User Manual
UTC-510/515/520/532/542
10.1”/15.6”/21.5”/32”/42.5”
Ubiquitous Touch Computer

UTC-510/515/520/532/542 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2020
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to improve the products described in this manual at any time without notice. No part
of this manual may be reproduced, copied, translated, or transmitted in any form or
by any means without the prior written permission of Advantech Co., Ltd. The infor-
mation provided in this manual is intended to be accurate and reliable. However,
Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringements
of the rights of third parties that may result from its use.
Acknowledgements
Award is a trademark of Award Software International, Inc.
AMD is a trademark of Advanced Micro Devices.
Corning Gorilla is a trademark of Corning Inc.
Intel, Atom, Celeron, and Core are trademarks of Intel Corp.
IBM, PC/AT, PS/2 and VGA are trademarks of International Business Machines Cor-
poration.
Microsoft Windows is a registered trademark of Microsoft Corp.
RTL is a trademark of Realtek Semiconductor Co., Ltd.
All other product names or trademarks are properties of their respective owners.
For more information about this or other Advantech products, please visit our website at
http://www.advantech.com
For technical support and service, please visit our support website at
http://support.advantech.com
This manual is applicable for UTC-510/515/520/532/542.
Part No. 2008050014 Edition 5
Printed in Taiwan April 2020

iii UTC-510/515/520/532/542 User Manual
Declaration of Conformity
FCC Class A
Packing List
Before installing the UTC system, check that the following materials have been
included in the shipment:
UTC-510/515/520/532/542 unit
Accessories for UTC-510/515/520
–DC 12V/5A 60W adaptor (UTC-515, UTC-520 A, B SKU)
–DC 12V/3A 36W adaptor (UTC-510)
–DC 12V/7A 84W adaptor (UTC-520 C/D/E SKU)
–SATA cable (not applicable for UTC-510)
–Packet of screws (not applicable for UTC-510)
Accessories for UTC-532
–SATA cable
–Packet of screws
–Antenna
If any of these items are missing or damaged, contact your distributor or sales repre-
sentative immediately.
Note! This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These lim-
its are designed to provide reasonable protection against harmful inter-
ference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harm-
ful interference, in such cases users will be required to correct the inter-
ference at their own expense.
Warning! Any modifications to this device that are not approved by the relevant
standards authority may void the authority granted to the user by the
FCC to operate this equipment.

UTC-510/515/520/532/542 User Manual iv
Technical Support and Assistance
1. Visit the Advantech website at http://support.advantech.com to obtain the latest
product information.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before calling:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages
Warnings
Contact information
Manufacturer
Advantech Co., Ltd.
No.1, Alley 20, Lane 26, Rueiguang Road Neihu District, Taipei, Taiwan 114, R.O.C.
TEL: [phone]
EU Distributor
Advantech Europe GmbH Kolberger Straße 7 D-40599 Düsseldorf, Germany
Tel: [phone]
Fax: [phone]
Warning! Batteries are at risk of exploding if incorrectly installed. Replace only
with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer's instructions.
Warning!  Input voltage rated 12V/3A (UTC-510)
 Input voltage rated 12V/5A (UTC-515/520A/B/D)
 Input voltage rated 12V/7A (UTC-520 C/D/E SKU)
 Input voltage rated 100 ~ 240 VAC 50/60 Hz for UTC-532/542
 Use a 3V/195mA lithium battery
 Packing: The unit should be carried with both hands and handled
with care.
 Maintenance: Use only approved products or a dry applicator to
clean and maintain the surfaces.
 CompactFlash: Turn off the system power before inserting or
removing the CompactFlash storage card.

