Advantech AIMB-308 Installation and operation manual

AIMB-308 Startup Manual 1
AIMB-308 Proprietary Motherboard
with 12th Gen Intel
®
Core
TM
i CPU Socket (LGA 1700)
Startup Manual
Specications
Packing List
For more information on this and other Advantech prod-
ucts, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our sup-
port website at:
https://www.advantech.com/support
This manual is for the AIMB-308 series Rev.A1.
Part No. 2041030800 1st Edition
Printed in China July 2022
Standard Functions
• CPU: LGA 1700 12th Gen Intel ® Core™ i9/i7/i5/i3/Cel-
eron/Pentium
• BIOS: AMI 256Mbit SPI BIOS
• Chipset: Intel®H610E PCH
• System Memory: Dual DDR4 3200 MHz, 32GB per 288-
pin slot without ECC function. Max. capacity to be 64GB
• SATA interface: Three on-board Serial ATA 3.0 connec-
tors support data transmission rates up to 600 MB/s.
All three SATA 3.0 support Advanced Host Controller
Interface (AHCI) technology
• PCIe slot: One PCIe x16 and one PCIe x4 expansion slot
• USB 3.2/2.0: Dual USB 3.2 Gen1 and dual 2.0 on both
rear and front side
Graphic Interface
• Chipset: CPU integrated graphics controller
• Display port: Resolution up to 4096x2304 @60Hz
refresh rate
• HDMI: Resolution up to 4096x2160 @30Hz refresh rate
Ethernet Interface
• Interface: 10/100/1000 Mbps
• Controller: (LAN1) Intel®I219-V; (LAN2) Intel®I226-V
Mechanical and Environmental Specs.
• Dimensions (L x W): 290.2 x 207.5 mm
• Power supply Voltage: +12V, +5Vsb
• Operating temperature: 0 ~ 40 °C (32 ~ 105 °F)
• Weight of board: 0.526 kg (1.16 lbs)
Before you begin installing your card, please make sure that
the following items have been shipped:
• AIMB-308
• Warranty card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.

2 AIMB-308 Startup Manual
The board has a number of jumpers that allow you to
congurethesystemtosuittheapplication.Thetablebelow
lists the function of each jumper and connector.
Connector/Jumper List
Label Function
ATX_P1 12V main power connector ( for
system and CPU)
ATX_P2 12V power connector ( for MB or
add-on card )
ATX_P3 PW ok/on and +5Vsb for MB
CPUFAN1 CPU fan connector (4-pin)
COM1 ~ COM2 Serial port:RS-232 (9-pin header)
DIMMA1 Channel A DIMM1
DIMMB1 Channel B DIMM1
GPIO1 8 bit GPIO from super I/O
PCIE1 PCIe x16 slot (Gen4 x16 link)
PCIE2 PCIe x4 slot (Gen3 x4 link)
NVME1 M.2 2280 M-key socket (Gen3
x2 link)
mSATA1 mSATA
PSON1 AT/ATX model selector
JFP1 Power switch/reset connector
JFP2 External speaker/HDD LED con-
nector/SMBus connector
JFP3
Suspend: fast glash ( ATX/AT )
System on: on ( ATX/AT)
Systemo󰀨:o󰀨(ATX/AT)
JWDT1 Watchdog timer
JOBS1 OBS alarm
ESPI1 Debug card header
JSMB1 NL ( VRTT FW update pin header )
JCASE1 Instruction switch connetor
JCMOS1 CMOS clear
JME1 Intel®ME update
SPI_TPM2 TPM module header
USB2A1 USB 2.0 port ( internal Type-A)
USB3C3 USB 3.2 Gen1 port
USB3C4 USB 3.2 Gen1 port
USB2C4 2 x USB 2.0 port
SATA 4 ~ 6 Serial ATA 3.0 power 1~3
SATAPWR4~6 Serial ATA power connector 1~3
SYSFAN1 System fan1
SMB1 ~ SMB2 PCIe x4 SMBus connection
selector
SMB3 ~ SMB4 PCIe x16 SMBus connection
selector
AUDIO1 Audio connector (Line-out, Mic-in )
LAN2_USB3C1 2 x LAN1/USB 3.2 (Gen1)
LAN1_USB2C2 2 x LAN2/USB 2.0
HDMI1 + DP1 HDMI connector and Display con-
nector1
JCMOS1: CMOS Clear
JME1: Intel ME Update
Closed Pins Result
1-2 *Keep CMOS data
*Enable ME update
2-3
Clear CMOS data
Disable ME update
* Default
*Keep CMOS data Clear CMOS data
*Enable ME update Disable ME update
JWDT1+JOBS1: Watchdog Timer Output
Closed Pins
Result
2-4, 8-10 Watchdog timer disable (2-4)
OBS beep (8-10)
4-6, 8-10 *Watchdog timer reset (4-6)
OBS beep (8-10)
* Default
Watchdog timer disable (2-4) *Watchdog timer reset (4-6)
OBS beep (8-10) OBS beep (8-10)
1 2 3
1 2 3
Jumpers and Connectors Jumpers and Connectors (Cont.)

AIMB-308 Startup Manual 3
SMB1 and SMB3 (Clock), SMB2 and SMB4 (Data):
PCIe SMBus Connection Setting
Closed Pins
Result
1-2 *Enable PCIe SMBus connection
2-3 Disable PCIe SMBus connection
* Default
*Enable PCIe SMBus connection Disable PCIe SMBus connection
Note! Both SMB1 and SMB2 jumpers should be
switched to the same setting, either 1-2 closed
or 2-3 closed.
Caution! The computer is supplied with a battery-powered
real-time clock circuit. There is a danger of ex-
plosion if battery is incorrectly replaced. Replace
only with same or equivalent type recommended
by the manufacturer. Discard used batteries ac-
cording to manufacturer’s instructions.
This device complies with the requirements in Part 15 of
the FCC rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired opera-
tion.
Jumpers and Connectors (Cont.) Declaration of Conformity
Figure 1: Board Layout: Jumper and Connector Locations
Intel LGA 1700 Core
i9/i7/i5/i3
ATX_P1 (for CPU/SYS)
ATX_P2(for MB/add-on card)
ATX_P3
SATA 4~6
SATAPWR 4~6
SYSFAN1
USB2A1(type-A)
PCH
PCIe1
PCIe2
SMB1~4
SMB2 SMB1
SMB4 SMB3
AUDIO1
LAN2_USB3C1 LAN1_USB2C2
HDMI1 + DP1
CPUFAN1
DIMMA1
DIMMB1
mSATA
PWR on/off
switch
LED
USB3C3
USB2C4
Intrusion switch
Board Layout
