Advantech PCA-6188 Installation and operation manual

PCA-6188 Startup Manual 1
PCA-6188 Full-sized PCI/ISA-bus socket 478
Pentium®4/Celeron®processor-with ATI M10
VGA chip CPU card
Before you begin installing your card, please make
sure that the following materials have been shipped:
If any of these items are missing or damaged, contact
your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at:
www.adobe.com/products/acrobat/readstep2.html
Standard SBC Functions
• CPU: Intel® socket 478 Celeron® (Northwood) 2.0~2.8 GHz,
Pentium® 4 (Northwood/Prescott) up to 3.4 GHz, FSB 400/533/
800 MHz; suppports Intel Hyper-Threading technology. CPU with
1.75V core voltage (Willamete) not supported.
•
BIOS: Award 4 Mb Flash memory BIOS
•
Chipset: Intel 875P with 6300ESB
•
System Memory: Dual Channel; Four 184-pin DIMM sockets
accepts up to 4 GB DDR 266/333/400 SDRAM (PC 2100/2700/
3200)
•
SATA/IDE interface: Supports up to two independent Serial ATA
hard drives (up to 150MB/s) and two IDE hard disk drives or four
enhanced IDE devices. BIOS enabled/disabled.
•
FDD interface: Supports up to two FDDs
•
Serial ports : Two serial RS-232 ports
•
Parallel port: One parallel port, supports SPP/EPP/ECP mode
•
Keyboard/mouse connector: Supports one standard PS/2 key-
board and mouse
•
Watchdog timer: 255 level timer intervals
•
USB (2.0): Maximum up to four Universal Serial Bus ports
VGA Interface
• Chipset: ATi Mobility Radeon 9600 Pro (AGP 8X)
•
Interface: AGP 8X
•
Display memory: 64MB DDR SDRAM integrated
•
Video Output :
CRT1, 2048 x 1536, up to 200Hz vertical rate
CRT2, 2048 x 1536, up to 200Hz vertical rate
1 LVDS, dual 115MHz interface, 2048 x 1536@60Hz,
1 DVI, 1600 x 1200@60Hz, 165MHz 2
Ethernet Interface
• Chipset:
• Single 10/100/1000Base-T:Intel 82547GI (CSA)
• Dual 10/100/1000Base-T: Intel 82547GI (CSA) and Intel 82541GI
(PCI)
•
Connection : On-board RJ-45 connector x 2
Mechanical and Environmental
• Dimensions (L x W): 338 x 122 mm
•
Power supply voltage: +5 V ± 12 V
•
Power requirements: Typical : +5V:7.32A, +12V:7.68A (Intel Pen-
tium® 4 3.06GHz with 533MHz FSB, 1GB DDR 333 SDRAM)
•
Operating temperature: 0 ~ 60 °C (depending on CPU)
•
Weight: 0.5 kg (weight of board)
Packing List Specifications
• 1 PCA-6188 Pentium ® 4/Celeron processor-based
single board computer
• 1 PCA-6188 Startup Manual
• 1 CD with driver utility and manual (in PDF format)
• 1 FDD cable p/n: 1700340640
• 2 Ultra ATA 66/100 HDD cables p/n: 1701400452
• 2 Serial ATA HDD data cable p/n: 1700071000
• 2 Serial ATA HDD power cable p/n: 1703150102
• 1 ATX 12V power converter
cable
p/n: 170304015K
• 1 Printer (parallel) port & COM
port cable kit
p/n: 1701260305
• 1 Dual COM port cable kit p/n: 1701092300
• 1 Y cable for PS/2 keyboard
and PS/2 mouse
p/n: 1700060202
• 2 Two USB port cable p/n: 1700100170
• 1 VGA cable p/n:1700000259
• 1 DVI cable p/n:1700000821
• 1 Video Cable( S / Composite
terminal)
p/n:1700000784
• Warranty card
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/nc
For technical support and service, please visit our
support website at:
http://service.advantech.com.tw/eservice/
This manual is for the PCA-6188 series Rev. A1.
Part No. 2002618810
Printed in Taiwan
1st. Edition
August 2004
PCA-6188 Full-sized PCI/ISA-bus socket 478 Pentium®4/Celeron® processor with ATI M10 VGA chip CPU card

2 PCA-6188 Startup Manual
The board has a number of jumpers that allow you to
configure your system to suit your application.
The table below lists the function of each of the jump-
ers and connectors.
• The CD disc contains a driver installer program that will
lead you through the installation of various device driv-
ers needed to take full advantage of your CPU card.
The computer is provided with a battery-powered
Real-time Clock circuit. There is a danger of explo-
sion if battery is incorrectly replaced. Replace only
with same or equivalent type recommended by the
manufacturer. Discard used batteries according to
manufacturer's instructions
Jumpers and Connectors
Label Function
J1 CMOS clear
J2 Watchdog timer output selection
Label Function
CN1 Primary IDE connector
CN2 Secondary IDE connector
CN3 Floppy drive connector
CN4 Parallel port
CN6 USB port 0, 1
CN7 VGA connector
VCN2 VGA-2 connector
VCN4 LVDS connector
VCN5 DVI connector
CN10 Serial port: COM2 ( 10-pin connector)
CN11 PS/2 keyboard and mouse connector
CN12 External keyboard connector
CN13 Reserved
CN14 CPU FAN connector
CN16 Power LED
CN17 External speaker
CN18 Reset connector
CN19 HDD LED connector
CN20 ATX feature connector
CN21 ATX soft power switch
CN22 HW Monitor Alarm
Close: Enable OBS Alarm
Open: Disable OBS Alarm
CN23 Serial port:COM1 ( 10-pin connector)
CN24 2 LAN ports
CN29 SM BUS Connector
CN43 AC97 Link connector
CN63 USB port 2,3
SA0 Serial ATA0
SA1 Serial ATA1
ATX1 ATX 12V Auxiliary power connector
J1: CMOS clear function
Pins Result
1-2 (open) Keep CMOS data*
1-2 (closed) Clear CMOS
J2: Watchdog timer output option
Closed pins Result
*default setting
1-2 IRQ11
2-3 System reset *
Software Installation
Caution
J2: Watchdog timer output option

PCA-6188 Startup Manual 3
Board Layout: Jumper and Connector Locations
CN1
CN2
CN3
CN4
SA1 SA0
CN20
J1
J2
CN13 CN22
VCN5
CN6 CN63
CN23
CN10
CN24
CN7
CN11
CN12
VCN2
VCN4
CN43
DIMM1
DIMM2
DIMM3 DIMM4
ATX1
CN14
CN21
CN19
CN17 CN16
CN18
CN29