v UTC-510/515/520/532/542 User Manual
Safety Instructions
1. Read these safety instructions carefully.
2. Retain this user manual for future reference.
3. Disconnect the equipment from all AC outlets before cleaning. Use only a damp
cloth for cleaning. Do not use liquid or spray detergents.
4. For pluggable equipment, the power outlet socket must be located near the
equipment and easily accessible.
5. Protect the equipment from humidity.
6. Place the equipment on a reliable surface during installation. Dropping or letting
the equipment fall may cause damage.
7. The openings of the enclosure are for air convection. Protect the equipment
from overheating. Do not cover the openings.
8. Ensure that the voltage is correct before connecting the equipment to a power
outlet.
9. Position the power cord away from high-traffic areas. Do not place anything over
the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If unused for a long time, disconnect the equipment from the power source to
avoid damage from transient overvoltage.
12. Never pour liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following occurs, have the equipment checked by authorized ser-
vice personnel:
The power cord or plug is damaged.
Liquid has penetrated the equipment.
The equipment has been exposed to moisture.
The equipment is malfunctioning or does not operate according to the user
manual.
The equipment has been dropped and damaged.
The equipment shows obvious signs of breakage.
15. Do not store the equipment in an environment with a room temperature of below
-20 °C (-4 °F) or above 60 °C (140 °F) as this may cause damage. The equip-
ment should be stored in a controlled environment.
16. Batteries are at risk of exploding if incorrectly installed. Replace only with the
same or equivalent type as recommended by the manufacturer. Discard used
batteries according to the manufacturer’s instructions.
17. Use only the recommended mounting apparatus to avoid damage caused by
falling.
18. In accordance with the IEC 704-1:1982 specifications, the sound pressure level
at the operator position does not exceed 70 dB (A).
DISCLAIMER: These instructions are provided according to IEC 704-1 standards.
Advantech disclaims all responsibility for the accuracy of any statements contained
herein.

UTC-510/515/520/532/542 User Manual vi
Warning! Because of the risk of electric shock, do not remove the equipment
cover during operation or when connected to a power outlet.
Caution! To avoid short circuits and otherwise damaging the device, do not allow
fluids to come in contact with the device. If fluids are accidentally spilled
on the equipment, remove the affected unit from service as soon as pos-
sible and contact service personnel to verify that personal safety is not
compromised. If the computer clock is unable to maintain accurate time
or the BIOS configuration resets to default settings, check the battery.
Caution! Do not replace the battery yourself. Contact a qualified technician or
your retailer. The computer is equipped with a battery-powered real-time
clock circuit. There is a danger of explosion if the battery is incorrectly
replaced. Replace only with same or equivalent type as recommended
by the manufacturer. Discard used batteries according to the manufac-
turer’s instructions.

vii UTC-510/515/520/532/542 User Manual
Contents
Chapter 1 General Information ............................1
1.1 Introduction ............................................................................................... 2
1.2 Specifications ............................................................................................ 2
1.2.1 UTC-510 ....................................................................................... 2
1.2.2 UTC-510(PoE) .............................................................................. 4
1.2.3 UTC-515 A/B/C ............................................................................. 5
1.2.4 UTC-515D/E/F .............................................................................. 6
1.2.5 UTC-515G..................................................................................... 8
1.2.6 UTC-520A/B/C .............................................................................. 9
1.2.7 UTC-520D/E/F ............................................................................ 10
1.2.8 UTC-520G................................................................................... 12
1.2.9 UTC-532A/C ............................................................................... 13
1.2.10 UTC-532E/F/G ............................................................................ 14
1.2.11 UTC-542D/F/G............................................................................ 16
1.3 Dimensions ............................................................................................. 17
1.3.1 UTC-510 ..................................................................................... 17
1.3.2 UTC-515 ..................................................................................... 18
1.3.3 UTC-520 ..................................................................................... 19
1.3.4 UTC-532 ..................................................................................... 20
1.3.5 UTC-542 .................................................................................... 21
Chapter 2 System Setup.....................................23
2.1 Quick Tour............................................................................................... 24
2.1.1 Front View................................................................................... 24
2.1.2 Rear View ................................................................................... 25
2.1.3 Side View .................................................................................... 25
2.2 I/O Ports .................................................................................................. 26
2.2.1 UTC-510 ..................................................................................... 26
2.2.2 UTC-510(PoE) ............................................................................ 26
2.2.3 UTC-515 ..................................................................................... 27
2.2.4 UTC-520 ..................................................................................... 27
2.2.5 UTC-532 ..................................................................................... 28
2.2.6 UTC-542 ..................................................................................... 28
2.3 Setup Procedures ................................................................................... 29
2.3.1 System Power On ....................................................................... 29
2.3.2 BIOS Setup ................................................................................. 29
2.3.3 System Software Installation....................................................... 29
2.3.4 Driver Installation ........................................................................ 29
Chapter 3 Upgrades and Installation.................31
3.1 Introduction ............................................................................................. 32
3.2 Installing a 2.5” SATA HDD..................................................................... 32
3.3 Installing a CFAST Card (A/B Models Only) ........................................... 33
3.4 Installing a Memory Module .................................................................... 33
3.5 Installing a Wireless LAN Card (Optional)............................................... 34
3.6 Installing Peripherals (Optional) .............................................................. 35
3.6.1 UTC-510/510(PoE) ..................................................................... 35
3.6.2 UTC-515/520/532 ....................................................................... 36
3.7 Panel Mount Installation for UTC-510 ..................................................... 36
3.8 Installing a DRAM Module for UTC-510.................................................. 37
3.8.1 UTC-510 ..................................................................................... 37

