Advantech AIMB-330F User manual

AIMB-330F
Socket 370 SBC for Multimedia
Applications
User’s Manual

AIMB-330F User’s Manual ii
Copyright
This document is copyrighted, © 2003. All rights are reserved. The origi-
nal manufacturer reserves the right to make improvements to the products
described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated or transmit-
ted in any form or by any means without the prior written permission of
the original manufacturer. Information provided in this manual is
intended to be accurate and reliable. However, the original manufacturer
assumes no responsibility for its use, nor for any infringements upon the
rights of third parties that may result from such use.
Acknowledgements
Award is a trademark of Award Software International, Inc.
VIA is a trademark of VIA Technologies, Inc.
IBM, PC/AT, PS/2 and VGA are trademarks of International Business
Machines Corporation.
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows® is a registered trademark of Microsoft Corp.
RTL is a trademark of Realtek Semi-Conductor Co., Ltd.
ESS is a trademark of ESS Technology, Inc.
UMC is a trademark of United Microelectronics Corporation.
SMI is a trademark of Silicon Motion, Inc.
Creative is a trademark of Creative Technology LTD.
All other product names or trademarks are properties of their respective
owners.
For more information on this and other Advantech products, please visit
our websites at: http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our support website at:
http://service.advantech.com.tw/eservice/
This manual is for the AIMB-330F Series.
Part No.2006033020
2nd Edition, September 2004

iii
Packing List
Before you begin installing your card, please make sure that the following
materials have been shipped:
• 1 AIMB-330 all-in one single board computer
• 1 CD-ROM or disks for utility, drivers, and manual (in PDF format)
• 1 warranty certificate
• 1 UDMA/66IDE flat cable
• 1 startup manual
• 1 2-port serial port cable
• 1 4-port serial cable (AIMB-330F only)
• 1 IEEE 1394 cable (optional)
If any of these items are missing or damaged, contact your distributor or
sales representative immediately.

AIMB-330F User’s Manual iv
Additional Information and Assistance
Step 1. Visit the Advantech web site at www.advantech.com where you
can find the latest information about the product.
Step 2. Contact your distributor, sales representative, or Advantech's cus-
tomer service center for technical support if you need additional
assistance. Please have the following information ready before
you call:
• Product name and serial number
• Description of your peripheral attachments
• Description of your software (operating system, version, application
software, etc.)
• A complete description of the problem
• The exact wording of any error messages

v
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User's Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the
equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or let-
ting it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power
source to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work according
to the user's manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE
THE STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR
ABOVE 60° C (140° F). THIS COULD DAMAGE THE EQUIPMENT. THE
EQUIPMENT SHOULD BE IN A CONTROLLED ENVIRONMENT.
16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED.REPLACE ONLY WITH THE SAME OR EQUIVALENT
TYPE RECOMMENDED BY THE MANUFACTURER, DISCARD USED
BATTERIES ACCORDING TO THE MANUFACTURER'S INSTRUC-
TIONS.
The sound pressure level at the operator's position according to IEC 704-1:1982 is
no more than 70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advan-
tech disclaims all responsibility for the accuracy of any statements contained
herein.

