Advanced Diagnostics AD30 User manual

AD30 Operating Instructions
Detection Area
Detection LED
‘ON’ Switch
Power LED
Audible
Detection
Signal
Step
Result
1 2
+ = Coil OK
ok
And / Or = Fault
ok
Power
Note: Although the detector needs to be as close as possible to the coil ,on certain vehicles
a) The coil will emit a signal when the door is opened.
b) The coil will emit a signal when the ign key is inserted into the ign and not turned on.
c) The ‘OK’ LED will flash at various times and the sound will vary dependant upon car.
Size 78(w) x 117(h) x 24(d)
Weight 135g
Auto Power Off Yes. Approx 2 mins
Power 9v / PP3 Battery
