Advantech AIMB-705 User manual

User Manual
AIMB-705
LGA1151 Intel®CoreTM i7/i5/i3
ATX with Dual display, Dual GbE
LAN, SATAIII, USB3.0, DDR4

AIMB-705 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2017
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
AMI is a trademark of American Megatrends Inc.
IBM and PC are trademarks of International Business Machines Corporation.
Intel® Core™, Intel® Core™ 2 Quad, Pentium® Dual Core and Celeron® are trade-
marks of Intel® Corporation.
WinBond is a trademark of Winbond Corporation.
All other product names or trademarks are properties of their respective owners.
Part No. 2001070501 Edition 2
Printed in China January 2017

iii AIMB-705 User Manual
A Message to the Customer
Advantech Customer Services
Each and every Advantech product is built to the most exacting specifications to
ensure reliable performance in the harsh and demanding conditions typical of indus-
trial environments. Whether your new Advantech equipment is destined for the labo-
ratory or the factory floor, you can be assured that your product will provide the
reliability and ease of operation for which the name Advantech has come to be
known.
Your satisfaction is our primary concern. Here is a guide to Advantech’s customer
services. To ensure you get the full benefit of our services, please follow the instruc-
tions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions,
you can easily find answers in your product documentation. These answers are nor-
mally a lot more detailed than the ones we can give over the phone.
So please consult this manual first. If you still cannot find the answer, gather all the
information or questions that apply to your problem, and with the product close at
hand, call your dealer. Our dealers are well trained and ready to give you the support
you need to get the most from your Advantech products. In fact, most problems
reported are minor and are able to be easily solved over the phone.
In addition, free technical support is available from Advantech engineers every busi-
ness day. We are always ready to give advice on application requirements or specific
information on the installation and operation of any of our products.

AIMB-705 User Manual iv
Declaration of Conformity
FCC
This device complies with the requirements in part 15 of the FCC rules:
Operation is subject to the following two conditions:
This device may not cause harmful interference
This device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B dig-
ital device, pursuant to Part 15 of the FCC Rules. These limits are designed to pro-
vide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Opera-
tion of this device in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his/her own expense. The
user is advised that any equipment changes or modifications not expressly approved
by the party responsible for compliance would void the compliance to FCC regula-
tions and therefore, the user's authority to operate the equipment.
Caution! There is a danger of a new battery exploding if it is incorrectly installed.
Do not attempt to recharge, force open, or heat the battery. Replace the
battery only with the same or equivalent type recommended by the man-
ufacturer. Discard used batteries according to the manufacturer's
instructions.

v AIMB-705 User Manual
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandise
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Initial Inspection
Before you begin installing your motherboard, please make sure that the following
materials have been shipped:
1 AIMB-705 Startup Manual
1 Driver CD (user’s manual is included)
2 Serial ATA HDD data cables
1 Serial ATA HDD cables
1 I/O port bracket
1 Warranty card
If any of these items are missing or damaged, contact your distributor or sales repre-
sentative immediately. We have carefully inspected the AIMB-705 mechanically and
electrically before shipment. It should be free of marks and scratches and in perfect
working order upon receipt. As you unpack the AIMB-705, check it for signs of ship-
ping damage. (For example, damaged box, scratches, dents, etc.) If it is damaged or
it fails to meet the specifications, notify our service department or your local sales
representative immediately. Also notify the carrier. Retain the shipping carton and
packing material for inspection by the carrier. After inspection, we will make arrange-
ments to repair or replace the unit.