AIMB-330F User’s Manual vi
W i c h t i g e S i c h e r h e i s h i n w e i s e
1. Bitte lesen sie Sich diese Hinweise sorgfältig durch.
2. Heben Sie diese Anleitung für den späteren Gebrauch auf.
3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie
Keine Flüssig-oder Aerosolreiniger. Am besten dient ein angefeuchtetes Tuch
zur Reinigung.
4. Die NetzanschluBsteckdose soll nahe dem Gerät angebracht und leicht
zugänglich sein.
5. Das Gerät ist vor Feuchtigkeit zu schützen.
6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten. Ein Kippen
oder Fallen könnte Verletzungen hervorrufen.
7. Die Belüftungsöffnungen dienen zur Luftzirkulation die das Gerät vor überhit-
zung schützt. Sorgen Sie dafür, daB diese Öffnungen nicht abgedeckt werden.
8. Beachten Sie beim. AnschluB an das Stromnetz die AnschluBwerte.
9. Verlegen Sie die NetzanschluBleitung so, daB niemand darüber fallen kann.
Es sollte auch nichts auf der Leitung abgestellt werden.
10. Alle Hinweise und Warnungen die sich am Geräten befinden sind zu
beachten.
11. Wird das Gerät über einen längeren Zeitraum nicht benutzt, sollten Sie es vom
Stromnetz trennen. Somit wird im Falle einer Überspannung eine Beschädi-
gung vermieden.
12. Durch die Lüftungsöffnungen dürfen niemals Gegenstände oder Flüssigkeiten
in das Gerät gelangen. Dies könnte einen Brand bzw. elektrischen Schlag aus-
lösen.
13. Öffnen Sie niemals das Gerät. Das Gerät darf aus Gründen der elektrischen
Sicherheit nur von authorisiertem Servicepersonal geöffnet werden.
14. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu trennen
und von einer qualifizierten Servicestelle zu überprüfen:
a - Netzkabel oder Netzstecker sind beschädigt.
b - Flüssigkeit ist in das Gerät eingedrungen.
c - Das Gerät war Feuchtigkeit ausgesetzt.
d - Wenn das Gerät nicht der Bedienungsanleitung entsprechend funktioniert
oder Sie mit Hilfe dieser Anleitung keine Verbesserung erzielen.
e - Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.
f - Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.
15. VOSICHT: Explisionsgefahr bei unsachgemaben Austausch der Batte-
rie.Ersatz nur durch densellben order einem vom Hersteller empfohlene-
mahnlichen Typ. Entsorgung gebrauchter Batterien navh Angaben des
Herstellers.
Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000
beträgt 70dB(A) oder weiger.
DISCLAIMER: This set of instructions is given according to IEC704-1.
Advantech disclaims all responsibility for the accuracy of any statements
contained herein.

vii
Caution! Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equiv-
alent type recommended by the manufacturer.
Dispose of used batteries according to the man-
ufacturer’s instructions.

AIMB-330F User’s Manual viii

ix
Content
Chapter 1 General Information ........................................2
1.1 Introduction ....................................................................... 2
1.2 Features ............................................................................. 3
1.3 Specifications .................................................................... 4
1.4 Board Dimensions............................................................. 6
Figure 1.1:Board Dimensions (Component Side)........... 6
Figure 1.2:Board Dimensions (Solder Side)................... 7
Chapter 2 Installation ......................................................10
2.1 Jumpers............................................................................ 10
2.2 Connectors....................................................................... 10
2.3 Locating jumpers and connectors.................................... 12
Figure 2.1:Locating Jumpers & Connectors................. 12
Figure 2.2:Locating Jumpers & Connectors(soldor side).
13
2.4 Setting Jumpers ............................................................... 14
2.5 CPU installation and upgrading ...................................... 15
2.5.1 Installing a CPU in the ZIF socket................................ 15
2.5.2 CMOS clear (JP1)......................................................... 16
2.6 DRAM installation .......................................................... 16
2.6.1 DDR SDRAM (DIMM 1 and DIMM 2)....................... 16
2.7 Primary (3.5") IDE connector (CN22)............................ 17
2.7.1 Connecting the hard drive............................................. 17
2.8 Secondary (2.5") IDE connector (CN20) ........................ 17
2.9 FDD connector (CN23) (optional) .................................. 18
2.9.1 Connecting the floppy drive ......................................... 18
2.10 LPT1 (primary parallel port) connectors .............. (CN5)19
2.11 LPT2 (secondary parallel port) connector (CN26) ......... 19
2.12 Keyboard/mouse connectors (CN6)................................ 19
2.13 Power connectors (CN18, FAN1, FAN2) ....................... 19
2.13.1 ATX power input connector (CN18)............................ 19
2.13.2 Fan power supply connector (FAN2, FAN1) ............... 19
2.14 Audio interfaces (CN4, CN10, CN11)............................ 20
2.14.1 Audio connector (CN4) ................................................ 20
2.14.2 Internal Speaker Connector (CN10) ............................. 20
2.14.3 CD audio-in connector (CN11)..................................... 20
2.15 Serial (COM1-6) (CN2, CN27, CN25) ........................... 20
2.15.1 Primary (COM1:CN2,COM2:CN27) ........................... 20
2.15.2 Secondary (COM3~COM6: CN25).............................. 20
2.16 COM-2 RS232/422/485 &COM 1-6 Ring select (9x2 ,

