch (H) is pressed. Any individual system
can be turned OFF or back ON by simply pressing its switch at any time during scrubbing.
NOTE: When operating the machine in reverse the squeegee automatically raises.
5b ST models: Lower the scrub deck using the Scrub Deck Raise/Lower Lever (14), this will activate the solution and scrub systems. Lower the squeegee using the Squeegee
Raise/Lower Lever (22), this will activate the vacuum system. All systems will start when the Drive Pedal (3) is activated.
NOTE: There are two scrub pressure settings. Normal Pressure is achieved by lowering the scrub deck, the pressure on the brushes is caused by the weight of the deck.
Extreme Pressure is achieved by lowering the deck and then pressing down on the Lever (14) and moving it to the notch, this compresses a spring to create additional pressure
on the brushes.
NOTE: The solution flow rate can be changed by pressing the Solution Increase Switch (B) or Solution Decrease Switch (D).
6 Begin scrubbing by driving the machine forward in a straight line at a normal walking speed and overlap each path by 2-3 inches (50-75 mm). Adjust the machine speed and
solution flow when necessary according to the condition of the floor.
CAUTION!
To avoid damaging the floor, keep the machine moving while the brushes are turning.
7 When scrubbing, check behind the machine occasionally to see that all of the waste water is being picked up. If there is water trailing the machine, you may be dispensing too
much solution, the recovery tank may be full, or the squeegee tool may require adjustment.
8 Advenger models only: The machine defaults to the EcoFlex cleaning mode (EcoFlex Switch Indicator is lit GREEN) conserving solution and detergent. Press the EcoFlex
Switch (J) to override the EcoFlex cleaning mode and temporarily increase scrub pressure, solution flow and the detergent ratio. This will cause the indicator to flash yellow for
one minute, solution flow rate will increase to the next level, scrub pressure will increase to the next level and the detergent ratio will increase to the pre-programmed ratio. The
pre-programmed ratio that is used during EcoFlex override can be adjusted. With the detergent system OFF, press and hold the Detergent ON/OFF Switch (E) for 2 seconds.
The detergent indicator will flash and each press of the switch will cycle through the available ratios (1:32, 1:50, 1:64, 1:100, 1:128, 1:150, 1:200, 1:256, 1:300, 1:400).
Once the desired ratio is displayed on the screen (F5), stop and it will lock in after 5 seconds.
9 For extremely dirty floors, a one-pass scrubbing operation may not be satisfactory and a “double-scrub” operation may be required. This operation is the same as a one-pass
scrubbing except on the first pass the squeegee is in the up position (press the Vacuum/Wand Switch (L) to raise the squeegee for Advenger models or lift the Squeegee Raise/
Lower Lever (22) for ST models). This allows the cleaning solution to remain on the floor to work longer. The final pass is made over the same area, with the squeegee lowered
to pick up the accumulated solution.
10a Advenger models: The recovery tank has a shut-off float (29) that causes ALL systems to turn OFF except the drive system when the recovery tank is full. When this float is
activated, the recovery tank must be emptied. The machine will not pick up water or scrub with the float activated.
NOTE: All other indicators vanish and a “Recovery Tank FULL” Indicator (F7) appears on the Display Panel when the float is activated.
10b ST models: The recovery tank has a shut-off float (29) that causes ALL systems to turn OFF except the drive system when the recovery tank is full. When this float is activated,
the recovery tank must be emptied. The machine will not pick up water or scrub with the float activated.
11 When the operator wants to stop scrubbing or the recovery tank is full;
Advenger models: Press the Scrub ON/OFF Switch (H) once. This will automatically stop the scrub brushes and solution flow and the scrub deck will raise up. The squeegee
will raise up after a brief delay and the vacuum will stop after a brief delay (this is to allow any remaining water to be picked up without turning the vacuum back on).
ST models: Use the Scrub Deck Raise/Lower Lever (14) to manually raise the scrub deck, this will stop the scrub motors and the solution flow. Use the Squeegee Raise/Lower
Lever (22) to manually raise the squeegee. The vacuum will stop after a brief delay (this is to allow any remaining water in the squeegee hose to be picked up without turning
the vacuum back on).
12 Drive the machine to a designated waste water “DISPOSAL SITE” and empty the recovery tank. To empty, pull the Drain Hose (31) from its rear storage area, then unscrew the
cap (hold the end of the hose above the water level in the tank to avoid sudden, uncontrolled flow of waste water). Refill the solution tank and continue scrubbing.