AIMB-705 User Manual vi

vii AIMB-705 User Manual
Contents
Chapter 1 Hardware Configuration......................1
1.1 Introduction ............................................................................................... 2
1.2 Features .................................................................................................... 2
1.3 Specifications ............................................................................................ 2
1.3.1 System .......................................................................................... 2
1.3.2 Memory ......................................................................................... 3
1.3.3 Input/Output .................................................................................. 3
1.3.4 Graphics........................................................................................ 3
1.3.5 Ethernet LAN ................................................................................ 3
1.3.6 Industrial Features ........................................................................ 3
1.3.7 Mechanical and Environmental Specifications.............................. 3
1.4 Jumpers and Connectors .......................................................................... 4
Table 1.1: Jumper list .................................................................. 4
Table 1.2: Connectors ................................................................. 4
1.5 Board Layout: Jumper and Connector Locations...................................... 6
Figure 1.1 Jumper and Connector Locations............................... 6
Figure 1.2 I/O View ...................................................................... 6
1.6 AIMB-705 Block Diagram.......................................................................... 7
Figure 1.3 AIMB-705 Block Diagram ........................................... 7
1.7 Safety Precautions .................................................................................... 7
1.8 Jumper Settings ........................................................................................ 8
1.8.1 How to set jumpers ....................................................................... 8
1.8.2 CMOS clear & ME clear (JCMOS1 & JME1) ................................ 8
Table 1.3: JCMOS1/JME1........................................................... 8
1.8.3 Watchdog timer output (JWDT1) .................................................. 8
Table 1.4: Watchdog timer output (JWDT1) ................................ 8
Table 1.5: ATX/AT mode selector (PSON1)................................ 9
Table 1.6: USB source switch between +5V and +5V_ DUAL for
onboard USB ports (JUSB_2) .................................... 9
1.9 System Memory ........................................................................................ 9
1.10 Memory Installation Procedures.............................................................. 10
1.11 PCI Bus Routing Table............................................................................ 10
Chapter 2 Connecting Peripherals ....................11
2.1 Introduction ............................................................................................. 12
2.2 Parallel Port (LPT1)................................................................................. 12
2.3 USB Ports and LAN Ports (LAN1_USB3_34,LAN2_USB34, USB3_12,
USB5, USB910) ...................................................................................... 13
2.4 VGA Connector and DVI-D Connector (VGA1 + DVI1)........................... 14
2.5 Serial Ports (COM1, COM2, COM3, COM4, COM5 & COM6) ............... 15
2.6 PS/2 Keyboard and Mouse Connector (KBMS1/KBMS2)....................... 16
2.7 CPU Fan Connector (CPUFAN1)............................................................ 16
2.8 System FAN Connector (SYSFAN1 and SYSFAN2) .............................. 17
2.9 Front Panel Connectors (JFP1, JFP2 & JFP3) ....................................... 18
2.9.1 Power LED and Keyboard Lock (JFP3) ...................................... 18
Table 2.1: PS/2 or ATX supply LED status.............................. 18
2.9.2 External Speaker (JFP2 pins 1, 4, 7 & 10).................................. 19
2.9.3 HDD LED Connector (JFP2 pins 2 & 5)...................................... 19
2.9.4 SM_Bus connector (JFP2 pins 8 & 11)....................................... 19
2.9.5 ATX Soft Switch (JFP1 pins 3 & 6) ............................................ 19
2.9.6 Reset Connector (JFP1 pins 9 & 12) .......................................... 19
2.10 Line Out, Mic In Connector (AUDIO1_AUDIO2) ..................................... 19
2.11 8-pin Alarm Board Connector (VOLT1)................................................... 20