UTC-510/515/520/532/542 User Manual viii
3.8.2 UTC-510(PoE) ............................................................................ 37
3.9 Installing an SSD Module for UTC-510................................................... 38
3.9.1 UTC-510 ..................................................................................... 38
3.9.2 UTC-510(PoE) ............................................................................ 38
3.10 Installing an mSATA SSD Module for UTC-510 .................................... 39
3.10.1 UTC-510 .................................................................................... 39
3.10.2 UTC-510(PoE) ........................................................................... 39
3.11 Installing a Wi-Fi Module for UTC-510................................................... 40
3.11.1 UTC-510 .................................................................................... 40
3.11.2 UTC-510(PoE) ........................................................................... 40
Appendix A Installation Accessories................... 41
A.1 Introduction ............................................................................................. 42
A.2 Wall Mount .............................................................................................. 43
A.3 Floor Stand ............................................................................................. 45
Appendix B UTC Peripherals ................................ 47
B.1 UTC-P01 (Camera Module) .................................................................... 48
B.1.1 Specifications.............................................................................. 48
B.1.2 Packing List ................................................................................ 48
B.1.3 Ordering Information................................................................... 48
B.2 UTC-P02 (MSR)...................................................................................... 49
B.2.1 Specifications.............................................................................. 49
B.2.2 Packing List ................................................................................ 49
B.2.3 Ordering Information................................................................... 49
B.3 UTC-P03 (RFID Reader) ........................................................................ 50
B.3.1 Specifications.............................................................................. 50
B.3.2 Packing List ................................................................................ 50
B.3.3 Ordering Information................................................................... 51
B.4 UTC-P06 (Smart Card Reader) .............................................................. 52
B.4.1 Specifications.............................................................................. 52
B.4.2 Packing List ................................................................................ 52
B.4.3 Ordering Information................................................................... 52
B.5 UTC-P07 (Barcode Reader) ................................................................... 53
B.5.1 Specifications.............................................................................. 53
B.5.2 Packing List ................................................................................ 54
B.5.3 Ordering Information................................................................... 54
B.6 UTC-P21 (4-in-1 Module)........................................................................ 55
B.6.1 Specifications.............................................................................. 55
B.6.2 Packing List ................................................................................ 55
B.6.3 Ordering Information................................................................... 55
B.7 UTC-510P-R01E..................................................................................... 56
B.7.1 Packing List ................................................................................ 56
B.7.2 Ordering Information................................................................... 57
B.8 UTC-510P-S01E ..................................................................................... 58
B.8.1 Packing List ................................................................................ 58
B.8.2 Ordering Information................................................................... 58
B.9 UTC-510P-B ........................................................................................... 59
B.9.1 Packing List ................................................................................ 60
B.9.2 Ordering Information................................................................... 60
B.10 UTC-510P-M01E ................................................................................... 61
B.10.1 Packing List ................................................................................ 61
B.10.2 Ordering Information................................................................... 61
Appendix C Touchscreen Options ....................... 63

ix UTC-510/515/520/532/542 User Manual
C.1 Touchscreen Options .............................................................................. 64