NOTE: Make sure the Recovery Tank Cover (26) and the Recovery Tank Drain Hose (31) cap are properly seated or the machine will not pick-up water correctly.
When the batteries require recharging the Battery LOW Indicator (F8) will come on (Advenger models) or the Battery Indicator (M) will flash red (ST models). Then the scrub brushes
and solution flow will stop and the scrub deck will raise up (Advenger models), manually raise the scrub deck on ST models. The squeegee will raise up after a brief delay and the
vacuum will stop after a brief delay (Advenger models), manually raise the squeegee on ST models. Transport the machine to a service area and recharge the batteries according to
the instructions in the Battery section of this manual.
revised 1/10

ENGLISH / A-15
FORM NO. 56041735 - Advenger™- A-15
WET VACUUMING
Steps to follow in fitting the machine with optional attachments for wet vacuuming.
1 Disconnect the Recovery Hose (37) from the Squeegee (11). Connect the coupler and hose from the wand kit to the recovery hose.
2 Attach suitable wet pick-up tools to the hose. (An optional Wand Kit PN56601087 is available from Advance).
3 Turn the Master Key Switch (A) ON and press the Wand Switch (L) (Advenger models) or lower the Squeegee Lever (22) (ST models). NOTE: The operator cannot be in the
seat for the vacuum motor to run on Advenger models. The vacuum motor will run continuously until the switch is pressed again (Advenger models) or the squeegee is raised
(ST models) to turn it OFF. NOTE: The “Recovery Tank FULL” indicator is disabled when the wand mode is activated. The float will stop the flow into the recovery tank.
SERVICE NOTE: Refer to the service manual for detailed functional descriptions of all controls and optional programmability.
FIGURE 6
14
3
18
37
26
29
31
11
!
!
23
22
M
D
C
B
G
H
I
L
A
A
J
D
C
B
F
F7
F8
F1
F5 F6
revised 1/10

A-16 / ENGLISH
A-16 - FORM NO. 56041735 - Advenger™
AFTER USE
1 When finished scrubbing, press the Scrub ON/OFF Switch (H), this will automatically raise, retract and stop all the machine systems (brush, squeegee,
vacuum, solution and detergent (EcoFlex models)) (Advenger models) or manually raise the scrub deck and squeegee. Then drive the machine to a service
area for daily maintenance and review of other needed service up keep.
2 To empty the solution tank;
Advenger models: Remove the Solution Drain Hose (2) from its storage clamp. Direct the hose to a designated “DISPOSAL SITE” and remove the plug.
Rinse the tank with clean water.
ST models: Drive the machine over a designated “DISPOSAL SITE”. Close the Solution Shutoff Valve (21). Remove the Solution Filter (40) and then slowly
open the shutoff valve. Rinse the tank with clean water.
3 To empty the recovery tank, pull the Recovery Tank Drain Hose (31) from its storage area. Direct the hose to a designated “DISPOSAL SITE” and unscrew
the plug (hold the end of the hose above the water level in the tank to avoid sudden, uncontrolled flow of waste water). Rinse the tank with clean water.
4 Remove the brushes or pad holders. Rinse the brushes or pads in warm water and hang up to dry.
5 Remove the squeegee and rinse it with warm water. Open the Recovery tank cover and hang the squeegee from the recovery tank using the Squeegee
Storage Hook (30).
6 Remove the hopper on cylindrical systems and clean thoroughly. Remove from either side of the machine by removing the skirt and tilting the hopper up and
away from housing, then pull out.
7 Check the maintenance schedule below and perform any required maintenance before storage.
MAINTENANCE SCHEDULE
MAINTENANCE ITEM Daily Weekly Monthly Yearly
Charge Batteries X
Check/Clean Tanks & Hoses X
Check/Clean/Rotate the Brushes/Pads X
Check/Clean the Squeegee X
Check/Clean Vacuum Shut-Off Float X
Check/Clean the vacuum motor foam filter(s) X
Empty/Clean Strainer Basket in Recovery Tank X
Clean Hopper on Cylindrical System X
Check Each Battery Cell(s) Water Level X
Inspect Scrub Housing Skirts X
Inspect and clean Solution Filter X
Clean Solution Trough on Cylindrical System X
Purge Detergent System (EcoFlex only) X
Lubrication of Machine X
* Check Carbon Brushes X
* Have Advance check the vacuum motor carbon motor brushes once a year or after 300 operating hours. The brush and drive motor carbon brushes check every
500 hours or once a year.