AIMB-705 User Manual viii
2.12 Case Open Connector (JCASE1) ........................................................... 21
2.13 Front Panel LAN Indicator Connector (LANLED1).................................. 22
Table 2.2: Front Panel LAN Indicator Connector ...................... 22
2.14 Serial ATA Interface (SATA0, SATA1, SATA2, SATA3)......................... 23
2.15 PCI Slots (PCI1 ~ PCI5).......................................................................... 23
2.16 PCIe x16 Expansion Slot (PCIEX16_1) .................................................. 24
2.17 PCIe x4 Expansion Slot (PCIEX4_1) ...................................................... 24
2.18 Auxiliary 4-pin connector (ATX12V1)..................................................... 25
2.19 SPI Flash Connector (SPI_CN1) ............................................................ 26
2.20 Low Pin Count Connector (LPC1)........................................................... 27
Table 2.3: Advantech LPC Module List ..................................... 27
Chapter 3 BIOS Operation.................................29
3.1 Introduction ............................................................................................. 30
Figure 3.1 Main setup screen ................................................... 30
3.2 Entering BIOS Setup............................................................................... 31
3.2.1 Main Menu .................................................................................. 31
Figure 3.2 Main setup screen .................................................... 31
3.2.2 Advanced BIOS Features Setup................................................. 32
Figure 3.3 Advanced BIOS features setup screen .................... 32
Figure 3.4 Platform Misc Configuration ..................................... 33
Figure 3.5 CPU Configuration ................................................... 34
Figure 3.6 PCH-FW Configuration............................................. 36
Figure 3.7 TPM Settings............................................................ 37
Figure 3.8 ACPI Settings .......................................................... 38
Figure 3.9 SMART Settings....................................................... 39
Figure 3.10Super IO Configuration............................................. 40
Figure 3.11Serial Port 1 Configuration ....................................... 40
Figure 3.12Parallel Configuration ............................................... 41
Figure 3.13PC Health Status...................................................... 42
Figure 3.14Super IO Configuration............................................. 43
Figure 3.15Serial Port 3 Configuration ....................................... 43
Figure 3.16Serial Port 4 Configuration ....................................... 44
Figure 3.17Serial Port 5 Configuration ....................................... 45
Figure 3.18Serial Port 6 Configuration ....................................... 45
Figure 3.19S5 RTC Wake Settings ............................................ 46
Figure 3.20Serial Port Console Redirection ............................... 47
Figure 3.21 Intel TXT Information............................................... 48
Figure 3.22PCI Subsystem Settings........................................... 49
Figure 3.23CSM Configuration ................................................... 50
Figure 3.24USB Configuration.................................................... 51
3.2.3 Chipset........................................................................................ 52
Figure 3.25Chipset ..................................................................... 52
Figure 3.26System Agent (SA) Configuration ............................ 52
Figure 3.27Graphics Configuration............................................. 53
Figure 3.28External Gfx Card Primary Display Configuration .... 53
Figure 3.29LCD Control.............................................................. 54
Figure 3.30PCH-IO Configuration .............................................. 57
Figure 3.31SATA Configuration.................................................. 60
Figure 3.32USB Configuration.................................................... 61
Figure 3.33HD Audio Configuration............................................ 62
3.2.4 Security....................................................................................... 63
Figure 3.34Security .................................................................... 63
3.2.5 Boot ............................................................................................ 64
Figure 3.35Boot .......................................................................... 64
3.2.6 Save & Exit ................................................................................. 65
Figure 3.36Save & Exit............................................................... 65

ix AIMB-705 User Manual
Chapter 4 Chipset Software Installation Utility 67
4.1 Before you begin ..................................................................................... 68
4.2 Introduction ............................................................................................. 68
4.3 Windows 10 / Windows 8.1 / Windows 7 Driver Setup ........................... 69
Chapter 5 Integrated Graphic Device Setup.....71
5.1 Introduction ............................................................................................. 72
5.2 Windows 7/8.1/10 Driver Setup............................................................... 72
Chapter 6 LAN Configuration.............................73
6.1 Introduction ............................................................................................. 74
6.2 Features .................................................................................................. 74
6.3 Installation ............................................................................................... 74
6.4 Windows 7/8.1/10 Driver Setup (LAN) .................................................... 74
Chapter 7 Intel ME...............................................75
7.1 Introduction ............................................................................................. 76
7.2 Installation ............................................................................................... 76
Chapter 8 Intel USB 3.0.......................................77
8.1 Introduction ............................................................................................. 78
8.2 Installation ............................................................................................... 78
Chapter 9 HD Audio ............................................79
9.1 Introduction ............................................................................................. 80
9.2 Installation ............................................................................................... 80
Appendix A Programming the Watchdog Timer..81
A.1 Watchdog timer overview........................................................................ 82
A.2 Programming the Watchdog Timer ......................................................... 82
Table A.1: Watchdog timer registers.......................................... 84
A.2.1 Example Programs ..................................................................... 84
Appendix B I/O Pin Assignments..........................89
B.1 Parallel Port (LPT1)................................................................................. 90
Table B.1: Parallel Port (LPT1) .................................................. 90
B.2 USB2.0 Type A Port (USB5) ................................................................... 90
Table B.2: USB2.0 Type A Port (USB3) .................................... 90
B.3 USB3.0 Header (USB3_12) .................................................................... 91
B.4 USB2.0 Header (USB910) ...................................................................... 91
Table B.3: USB2.0 Header (USB56, USB78, USB1112)........... 91
B.5 VGA Connector (VGA1) .......................................................................... 92
Table B.4: VGA Connector (VGA1) ........................................... 92
B.6 DVI Interface ........................................................................................... 92
Table B.5: DVI-D Connector (DVI1/DVI2).................................. 92
B.7 RS-232 and COM3 Interface................................................................... 93