AIMB-330 User’s Manual x
2.0mm Pin-header) (JP4)21
2.17 COM1~COM6 Pin-9 voltage output select(JP3) ............ 21
2.18 VGA interface connections ............................................. 23
2.18.1 CRT display connector (CN1) ...................................... 23
2.18.2 Flat panel display connector (CN13,CN14) ................. 23
2.18.3 LCD VDDSAFE setting (JP2)...................................... 24
2.18.4 Inverter power connector (CN17)................................. 24
2.19 Ethernet configuration..................................................... 24
2.19.1 RJ-45 connector (CN9)................................................. 24
2.19.2 Network boot ................................................................ 24
2.20 Watchdog timer configuration ........................................ 25
2.21 USB connector (CN7,CN9,CN16).................................. 25
2.22 Digital I/O (CN19: 4 Outputs, 4 Inputs) ......................... 25
2.22.1 Digital output programming ......................................... 26
2.23 IrDA Connector (CN21).................................................. 26
2.24 Front Panel Connector(CN21) ........................................ 26
2.25 COMS Power (JP1)......................................................... 26
2.26 Watch Dog programer (CN12)........................................ 27
2.27 PCI slot expension (PCI1 or PCI2) ................................. 27
Chapter 3 Chipset Software Installation Utility............30
3.1 Before you begin ............................................................. 30
3.2 Introduction ..................................................................... 30
3.3 Installing VIA CLE266 the Utility.................................. 31
3.4 Connections for Standard LCDs ..................................... 36
Chapter 4 Audio Setup.....................................................38
4.1 Introduction ..................................................................... 38
4.2 Driver installation............................................................ 38
4.2.1 Before you begin........................................................... 38
4.2.3 Windows 2000 drivers.................................................. 41
Chapter 5 VGA Setup ......................................................46
5.1 Introduction ..................................................................... 46
5.2 Windows XP Installation ............................................... 46
5.3 Installation for Windows 2000........................................ 50
5.4 Dual Display Setting ....................................................... 52
Chapter 6 Award BIOS Setup.........................................58
6.1 Introduction ..................................................................... 58
6.1.1 CMOS RAM Auto-backup and Restore ....................... 58
6.2 Entering Setup................................................................. 59
Figure 6.1:Award BIOS Setup initial screen ................ 59
6.3 Standard CMOS Setup .................................................... 60
Figure 6.2:Standard CMOS features screen ................. 60

xi
6.4 Advanced BIOS Features................................................ 60
Figure 6.3:Advanced BIOS features screen.................. 61
6.4.1 Virus Warning............................................................... 61
6.4.2 CPU Internal Cache ...................................................... 61
6.4.3 External Cache.............................................................. 61
6.4.4 CPU L2 Cache ECC Checking ..................................... 61
6.4.5 Processor Number Feature............................................ 61
6.4.6 Quick Power On Self Test ............................................ 61
6.4.7 First/Second/Third/Other Boot Device......................... 62
6.4.8 Swap Floppy Drive ....................................................... 62
6.4.9 Boot UP Floppy Seek ................................................... 62
6.4.10 Boot Up NumLock Status............................................. 62
6.4.11 Gate A20 Option........................................................... 62
6.4.12 Typematic Rate Setting................................................. 62
6.4.13 Typematic Rate (Chars/Sec) ......................................... 62
6.4.14 Typematic Delay (msec)............................................... 62
6.4.15 Security Option ............................................................. 62
6.4.16 APIC Mode................................................................... 63
6.5 Advanced Chipset Features............................................. 63
Figure 6.4:Advanced Chipset Feature .......................... 63
6.5.1 DRAM Clock/Driver Control ....................................... 63
6.5.2 AGP&P2P Bridge Control............................................ 63
6.5.3 CPU & PCI Bus Control............................................... 63
6.5.4 Memory Hole................................................................ 64
6.5.5 System BIOS Cache...................................................... 64
6.5.6 Video RAM Cacheable................................................. 64
6.5.7 VGA Share Memory Size............................................. 64
6.5.8 Select Display Device................................................... 64
Figure 6.5:Slect Display Device ................................... 64
6.5.9 Panel Type .................................................................... 64
6.6 Integrated Peripherals .......................... 65
Figure 6.6:Integrated peripherals.................................. 65
6.6.1 VIA Onchip IDE Device............................................... 65
Figure 6.7:VIA Onchip IDE Device............................. 66
6.6.2 VIA Onchip PCI Device ............................................... 66
Figure 6.8:VIA Onchip PCI Device ............................. 66
6.6.3 Super I/O Device .......................................................... 67
Figure 6.9:Super I/O Device......................................... 67
6.6.4 Init Display First ........................................................... 67
6.6.5 PWR ON After PWR Fail............................................. 67
6.6.6 Onboard Serial Port 3/4/5/6 Use IRQ........................... 67
6.6.7 Onboard Parallel Port2.................................................. 67
6.6.8 Parallel Port2 Mode ...................................................... 67
6.6.9 LPT2 ECP Mode Use DMA ......................................... 68
6.7 Power Management Setup............................................... 68