UTC-510/515/520/532/542 User Manual x

Chapter 1
1General Information

UTC-510/515/520/532/542 User Manual 2
1.1 Introduction
Advantech’s UTC-500 series products are 10.1”, 15.6”, 21.5”, 32”, and 42.5” fanless,
low-power, all-in-one touch panel computers suitable for use as control room comput-
ing devices, production line industrial digital signage, showroom interactive signage,
self-service kiosks, and public service terminals that support diverse digital retail,
hospitality, healthcare, education, entertainment, and information processing applica-
tions. Featuring a protective enclosure, advanced touchscreen technology, wireless
capabilities, and multiple I/O, the high-performance UTC-500 series devices can also
be integrated with a wide range of optional peripherals and accessories according to
specific application requirements.
1.2 Specifications
1.2.1 UTC-510
System
CPU
Intel® Atom™
E3825
(UTC-510D)
Intel® Celeron®
J1900
(UTC-510D)
Intel® Celeron®
N3350
(UTC-510G)
Intel® Pen-
tium® N4200
(UTC-510G)
Base Fre-
quency
1.33 GHz (dual-
core)
2 GHz (quad-
core)
1.10 GHz (dual-
core)
1.10 GHz (dual-
core)
Cache L2 cache 1 MB L2 cache 2 MB L2 cache 2 MB L2 cache 2 MB
Memory
1 x 204-pin
SODIMM DDR3L
1066 MHz, up to 8
GB
1 x 204-pin
SODIMM
DDR3L
1333 MHz, up to
8 GB
1 x 204-pin SODIMM DDR3L 1866
MHz, up to 8 GB
HDD 1 x 2.5 internal SATA HDD bay
Network (LAN) 1 x Gigabit Ethernet port (with Wake-on-LAN support)
I/O
2 x RS-232 COM (COM1 RS-422/
485 supported)
1 x USB 2.0/1 x USB 3.0/2 x USB
2.0 (optional)
1 x Gigabit Ethernet (RJ-45)
1 x VGA
1 x Audio Line-Out, 1 x Mic-In
2 x RS-232 COM (COM1 RS-422/
485 supported)
2 x USB 3.0/2 x USB 2.0 (optional)
1 x Gigabit Ethernet (RJ-45)
1 x VGA
1 x Audio Line-Out, 1 x Mic-In
Stereo
Speaker 1 x 2W
Bus Expansion 1 x Half-size mini PCIe
1 x Half-size mSATA
1 x Full-size mini PCIe
1 x Half-size mSATA
Mount Options VESA 75 x 75 mm
Dimensions
(W x H x D) 265.4 x 182.4 x 39.55 mm (10.44 x 7.18 x 1.55 in)
Weight 1.80 kg (3.97 lb)
OS Support
WES7P 32/64bit
WES7E 32 bit
Windows Pro Embedded 7 Pro 32/
64 bit
WE8S 32 bit
Windows Embedded 8.1 Industry
Pro 64 bit
Windows 10 IoT Enterprise 64 bit
Linux Ubuntu 16.04
Android 4.4
Windows 10 IoT Enterprise
Linux Ubuntu 16.04
Android 6.0

3 UTC-510/515/520/532/542 User Manual
Chapter 1 General Information
Environ-
mental
Front Panel
Protection IP65 compliant
Operating
Temperature
0 ~ 40 °C (32 ~
104 °F)
0 ~ 35 °C (32 ~
95 °F) 0 ~ 45° C (32 ~ 113° F)
Relative
Humidity 10 ~ 95% @ 40 °C non-condensing
Vibration 1 Grms
Shock 5G peak acceleration (11 msec. duration)
Certification CE, FCC, CB, UL, CCC, BSMI
Power
Supply
Input Rating 12 V/3 A (36W ITE adapter)
Power
Consumption
Typical 10W
Max. 20W
LCD Panel
Size/Type 10.1” TFT LCD with LED backlight
Max. Resolu-
tion 1280 x 800
Max. Color 16.7M
Pixel Pitch 169.5 x 169.5 um
Brightness 350 cd/m2
Viewing Angle 170°/170°
Camera 5 megapixel (optional)
Touch-
screen
(PE/GE)
Type Glass panel with projected capacitive touch
Light
Transmission 80% ± 5% / 90%
Controller USB interface