AIMB-705 User Manual x
Table B.6: RS-232 Interface (Rear) ........................................... 93
Table B.7: RS-232 Interface (onboard)...................................... 93
Table B.8: COM3 Interface (onboard) ....................................... 93
B.8 PS/2 Keyboard and Mouse Connector (KBMS1).................................... 94
Table B.9: Keyboard and Mouse Connector (KBMS1) .............. 94
B.9 External Keyboard Connector (KBMS2) ................................................. 94
Table B.10:External Keyboard Connector (KBMS2)................... 94
B.10 JWDT1 and HW Monitor Alarm (JOBS1)................................................ 95
Table B.11:JWDT1+JOBS1........................................................ 95
B.11 System Fan Connector (SYSFAN1/SYSFAN2) ...................................... 95
Table B.12:Fan Connector (SYSFAN1/SYSFAN2) ................... 95
B.12 LED and Keyboard Lock (JFP3) ............................................................ 95
Table B.13: LED and Keyboard Lock (JFP3).............................. 95
B.13 External Speaker Connector (JFP2) ....................................................... 96
Table B.14:External Speaker Connector (JFP2) ........................ 96
B.14 Reset Connector (JFP1) ......................................................................... 96
Table B.15:Reset Connector (JFP1)........................................... 96
B.15 HDD LED Connector (JFP2)................................................................... 96
Table B.16:HDD LED Connector (JFP2) .................................... 96
B.16 ATX Soft Switch (JFP1) ......................................................................... 97
Table B.17:ATX Soft Switch (JFP1)........................................... 97
B.17 SNMP SM_BUS Bus Connector (JFP2) ................................................. 97
Table B.18:SM Bus Connector (JFP2) ....................................... 97
B.18 USB/LAN ports (LAN1_USB3_34 and LAN2_USB34) ........................... 97
Table B.19:USB2.0 Port ............................................................. 97
Table B.20:USB3.0 Port ............................................................. 98
Table B.21:Giga LAN 10/100/1000 Base-T RJ-45 port .............. 98
B.19 Line Out, MIC IN Connector (AUDIO)..................................................... 98
B.20 Front Panel Audio Connector (FPAUD1) ................................................ 99
Table B.22:Front Panel Audio Connector (FPAUD1) ................. 99
B.21 8-pin Alarm Board Connector (VOLT1)................................................... 99
Table B.23:8-pin Alarm Board Connector (VOLT1) .................... 99
B.22 Case Open Connector (JCASE1) ......................................................... 100
Table B.24:Case Open Connector (JCASE1)........................... 100
B.23 Front Panel LAN LED Connector (LAN_LED1) .................................... 100
Table B.25:LAN LED Connector (LANLED1) ........................... 100
B.24 SPI_CN1: SPI Flash Card Pin Connector............................................. 100
Table B.26:SPI_CN1:SPI Fresh Card Pin Connector............... 100
B.25 GPIO Connector ................................................................................... 101
Table B.27:GPIO Connector (GPIO1) ...................................... 101
B.26 Fixed I/O Ranges Decoded by Intel PCH ............................................. 101
Table B.28:Fixed I/O Ranges Decoded by Intel PCH............... 101
B.27 System I/O Ports................................................................................... 102
B.28 DMA Channel Assignments .................................................................. 103
Table B.29:DMA channel assignments..................................... 103
B.29 Interrupt Assignments ........................................................................... 103
Table B.30:Interrupt assignments............................................. 103
B.30 1st MB Memory Map............................................................................. 103
Table B.31:1st MB memory map .............................................. 103

