AIMB-762 Startup Manual 1
AIMB-762 Socket LGA 775 Intel®Pentium®D /
Pentium®4 / Celeron®D 800 MHz FSB ATX
Motherboard with PCI-E, DDR2 and Dual GbE
Before you begin installing your card, please make
sure that the following materials have been shipped:
If any of these items are missing or damaged, contact
your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF
file. Acrobat Reader can be downloaded at:
www.adobe.com/Prodindex/acrobat/read-
step.html (Acrobat is a trademark of Adobe).
Standard SBC Functions
•CPU: LGA 775 Pentium D/Pentium 4/Celeron D up to
3.2/3.8/3.06 GHz, FSB 533/800 MHz.The CPU has
built-in 2 x 1024KB/2 x 2048KB (for Pentium D CPU),
1024KB/2048KB (for Pentium 4 CPU), 256KB/512 KB
(For Celeron D CPU) full-speed L2 cache.
•BIOS: Award 8 Mb flash memory BIOS
•Chipset: Intel 945G with ICH7R
• System Memory: Up to 4 GB; four 240-pin DIMM
sockets. Supports dual channel DDR2 400/533/667
SDRAM.
Note: Due to the inherent limitations of PC architec-
ture, the system may not fully detect 4 GB
RAM when 4 GB RAM is installed.
•SATA2/IDE Interface: Four on-board serial ATA2 con-
nectors with a data transmission rate of up to 300 MB/s
supporting Advanced Host Controller Interface (AHCI)
technology. One IDE hard disk drive or two enhanced
IDE devices. Supports PIO mode 4 (16.67 MB/s data
transfer rate) and ATA 33/66/100 (33/66/100 MB/s data
transfer rate) BIOS enabled/disabled.
•FDD interface: Supports one FDD
•Serial ports: Two serial ports, COM1 is of RS 232;
COM2 is of RS 232/422/485.
•Parallel port: One parallel port, supports SPP/EPP/
ECP mode
•Keyboard/mouse connector: Supports one standard
PS/2 keyboard and mouse
•Watchdog timer: 255 level timer intervals
•USB 2.0: Supports up to eight USB 2.0 ports
VGA Interface
•Chipset: Chipset integrated VGA controller
•Display memory: Dynamically shared system memory
up to 224 MB
•Resolution: Up to 2048 x 1536 @ 75 MHz refresh rate
Ethernet Interface
•Single 10/100/1000Base-T: Intel® 82573
•Dual 10/100/1000Base-T: Intel® 82573 x 2
Mechanical and Environmental
•Dimensions (L x W): 304.8 x 243.8 mm
•Power supply voltage: +5 V, ± 12 V
• Power requirements: Maximum: +5 V at 3.10 A, +3.3V
at 1.54A, +12V at 9.90 A (Intel Pentium D 3.2GHz (800
MHz FSB), 4 x 1GB DDR2 667 SDRAM)
•Operating temperature: 0 ~ 60°C (depending on
CPU)
•Weight: 0.5 kg (weight of board)
Packing List Specifications
• AIMB-762 Pentium® 4 / Celeron® D processor
based industrial motherboard
• 1 AIMB-762 startup manual
• 1 CD with driver utility and
manual
• 1 FDD cable p/n:1700340640
• 2 Ultra ATA 66/100 HDD cables p/n: 1701400452
• 2 Serial ATA HDD data cable p/n: 1700071000
• 2 Serial ATA HDD power cable p/n: 1703150102
• 1 ATX 12 V power converter
cable
p/n:170304015K
• 1 COM port cable kit p/n: 1701090401
• 1 I/O port bracket p/n: 1962015680
• 1 jumper package p/n: 9689000068
• 1 warranty card p/n: 2190000902
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the AIMB-762 series Rev. A1
Part No. 2002076210
Printed in Taiwan
1st Edition
March 2006
AIMB-762 Socket LGA 775 Intel
®
Pentium
®
D/Pentium
®
4 / Celeron
®
D
800 MHz FSB ATX Motherboard with PCI-E, DDR2 and Dual GbE
CA-6184-B1

2 AIMB-762 Startup Manual
The board has a number of jumpers that allow you to
configure your system to suit your application. The
table below lists the function of each of the jumpers
and connectors.
Jumpers and Connectors
Other Connectors
Label Function
JP1 COM2 RS 232/422/485 Mode Selector
CN1 Primary IDE connector
CN3 FDD connector, Supports 360 KB / 1.2 MB /
720 KB / 1.44 MB FDD x 2
CN4 Parallel port, Parallel port x 1, supports SPP/
EPP/ECP mode
CN6 USB port 4, 5
CN7 VGA connector
CN9 Serial port: COM1; RS-232 (D-sub 9-pin
connector)
CN10 Serial port: COM2; RS-232 (9-pin connec-
tor)
CN11 PS/2 keyboard and mouse connector
Cable length: 20 meters
CN12 External keyboard connector (6-pin)
CN13 Infrared connector
CN14 CPU FAN connector
CN15 System FAN connector 1
CN16 Power LED
CN17 External speaker
CN18 Reset connector
CN19 HDD LED connector
CN21 ATX soft power switch (PS_ON)
CN22 HW Monitor Alarm
Close: Enable OBS Alarm
Open: Disable OBS Alarm
CN29 SM bus connector
CN31 LAN1; USB ports 0, 1
CN32 LAN2; USB ports 2, 3
CN37 System FAN connector 2
CN55 Line Out, Mic IN connector
CN56 CD IN (Audio input from CD-ROM)
CN57 AUX IN connector
CN59 Front panel audio connector
CN62 8-pin Alarm Board Connector
CN63 USB ports 6, 7
CN64 Case Open
CN65 Front Panel LAN indicator connector
SA0 Serial ATA0
SA1 Serial ATA1
SA2 Serial ATA2
SA3 Serial ATA3
ATX1 ATX 12 V auxiliary power connector
(for CPU)
ATX3 24-pin ATX power connector
J1: CMOS clear function
Pins Result
1-2 Keep CMOS data*
2-3 Clear CMOS data
JP1: COM2 RS 232/422/485 Mode Selector
Users can use JP1 to select among RS 232/422/485
modes for COM2 (CN10). The default setting is RS
232.
J2: Watchdog timer output option
Closed pins Result
1-2 IRQ11
2-3 System reset *
J12: ATX, AT mode selector
Closed Pins Result
1-2 AT Mode
2-3 ATX Mode
1 - 2 closed
IRQ11
2 - 3 closed
System Reset
1 - 2 closed
AT Mode
2 - 3 closed
ATX Mode

AIMB-762 Startup Manual 3
Board Layout: Jumper and Connector Locations

4 AIMB-762 Startup Manual
The CD disc contains a driver installer program that
will lead you through the installation of various device
drivers needed to take full advantage of your mother-
board
The computer is supplied with a battery-powered
Real-time Clock circuit. There is a danger of explosion
if battery is incorrectly replaced. Replace only with
same or equivalent type recommended by the manu-
facturer. Discard used batteries according to manu-
facturer's instructions.
This device complies with the requirements in Part 15
of the FCC rules. Operation is subject to the following
two conditions:
1. This device may not cause harmful interference
2. This device must accept any interference received,
including interference that may cause undesired oper-
ation
Software Installation Specifications
Caution
