Advantech MIO-2361 Series User manual

User Manual
MIO-2361
Intel® Atom™ E3900 series/
Pentium N4200/Celeron N3350,
Pico-ITX SBC, Onboard LPDDR4,
eMMC, 48-bit LVDS, HDMI, 2
GbE, USB3.0, 2 COM, M.2 E-key
2230, F/S mSATA,
opt. mPCIe, SMBus

MIO-2361 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2019
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice.
No part of this manual may be reproduced, copied, translated or transmitted in any
form or by any means without the prior written permission of Advantech Co., Ltd.
Information provided in this manual is intended to be accurate and reliable. However,
Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringements
of the rights of third parties, which may result from its use.
Acknowledgements
AMI is a trademark of AMI Software International, Inc.
Intel® is a trademark of Intel® Technologies, Inc.
IBM, PC/AT, PS/2 and VGA are trademarks of International Business Machines Cor-
poration.
Intel and Atom® are trademarks of Intel Corporation.
Microsoft Windows® is a registered trademark of Microsoft Corp.
RTL is a trademark of Realtek Semi-Conductor Co., Ltd.
ESS is a trademark of ESS Technology, Inc.
UMC is a trademark of United Microelectronics Corporation.
SMI is a trademark of Silicon Motion, Inc.
Creative is a trademark of Creative Technology LTD.
All other product names or trademarks are properties of their respective owners.
Part No.2006236100 Edition 1
Printed in China September 2019

iii MIO-2361 User Manual
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Technical Support and Assistance
1. Visit the Advantech web site at www.advantech.com/support where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages

MIO-2361 User Manual iv
Packing List
Before installation, please ensure the following items have been shipped:
Item Part Number
1 MIO-2361 SBC
1 Startup manual
Cables
Heatsink:
Stud & Screw
Ordering Information
Model Number Description
Optional Accessories
Part No. Description
Part Number Description
1700006291 SATA cable 7P 30 cm w/ right angle
1701200220 COM PORT cable 2*10P-2.0/D-SUB 9P(M)*2 22 cm
1700027546-01 A cable 1*5P-2.0/1*5P-2.0+SATA 15P 15cm MIO-236
1700002172 USB cable 2.0mm pitch USB-A(F) 17cm
1700019705 AT Power cable 12cm
1960087918T001 CPU heatsink for MIO-2361 29mm
Part Number Description
9666226300E Stud and screw pack, including:
1935031500 Screw R/S D=5.3 H=2 + M3*15L, 4 pcs
1910002596-01 Stud F=M3*10L M=M3*5L B=5 H=19, 4 pcs
193B0204C0 Screw F/S D=3.5 H=0.8 + M2*4L, 2 pcs
MIO-2361EW-S1A1 Intel®APL-E3930, eMMC 32G, -40~+85°C
MIO-2361EW-S6A1 Intel®APL-E3940, eMMC 32G, -40~+85°C
MIO-2361EW-S7A1 Intel®APL-E3950, eMMC 32G, -40~+85°C
MIO-2361N-S1A1 Intel®APL-N4200, eMMC 32G, 60°C
1960089107N001 MIO-2361 Heat spreader
IDK-1110WP-50XGA1E 10.1" LED PANEL 500N
IDK-1115P-50XGA1E 15" LED PANEL 500N

v MIO-2361 User Manual
Declaration of Conformity
This device complies with the requirements in part 15 of the FCC rules: Operation is
subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that
may cause undesired operation
FCC Class B
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful inter-
ference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be determined by turning the equip-
ment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Caution! There is a danger of a new battery exploding if it is incorrectly installed.
Do not attempt to recharge, force open, or heat the battery. Replace the
battery only with the same or equivalent type recommended by the man-
ufacturer. Discard used batteries according to the manufacturer's
instructions.

MIO-2361 User Manual vi
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to
the user's manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE 60° C
(140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.
16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.
The sound pressure level at the operator's position according to IEC 704-1:1982 is
no more than 70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.

vii MIO-2361 User Manual
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
To avoid electrical shock, always disconnect the power from your PC chassis
before you work on it. Don't touch any components on the CPU card or other
cards while the PC is on.
Disconnect power before making any configuration changes. The sudden rush
of power as you connect a jumper or install a card may damage sensitive elec-
tronic components.