Chapter 1
1Hardware
Configuration

AIMB-705 User Manual 2
1.1 Introduction
AIMB-705 motherboard is the most advanced Intel H110 board for industrial applica-
tions that require high-performance computing. The motherboard supports 6th and
7th generation Intel Core i7/i5/i3 and DDR4 1866/2133 MHz memory up to 32 GB.
AIMB-705 provides cost-effective integrated graphics with 1 GB VRAM max shared
memory and 2 GB or above system memory installed.
AIMB-705 provides dual display interfaces (single display for VG sku). Users can use
the onboard VGA and the DVI port at the same time (VGA only for VG sku). In addi-
tion, the AIMB-705 has dual Gigabit Ethernet LAN (single GbE for VG sku) via dedi-
cated PCIe x1 bus, which offers bandwidth of up to 500 MB/s, eliminating network
bottlenecks.
By using the Intel H110 chipset, the AIMB-705 offers five 32-bit, 33 MHz PCI slots;
one PCIe x4 slot, one PCIe x16 slot and a variety of features such as 4 x onboard
SATA III interfaces (bandwidth = 600 MB/s), 4 x USB 3.0, 5 x USB 2.0 connectors
and HD Audio. These ful I/O capabilities ensure even more reliable data storage
capabilities and high-speed I/O peripheral connectivity.
The AIMB-705 also adopts Advantech’s unique patented Sleep Mode Control Circuit
for AT Mode. AIMB-705 is the ideal platform for today’s industrial applications.
1.2 Features
PCIe architecture: The Intel H110 PCH chipset supports 1 PCIe x16 slot, 1
PCIe x4 slot.
High Performance I/O capability: Dual Gigabit LAN via PCIe x1 bus (single
GbE for VG sku), 5 PCI 32-bit/33MHz PCI slots, 4 SATA III, 4 USB 3.0, 5 USB
2.0.
Standard ATX form factor with industrial features: AIMB-705 provides indus-
trial features like long longevity, reliable operation under wide temperature
range, watchdog timer functions, etc.
DDR4 1866/2133 up to 32 GB: DDR4 provides up to 50 percent increased per-
formance and bandwidth while saving up to 40 percent .
SUSI API: AIMB-705 supports SUSI 4.0 API which helps customer to develop
their own remote management programs under Windows 7 and Windows 8.1.
1.3 Specifications
1.3.1 System
CPU: LGA1151-socket 6th and 7th generation Core i7/i5/i3, Pentium and Cel-
eron processor.
L3 Cache: Please refer to CPU specification for detailed information.
BIOS: AMI SPI BIOS (128Mbit)
System Chipset: H110
SATA Hard Disk Drive Interface: AIMB-705 supports four SATA III ports without
RAID function.
Note! The Intel 7th generation processors only support Windows 10 (64-bit).