UTC-510/515/520/532/542 User Manual 4
1.2.2 UTC-510(PoE)
System
CPU Intel® Celeron® N2807
(UTC-510D)
Intel® Celeron® J1900
(UTC-510D)
Base Frequency 1.58 GHz (dual-core) 2 GHz (quad-core)
Cache L2 cache 1 MB L2 cache 2 MB
Memory 1 x SODIMM DDR3L 1333 MHz,
up to 8 GB
1 x SODIMM DDR3L 1333
MHz, up to 8 GB
HDD 1 x 2.5 internal SATA HDD bay
Network (LAN) 2 x Gigabit Ethernet ports (with Wake-on-LAN support)
I/O
2 x RS-232 COM
(COM2 support for RS-422/485 optional)
3 x USB 2.0/1 x USB 3.0/1 x USB 2.0 (optional)
2 x Gigabit Ethernet ports (1 with PoE)
1 x Headphone with mic
Stereo Speaker 2 x 2W
Bus Expansion 1 Full-size mini PCIe/mSATA
1 Half-size mini PCIe
Mount Options VESA 75 x 75 mm
Dimensions
(W x H x D) 265.4 x 182.4 x 39.55 mm (10.44 x 7.18 x 1.55 in)
Weight 1.80 kg (3.97 lb)
OS Support Windows Embedded 7/8, Windows 10 IoT Enterprise, Linux Ubuntu 14.04, Android
4.4.2
Environmental
Operating
Temperature 0 ~ 45 °C (32 ~ 113 °F) 0 ~ 40 °C (32 ~ 104 °F)
Relative
Humidity 10 ~ 95% @ 40 °C non-condensing
Vibration 1 Grms
Shock 5G peak acceleration (11 msec. duration)
Certification CE, FCC, CB, UL, CCC, BSMI
Front Panel
Protection IP65 compliant
Power Supply
Power over Ether-
net IEEE 802.3at/30W
Input Rating 12 V/3 A ~ 24 V/1.5 A, 36W ITE adapter (optional)
Power
Consumption
Typical 10W
Max. 20W
LCD Panel
Size/Type 10.1” TFT LCD with LED backlight
Max. Resolution 1280 x 800
Max. Color 16.7M
Pixel Pitch 169.5 x 169.5 um
Brightness 350 cd/m2
Viewing Angle 170°/170°
Camera 5 megapixel (optional)
Touchscreen
(PE/GE)
Type Glass panel with projected capacitive touch
Light
Transmission 80% ± 5% / 90%
Controller USB interface

5 UTC-510/515/520/532/542 User Manual
Chapter 1 General Information
1.2.3 UTC-515 A/B/C
System
CPU
AMD® G-Series
T40E dual-core 1.0
GHZ (UTC-515A)
Intel® Atom™
D2550 dual-core 1.8
GHz (UTC-515B)
Intel® Core™ i3-
3217UE 1.6 GHz
(UTC-515C)
Can be equipped with
Intel® Core™ i7-
3517UE 1.7 GHz
upon request
Chipset T40E + A50M
Intel ® Atom™
D2550 + Intel ®
NM10
Intel® QM77
Cache L2 cache 512 KB L2 cache 1 MB L2 cache 1 MB
(L3 cache 3 MB)
Memory
1 x SODIMM DDR3
1066 MHz, up to 4
GB
1 x SODIMM DDR3
1066 MHz, up to 4
GB
1 x SODIMM DDR3/
DDR3L 1333/1600
MHz, up to 8 GB
HDD 1 x 2.5 internal SATA HDD bay
Network (LAN) 2 x Gigabit Ethernet ports (with Wake-on-LAN support)
I/O
3 x RS-232 COM
(RS-422/485
optional)
4 x USB 2.0
2 x Gigabit Ethernet
(RJ-45)
1 x VGA/HDMI
1 x Audio Line-Out
1 x Mic-In
3 x RS-232 COM
(RS-422/485
optional)
4 x USB 2.0
2 x Gigabit Ethernet
(RJ-45)
1 x VGA/HDMI
1 x Audio Line-Out
1 x Mic-In
2 x RS-232 COM (RS-
422/485 optional)
2 x USB 2.0, 2 x USB
3.0
2 x Gigabit Ethernet
(RJ-45)
1 x VGA/HDMI
1 x Audio Line-Out
1 x Mic-In
Stereo
Speaker 2 x 1W
Bus
Expansion 1 x Full-size mini PCIe/mSATA
Mount Options VESA 100 x 100 mm
Dimensions
(W x H x D) 389.81 x 240.12 x 45.20 mm (15.34 x 9.45 x 1.77 in)
Weight 4.85 kg (10.67 Ib)
OS Support
Windows XP/XPE,
Windows Embedded
7/8
Windows Embed-
ded 7 (32 bit)
Windows Embedded
7/8, Windows 10 IoT
Enterprise
Environmental
Operating
Temperature 0 ~ 40 °C (32 ~ 104 °F)
Relative
Humidity 10 ~ 95% @ 40 °C non-condensing
Vibration 0.5 Grms
Shock 5G peak acceleration (11 msec. duration)
EMC/Safety CE, FCC, CB, UL, CCC, BSMI
Front Panel
Protection IP65/NEMA4 compliant
Power Supply
Input Rating 12 V/5 A (60W ITE adapter) 12 V/5 A (60W ITE
adapter)
Power
Consumption
Typical 32W
Max. 40W
Typical 40W
Max. 50W