AIMB-330 User’s Manual xii
Figure 6.10:Power management setup screen............... 68
6.7.1 Power Management Option .......................................... 68
6.7.2 HDD Power Down........................................................ 69
6.7.3 Suspend Mode............................................................... 69
6.7.4 Video Off Option......................................................... 69
6.7.5 Video Off Mode............................................................ 69
6.7.6 Modem Use IRQ........................................................... 69
6.7.7 Soft-Off by PWR-BTTN .............................................. 69
6.7.8 IRQ/Event Activity....................................................... 70
Figure 6.11:IRQ/Event Activity ................................... 70
6.8 PnP/PCI Configurations .................................................. 70
6.8.1 PnP OS Installed ........................................................... 70
Figure 6.12:PnP/PCI configurations screen.................. 70
6.8.2 Reset Configuration Data.............................................. 71
6.8.3 Resources controlled by:............................................... 71
6.8.4 PCI/VGA Palette Snoop ............................................... 71
6.9 PC Health Status.............................................................. 71
6.9.1 CPU Warning Temperature .......................................... 71
Figure 6.13:PC health status screen.............................. 71
6.9.2 Current CPU Temperature ............................................ 71
6.9.3 Current CPUFAN Speed............................................... 71
6.9.4 +5V/+12V/-12V/-5V .................................................... 71
6.9.5 Shut Dowm Temperature.............................................. 72
6.10 Password Setting ............................................................. 72
Figure 6.14:Password Setting ....................................... 72
6.11 Save & Exit Setup ........................................................... 73
Figure 6.15:Save and Exit Setup................................... 73
6.12 Exit Without Saving........................................................ 74
Figure 6.16:Exit Without Saving.................................. 74
Chapter 7 PCI Bus Ethernet Interface...........................76
7.1 Introduction ..................................................................... 76
7.2 Features ........................................................................... 76
7.3 Installation of Ethernet Driver......................................... 76
7.3.1 Installation for Windows 2000 ..................................... 77
7.3.2 Installation for Windows XP ........................................ 79
7.4 Further information ......................................................... 80
Appendix A Programming the Watchdog Timer .............82
A.1 Programming the watchdog timer................................... 82
Appendix B Sample Code of GPIO programming ...........86
Appendix C AIMB-330 Jumper and Connector Settings 90
C.1 Connectors ...................................................................... 90
C.2 CN1 VGA D-TYPE 15 Pins connector........................... 91
C.3 CN2 COM1 D-TYPE 9 Pins connect.............................. 91

