Advantech SIMB-A01 Installation and operation manual

SIMB-A01 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 x Intel Q35 ATX Main board
• 1 x CD ROM per carton, which contains the followings:
- User’s Manual in PDF file
- Drivers
• 1 x SATA cable kit (SATA/Power)
• 1 x I/O Shield
• 1 x Startup Manual per carton
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note1:
Acrobat Reader is required to view any PDF file. Acrobat
Reader can be downloaded at: www. adobe.com/Prodindex/
acrobat/readstep.html (Acrobat is a trademark of Adobe).
SIMB-A01
Intel® Q35 LGA775 socket for Intel® Core™ 2
Quad ATX Motherboard Startup Manual
System
• CPU:Intel® Q35 LGA775 socket for Intel® Core™ 2
Quad / Core™2 Duo / processors compatible with Intel®
05B/05A/06 processors support Intel® next generation
45nm multi-core CPU
• FSB:1333 / 1066 / 800 MHz
• BIOS:AMI 32 Mb SPI BIOS
• SystemChipset:Intel Q35 GMCH/ICH9R
• I/OChipset:Winbond W83627DHG-A
• Memory:Four 240-pin DIMM sockets support up to 8 GB
Dual Channel DDR2 800/667 SDRAM
• WatchdogTimer:Reset: 1 sec.~255 min. and 1 sec. or 1
min./step
• H/WStatusMonitor:Monitoring temperatures, voltages,
and cooling fan status. Auto throttling control when CPU
overheats
• ExpansionSlots:1 x PCI Express x16, 1 x PCI Express
x1, 5 x PCI (PCI Rev. 2.3 compliant)
• DIO:16 bit (8-in/8-out by PCA9555)
• S3/S4:Ye s
• TPM:TPM1.2 (Infineon® TPM chip 9635 TT 1.2 on board)
• WakeuponLANorRing:LAN (PME / RPL)
• SmartFanControl:Yes , support 3 modes (Silent/Opti-
mal/Performance)
Display
• Chipset:Intel Q35 GMCH integrated Graphics Media
Accelerator 3100
• DisplayMemory:Intel DVMT 4.0 supports up to 384 MB
video memory
• Max.Resolution:2048 x 1536 bpp(@ 75Hz)
• VGA:Yes , on board GMA 3100
• LVDS/DVI/HDMI:Through ADD2 LVDS Card
• SecondaryVGA:Yes , through ADD2 card
Audio
• AudioCodec:Realtek® ALC888, 7.1 W/O multiple
streaming or 5.1+2 with multiple streaming HD audio
• AudioInterface:Mic in, Line in, Line out
• AudioAmplier(W):Dual 6W Amp.(TPA3005D2 ,
Optional)
Ethernet
• LAN1:RTL8111C Gigabit LAN
• LAN2:RTL8111C Gigabit LAN
Specications Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the SIMB-A01 series Rev. A1.
Part No. 20060A0110
Printed in China
1st Edition
July 2011

2 SIMB-A01 Startup Manual
Connectors
Label Function Note
AAFP Front Panel Audio Connector
CHA_FAN1 Chassis Fan Connector
CPU_FAN CPU Fan Connector
F_PANEL
System Panel Connector
SPDIF_OUT Digital Audio connector
Connectors and Jumpers

SIMB-A01 Startup Manual 3
Jumpers
Label Function Note
CLRTC Clear CMOS
Norrnal* Clear CMOS
CHASSIS Chassis Intrusion Connector
JCOMPWR
1,2,3,4 COM1,2,3,4 RI/+5V/+12V Select
RI* +5V +12V
JCOMPWR
5,6,7,8 COM4 RS-232/422/485 Select
JCOMPWR5 JCOMPWR6, 7
RS-232*
RS-422
RS-485
Connectors and Jumpers

4 SIMB-A01 Startup Manual
The manufacturer reserves the right to make changes, with-
out notice, to any product, including circuits and/or software
described or contained in this manual in order to improve
design and/or performance. The manufacturer assumes
no responsibility or liability for the use of the described
product(s), conveys no license or title under any patent,
copyright, or masks work rights to these products, and
makes no representations or warranties that these products
are free from patent, copyright, or mask work right infringe-
ment, unless otherwise specified. For the detail product
information, please refer to user’s manual.
Safety Declaration
This device complies with the requirements in Part 15 of
the FCC rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation.
Board Diagram
Disclaimer and Notice