UTC-510/515/520/532/542 User Manual 6
1.2.4 UTC-515D/E/F
LCD Panel
Size/Type 15.6” TFT LCD with LED backlight
Max.
Resolution 1366 x 768 (FHD 1920 x 1080 optional)
Max. Color 16.7M
Pixel Pitch 252 x 252 um
Brightness 400 cd/m2
Viewing Angle 170°/160°
Touchscreen
(PE/RE/GE)
Type Glass panel with projected capacitive/5-wire analog resistive touch
Light
Transmission 90% ± 2% / 80% ± 5% / 90%
Controller USB interface
System
CPU Intel® Celeron®
J1900 (UTC-515D)
Intel® Core™ i5-
4300U (UTC-515E)
Can be equipped with
Intel® Core™ i3-
4010U/Celeron®
2980U upon request
Intel® Core™ i3-
6100U (UTC-515F)
Base
Frequency 2 GHz (quad-core) 1.9 GHz (dual-core) 2.3 GHz (dual-core)
Cache L2 cache 2 MB L3 cache 3 MB L3 cache 3 MB
Memory
1 x SODIMM DDR3L
1333 MHz, up to 8
GB
1 x SODIMM DDR3L
1333/1600 MHz, up to
8 GB
1 x SODIMM DDR3L
1333 MHz, up to 16
GB
HDD 1 x 2.5 internal SATA HDD bay
Network (LAN) 2 x Gigabit Ethernet ports (with Wake-on-LAN support)
I/O
2 x RS-232 COM
(RS-422/485
optional)
3 x USB 2.0/1 x USB
3.0
2 x Gigabit Ethernet
(RJ-45)
1 x VGA/HDMI
1 x Audio Line-Out
1 x Mic-In
2 x RS-232 COM (RS-
422/485 optional)
2 x USB 2.0/2 x USB
3.0
2 x Gigabit Ethernet
(RJ-45)
1 x VGA/HDMI
1 x Audio Line-Out
1 x Mic-In
2 x RS-232 COM (RS-
422/485 optional)
2 x USB 2.0/2 x USB
3.0
2 x Gigabit Ethernet
(RJ-45)
1 x VGA/HDMI
1 x Audio Line-Out
1 x Mic-In
Stereo
Speaker 2 x 1W
Bus
Expansion 1 x Full-size mini PCIe/mSATA
Mount Options VESA 100 x 100 mm
Dimensions
(W x H x D) 389.81 x 240.12 x 45.20 mm (15.34 x 9.45 x 1.77 in)
Weight 4.85 kg (10.67 Ib)
OS Support
Windows Embedded
7/8, Windows 10 IoT
Enterprise, Linux
Ubuntu 14.04,
Android 4.4.2
Windows Embedded 7/8, Windows 10 IoT
Enterprise