3 AIMB-705 User Manual
Chapter 1 Hardware Configuration
1.3.2 Memory
RAM: Up to 32 GB in two 288-pin DIMM sockets. Supports dual-channel DDR4
1866/2133 MHz SDRAM.
–AIMB-705: supports non-ECC unbuffered DIMMs and does not support any
memory configuration that mixes non-ECC with ECC unbuffered DIMMs
1.3.3 Input/Output
PCIe slot: 1 PCIe x16 expansion slot, 1 PCIe x4 expansion slot.
PCI Bus: 5 PCI slots, 32-bit, 33 MHz PCI 2.2 compliant.
Enhanced parallel port: Configured to LPT1 or disabled. Standard DB-25
female connector cable is a optional accessory. Because Intel H110 do not offer
LPC DMA functions, the parallel port only supports SPP/EPP.
Serial port: G2 sku supports six serial ports, one is RS-232/422/485 with hard-
ware auto-flow control and five are RS-232. Two DB-9 connectors with RS-232
located in rear panel.VG sku supports two DB-9 connectors with RS-232
located in rear panel.
USB port: Supports up to 4 USB 3.0 ports with transmission up to 5 Gbps and 5
USB 2.0 ports with transmission rates up to 480 Mbps.
LPC: One LPC connector to support Advantech LPC modules, including PCA-
COM232-00A1E and PCA-TPM-00B1E.
GPIO: AIMB-705 supports 8-bit GPIO from super I/O for general purpose con-
trol application.
1.3.4 Graphics
Processor: Integrated Intel HD Graphics.
Display memory: Shared memory is subject to OS (install 2 GB or above mem-
ory for basic system configuration).
DVI-D (G2 sku only): Resolution up to 1920 x 1200 @ 60 Hz.
VGA: Resolution up to 1920 x 1200 @ 60 Hz.
1.3.5 Ethernet LAN
Supports dual 10/100/1000Base-T Ethernet port (s) via PCIe x1 bus which pro-
vides a 500 MB/s data transmission rate.
Interface: 10/100/1000Base-T.
Controller: Intel I219-V(PHY) for LAN1, Intel I211-AT for LAN2 (G2 sku only).
1.3.6 Industrial Features
Watchdog timer: Can generate system reset or NC. The watchdog timer is pro-
grammable, with each unit equal to one second (255 levels)
1.3.7 Mechanical and Environmental Specifications
Operating temperature: 0 ~ 60°C (32 ~ 140° F, depending on CPU)
Storage temperature: -20 ~ 70° C (-4 ~ 158° F)
Humidity: 5 ~ 95% non-condensing
supply voltage: +3.3 V, +5 V, ±12 V, +5 VSB
Note! A 32-bit OS may not fully detect 4 GB of RAM when 4 GB is installed.

AIMB-705 User Manual 4
consumption: Intel Core Intel I7-6700 @ 3.4 GHz; DDR4 8 G x 2
Maximum: +3.3 V @ 0.49 A, +5 V @ 3.13 A, +12 V @ 7.88 A, +5 Vsb @ 0.08 A,
-5 V @ 0.07 A, -12 V @ -0.07 A
Board size: 304.8 x 228.6 mm (12" x 9.6")
Board weight: 0.7 kg (1.54 lb)
1.4 Jumpers and Connectors
Connectors on the AIMB-705 motherboard link it to external devices such as hard
disk drives and a keyboard. In addition, the board has a number of jumpers that are
used to configure your system for your application.
The tables below list the function of each of the jumpers and connectors. Later sec-
tions in this chapter give instructions on setting jumpers. Chapter 2 gives instructions
for connecting external devices to your motherboard.
Table 1.1: Jumper list
Label Function
JCMOS1 CMOS clear
JWDT1 Watchdog reset
PSON1 AT(1-2) / ATX(2-3) mode selector
JUSB_2 USB source switch between +5 V and +5 V_ DUAL for On Board
USB ports
JCASE1 Case open connector
JOBS1
HW monitor
Close: enable OBS alarm
Open: disable OBS alarm
JME1 Intel ME enable/disable
Table 1.2: Connectors
Label Function
EATXPWR1 ATX 24-pin main connector (for system)
ATX12V1 ATX 12 V auxiliary connector (for CPU)
DIMMA1 Channel A DIMM1
DIMMB1 Channel B DIMM1
SATA0 ~ 3 SATA III (Gen3)
LAN1_USB3_34 LAN1 / USB 3.0 port 1, 2 stack connector
LAN2_USB34 LAN2 / USB 2.0 port 1, 2 stack connector (LAN2 for G2 sku only)
USB3_12 USB 3.0 (pin header)
USB5 USB 2.0 (type A)
USB910 USB 2.0
PCIEX16_1 PCIe x16 slot (Gen3)
PCIEX4_1 PCIe x4 slot (Gen2)
PCI1 ~ 5 PCI slot (32-bit/33 MHz)
VGA1+DVI1 VGA connector / DVI connector (DVI1 for G2 sku only)
COM12 Serial port: RS-232
COM3 Serial port: RS-232/422/485 (G2 sku only)
COM4 ~ 6 Serial port: RS-232 (G2 sku only)