MIO-2361 User Manual viii

ix MIO-2361 User Manual
Contents
Chapter 1 General Introduction ...........................1
1.1 Introduction ............................................................................................... 2
1.2 Specifications ............................................................................................ 2
1.2.1 General Specifications .................................................................. 2
1.2.2 OS Support List............................................................................. 3
1.2.3 Functional Specifications .............................................................. 3
1.2.4 Mechanical Specifications............................................................. 4
1.2.5 Electrical Specifications ................................................................ 4
1.2.6 Environmental Specifications........................................................ 5
1.3 Function Block Diagram ............................................................................ 6
Chapter 2 H/W Installation....................................7
2.1 Jumpers .................................................................................................... 8
2.1.1 Jumper Description ....................................................................... 8
2.1.2 Jumper List ................................................................................... 8
Table 2.1: Jumper List ................................................................. 8
2.1.3 Jumper Settings ............................................................................ 8
Table 2.2: J3: LCD Power ........................................................... 8
2.2 Connectors................................................................................................ 9
2.2.1 Connector List............................................................................... 9
2.2.2 Connector Settings ....................................................................... 9
2.3 Mechanical .............................................................................................. 12
2.3.1 Jumper and Connector Locations ............................................... 12
Figure 2.1 MIO-2361 Connector Locations (Bottom Side)......... 12
2.3.2 Board Dimensions....................................................................... 13
Figure 2.2 MIO-2361 Mechanical Drawing (Top Side) .............. 13
Figure 2.3 MIO-2361 Mechanical Drawing (Bottom Side) ......... 13
Figure 2.4 MIO-2361 Mechanical Drawing (Side View)............. 14
Figure 2.5 MIO-2361 Mechanical Drawing (Side View with Heat-
sink) .......................................................................... 14
Figure 2.6 MI/O module height constraints................................ 15
Chapter 3 BIOS Settings.....................................17
3.1 Entering Setup ........................................................................................ 19
3.1.1 Main Setup.................................................................................. 19
3.1.2 Advanced BIOS Features Setup................................................. 21
3.1.3 Chipset Configuration ................................................................. 30
3.1.4 Security ....................................................................................... 40
3.1.5 Boot............................................................................................. 41
3.1.6 Save & Exit ................................................................................. 42
Chapter 4 S/W Introduction & Installation ........43
4.1 S/W Introduction...................................................................................... 44
4.2 Driver Installation .................................................................................... 44
4.2.1 Windows 10 Professional............................................................ 44
4.2.2 Other OS..................................................................................... 44
4.3 Value-Added Software Services ............................................................. 44
4.3.1 SUSI Introduction........................................................................ 44
4.3.2 Software APIs ............................................................................. 45

MIO-2361 User Manual x
4.3.3 SUSI Installation ......................................................................... 46
4.3.4 SUSI Sample Programs.............................................................. 47
Appendix A PIN Assignments .............................. 55
A.1 Jumper Settings ...................................................................................... 56
A.2 Connectors.............................................................................................. 58
Table A.1: Connector list ........................................................... 58
Appendix B WDT & GPIO ...................................... 73
B.1 Watchdog Timer Sample Code............................................................... 74
B.2 GPIO Sample Code ................................................................................ 75
Appendix C System Assignments........................ 77
C.1 System I/O Ports..................................................................................... 78
Table C.1: System I/O Ports ...................................................... 78
C.2 1st MB Memory Map............................................................................... 78
Table C.2: 1st MB Memory Map ................................................ 78
C.3 Interrupt Assignments ............................................................................. 79
Table C.3: Interrupt assignments............................................... 79

Chapter 1
1General Introduction
This chapter gives background
information on the MIO-2361.
Sections include:
Introduction
Product Features
Specifications