7 UTC-510/515/520/532/542 User Manual
Chapter 1 General Information
Environmental
Operating
Temperature 0 ~ 40 °C (32 ~ 104 °F)
Relative
Humidity 10 ~ 95% @ 40 °C non-condensing
Vibration 0.5 Grms
Shock 5G peak acceleration (11 msec. duration)
Certification CE, FCC, CB, UL, CCC, BSMI
Front Panel
Protection IP65/NEMA4 compliant
Power Supply
Input Rating 12 V/5 A (60W ITE
adapter)
12 V/5 A (60W ITE
adapter)
12 V/5 A (60W ITE
adapter)
Power
Consumption
Typical 35W
Max. 40W
Typical 40W
Max. 50W
Typical 35W
Max. 40W
LCD Panel
Size/Type 15.6” TFT LCD with LED backlight
Max.
Resolution 1366 x 768 (FHD 1920 x 1080 optional)
Max. Color 16.7M
Pixel Pitch 252 x 252 um
Brightness 400 cd/m2
Viewing Angle 170°/160°
Touchscreen
(PE/RE/GE)
Type Glass panel with projected capacitive/5-wire analog resistive touch
Light
Transmission 90% ± 2% / 80% ± 5% / 90%
Controller USB interface

UTC-510/515/520/532/542 User Manual 8
1.2.5 UTC-515G
System
CPU Intel® Pentium® N4200 (UTC-515G)
Intel® Atom® E3950 (available upon request)
Base Frequency 1.1 GHz (N4200/quad-core)
1.6 GHz (E3950/quad-core)
Cache L2 cache 2 MB
Memory 1 x 204 pin SODIMM DDR3L 1867 MHz, up to 8 GB
HDD 1 x 2.5 internal SATA HDD bay
Network (LAN) 2 x Gigabit Ethernet ports (with Wake-on-LAN support)
I/O
2 x RS-232 COM (RS-422/485)*
2 x USB 2.0 / 2 x USB 3.0
2 x Gigabit Ethernet (RJ-45)
1 x VGA
1 x HDMI
1 x Audio Line-Out
1 x Mic-In
Stereo Speaker 2 x 1W
Bus Expansion 1 x Full-size mini PCIe/M.2
Mount Options VESA 100 x 100 mm
Dimensions
(W x H x D) 389.81 x 240.12 x 45.20 mm (15.34 x 9.45 x 1.77 in)
Weight 4.85 kg (10.67 Ib)
OS Support
Windows 10 IoT Enterprise
Android 6.0
Linux Ubuntu 17.04
Environmental
Operating
Temperature 0 ~ 40 °C (32 ~ 104 °F)
Relative
Humidity 10 ~ 95% @ 40 °C non-condensing
Vibration 0.5G
Shock 5G peak acceleration (11 msec. duration)
Certification CE, FCC, CB, UL, CCC, BSMI
Front Panel
Protection IP65/NEMA4 Compliant
Power Supply
Input Rating 12 V/5 A (60 W ITE adapter)
Power
Consumption
Typical 35W
Max. 40W
LCD Panel
Size/Type 15.6” TFT LCD with LED backlight
Max. Resolution 1366 x 768 (FHD 1920 x 1080 optional)
Max. Color 16.7M
Pixel Pitch 252 x 252 um
Brightness 400 cd/m2
Viewing Angle 170°/160°
Camera 5 megapixel (optional)
Touchscreen
(PE/RE/GE)
Type Glass panel with projected capacitive/5-wire analog resistive
touch
Light
Transmission 90% ± 2%/80% ± 5%/90%
Controller USB interface