5 AIMB-705 User Manual
Chapter 1 Hardware Configuration
LPT1 Parallel port supporting SPP/EPP mode
KBMS1 Keyboard and Mouse PS/2 connector
KBMS2 Keyboard and Mouse PS/2 connector (box header)
JFP1 switch / reset connector
JFP2 External speaker / HDD LED connector / SM Bus connector
JFP3
Keyboard lock and LED
Suspend: fast flash (ATX/AT)
System On: on (ATX/AT)
System Off: off (AT/ATX)
VOLT1 Voltage Display
CPUFAN1 CPU fan connector (4 pin)
SYSFAN1 ~2 System fan connector (4 pin)
LANLED1 Front panel LAN indicator connector
AUDIO1 Audio connector (Line-out, Mic-in)
FPAUD1 Front panel audio pin header
SPI_CN1 SPI flash card pin header
SPDIF_OUT1 SPDIF audio output pin header
GPIO1 8 bit GPIO from super I/O
SMBUS1 SM bus from PCH
LPC1 Low pin count connector for Advantech TPM LPC and RS232
modules.
Table 1.2: Connectors

AIMB-705 User Manual 6
1.5 Board Layout: Jumper and Connector
Locations
Figure 1.1 Jumper and Connector Locations
Figure 1.2 I/O View
KBMS1
DIMMB1
DIMMA1
SYSFAN1
VOLT1
EATXPWR1
PSON1
JWDT1+JOBS1
JFP3
JFP1+JFP2 SMBUS1
GPIO1
LPT1
SPI_CN1
SATA0 ~ SATA3
COM3
COM4
COM5
COM6
LP C1
USB5
USB910
USB3_12
CPU1
CPUFAN1
PCI1
PCI2
PCI3
PCI4
PCIEX4_1
PCI5
PCIEX16_1
FPAUD1
LANLED1
SPDIF_OUT1
AUDIO1
AUDIO2
LAN1_USB3_34
LAN2_USB34VGA1+DVI1
COM12
SYSFAN2
KBMS2
ATX12V1
JCASE1
JCMOS1
AIM B-705G2-00A1E
AI MB-705VG-00A1E

7 AIMB-705 User Manual
Chapter 1 Hardware Configuration
1.6 AIMB-705 Block Diagram
Figure 1.3 AIMB-705 Block Diagram
1.7 Safety Precautions
Warning! Always completely disconnect the cord from your chassis
whenever you work with the hardware. Do not make connections while
the is on. Sensitive electronic components can be damaged by sudden
surges. Only experienced electronics personnel should open the PC
chassis.
Caution! Always ground yourself to remove any static charge before touching the
motherboard. Modern electronic devices are very sensitive to static
electric discharges. As a safety precaution, use a grounding wrist strap
at all times. Place all electronic components on a static-dissipative
surface or in a static-shielded bag when they are not in the chassis.
Caution! The computer is provided with a battery-ed Real-time Clock
circuit. There is a danger of explosion if battery is incorrectly replaced.
Replace only with same or equivalent type recommended by the
manufacturer. Discard used batteries according to manufacturer’s
instructions.
Caution! There is a danger of a new battery exploding if it is incorrectly installed.
Do not attempt to recharge, force open, or heat the battery. Replace the
battery only with the same or equivalent type recommended by the
manufacturer. Discard used batteries according to the manufacturer’s
instructions.