MIO-2361 User Manual 2
1.1 Introduction
MIO-2361 is related to 2.5” Pico-ITX SBC with Intel® Atom™ E3900 series/ Pentium
N4200/Celeron N3350 Processor. MIO-2361 supports Onboard LPDDR4-2400,
eMMC up to 64GB (TBC), Dual GbE, USB3.0, 2 x RS-232/422/485, 12/24V input; the
board also supports Dual independent display by 48-bit LVDS & HDMI.Besides, MIO-
2361 has M.2 E-key, mSATA/mPCIe for expansion. MIO-2361, Advantech Innovative
Extension SBC, is equipped with flexible multiple I/O functions to assist integrators in
developing optimized solutions.
1.2 Specifications
1.2.1 General Specifications
CPU: Intel® Atom™ E3900 series/ Pentium N4200/Celeron N3350
System Chipset Intel® Celeron/Atom SoC integrated
BIOS: AMI EFI 64 Mbit Flash BIOS
System Memory: LPDDR4-2400MT/s, up to 8 GB
Watchdog Timer: 65536 level, 0~65535 sec
Expansion Interface:
–1 x M.2 E-key 2230
–1 x Full-size mPCIe/mSATA 1/1*(optional)
Battery: Lithium 3 V / 210 mAH
I/O
Internal I/O interface: 1 x SATA3.0, 2 x USB2.0, 2 x RS-232/422/485, 1 x HD
Audio, GPIO, SMBus, I2C*(optional)
Rear I/O ports: 2 x RJ45 Ethernet, 1 x HDMI, 2 x USB 3.0, 1 x Power connector
(or DC jack, supported by request)
Ethernet
Controller:
LAN1: Intel i210AT/IT
LAN2: Intel i210AT/IT (*i210IT is for EW-series)
Speed: 10/100/1000 Mbps
Connector: 2 x RJ45
Standard: Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.ab
Supports wake-on-LAN
Display
Controller: Intel® SoC E3900 series, DirectX*12, and OpenGL4.4 support
Resolution:
–LVDS: Dual-Channel 48-bit, up to 1920 x 1200
–HDMI1.4b: up to 3840 x 2160 at 30Hz

3 MIO-2361 User Manual
Chapter 1 General Introduction
1.2.2 OS Support List
1.2.3 Functional Specifications
Processor
Chipset
OS
Windows 10 (×64) Yes (UEFI mode only)
Yocto Yocto BSP (Support by request)
Processor
Intel® Pentium N4200/Celeron N3350
Intel® Atom™E3950/Intel® Atom™E3940/Intel®
Atom™E3930
Frequency
–N4200: 2.50 GHz
–N3350: 2.40 GHz
–E3950: 2.00 GHz
–E3940: 1.80 GHz
–E3930: 1.80 GHz
Manufacturing Technology: 14 nm
L2 cache: 2 MB
Memory Supports LPDDR4-2400MT/s, up to 8 GB
Socket: Onboard LPDDR4
Graphic Engine
3D: DX12, OGL4.3, OGL ES3.0, OCL 1.2
HW Decode: HEVC/H.265, H.264, MVC, VP8, VP9,
MPEG2, VC-1, WMV9
HW Encode: HEVC/H.265, H.264, MVC, VP8
Display
HDMI: up to 3840 x 2160 at 30Hz
LVDS: Dual-Channel 48-bit, up to 1920 x 1200
Dual independent display: HDMI+48-bit LVDS
Control Hub Intel® Atom SoC integrated
Audio
High Definition Audio (HD) ALC-888S codec
Up to 2 channel of PCM (Pulse Code Modulation) audio output
Connectors: Line-in/Line-out/MIC
PCI-Express Interface
4 PCI-Express x1 Lanes
Lane 1: Intel i210 GbE controller
Lane 2: Intel i210 GbE controller
Lane 3: M.2 E-key 2230
Lane 4: Full-size mPCIe/mSATA connector
SATA Interface 1 x mSATA by mini-PCIe socket
1 x SATAIII (Max. Data transfer Rate 600 MB/s)
USB Interface
2 x internal USB ports
2 x rear I/O ports at coastline, 2 x USB3.0
Transmission speed up to 480 Mbps (USB 2.0) / 5 Gbps (USB
3.0)
Power Management
Full ACPI (Advanced Configuration and Power Interface) 3.0
Supports S0, S3, S4, S5
Support Wake on LAN

MIO-2361 User Manual 4
Storage
Expansion
Others
1.2.4 Mechanical Specifications
1.2.4.1 Dimensions (mm)
L100 mm x W72 mm (3.9" x 2.8")
1.2.4.2 Height on top (mm)
30.61 mm (included Heatsink)
1.2.4.3 Height under bottom (mm)
16.52 mm (Rear I/O USB, HDMI)
1.2.5 Electrical Specifications
Power Supply Type: Single 12 V DC power input (support DC power hot plug)
1.2.5.1 Power supply Voltage
12V or 24V +/- 10%
BIOS AMI EFI 64 Mbit Flash BIOS via SPI
eMMC
32GB (default).
64GB* (optional, TBC)
Note#1: verified with 1410028472-01/SQF-MM5M2-32G-M5E
M.2 E-Key 2230 (PCIe x1, USB2.0)
mPCIe/mSATA 1/1*(optional)
Ethernet
Controller: Intel® i210IT/i210AT
Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE
802.ab
Supports 10/100/1000 Mbps
Connectors: 2 x RJ45
LAN LED
–Link: Green (100Mbps)/ Orange (1000Mbps)
–Active: Green (flash)
Supports wake on LAN
Serial ports
Controller: EC IS200
2 x 232/422/485 serial ports with ESD protection:
air gap ± 15 kV, contact ± 8 kV
GPIO
Controller: EC IS200
16-bit (programming) through Super I/O, pin header
5 V tolerance
SMBus Default is SMBus
I2C By optional request