9 UTC-510/515/520/532/542 User Manual
Chapter 1 General Information
1.2.6 UTC-520A/B/C
System
CPU
AMD® G-Series T40E
dual-core 1.0 GHz
(UTC-520A)
Intel® Atom™ D2550
dual-core 1.8 GHz
(UTC-520B)
Intel® Core™ i7
3517UE 1.7 GHz
(UTC-520C)
Chipset T40E + A50M Intel® Atom™ D2550
+ Intel® NM10 Intel® QM77
Cache L2 cache 512 KB L2 cache 1 MB L2 cache 1 MB (L3
cache 4 MB)
Memory 1 x SODIMM DDR3
1066 MHz, up to 4 GB
1 x SODIMM DDR3
1066 MHz, up to 4 GB
1 x SODIMM DDR3/
DDR3L 1333/1600
MHz, up to 8 GB
SSD 1 x CFast
HDD 1 x 2.5 internal SATA HDD bay
Network (LAN) 2 x Gigabit Ethernet ports
I/O
3 x RS-232 COM (RS-
422/485 optional)
4 x USB 2.0
2 x Gigabit
Ethernet (RJ-45)
1 x VGA/HDMI
1 x Audio Line-Out
1 x Mic-In
3 x RS-232 COM (RS-
422/485 optional)
4 x USB 2.0
2 x Gigabit
Ethernet (RJ-45)
1 x VGA/HDMI
1 x Audio Line-Out
1 x Mic-In
2 x RS-232 COM
(RS-422/485
optional)
2 x USB 2.0, 2 x
USB 3.0
2 x Gigabit Ethernet
(RJ-45)
1 x VGA/HDMI
1 x Audio Line-Out
1 x Mic-In
Stereo
Speaker 2 x 3W
Bus
Expansion 1 x Full-size mini PCIe/mSATA
Dimensions
(W x H x D) 517.64 x 313.51 x 43.50 mm (20.38 x 12.34 x 1.71 in)
Weight 8 kg (17.6 lb)
OS Support
Windows XP/ XPE/
Windows Embedded
7/8
Windows Embedded
7 (32 bit)
Windows Embed-
ded 7/8, Windows
10 IoT Enterprise
Environmental
Operating
Temperature 0 ~ 40 °C (32 ~ 104 °F)
Relative
Humidity 10 ~ 95% @ 40 °C non-condensing
Vibration 0.5 Grms
Shock 5 G peak acceleration (11 msec. duration)
EMC CE, FCC, UL, CB, CCC, BSMI
Front Panel
Protection IP65/NEMA4 compliant
Power
Input Rating 12 V/5 A
(60W ITE adapter)
12 V/7 A
(84W ITE adapter)
Power
Consumption
Typical 32W
Max. 40W
Typical 45W
Max. 65W

UTC-510/515/520/532/542 User Manual 10
1.2.7 UTC-520D/E/F
LCD Panel
Size/Type 21.5” TFT LCD with LED backlight
Max.
Resolution 1920 x 1080
Max. Color 16.7 M
Pixel Pitch 248.25 x 248.25 um
Brightness 250 cd/m2 (400 cd/m2 optional)
Viewing Angle 178°/178°
Touchscreen
(PE/RE/GE)
Type Glass panel with projected capacitive/5-wire analog resistive touch
Light
Transmission 90% ± 2% / 80%± 5% / 90%
Controller USB interface
System
CPU
Intel® Celeron®
J1900
(UTC-520D)
Intel® Core™ i5-
4300U
(UTC-520E)
Can be equipped with
Intel® Core™ i3-
4010U/Celeron®
2980U upon request
Intel® Core™ i5-
6300U
(UTC-520F)
Base
Frequency 2 GHz (quad-core) 1.9 GHz (dual-core) 2.6GHz (dual-core)
Cache L2 cache 2 MB L3 cache 3 MB L3 cache 4 MB
Memory
1 x SODIMM DDR3L
1333 MHz, up to 8
GB
1 x SODIMM DDR3L
1333/1600 MHz, up to
8 GB
2 x SODIMM DDR3L
1600 MHz,
up to 16 GB
HDD
1 x 2.5 internal SATA
HDD bay
1 x 2.5 internal SATA
HDD bay
1 x 2.5 internal SATA
HDD bay
Network (LAN) 2 x Gigabit Ethernet ports (with Wake-on-
LAN support)
2 x Gigabit Ethernet
ports (with Wake-on-
LAN support)
I/O
2 x RS-232 COM
(RS-422/485
optional)
3 x USB 2.0/1 x USB
3.0
2 x Gigabit Ethernet
(RJ-45)
1 x VGA/HDMI
1 x Audio Line-Out
1 x Mic-In
2 x RS-232 COM
(RS-422/485 optional)
2 x USB 2.0/USB 3.0
2 x Gigabit Ethernet
(RJ-45)
1 x VGA/HDMI
1 x Audio Line-Out
1 x Mic-In
2 x RS-232 COM
(RS-422/485
optional)
3 x USB 2.0/2 x USB
3.0
2 x Gigabit Ethernet
(RJ-45)
1 x VGA/HDMI
1 x Audio Line-Out
1 x Mic-In
Stereo
Speaker 2 x 3W
Bus
Expansion 1 x Full-size mini PCIe/mSATA
Mount Options VESA 100 x 100 mm
Dimensions
(W x H x D) 517.64 x 313.51 x 43.50 mm (20.37 x 12.34 x 1.71 in)
Weight 8 kg (17.6 lb)