NOTE: Refer to the Service Manual for more detail on maintenance and service repairs.
8 Store the machine indoors in a clean dry place. Keep from freezing. Leave the tanks open to air them out.
9 Turn the Master Key Switch (A) OFF (O) and remove the key.
LUBRICATING THE MACHINE
Once a month, apply light machine oil to lubricate the:
• Steering Chain
• General Pivot Points For the Squeegee and Scrub Deck Linkage
• Side Skirt Height Adjustment Knobs
• Steering Wheel Shaft Universal joint
• Front Roller Bumper
revised 1/10

ENGLISH / A-17
FORM NO. 56041735 - Advenger™- A-17
CHARGING WET BATTERIES
Charge the batteries each time the machine is used or when the Battery Indicator (F6) is reading less than full or when the Battery Condition Indicator (M) is
flashing RED.
WARNING!
Do not fill the batteries before charging.
Charge batteries in a well-ventilated area.
Do not smoke while servicing the batteries.
When Servicing Batteries...
*Remove all jewelry
*Do not smoke
*Wear safety glasses, rubber gloves and a rubber apron
*Work in a well-ventilated area
*Do not allow tools to touch more than one battery terminal at a time
* ALWAYS disconnect the negative (ground) cable first when replacing batteries to prevent sparks.
* ALWAYS connect the negative cable last when installing batteries.
If your machine shipped with an onboard battery charger do the following:
Turn the Key Switch (A) OFF. Open the Battery Compartment (10) and the Battery Charger Access Door (16) for proper ventilation. Unwind the electrical cord from the side of the
onboard charger and plug it into a properly grounded outlet. Refer to the OEM product manual for more detailed operating instructions.
If your machine shipped without an onboard battery charger do the following:
Open the Battery Compartment (10) and set the Prop-Rod (33). Disconnect the batteries from the machine and push the connector from the charger into the Battery Pack Connector
(34). Follow the instructions on the battery charger. SERVICE NOTE: Make sure you plug the battery charger into the connector that attaches to the batteries.
CAUTION!
To avoid damage to floor surfaces, wipe water and acid from the top of the batteries after charging.
CHECKING THE BATTERY WATER LEVEL
Check the water level of the batteries at least once a week.
After charging the batteries, remove the vent caps and check the water level in each battery cell. Use distilled or demineralized water in a battery filling dispenser
(available at most auto parts stores) to fill each cell to the level indicator (or to 10 mm over the top of the separators). DO NOT over-fill the batteries!
CAUTION!
Acid can spill onto the floor if the batteries are overfilled.
Tighten the vent caps. Wash the tops of the batteries with a solution of baking soda and water (2 tablespoons of baking soda to 1 liter of water).
CHARGING GEL (VRLA) BATTERIES
Charge the batteries each time the machine is used or when the Battery Indicator (F6) is reading less than full (on Advenger models) or when the Battery Condition
Indicator (M) is flashing RED.
WARNING!
Charge batteries in a well-ventilated area.
Do not smoke while servicing the batteries.
When Servicing Batteries...
*Remove all jewelry
*Do not smoke
*Wear safety glasses, rubber gloves and a rubber apron
*Work in a well-ventilated area
*Do not allow tools to touch more than one battery terminal at a time
* ALWAYS disconnect the negative (ground) cable first when replacing batteries to prevent sparks.
* ALWAYS connect the negative cable last when installing batteries.
CAUTION!
Your voltage regulated lead acid (VRLA) battery will deliver superior performance and life ONLY IF IT IS RECHARGED PROPERLY!
Under or overcharging will shorten battery life and limit performance. Be sure to FOLLOW PROPER CHARGING INSTRUCTIONS!
DO NOT ATTEMPT TO OPEN THIS BATTERY! If a VRLA battery is opened, it loses its pressure and the plates become oxygen
contaminated. THE WARRANTY WILL BE VOIDED IF THE BATTERY IS OPENED.
If your machine shipped with an onboard battery charger do the following:
Turn the Key Switch (A) OFF. Open the Battery Compartment (10) and the Battery Charger Access Door (16) for proper ventilation. Unwind the electrical cord from the side of the
onboard charger and plug it into a properly grounded outlet. Refer to the OEM product manual for more detailed operating instructions.