5 MIO-2361 User Manual
Chapter 1 General Introduction
1.2.5.2 Power Consumption
Typical in Windows 10 Idle Mode:
E3950: 8.59 W (12V)
E3950: 8.81 W (24V)
Max in Windows 10 HCT12 (10 minutes):
E3950: 26.27 W (12V)
E3950: 26.51 W (24V)
1.2.5.3 RTC Battery
Typical Voltage: 3.0 V
Normal discharge capacity: 210 mAh
1.2.6 Environmental Specifications
1.2.6.1 Operating Humidity
40 °C @ 95% RH Non-Condensing
1.2.6.2 Operating Temperature
Standard: 0 ~ 60 °C (32 ~ 140 °F)
Extend: -40 ~ 85 °C (-40 ~ 185 °F)
1.2.6.3 Storage Humidity
Storage: -40 ~ 85 °C (-40 ~ 185 °F)
Storage: 60 °C @ 95%relative humidity, non-condensing
1.2.6.4 Storage Temperature
-40 ~ 85 °C (-40 ~ 185 °F)
1.2.6.5 Thermal Management
1. Maximum operating temperature on any components are tested with the heat-
sink.
2. Temperature Specifications condition:
Industrial Grade: 85°C, CPU @50% loaded, the key parts are allowed to start
throttling for thermal protection.
Commercial Grade: 60°C, CPU @100% loaded, the board needs to run at nom-
inal frequency.

MIO-2361 User Manual 6
1.3 Function Block Diagram
Atom E3900 Series
Pentium N4200
Celeron N3350
1.8~2.0GHz
24x31mm
5.5W to 12W
Dual
Channel
LPDDR4 2400
onboard memory, up to 8GB
LPC
EIO-IS200
16-bit GPIO
COM1: RS-232/422/485
COM2: RS-232/422/485
Watchdog Timer
1 x Intel i210
PCIex1 RJ45
Audio Codec HD Audio
Line-in
Line-out
Mic-in
AMI BIOS SPI
2 USB3.0 USB3.0/USB2.0
1 SATAIII
Full-size Mini-PCIe/
Full-size mSATA*
(optional)
PCIe x1
SATAIII 600MB/s
DDI
NXP
PTN3460
eDP 48-bit
LVDS
2 USB2.0
SMBus/
I2C* (optional)
I2C
SATAIII 600MB/s
USB2.0
SMBus
HDMI
1 x Intel i210
PCIex1 RJ45
M.2
(E-Key 2230)
PCIex1
USB2.0
USB2.0
eMMC
eMMC
TPM2.0
LPC

Chapter 2
2H/W Installation
This chapter explains the setup
procedures of the MIO-2361 hard-
ware, including instructions on
setting jumpers and connecting
peripherals, as well as switches,
indicators and mechanical draw-
ings. Be sure to read all safety
precautions before you begin the
installation procedure.

MIO-2361 User Manual 8
2.1 Jumpers
2.1.1 Jumper Description
Cards can be configured by setting jumpers. To close a jumper, you connect the pins
with the clip. To open a jumper, you remove the clip. Sometimes a jumper will have
three pins, labeled 1, 2 and 3. In this case you would connect either pins 1 and 2, or
2 and 3.
The jumper settings are schematically depicted in this manual as follows.
A pair of needle-nose pliers may be helpful when working with jumpers. If you have
any doubts about the best hardware configuration for your application, contact your
local distributor or sales representative before you make any changes.Generally, you
simply need a standard cable to make most connections.
2.1.2 Jumper List
2.1.3 Jumper Settings
Warning! To avoid damaging the computer, always turn off the power supply
before setting jumpers.
Table 2.1: Jumper List
J3 LCD Power
SW1 Auto Power On/LVDS VCON
SW1 & SW2 12V
SW1 & SW2: 24V
Table 2.2: J3: LCD Power
Setting Function
(1-3)* +3.3V
(3-5) +5V
(3-4) +12V

