Advantech ASR-1000K-00A1E Installation and operation manual

ASR-1000K-00A1E Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
• Startup manual x 1
• China RoHS x 1
• mSAS-HD 8643 to 8643 cables x 2
• Mylar for HPC-8316 front panel LED x 1
• Mylar for HPC-8212/8224/8424 front panel LED x 1
• Mylar for HPC-8212/8224/8424 front panel USB x 1
• 2.5” HDD metal cover for HPC-8316 x 1
• Screws of 2.5” HDD cover x 3
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF
le.AcrobatReadercanbedownloadedat:
http://www.adobe.com/downloads/ (Acrobat is a
trademark of Adobe)
ASR-1000K-00A1E
JBOD Kit for HPC-8xxx Series Chassis
Startup Manual
Standard Functions
• Max Storage: 72 SAS/SATA HDDs, storage daisy chain
support
• Host Interface: SAS 12G x 4 wide-ports
• Connect to Disk: SAS 12G interface
• MiniSAS HD SFF-8644 Port: 2 (In/Out)
• Front Button: Power, Mute
Note: Buzzer is warning while the system fault LED is
on caused by any of HDD/SAS Expander/PSU/
Fan/Overheat failure or abnormal voltage, till the
mute button is pressed.
• Front LED: Power (blue/blinking/off), System fault (red/
off), Fan fault (red/off), Overheat (red/off)
• Smart Fan Control
Mechanical and Environmental
• Dimensions (W x H x D): 175 x 53.2 x 181.77 mm
130 x 170 mm (board only)
• Operating temperature: 0 ~ 35 °C
• Storage Temperature: -40 ~ 60 °C
• Vibration (non-operating): 0.25 Grms
• Certification: CE, FCC
• Weight: 0.5 kg (board with bracket)
Specications
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the ASR-1000K-00A1E series.
Part No. 2001100000
Print in China
1st Edition,
June 2016

2 ASR-1000K-00A1E Startup Manual
Hardware Switch
SW1
Pin1 OFF / ON (HPC-8212)
Pin2 OFF / ON (HPC-8224)
Pin3 OFF / ON (HPC-8316)
Pin4 OFF / ON (HPC-8424)
SW5
Pin1 OFF
Pin2 OFF
Pin3 ON
Pin4 ON
Pin5 OFF
Pin6 OFF
SW6
Pin1 OFF
Pin2 OFF
Pin3 ON
Pin4 ON
Pin5 OFF
Pin6 OFF
SW7
Pin1 ON
Pin2 OFF
Pin3 OFF
Pin4 ON
Pin5 OFF
Pin6 OFF
This device complies with the requirements in Part 15 of
the FCC rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired opera-
tion
The board has a number of jumpers that allow you to con-
gureyoursystemtosuityourapplication.Thetablebelow
lists the function of each jumper and connector.
Connector list
Label Function
ATXPWR1 ATX main power connector
(24-pin)
SYSFAN0~SYSFAN3 System FAN connector (4-pin)
CN3, CN4 External MiniSAS HD SFF-8644
connector to Host
CN5, CN6 Internal MiniSAS HD SFF-8643
connector to Expander
CN7 Power/System fault LED con-
nector (2x5-pin)
CN8 Fan / Overheat LED connector
(5-pin)
CN10 Mute button connector (2-pin)
CN11 Power button connector (2-pin)
CN1 Power supply's mute connector
(2-pin)
PCN6 Power supply’s TTL connector
(2-pin with housing)
BZ_SEL1 Buzzer (2-3 Closed: On as de-
fault, 1-2 Closed: Always mute)
SW1 Smart fan for HPC-8xxx chassis
support
JCASE1 Reserved (1-2 Closed: No func-
tion as default)
PSOC_UR1 For debug purpose (4-pin)
UPDATE_CON1 Forrmwareupdate(5-pin)
SMB_CON2 For debug purpose (4-pin)
Note: Please connect the SYSFAN0~SYSFAN3 con-
nectors in the correct sequence. For example,
if there are four fans in the chassis to be con-
nected, correct method would be to connect
them into SYSFAN0, SYSFAN1, SYSFAN2
and SYSFAN3. If fans are connected out of
sequence, alarm will not function correctly.
Declaration of Conformity
Jumpers and Connectors

ASR-1000K-00A1E Startup Manual 3
Board Layout & Installation: Jumper and Connector Locations
InstalltoHPC-8xxxchassisandxfollowingthestepsbelow:
1. Check SW 1 setting to match the supported chassis
2. Fix the JBOD kit into HPC-8xxx chassis with screws
3. Connect SYSFAN0~ SYSFAN3 with chassis fans
4. Connect CN5/CN6 with internal MiniSAS cables
5. Connect CN7, CN8 to chassis Power/System fault/Fan/ Overheat LEDs
6. Connect CN10/CN11 to chassis Mute/Power buttons
7. Connect CN1 with power supply Mute
8. Connect PCN6 with power supply TTL
9. Connect ATXPWR1 with power supply
Board Layout & Installation
CN1
ATXPWR1
SW5~SW7
SMB_CON2
PCN6
CN7 CN8
JCASE1 CN10
CN11
BZ_SEL1
SYSFAN0~SYSFAN3
PSOC_UR1,
UPDATE_CON1
SW1
CN5, CN6
CN3, CN4