If your machine shipped without an onboard battery charger do the following:
Open the Battery Compartment (10) and set the Prop-Rod (33). Disconnect the batteries from the machine and push the connector from the charger into the Battery Pack Connector
(34). Follow the instructions on the battery charger. SERVICE NOTE: Make sure you plug the battery charger into the connector that attaches to the batteries.
IMPORTANT: Make sure you have an appropriate charger for use on Gel cell batteries. Use only “voltage-regulated” or “voltage-limited” chargers.
Standard constant current or taper current chargers MUST NOT be used. A temperature-sensing charger is recommended, as manual adjustments are
never accurate and will damage any VRLA battery.

A-18 / ENGLISH
A-18 - FORM NO. 56041735 - Advenger™
SQUEEGEE MAINTENANCE
If the squeegee leaves narrow streaks or water, the blades may be dirty or damaged. Remove the squeegee, rinse it under warm water and inspect the blades.
Reverse or replace the blades if they are cut, torn, wavy or worn.
To Reverse or Replace the Rear Squeegee Wiping Blade...
1 See Figure 7. Raise the squeegee tool off the floor, then unsnap the Rear Squeegee Blade Removal Latch (35) on the squeegee tool.
2 Remove the Tension Strap (AA).
3 Slip the rear blade off the alignment pins.
4 The squeegee blade has 4 working edges. Turn the blade so a clean, undamaged edge points toward the front of the machine. Replace the blade if all 4
edges are nicked, torn or worn to a large radius.
5 Install the blade, following the steps in reverse order and adjust the squeegee tilt.
To Reverse or Replace the Front Squeegee Blade...
1 Raise the squeegee tool off the floor, then loosen the (2) Thumb Nuts (AB) on top of the squeegee and remove the squeegee tool from the mount.
2 Loosen the Front Squeegee Blade Removal Thumb Nut (39), then remove Tension Strap (AC) and blade.
3 The squeegee blade has 4 working edges. Turn the blade so a clean, undamaged edge points toward the front of the machine. Replace the blade if all 4
edges are nicked, torn or worn to a large radius.
4 Install the blade, following the steps in reverse order and adjust the squeegee tilt.
SQUEEGEE ADJUSTMENT
There are two squeegee tool adjustments possible, angle and height.
Adjust the squeegee angle whenever a blade is reversed or replaced, or if the squeegee is not wiping the floor dry.
1 Park the machine on a flat, even surface and lower the squeegee. Then drive the machine forward enough to have the squeegee blades fold over to the
rear.
2 Adjust the squeegee tilt and height using the Squeegee Tilt Adjust Knob (32) and Squeegee Height Wheel (AD) so that the rear squeegee blade touches the
floor evenly across its entire width and is bent over slightly as shown in the squeegee cross section.
FIGURE 7

ENGLISH / A-19
FORM NO. 56041735 - Advenger™- A-19
SIDE SKIRT MAINTENANCE
The side skirts’ function is to channel the waste water to the squeegee, helping contain the water within the machine’s cleaning path. During normal use the
blades will wear in time. The operator will notice a small amount of water leaking out underneath the side skirts. A height adjustment can easily be made to lower
the blades so that all the water can be picked up by the squeegee.
To reverse or replace the scrub system side skirt(s)...
1 See Figure 8. Loosen the (2) side skirt Retainer Knobs (15) (2 per side) and pull the Skirt Assemblies (AA) slightly forward (disc only) and then off from the
scrub deck.
2 Remove all the hardware that holds the blades to the skirt housings.
3 Replace the blades as a set if they are nicked, torn or worn beyond their ability to be adjusted.
4 Reinstall the skirt housing assemblies onto the machine and adjust the blade for proper contact to the floor when the brush deck is placed in the scrub
position.
SIDE SKIRT HEIGHT ADJUSTMENT
1 See Figure 8. The side skirt housing knob retainer screw studs have leveling Adjuster Collars (19), that are to be raised or lowered to compensate for blade
wear.
2 To adjust, remove the Skirt Assemblies (AA) from the Scrub Deck (AB) to access the Adjuster Collars (19). Adjustment Tip: The skirts Retainer Knobs (15)
can be loosened with skirts left on and the Adjuster Collars (19) rotated by reaching under the skirt housing.
Turn the Adjuster Collars3 (19) (Up or Down) to where the blades just fold over enough when scrubbing that all the waste water is contained inside the skirting.
Note: Make small adjustments to obtain good blade wiping. Do not lower the blades too much to where they fold over excessively and cause unneeded
blade wear.
FIGURE 8
Disc
Cylindrical