9 MIO-2361 User Manual
Chapter 2 H/W Installation
2.2 Connectors
2.2.1 Connector List
2.2.2 Connector Settings
2.2.2.1 Battery Connector (CN4)
MIO-2361 supports Lithium 3 V/210 mAH CR2032 battery with wire.
2.2.2.2 12 V Power Input Connector (CN1)
Main power connector supports single 12 V input, and there's an optional choice of
DC/Jack (CN2, co-layout with 2pin power connector)
2.2.2.3 GPIO (General Purpose Input Output) (CN34 & CN35)
The board supports 16-bit GPIO (5 V tolerance) through GPIO pin header. The 16
digital inputs and outputs can be programmed to read or control devices, with each
input or output defined.
2.2.2.4 HDMI/ LVDS Interface Connections (CN13/CN12)
MIO-2361 has a dual display interface which supports HDMI displays (included pas-
sive LCD and active LCD displays).
CN1 12 V Power Input
CN2 DC JACK
CN4 Battery
CN9 LAN
CN10 LAN
CN12 48-bit LVDS Panel
CN13 HDMI
CN15 SATA
CN16 Audio
CN18 Mini PCIE
CN22 External USB3.0
CN23 SMBus
CN33 Internal USB
CN34 GPIO
CN35 GPIO
CN45 Front panel
CN54 COM1/COM2
CN57 Inverter Power Output
Note! How to clear CMOS: (follow below steps)
1. Turn off system power
2. Unplug CR2032 battery cable on CN4
3. Waiting for 15 sec or short CN4 pin 1-2
4. Connect battery cable on CN4
5. Turn on system power

MIO-2361 User Manual 10
HDMI display connector (CN13)
Supports HDMI1.4b. Resolution: up to 3840 x 2160 at 30Hz.
LVDS LCD panel connector (CN12)
MIO-2361 supports dual channel 48-bit LVDS LCD panel displays. Resolution: up to
1920 x 1200.
2.2.2.5 Front Panel Connector(CN45)
MIO-2361 integrates below functions as front panel 9-pin connector.
Power button
Supports power on/off button in ATX mode.
Reset
If you install a reset switch, it should be an open single pole switch. Momentarily
pressing the switch will activate a reset.
Power LED
Power LED indicator light lit when power is on.
HDD LED
HDD LED indicator for hard disk access is for an active low signal.
2.2.2.6 SATA Connector (CN15)
MIO-2361 supports one high performance Serial ATA interfaces. Data transfer rates
up to 600 MB/s enabling very fast data and file transfer, and independent DMA oper-
ation on two ports.
2.2.2.7 Mini PCIe Connector (CN18)
MIO-2361 supports a full size mini PCIe slot. PCI Express Mini Card (also known as
Mini PCI Express, Mini PCIe, and Mini PCI-E) is a replacement for the Mini PCI form
factor based on PCI Express. It is developed by the PCI-SIG. The host device sup-
ports both PCI Express and USB 2.0 connectivity. The mini PCIe slot also integrates
SATAIII signals, supports mSATA interface modules. (*mSATA is by optional request)
2.2.2.8 USB Connectors (CN22 and CN33)
MIO-2361 provides 4 x USB (Universal Serial Bus) ports, two are external I/O ports
(CN22); the other two are internal USB ports (CN33). The rear I/O USB port supports
two USB 3.0 ports. The USB 3.0 ports comply with USB specification Rev. 3.0 which
supports 5.0 Gbps transfer rate and backward compatible with USB 2.0 device. This
gives complete Plug and Play, and hot attach/detach for up to 127 external devices.
Other USB interfaces comply with USB specification Rev. 2.0 which supports 480
Mbps transfer rate and are fuse protected.
2.2.2.9 COM Port Connectors (CN54)
MIO-2361 provides two serial ports in 10 x 2pin pin header. COM1/COM2 is for
RS232/422/485 functionality. It provides connections for serial devices or a communi-
cation network. The pin assignments for the COM port connector can be found in
Appendix.
2.2.2.10 Ethernet Connector (CN9/CN10)
MIO-2361 uses Intel® i210IT/i210AT Ethernet chip (10/100/1000 Mbps) linked to
dedicated PCIe x1 lane via RJ-45 connector.
2.2.2.11 High Definition Audio Interface (CN16)
MIO-2361 provides one 5 x 2 pin box header for audio device. It can support high
definition audio stereo via customized audio module that has a codec onboard.