xiii
C.4 CN3 PCMCIA connector ................................................ 92
C.5 CN4 Audio connector...................................................... 92
C.6 CN26 LPT-2 connector 25-pin D-sub............................. 92
C.7 CN5 LPT1 D-TYPE 25 Pin connector............................ 93
C.8 CN10 Internal speaker(4x1,2.0mm Wafer-box) ............. 93
C.9 CN11 CD-Input connector (4x1,2.54 mm Wafer-box)... 94
C.10 CN12 Reserved to program the Watch-dog .................... 94
C.11 CN17 Inverter power(5x1,2.0 mm Wafer-box) .............. 94
C.12 CN13 24-bit LVDS (20X2, DF13 connector)................. 95
C.13 CN14 12-bit LVDS ............................ 96
C.14 CN16 Embedded USB (9x2,2.54 mm Pin-header) ......... 97
C.15 CN18 ATX Power connector (10x2,ATX) ..................... 97
C.16 CN19 DIO Connector(8x2,2.54mm pin-header)............. 98
C.17 CN20 Secondary IDE(22x2 ,2.0mm Box-header) .......... 98
C.18 CN21 IrDA Connector(5x1,2.54mm Pin-header)........... 99
C.19 CN22 Primary IDE(20x2 , 2.54mm Box-header) ......... 100
C.20 CN23 Floppy(26 Pin FDC connector)(optional)........... 101
C.21 CN24 Front Panel connector ........................................ 102
C.22 CN25 COM3 - COM6(20x2 , 2.0 mm Box-header) ..... 102
C.23 CN27 COM-2(7x2,2.0mm Box-header) ....................... 103
C.24 CN6 K/B & M/S Connector.................... 103
C.25 CN7 USB Connector.................................................... 103
C.26 CN8 LCD 40-pin HIROSE .......................................... 104
C.27 CN9 LAN+USB*2 Connector .................. 105
C.28 CN28 Mini PCI ............................................................ 105
C.29 CN29 Compact Flash (IDE Secondary Slave) ............. 105
C.30 CN30,CN31 IEEE-1394............................................... 105
C.31 CN33 DVI .................................................................... 106
C.32 FAN1 CPU FAN (3x1,2.54 mm Molex)....................... 106
C.33 FAN2 System FAN (3x1,2.54 mm Molex)................... 106
C.34 JP1 COMS Power(3x1,2.0 mm Pin-header) ................. 106
C.35 JP5 LVDS VDDSAFE sel.(3x1,2.0 mm Pin-header).... 106
C.36 JP3 COM1-6 Pin-9 V out (11x2,2.0mm Pin-header).... 107
C.37 JP4 COM-2 RS232/422/485 and COM-1 to COM-6 Ring
signal select (9x2 , 2.0mm Pin-header)108
Appendix D IRQ Resources..............................................110
D.1 IRQ Resource Guide ..................................................... 110

AIMB-330 User’s Manual xiv

CHAPTER
1
General Information
This chapter gives background infor-
mation on the AIMB-330F.
Sections include:
• Sections include:
• Introduction
• Features
• Specifications
• Board layout and dimensions

AIMB-330F User’s Manual 2
Chapter 1 General Information
1.1 Introduction
The AIMB-330F utilizes an EmbeddedATX form factor (Socket 370)
design that supports Socket 370 for Intel Celeron® / Pentium® III pro-
cessors (Tulatin), VGA C3 above 750MHz. This effective Embedde-
dATX socket 370 solution gives end users the choice of good, economical
performance with the VIA C3 series processors, or the impressive perfor-
mance of the Intel Celeron® and Pentium III series. This processor flexi-
bility combined with all the other on-board features, explains why the
AIMB-330F is the new top-of-the-line Industrial Motherboard solution at
Advantech.
The AIMB-330F is loaded with special on-board features that rival full-
size systems. It has standard 10/100Base-T PCI Ethernet, 2 channel 48-
bit LVDS LCD panel support as well as SSD support for CompactFlash®.
There is a Mini PCI socket for optional international version modem, plus
optional support for AC97 3D stereo surround sound with speaker-out,
CD-input, line-in, line-out and microphone. The AIMB-330F also
includes two 184-pin DDR DIMM sockets for up to 2 GB total on-board
memory.
The AIMB-330F was designed using feedback and knowledge gained
from our customers. It has more of the features our customers have
requested. It is 100% PC compatible and is ready to handle the most chal-
lenging Industrial motherboard environments. Besides the great onboard
memory flexibility and capacity, the AIMB-330F has six on-board serial
ports, each with +5/+12 V power, six USB connectors, watchdog timer
and tough industrial grade construction. The Award 256 KB Flash BIOS
supports Plug & Play, Boot from Ethernet, Boot from CD-ROM, Boot
from Zip drive, Wake-on-Lan, Modem. All these features make the
AIMB-330F a very "system integrator friendly" solution, perfect for han-
dling gaming, ATM, kiosks and DVR multimedia applications in the
harshest unmanned environments.