AIMB-705 User Manual 8
1.8 Jumper Settings
This section provides instructions on how to configure your motherboard by setting
the jumpers. It also includes the motherboard default settings and your options for
each jumper.
1.8.1 How to set jumpers
You can configure your motherboard to match the needs of your application by set-
ting the jumpers. A jumper is a metal bridge that closes an electrical circuit. It consists
of two metal pins and a small metal clip (often protected by a plastic cover) that slides
over the pins to connect them. To “close” (or turn on) a jumper, you connect the pins
with the clip. To “open” (or turn off) a jumper, you remove the clip. Sometimes a
jumper consists of a set of three pins, labeled 1, 2, and 3. In this case you connect
either pins 1 and 2, or 2 and 3. A pair of needle-nose pliers may be useful when set-
ting jumpers.
1.8.2 CMOS clear & ME clear (JCMOS1 & JME1)
The AIMB-705 motherboard contains a jumper that can erase CMOS data and reset
the system BIOS information. Normally this jumper should be set with pins 1-2
closed. If you want to reset the CMOS data, set J1 to 2-3 closed for just a few sec-
onds, and then move the jumper back to 1-2 closed. This procedure will reset the
CMOS to its default setting.
1.8.3 Watchdog timer output (JWDT1)
The AIMB-705 contains a watchdog timer that will reset the CPU. This feature means
the AIMB-705 will recover from a software failure or an EMI problem. The JWDT1
jumper settings control the outcome of what the computer will do in the event the
watchdog timer is tripped.
Table 1.3: JCMOS1/JME1
Function Jumper Setting
* Keep CMOS and ME data
Clear CMOS and ME data
* default setting
1-2 closed
123
2-3 closed
123
Table 1.4: Watchdog timer output (JWDT1)
Function Jumper Setting
NC
2-4 closed

9 AIMB-705 User Manual
Chapter 1 Hardware Configuration
AIMB-705 allows users to set USB between +5 V_DUAL and +5 V for onboard USB
ports. When the jumper is set as +5 V, the board doesn't support wake up from S3 via
keyboard or mouse.
1.9 System Memory
AIMB-705 has two 288-pin memory sockets for DDR4 1866/2133 MHz memory mod-
ules with maximum capacity of 32 GB (Maximum 16 GB for each DIMM). AIMB-705
only supports non-ECC DDR4 memory modules.
Please note that AIMB-705 does NOT support registered DIMMs (RDIMMs).
* Reset
* default setting
Note! The interrupt output of the watchdog timer is a low level signal. It will be
held low until the watchdog timer is reset.
Table 1.5: ATX/AT mode selector (PSON1)
Function Jumper Setting
AT Mode
* ATX Mode
* default setting
Table 1.6: USB source switch between +5V and +5V_ DUAL for onboard
USB ports (JUSB_2)
Function Jumper Setting
*USB +5 V_DUAL
USB +5 V
* default setting
Note! When USB is switched to +5 V, it can’t be connected with ed KVM.
Table 1.4: Watchdog timer output (JWDT1)
4-6 closed
1-2 closed
123
2-3 closed
123
1-2 closed
123
2-3 closed
123

AIMB-705 User Manual 10
1.10 Memory Installation Procedures
To install DIMMs, first make sure the two handles of the DIMM socket are in the
“open” position. i.e. The handles lean outward. Slowly slide the DIMM module along
the plastic guides on both ends of the socket, and then press the DIMM module right
down into the socket, until you hear a click. This is when the two handles have auto-
matically locked the memory module into the correct position of the DIMM socket. To
remove the memory module, just push both handles outward, and the memory mod-
ule will be ejected by the mechanism in the socket.
1.11 PCI Bus Routing Table
PCI Slot PCI1 PCI2 PCI3 PCI4 PCI5
IDSEL AD27 AD28 AD29 AD30 AD31
INTA INTB# INTA# INTD# INTC# INTB#
INTB INTC# INTB# INTA# INTD# INTC#
INTC INTD# INTC# INTB# INTA# INTD#
INTD INTA# INTD# INTC# INTB# INTA#