3 Chapter1
1.2 Features
• All-in-one design simplifies system integration and increases system
stability
• Socket 370 supports Intel® Celeron®/Pentium® III processors(Tul-
atin), VGA C3 above 750MHz.
• Dual display support
• 2/6 serial ports, one RS-232/422/485, the others are RS-232, COM 3~6
shared IRQ
• Supports DDR266 DRAM memory sockets
• 6 USB 2.0 interface compliant included 1 Embedded USB
• Supports Mini PCI interface for optional modem/wireless LAN
• Supports I2C, DIO interface
• Supports system overheat temperature control
• 63-level watchdog timer, jumperless on-line setup supported
• Supports 2 slots Cardbus and 2 ports IEEE 1394 interface(optional)

AIMB-330F User’s Manual 4
1.3 Specifications
Standard SBC functions
• CPU: Socket 370 for Intel®Celeron®/Pentium III processors(Tul-
atin),VGA C3 abrove 750MHz.
• BIOS: Award 256 KB Flash memory
• Chipset: VIA CLE266 + 8235 Chipset
• System memory: DDR DIMM x2, Max. 2G
• Enhanced IDE interface: 2 x EIDE, 40-pin UDMA 66&100 and 44-
pin UDMA 33
• FDD interface: Supports up to one FDD (optional)
• Serial ports: 2/6 serial RS-232 ports, COM1,3,4,5,6: RS-232, COM2:
RS-232/422/485, COM3~6 share IRQ. It will depend on the OS sup-
port to have a share IRQ capability.
• Parallel port: 1/2 parallel ports, supports SPP/EPP/ECP mode
• Infrared port: Shared with COM2. Transfer rates up to 1.15 Mbps
• Keyboard/mouse connector: Supports standard PC/AT keyboard and
a PS/2 mouse
• Power management: Supports power saving modes including Normal/
Standby/Suspend modes. APM 1.1 compliant
• Watchdog timer: 63 level timer intervals
• USB: Six universal serial bus ports (USB2.0), EmbeddedUSB will
occupy 2 USB resources.
• Expansion Interface: 1 x PCI, 1 x mini PCI, 2 x Cardbus, 2 x Firewire
Solid state disk
• Supports one 50-pin socket for CompactFlash™ card
VGA/LCD interface
• Chipset: VGA CLE266
• Display mode: Maximum 3D resolution supported, LCD panel: 1600 x
1200. CRT 1400x1050, DVI 1280x1024
• Dual display combination: CRT +24-bit LCD panel; CRT+ LVDS
panel

5 Chapter1
Ethernet interface
• Chipset: ReakTek RTL 8139DL 10/100M or Intel 82541GI (10/100/
1000M optional)
• Ethernet interface: 1 x RJ45
• Connection: On-board RJ-45 connector
• Speed: 10/100Base-T or 1000Base-T
• Standard: IEEE 802.3, IEEE 802.3u, IEEE 802.3z/ab (optional)
• Built-in boot ROM
Display
• Chipset: VIA CLE266/VT8623CD
• Memory Size: VIA Direct Memory Execution model to use system
memory
• Resolution: Maxium 3D Resolution Supported:
LCD panel:1600 x 1200
CRT: 1400 x 1050
DVI: 1280 x 1024
Mechanical and environmental
• Power requirements: +12 V(CPU)@ 0.33 mA, +5 V@ 6.15 mA,+3.3
V@ 2.6A (PentiumIII, 1.26 G, DDR333 512+256 M)
• Operating temperature: 0 ~ 60° C (32 ~ 140° F)
• Operating humidity: 0% ~ 90% relative humidity, noncondensing
• Dimensions (L x W): 244 x 244 mm (9.6" x 9.6")
• Weight: 0.7 kg (1.2 lb)

AIMB-330F User’s Manual 6
1.4 Board Dimensions
Figure 1.1: Board Dimensions (Component Side)
H
G
F
